Disk reports predicted failure event
•
0 likes•604 views
A predictive failure alert was reported for disk 1c.xx.xx in NetApp cluster node Cluster-02. The disk reported a predicted failure event. If a matching spare disk is available, rapid RAID recovery will begin by copying the data from the pre-failed disk to the spare. If no spares are available, the disk will eventually fail and cause the RAID group to degrade until a spare is available to reconstruct the data. Proactive assignment of a partner node's spare disk is recommended.
Report
Share
Report
Share
Download to read offline
![Which would show the status 'prefail' against the disk reporting disk.ioRecoveredError scsi
errors. If it’s so, then only 2 things can happen:
1) If there is a matching spare disk assigned on that Node :
It will be automatically selected for Rapid RAID Recovery. In this process, the prefailed disk will be
copied to the spare. At the end of the copy process, the prefailed disk is removed from the RAID
configuration. The node will spin that disk down, mark it as `broken', so that it can be removed from
the shelf.
As shown in the following output: [Rapid RAID Recovery has begun]
data 1.xx.xx 0 SAS 10000 1.63TB 1.64TB (prefail, copy in progress) = disk reporting error
data 1.xx.xx 0 SAS 10000 1.63TB 1.64TB (2 % copied) = new spare
2) If there are no spares on that Node:
Disk will eventually fail and the raid-group will go in a degraded state. Once the suitable spare disk is
available, the contents of the disk being removed (broken state) will be reconstructed onto that
spare disk, until that happens, RG will remain in degraded state and raid-group performance could
see latency issues depending upon the raid-group disk utilization %.
Not an ideal situation;
Proactive action: Check if you have matching spare on the partner node if so then assign it to the
failed-disk node and hopefully data would be copied to new disk before it actually fails.
ashwinwriter@gmail.com
