1. Drupal (6) my experience
W.G. Paseman
2/23/2012
1 © W. G.Paseman 2/23/12

2. Agenda
 My Experience
 Drupal (6) Content Authoring
 Web Site 1.0 – Microsoft Frontpage
 Edit Hierarchical Document on your computer
 Web Site 2.0 – Drupal
 CMS (Content Management System) in the cloud
 Drupal (6) Site Development
 Web Application –SAAS
 Choosing a Development Process
 Selecting a Host
 Deploy
 Creating a UI
2 © W. G.Paseman 2/23/12

3. Drupal (6) Content Authoring
W.G. Paseman
3 © W. G.Paseman 2/23/12

4. Web Site 1.0/Site Example/Frontpage
Word Class Styled Text Menus
Hypertext Links
Three Column Layout
4 © W. G.Paseman 2/23/12

5. Web Site 1.0/Authoring/FrontPage
Directory Style
Content Organization
5 © W. G.Paseman WYSIWYG Editor 2/23/12

6. Web Site 1.0 - Edit a Hierarchical
Document on your computer
 Site Example: paseman.com
 Multiple users browse a site containing a File System of hyperlinked documents.
 Directory Hierarchy maps to Site Structure
 Authoring: Frontpage
 Provides a “Word – like” WYSIWYG model of Web document.
 Generates HTML automatically
 Deploys Directories/Files to Host
 CLIENT ONLY SOFTWARE
 Architecture
 Client: Browser(Http(Url))
 Transport: html+ css+ javascript+ img + …
 <div class="content"><p>Some Content<p></div>
 Server: Two Tier Architecture
 Tier 1: Web Server - Presentation
 Tier 2: File System - Storage
 <div class="content"><p>Some Content<p></div>
6 © W. G.Paseman 2/23/12

7. Web Site 1.0/Authoring/Issues
 Novelty
 People don't come back to static Web pages so I need to continually publish new stuff.
 Manage Volume
 I have more content than fits on my home page
 I have more content than I want to display at one time.
 e.g. Hermitage displays only 150K items at a time of a 3M item collection
 Fixed File hierarchies are a poor organizational principle for large volumes of data
 Manage Variety of Structured Data
 I have fundamentally different types of content, and I need a checklist for each type to make sure it
is filled in consistently and correctly.
 Destinations have location, theme, best times, categories, contact….
 Tours are a collection of Destinations…
 Products have prices…
 Volume and Variety mean I should keep content in a relational (SQL) database.
 Manage Workflow
 Version Control: I need to update old stuff
 Revision Control: I need controlled release of new content (E.g. Weekly issues)
 I manage different groups, in different locations, each responsible for a portion of the site.
 Workflow is easier to manage in a centralized fashion, so I ought move CMS behavior from
client to the server. This means I ought add a “behavior” tier to the server.
7 © W. G.Paseman 2/23/12

8. Web Site 2.0/Site Example/Drupal View
 How Drupal uses the SQL database for the reader (user)
 What happens if we drill down here?
Slideshow“View”
- Banner
Content Type
- SQL Select &
Sort
Grid “View”
Taxonomy - Destination
- ount of
C Content Type
Product - SQL Select &
Content Types Sort
- SQL Project
8 © W. G.Paseman 2/23/12

9. Web Site 2.0/Site Example/Drupal Node
Wysiwyg Stuff
- Embedded Media
- Formatted Text
- Hyperlinks
User Defined Fields
- Acts as Checklist
- Aids Search
- Aids Integration
- Types include
- ext
T
- icture
P
- ocation
L
9 © W. G.Paseman 2/23/12

10. Web Site 2.0/Authoring/
Content Management System/Drupal
 How Drupal uses the SQL database for the author
 What happens if we drill down here?
Navigate content as rows in a Relational DB
Not Files in a File System
Multiple Content Types
Release Management Multiple Authors
10 © W. G.Paseman 2/23/12

11. Web Site 2.0/Authoring/Drupal/Node
WYSIWYG Functionality
 Code for this editor resides on the server, not the client.
 It is accessed by the authors through their browsers.
 In my case, the same code is accessed by an author in a
Saratoga living room and an author in a Cebu Cybercafe.
11 © W. G.Paseman 2/23/12

12. Web Site 2.0/Authoring/Drupal/CCK
Author
Defined
Fields
12 © W. G.Paseman 2/23/12

13. Web Site 2.0/Authoring/Drupal/
Management
 Menus let me create a direct link to this piece of content
from the menus
 Vocabularies put Taxonomy system “tags” on the content so I
 Can sort content
 Can create Drilldowns
 Revisions let me record changes I made to the same piece of
content over time.
 Authoring information lets me know which author added/
changed the content.
 Publishing options let me control content visibility.
 File attachments let me associate downloadable files with this
content
 Comment settings let me control who (if anyone) can
comment on the content
 URL path setting let me create “Frontpage-like” hierarchical
links to the content. E.g. this “node’s” name is
 http://pacificseduction.com/node/62, however this
setting let’s me refer to it as
 http://pacificseduction.com/Carnaza
13 © W. G.Paseman 2/23/12

14. Web Site 2.0/CMS in the cloud
 Site Example: pacificseduction.com
 1.0 Multiple users browse a site containing a File System of hyperlinked documents.
 2.0 Multiple User Types access a Site that frontends a Database of multiple Content types.
 Authoring
 “Frontpage on Client” becomes “CMS In Cloud”
 Permissions + Roles (later)
 Architecture
 Client: Browser(Http(Url))
 Transport: html+ css+ javascript+ img + …
 <div class="content"><p>Some Content<p></div>
 Server: 3 Tier
 Tier 1: Web Server - Presentation
 <div class="content"><p>Some Content<p></div>
 Tier 2: App Server - Logic
 <div class="content"><?php print $content ?></div>
 Implements CMS functionality in the cloud
 Tier 3: File System is replaced with DB Storage
 Hierarchical Database becomes Relational
14 © W. G.Paseman 2/23/12

15. Web Site 2.0/Issues
 I need more than just Content, I need Engagement
 I need to treat different types of users differently
 Change what people see depending on their "role".
 Need to model users explicitly.
 Access Control – role/permissions
 I can increase engagement via some standard applications, E.g.
 All Users can see content.
 Registered Users can comment (comment module) on content.
 Paid Users can blog (blog module) and access premium content.
 But I would like more behavior…. Add more cloud applications, E.g.
 Products have price … and need a shopping cart!
 Destinations have price … and need a reservation system.
15 © W. G.Paseman 2/23/12

16. Drupal (6) Site Development
W.G. Paseman
16 © W. G.Paseman 2/23/12

17. Agenda
 Procedural (Amateur) vs. Declarative (Expert) Knowledge
 20101009_619_BarkadaStores
 20110322_620_BarkadaMall_DNAsolutions
 20110506_620_resortsmall
 20110821_622_internationaltouristboards
 20111120_622_pacificseduction
 Selecting a Host
 Select/Modify your hosting Platform
 Choosing a Development Process
 Manage How site changes over time.
 Deploy
 Prep Host
 From drupal.org download core or distribution (e.g. opendeals) and Patch locally
 From drupal.org Select and Download, Modules
 Upload, Configure Site
 Enable, Configure Modules
 Set Roles and Permissions
 Creating a UI
 Select/Modify your “theme”
17 © W. G.Paseman 2/23/12

18. Selecting a Host/Options
 Localhost
 Free, but you might get shut down if you open it up.
 Shared Server
 order.1and1.com - $20/mo (Where I’ve been for a year)
 Dedicated Server
 People seem to be migrating to to cloud instead
 Cloud Server
 www.rackspace.com/cloud/cloud_hosting_products $150/mo
 linode.com 1536 (barebones) - $60.00
 AWS free usage tier - http://aws.amazon.com/free/
 www.coursera.org/saas
 Drupal optimized Hosts
 www.acquia.com/cloud-pricing $169/mo <- support is $100 of this
 Omega8.cc $64/mo <- trying Aegir out, but support is “early”
18 © W. G.Paseman 2/23/12

19. Selecting a Host/Issues
 Resources required
 Compare http://drupal.org/requirements
 15 Meg disk, Apache 1.3, 2.x. , MySQL 5, php 5.3
 To phpinfo on your site choice e.g.
 http://blossomdiagnostics.com/phpinfo.php
 <?php phpinfo(); ?>
 Php.ini
 Drupal 6
 register_globals = false
 memory_limit = 36M
 Drupal 7
 register_globals = false
 memory_limit = 128M
19 © W. G.Paseman 2/23/12

20. Choosing a Development Process
 Drupal Structure: Their files, your files and a DB
 Development Approach
 Local + Upload
 My Local environment was different from Target
 Backup DB, Upload Files (onErr migrate oldfiles + Backup)
 Utilize a drupal specific methodology (Aegir)
 Site(DB) -> PSV8.0 -> PSV8.0 -> PSV9.0
 Platform -> Drupal6.22 -> Drupal6.24 -> Drupal6.24
 My Tools
 On Host: phpMyAdmin
 On Dev machine
 Browser + firebug
 Cyberduck - ftp
 SSH – crontab
 Drupal Update
20 © W. G.Paseman 2/23/12

21. Choosing a Development Process/
Cyberduck
21 © W. G.Paseman 2/23/12

22. Deploy/Prep Host
 MySQL Administration
 Database name : db396153918
 User name : dbo396153918
 Host name : db396153918.db.1and1.com
 Port : 3306
 Description : 20120222_624_pacificseduction
 Version : MySQL5.0
 Password: xxxxx
 Domain Administration
 pacificseduction.com -> /drupal/20120222_624_pacificseduction
 Email Administration
 *@pacificseduction.com -> pacificseduction@gmail.com
 Create /drupal/keys directory if you are using SSL (must be peer)
22 © W. G.Paseman 2/23/12

23. Deploy/Download Core or Distribution, Patch
 Download/unzip distribution (or) Drupal core (6.24 or 7.13)
 OpenDeals, commerce_kickstart
 Rename top directory {root} to mySQL Description String
 (e.g. 20120222_624_pacificseduction)
 uncomment "RewriteBase /" in {root}/.htaccess
 Needed for Clean URLs
 Create {root}/php.ini containing
 register_globals = off
 memory_limit = 96M
 Duplicate the {root}/sites/default/default.settings.php file to
{root}/sites/default/settings.php.
 “Get Info” and change settings.php permissions to “everyone Read and
write”
23 © W. G.Paseman 2/23/12

24. Deploy/Select, Download Modules
 Drupal adds behavior via distributions and Modules
 14,900 modules – about 11,000 a year ago
 Token – Why this isn’t in core, I don’t know…
 Cck – Add User Defined Fields
 Filefield – Uploadable Files
 Imagefield, imagecache, imageapi – Uploadable images
 Views – Create Slideshows, Lists, Grids
 google_analytics – Track your site via google.com/analytics/
 Ubercart – product catalog + shopping cart
 Thickbox – lightbox for Products
 Add Modules to {root}/sites/all/modules
 Follow per module README file instructions
 E.g. ubercart_marketplace Place packingslip.itpl in {root}/sites/all/
modules/ubercart/uc_order/templates directory.
24 © W. G.Paseman 2/23/12

25. Deploy/Select, Download Modules
 My Primary “Function” (Module) “How
To” Resource is “Using Drupal”
 Example sites for job postings, product
reviews, wikis, photo galleries, stores,
event management
 Addresses multilingual, workflow
 Theming - not so much
 Other Resources
 drupal.org
 ubercart.org
 youtube
25 © W. G.Paseman 2/23/12

26. Deploy/Download Modules
20111120_622_pacificseduction
 token  captcha  Ubercart
 cck  menu_block  thickbox
 imageapi  nice_menus  securepages
 imagecache  taxonomy_menu  uc_coupon
 imagefield  ubercart_
 Pathauto
 filefield marketplace
 date  Gmap, location*
 Imce, ckeditor
 calendar
 admin_menu  embed_gmap
 jquery_ui
 vertical_tabs  ad
 jquery_update
 advanced_help  advcontact
 libraries
 Chart
 views  Devel*
 faq
 views_slideshow  Skinr
 Fb*
 Drupad*  google_analytics
26 © W. G.Paseman 2/23/12

27. Deploy/Upload, Configure Site
 All subsequent configuration is done from your url in your browser
 Choose profile(done) Open Deals
 Choose language(done) English (built-in)
 Verify requirements(done)
 Set up database(done)
 Database name : db396153918
 User name : dbo396153918
 Database password: xxxxxx
 Host name : db396153918.db.1and1.com
 Port : 3306
 Install profile(done) => Completed 95 of 95. Installed Open Deals module.
 Configure site
 Site name: pacificseduction.com
 Site e-mail address: webmaster pacificseduction.com
 Username: webmaster
 E-mail address: webmaster@pacificseduction.com
 Default country: Philippines
 Default time Zone: Asia/Hong Kong
27 © W. G.Paseman 2/23/12

28. Deploy/Enable Modules
 Modules are enabled
 Modules use memory
 Modules use CPU
 Modules get updated
 This modifies your DB
 Modules are configured
28 © W. G.Paseman 2/23/12

29. Upload, Enable, Configure Modules/
Configure
29 © W. G.Paseman 2/23/12

30. Quiz
 How many lines of custom php code are in Pacific Seduction?
30 © W. G.Paseman 2/23/12

31. Deploy/Set Roles and Permissions
31 © W. G.Paseman 2/23/12

32. Creating a UI
 This is “A Whole Nother presentation”, but to start
 /admin/build/themes/settings/global
 Upload logo image: gsmlogo2_80.jpg
 Upload icon image: PacificSeduction_favicon.ico
 Note: need to clear cache to see new icon
 admin/build/block
 move “Powered by Drupal” to “disabled”
32 © W. G.Paseman 2/23/12

33. Summary
 My Experience
 Drupal (6) Content Authoring
 Web Site 1.0 – Microsoft Frontpage
 Edit Hierarchical Document on your computer
 Web Site 2.0 – Drupal
 CMS (Content Management System) in the cloud
 Drupal (6) Site Development
 Web Application –SAAS
 Choosing a Development Process
 Selecting a Host
 Deploy
 Creating a UI
33 © W. G.Paseman 2/23/12
