Example: Consider the language L of strings, defined
over Σ={a, b}, starting with b. The language L may
be expressed by RE b(a + b)*
, may be accepted by the
following FA
a,b
a,b
b
a
–– +
1
9/14/2022

21. 21
 Example:
Consider the language L of strings, defined over
Σ={a, b}, ending in a. The language L may be
expressed by RE
(a+b)*
a
This language may be accepted by the following FA
9/14/2022

22. 22
Example Continued …
There may be another FA corresponding to the given
language.
a
b
+
b
–
a
9/14/2022

23. 23
Example continued …
a
b
b
b
a
+
a
––
9/14/2022

24. 24
Note
 It may be noted that corresponding to a given language
there may be more than one FA accepting that
language, but for a given FA there is a unique language
accepted by that FA.
9/14/2022

25. 25
Note
 It is to be noted that given the languages L1 and L2
,where
L1 = The language of strings, defined over Σ={a, b},
beginning with a
L2 = The language of strings, defined over
Σ={a, b}, not beginning with b
The  does not belong to L1 while it does belong to L2 .
This fact may be depicted by the corresponding
transition diagrams of L1 and L2.
9/14/2022

26. 26
FA1
Corresponding to L1
 The language L1
may be expressed by the regular
expression a(a + b)*
a,b
a
b a,b
–– +
9/14/2022

27. 27
FA2
Corresponding to L2
 The language L2
may be expressed by the regular
expression a (a + b)*
+ Λ
a,b
a,b
a
b
 +
9/14/2022

28. 28
Example
 Consider the Language L of Strings of length two or
more, defined over Σ = {a, b}, beginning with and
ending in same letters.
The language L may be expressed by the following
regular expression
a (a + b)*
a + b (a + b)*
b
It is to be noted that if the condition on the length of
string is not imposed in the above language then the
strings a and b will then belong to the language.
This language L may be accepted by the following FA
9/14/2022

29. 29
Example Continued …
b
a
a
b
+
a
b
b
a
+
b
a
–
9/14/2022

30. 30
Task
 Build an FA accepting the Language L of Strings,
defined over Σ = {a, b}, beginning with and ending
in same letters.
9/14/2022

31. 31
Example
Consider the language L = {w belongs to {a,b}*
:
length(w) >= 2 and w neither ends in aa nor bb}.
The language L may be expressed by the regular
expression
(a+b)*
(ab+ba)
This language may be accepted by the following FA
9/14/2022

32. 32
Example Continued …
b
a
b
4+
b
2
a
a
5+
a
3
b
1–
a b
9/14/2022

33. 33
Note
 It is to be noted that building an FA corresponding to
the language L, discussed in the previous example,
seems to be quite difficult, but the same can be done
using tree structure along with the technique
discussed in the book
Introduction to Languages and Theory of
Computation, by J. C. Martin
so that the strings ending in aa, ab, ba and bb should
end in the states labeled as aa, ab, ba and bb,
respectively;as shown in the following FA
9/14/2022

34. 34
Example continued …
a
a
aa
b
a
b
Λ
a
b
a
a
a
b
b
b
b
a
b
ab
ba
bb
9/14/2022

35. 35
Task
 Using the technique discussed by Martin, build an FA
accepting the following language
L = {w belongs to {a,b}*
: length(w) >= 2 and second
letter of w, from right is a}.
9/14/2022

36. 36
Task
 Using the technique discussed by Martin, build an FA
accepting the following language
L = {w belongs to {a,b}: w neither ends in ab nor ba}.
9/14/2022
