Documentum Spring Data
Michael Mohen
Chief Architect, ECD
Distinguished Engineer

Thursday May 5th // 8:30am – 12:30pm
Sessions Available
• xCP
• D2
• Captiva
• Docker
• Documentum APIs
• InfoArchive
Please bring your laptops!

Documentum APIs
REST
Simple,
Scalable, In
Demand
CMIS
Standard,
Limited
DFS-SOAP
Heavy, Antiquated
Complete
DFC
There are a variety of APIs available today;
DFC and REST are dominate

DFS, CMIS, Core REST, D2 REST
ComparisonCore REST D2 REST DFS CMIS
Major Users Documentum new clients D2 clients and integration
Documentum classic
clients
Interoperability
API Type
REST
(XML, JSON)
Same as Core REST
SOAP
(XML)
SOAP, REST
(XML, JSON)
Services
Fundamental services,
Extended services
(Search, Comment, CTS, RPS,
…)
Core REST
+ D2 extension (12)
Fundamental services,
Extended services
(Search, Comment, CTS,
BPM, RPS, …)
Operations for
document, folder and
relationship only
Authenticatio
n
Basic, Ticketed,
SSO (6)
Same as Core REST Basic, SSO (4) Basic, SSO (1)
Extensibility
Service extensibility
Authentication extensibility
NA Service extensibility NA
Note - There are REST interfaces for Captiva and IA

 Spring Data is a high level SpringSource project whose purpose
is to unify and ease the access to different kinds of persistence
stores, both relational database systems and NoSQL data
stores.
 Part of the Spring Framework, one of the most widely used
frameworks for software development today
– MVC, integration, batch, web, et al
 Spring Data provides a data access layer
– Transactions, resources, abstraction, exceptions, et al
 This is an umbrella project contains many subprojects that are
specific to a given database.
– JPA, Neo4J, MongoDB and many more
What is Spring Data?

 Why another API?
 Spring Data for Documentum provides a abstraction for
the Documentum platform
 The goal of Documentum Spring Data repository
abstraction is to significantly reduce the amount of
boilerplate code required to implement data access
layers for various persistence stores.
 Uses the same terminaology as Spring Data
– Repository, CrudRepository, et al
 Based on the Documentum Foundation Classes (DFC)
Spring Data for Documentum

 Spring Data for Documentum provides full CRUD (create,
read, update and delete) operations
– Based on Spring Boot
 Just like in Spring Data JPA, methods include –
– findAll()
– Count()
– findOne()
– delete()
– save()
– exists()
 Annotations for Documentum objects like relations, content,
types

• Spring Data for Documentum
also provides seamless
interoperability with other
Spring modules
– Web, Messaging, AOP and more
• Build your own REST
controllers
• Based on DFC, so backwards
compatible for Documentum 6.7
SP2
• Runs on Java 7

Documentum Spring Data Architecture
Client
Technologies
Spring Data
Layer
Repository
Documentum Foundation Classes Business Object Framework
Content Server
CRUD Repository
Core Spring Data
Many
Techs
Many
Apps
AnnotationsInterfaces
Spring Boot

Documentum Spring Data – the Approach
Spring Boot
• Start with Spring
Boot
• Build your entities,
controllers, et al
Import Dependencies
• Junit tests
• CI
• Expose REST
Build a UI
• Expose to Web
framework, like
AngularJS, Express
• Great with Node.js
Build Your Spring
Project
Import Documentum
Spring Data
JAVA
Web Project (AngularJS,
Express)
WEB
Create your project

Maven
Creating a new project is easy; just import the spring-boot-starter-dctm
dependency!
<dependency>
<groupId>com.emc.documentum.spring</groupId>
<artifactId>spring-boot-starter-dctm</artifactId>
<version>0.0.1-SNAPSHOT</version>
</dependency> Add this to
your POM;
pubic maven
repo now
available!

Annotations
 @DctmEntity
 @DctmAttribute
 @Content
 @Relation
Documentum
attribute
annotation

Entity Class
In this example, we
have a entity called
Student; this is a
Documentum type
Student entity
– this maps to
a type in
Documentum

Interfaces
With Spring Data’s repositories, you need only to write an interface with finder
methods defined according to a given set of conventions (which may vary
depending on the kind of persistence store you are using). Spring Data will provide
an appropriate implementation of that interface at runtime.

 What does this mean for DFS, Core REST and other
APIs?
– Not much - DFS will continue to be supported, since we use it in
many products today. REST will also be supported and
maintained going forward. Spring Data for Documentum
provides developers another set of tools for developing
applications on the Documentum platform.
 In this release, what is not included?
– Not all DFC API features are in Spring Data for Documentum
today; workflow and lifecycles are not in the base release. As the
community grows, we will add more features!
 Can I contribute to the project?
– Yes
Key questions

https://github.com/Enterprise
-Content-Management

<Demos>

THANK YOU!
