This document discusses how to create a custom object store in Mule. It explains that an object store persists data between messages. To create a custom store, you implement the ObjectStore interface and can override interfaces like ListableObjectStore. The document provides a code snippet of a custom MyObjectStore class that uses a Hashtable to store objects, implementing the required ObjectStore methods. It notes that the custom store can then be configured in components that require object stores.

1. Creating Custom Object
Store
- By Rahul Kumar

2. Custom Object Store
An object store is a facility for storing objects in Mule. Mule uses object stores
whenever it needs data to persist for later retrieval. Internally, Mule uses object
stores in various filters, routers, and other message processors that need to
store their state between messages. In most cases, Mule creates and manages
object stores automatically, so no user configuration is necessary.

3. Creating Custom Object
Store
Create your own object Store by:
Implementing org.mule.api.store.ObjectStore interface
Overriding the standard implementations of Object Stores like
org.mule.api.store.ListableObjectStore, org.mule.api.store.PartitionableObjectStore
org.mule.api.store.PartitionableExpirableObjectStore and many more

4. Snippet for Custom
Object Store
package org.rahul.objectstore;
import java.io.Serializable;
import java.util.Hashtable;
import org.mule.api.store.ObjectStore;
import org.mule.api.store.ObjectStoreException;
public class MyObjectStore implements ObjectStore {
private static Hashtable<String,String> myStore= new Hashtable<String,String>();
public static Hashtable<String, String> getMyStore() {
return myStore;
}
public static void setMyStore(Hashtable<String, String> myStore) {
MyObjectStore.myStore = myStore;
}

5. Snippet for Custom
Object Store
@Override
public boolean contains(Serializable key) throws ObjectStoreException {
return getMyStore().containsKey(key);
}
@Override
public void store(Serializable key, Serializable value)
throws ObjectStoreException {
getMyStore().put(key.toString(), value.toString());
}
@Override
public Serializable retrieve(Serializable key) throws ObjectStoreException {
return getMyStore().get(key);
}

6. Snippet for Custom
Object Store
@Override
public Serializable remove(Serializable key) throws ObjectStoreException {
return getMyStore().remove(key);
}
@Override
public boolean isPersistent() {
return false;
}
@Override
public void clear() throws ObjectStoreException {
getMyStore().clear();
}
}

7. Snippet for Custom
Object Store
The above provided snippet can be used to create a custom Onject store.
This object store is storing objects inside a HashTable

8. Configuration
Provide this object store in the components which requires object stores like
idempotent filter, Until Successful scope etc.
