SOZIALE SYSTEME
MICROSERVICES
AGILITÄT
CONWAYS LAW REVISITEDJens Himmelreich - XPDays 2015
CONWAYS
LAW
HOW DO
COMMITTEES
INVENT?by MELVIN E. CONWAY
That kind of intellectual activity which creates
a useful whole from its diverse parts may be
called the design of a system. Whether the
particular activity is the creation of specifica-
tions for a major weapon system, the formation of a rec-
ommendation to meet a social challenge, or the program-
ming of a computer, the general activity is largely the
same.
Typically, the objective of a design organization is the
creation and assembly of a document containing a coherent-
ly structured body of information. We may name this
information the system design. It is typically produced for
a sponsor who usually desires to carry out some activity
guided by the system design. For example, a public official
may wish to propose legislation to avert a recurrence of a
recent disaster, so he appoints a team to explain the catas-
trophe. Or a manufacturer needs a new product and desig-
nates a product planning activity to specify what should be
introduced.
The design organization may or may not be involved in
the construction of the system it designs. Frequently, in
public affairs, there are policies which discourage a group's
acting upon its own recommendations, whereas, in private
industry, quite the opposite situation often prevails.
It seems reasonable to suppose that the knowledge that
one will have to carry out one's own recommendations or
that this task will fall to others, probably affects some
design choices which the individual designer is cailed upon
to make. Most design activity requires continually making
choices. Many of these choices may be more than design
decisions; they may also be personal decisions the designer
makes about his own future. As we shall see later, the
incentives which exist in a conventional management en-
vironment can motivate choices which subvert the intent of
the sponsor.!
stages of design
The initial stages .of a design effort are concerned more
with structuring of the design activity than with the system
itsel£.2 The full-blown design activity cannot proceed until
certain preliminary milestones are passed. These include:
1. Understanding of the boun9aries, both on the design
activity and on the system to be designed, placed by
the sponsor and by the worltl's realities.
2. Achievement of a preliminary notion of the system's
organization so that design task groups can be mean-
ingfully assigned.
We shall see in detail later that the very act of organiz-
1 A related, but much more comprehensive discussion of the behavior of
system-designing organizations is found in John Kenneth Galbraith's,
The New Industrial State (Boston, Houghton Mifflin, 1967). See especially
Chapter VI, "The Technostructur<!."
2 For o discussion of the problems which may arise when the design
activity takes the form of o project in a functional environment, see C. J.
Middleton, "How to Set Up o Project Organization," Harvard Business
Review, March-April, 1967, p. 73.
28
design organization criteria
ing a design team means that certain design decisions have
already been made, explicitly or otherwise. Given any
design team organization, there is a class of design alterna-
tives which cannot be effectively pursued by such an
organization because the necessary communication paths
do not exist. Therefore, there is no such thing as a design
group which is both organized and unbiased.
Once the organization of the design team is chosen, it is
possible to delegate activities to the subgroups of the
organization. Every time a delegation is made and some-
body's scope of inquiry is narrowed, the class of design
alternatives which can be effectively pursued is also nar-
rowed.
Once scopes of activity are defined, a coordination prob-
lem is created. Coordination among task groups, although
it appears to lower the productivity of the individual in the
small group, provides the only possibility that the separate
task groups will be able to consolidate their efforts into a
unified system design.
Thus the life cycle of a system design effort proceeds
through the following general stages:
1. Drawing of boundaries according to the ground
rules.
2. Choice of a preliminary system concept.
3. Organization of the design activity and delegation of
tasks according to that concept.
4. Coordination among delegated tasks.
5. Consolidation of subdesigns into a single design.
It is possible that a given design activity will not pro-
ceed straight through this list. It might conceivably reorga-
nize upon discovery of a new, and obviously superior,
design concept; but such an appearance of uncertainty is
unflattering, and the very act of voluntarily abandoning a
creation is painful and expensive. Of course, from the
Dr. Conway is manager, pe-
ripheral systems research, at
Sperry Rand's Univac Div.,
where he is working on recog-
nition of continuous speech. He
has previously been a research
associate at Case Western Re-
serve Univ., and a software
consultant. .He has an MS in
physics from CaiTech and a
PhD in math from Case.
:C»ATAMATION
HOW DO
COMMITTEES
INVENT?Melvin Conway - Datamation, April 1968
ORGANIZATIONS WHICH DESIGN
SYSTEMS ARE CONSTRAINED TO
PRODUCE DESIGNS WHICH ARE COPIES
OF THE COMMUNICATION STRUCTURES
OF THESE ORGANIZATIONS.
MELVIN CONWAY
IF YOU HAVE FOUR GROUPS
WORKING ON A COMPILER,

YOU'LL GET

A 4-PASS COMPILER.
HACKERDICTIONARY
A
B
C
A
B
C
A
B
C
?
A
B
C
A
B
C
A
B
C
A
B
C
ORGANISATIONspiegelt sich im
SYSTEM
ORGANISATIONmaterialisiert sich im
SYSTEM
ORGANISATIONzementiert im
SYSTEM
ORGANISATIONist eine Hypothese für die
DOMÄNE
ORGANISATIONoperationalisiert
DOMÄNE
DOMÄNEoperationalisiert in
ORGANISATIONmaterialisiert im
SYSTEM
GIVEN ANY DESIGN TEAM
ORGANIZATION, THERE IS A CLASS
OF DESIGN ALTERNATIVES WHICH
CANNOT BE EFFECTIVLEY PURSUED
BY SUCH AN ORGANIZATION …
MELVIN CONWAY
BECAUSE THE DESIGN WHICH
OCCURS FIRST IS ALMOST NEVER
THE BEST POSSIBLE … THEREFORE,
FLEXIBILITY OF ORGANIZATION IS
IMPORTANT TO EFFECTIVE DESIGN.
MELVIN CONWAY
DOMÄNE
ORGANISATION
SYSTEM
KOPPLUNG
Copyright © 2007, 2008, 2011 by Alan MacCormack, John Rusnak, and Carliss Baldwin
Working papers are in draft form. This working paper is distributed for purposes of comment and
discussion only. It may not be reproduced without permission of the copyright holder. Copies of working
papers are available from the author.
Exploring the Duality
between Product and
Organizational Architectures:
A Test of the “Mirroring”
Hypothesis
Alan MacCormack
John Rusnak
Carliss Baldwin
Working Paper
08-039
EXPLORING THE DUALITY BETWEEN

PRODUCT AND ORGANIZATIONAL ARCHITECTURES:

A TEST OF THE MIRRORING HYPOTHESISAlan McCormick, John Rusnak, Carliss Baldwin
Harvard Business School Working Paper, 27 Mar 2008
MIRRORING HYPOTHESES
„Loosely-coupled organizations

will tend to develop products
with more modular architecture

than tightly-coupled organizations.“
MIRRORING HYPOTHESES
„Loosely-coupled organizations

will tend to develop products
with more modular architecture

than tightly-coupled organizations.“
MIRRORING HYPOTHESES
„Loosely-coupled organizations

will tend to develop products
with more modular architecture

than tightly-coupled organizations.“
MIRRORING HYPOTHESES
„Loosely-coupled organizations

will tend to develop products
with more modular architecture

than tightly-coupled organizations.“
MIRRORING HYPOTHESES
„Loosely-coupled organizations

will tend to develop products
with more modular architecture

than tightly-coupled organizations.“
GNUCASH
MYBOOKS
ABIWORD
STARWRITER
GNUMERIC
STARCALC
LINUX 2.1.32
SOLARIS
LINUX 2.6.8
XNU
MYSQL
BERKELEY DB
GNUCASH
MYBOOKS
ABIWORD
STARWRITER
GNUMERIC
STARCALC
LINUX 2.1.32
SOLARIS
LINUX 2.6.8
XNU
MYSQL
BERKELEY DB
7,74%
47,14%
8,25%
41,77%
23,62%
54,31%
7,18%
22,59%
7,21%
24,83%
11,3%
43,23%
IN ALL PAIRS WE EXAMINE, THE
LOOSELY-COUPLED ORGANIZATION
DEVELOPS A PRODUCT WITH A MORE
MODULAR DESIGN THAN THAT OF THE
TIGHTLY-COUPLED ORGANIZATION.
MACCORMACK, RUSNACK, BALDWIN
QUALITÄT
THE INFLUENCE OF ORGANIZATIONAL STRUCTURE ON
SOFTWARE QUALITY: AN EMPIRICAL CASE STUDY
Nachiappan Nagappan
Microsoft Research
Redmond, WA, USA
nachin@microsoft.com
Brendan Murphy
Microsoft Research
Cambridge, UK
bmurphy@microsoft.com
Victor R. Basili
University of Maryland
College Park, MD, USA
basili@cs.umd.edu
ABSTRACT
Often software systems are developed by organizations consisting
of many teams of individuals working together. Brooks states in
the Mythical Man Month book that product quality is strongly
affected by organization structure. Unfortunately there has been
little empirical evidence to date to substantiate this assertion. In
this paper we present a metric scheme to quantify organizational
complexity, in relation to the product development process to
identify if the metrics impact failure-proneness. In our case study,
the organizational metrics when applied to data from Windows
Vista were statistically significant predictors of failure-proneness.
The precision and recall measures for identifying failure-prone
binaries, using the organizational metrics, was significantly higher
than using traditional metrics like churn, complexity, coverage,
dependencies, and pre-release bug measures that have been used
to date to predict failure-proneness. Our results provide empirical
evidence that the organizational metrics are related to, and are
effective predictors of failure-proneness.
Categories and Subject Descriptors
D.2.8 [Software Engineering]: Software Metrics – complexity
measures, performance measures, process metrics, product
metrics.
General Terms
Measurement, Reliability, Human Factors.
Keywords
Organizational structure, Failures, Code churn, People, Empirical
Studies.
1. INTRODUCTION
Software engineering is a complex engineering activity. It
involves interactions between people, processes, and tools to
develop a complete product. In practice, commercial software
development is performed by teams consisting of a number of
individuals ranging from the tens to the thousands. Often these
people work via an organizational structure reporting to a manager
or set of managers.
The intersection of people [9], processes [29] and organization
[33] and the area of identifying problem prone components early
in the development process using software metrics (e.g. [13, 24,
28, 30]) has been studied extensively in recent years. Early
indicators of software quality are beneficial for software engineers
and managers in determining the reliability of the system,
estimating and prioritizing work items, focusing on areas that
require more testing, inspections and in general identifying
“problem-spots” to manage for unanticipated situations. Often
such estimates are obtained from measures like code churn, code
complexity, code coverage, code dependencies, etc. But these
studies often ignore one of the most influential factors in software
development, specifically “people and organizational structure”.
This interesting fact serves as our main motivation to understand
the intersection between organizational structure and software
quality: How does organizational complexity influence quality?
Can we identify measures of the organizational structure? How
well do they do at predicting quality, e.g., do they do a better job
of identifying problem components than earlier used metrics?
Conway’s Law states that “organizations that design systems are
constrained to produce systems which are copies of the
communication structures of these organizations.” [8]. Similarly,
Fred Brooks argues in the Mythical Man Month [6] that the
product quality is strongly affected by org structure. With the
advent of global software development where teams are
distributed across the world the impact of organization structure
on Conway’s law [15] and its implications on quality is
significant. To the best of our knowledge there has been little or
no empirical evidence regarding the relationship/association
between organizational structure and direct measures of software
quality like failures.
In this paper we investigate this relationship between
organizational structure and software quality by proposing a set of
eight measures that quantify organizational complexity. These
eight measures provide a balanced view of organizational
complexity from the code viewpoint. For the organizational
metrics, we try to capture issues such as organizational distance of
THE INFLUENCE OF ORGANISATIONAL STRUCTURE
ON SOFTWARE QUALITY:

AN EMPIRICAL CASE STUDYNachiappan Nagappan, Brendon Murphy, Victor R. Basili
Microsoft Research TechReport, January 2008
IN THIS PAPER WE PRESENT A METRIC
SCHEME TO QUANTIFY ORGANIZATIONAL
COMPLEXITY, IN RELATION TO THE
PRODUCT DEVELOPMENT PROCESS TO
IDENTIFY IF THE METRICS IMPACT
FAILURE-PRONENESS.
NAGAPPAN, MURPHY, BASILI
ORGANIZATIONAL STRUCTURE
CODE CHURN
CODE COMPLEXITY
DEPENDENCIES
CODE COVERAGE
PRE-RELEASE BUGS
86,2%
78,6%
79,3%
74,4%
83,3%
73,8%
84,0%
79,9%
66,0%
69,9%
54,4%
62,9%
PRECISION
RECALL
THE PRECISION AND RECALL MEASURES
FOR IDENTIFYING FAILURE-PRONE
BINARIES, USING THE ORGANIZATIONAL
METRICS, WAS SIGNIFICANTLY HIGHER
THAN USING TRADITIONAL METRICS.
NAGAPPAN, MURPHY, BASILI
MUSTER
1
CD
WEBSHOP
CD
CD
WEBSHOP
PROD
WEBSHOP
PROD
WEBSHOP
MUSTERtemporal
MUSTER
MUSTERtechnisch-organisatorisch
AB
A
B
B
A
MUSTER
2
SHOP
SHOP
RECO TRACKING
SEARCH
NEWS-
LETTER
SHOP
RECO TRACKING
SEARCH
NEWS-
LETTER
SEO ATTRIBUTE
SHOP
RECO TRACKING
SEARCH
NEWS-
LETTER
SEO ATTRIBUTE
SHOP
RECO TRACKING
SEARCH
NEWS-
LETTER
SEO ATTRIBUTE
MUSTERfunktional
MUSTER
3
SHOP
SHOP
D
SHOP
DI
SHOP
DWAWII
SHOP
DWAWII
SHOP
DWAWII
FRONTEND
APPLIKATION
DWAWII
FRONT
APPLIKATION
DWAWII
T1
FRONT
T2
MUSTERsozial
MUSTERtemporal - funktional - sozial
DWAWII
SH
FRONT
OP
RECO TR
SEA NEWS
SEO ATTR
PROD
DWAWII
SH
FRONT
OP
RECO TR
SEA NEWS
SEO ATTR
PROD
FEATURE (BILD)
FEATURE (PREIS)
CONWAYkonstruktiv
DOMÄNEoperationalisiert in
ORGANISATIONmaterialisiert im
SYSTEM
TEST
FRONTEND
APPLIKATION
PRODUKTION
DATENBANK
BETRIEB
FEATURE
EFFIZIENZ
KUNDE PRODUKT BILD
SUCHE WARENKORB NAVIGATION EMPFEHLUNG DETAILSEITE MEINKONTO
REDUNDANZ
VERTIKALE
VERTIKALESelf Contained System
VERTIKALEMicroservice mit UI
AMAZONNETFLIX
OTTO
GALERIA
TALENTFORMATION
DEVOPS MICROSERVICES
Quellen
PHASENdes
KAUFPROZESSES
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
KUNDENORIENTIERUNG
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
TIME-TO-MARKET
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
DB DB DB DB DB
HTML HTML HTML HTML HTML
A B
C
A B
C
A B
C
A B
C
A B
C
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
DB DB DB DB DB
HTML HTML HTML HTML HTML
VARIANTE
PRODUKT

KNOTEN
PRODUKT
WARENKORB

POSTITION
ARTIKEL
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
DB DB DB DB DB
HTML HTML HTML HTML HTML
A B
C
A B
C
A B
C
A B
C
A B
C
HTML
DETAIL
HTML
NAVIGATION
HTML
EMPFEHLUNG
HTML
MINIWARENKORB
HTML
ANREDE
STYLEGUIDE
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
DB DB DB DB DB
HTML HTML HTML HTML HTML
A B
C
A B
C
A B
C
A B
C
A B
C
HTMLHTML HTML HTML HTML
RWD APP INSTORE
ARCHITEKTUR-
PRINZIPIEN
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
FACHLICHE ISOLATION
Bounded Context
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
ORGANISATORISCHE ISOLATION
Separates Scrumteam
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
TECHNISCHE ISOLATION
Keine synchrone Kopplung
FRONTENDINTEGRATION
DETAILNAVIGATION
EMPFEHLUNG
MINIWARENKORBANREDE
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
REST-INTEGRATION
smart endpoints and dump pipes
BEWERTEN
PIM
MICROSERVICES
synchrone Kopplung erlaubt
DETAIL
SEITE BACKOFFICE
PRODUKT
VERGLEICH
SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
PAGER PAGER PAGER PAGER PAGER
BETRIEBLICHE ISOLATION
You Built it - you run it!
CONWAYkompakt
DOMÄNE
ORGANISATION
SYSTEM
DOMÄNEoperationalisiert in
ORGANISATIONmaterialisiert im
SYSTEM
ORGANISATION
SYSTEM
Wie spiegelt sich meine Organisation
im technischen System?
DOMÄNE
ORGANISATION
Welche Hypothese über die Domäne
stellt meine Organisation dar?
?ENDEFragen?
QUELLEN
HOW DO COMMITTEES INVENT?
http://www.melconway.com/Home/pdf/committees.pdf
EXPLORING THE DUALITY BETWEEN PRODUCT AND ORGANIZATIONAL ARCHITECTURES:

A TEST OF THE MIRRORING HYPOTHESIS
http://www.hbs.edu/research/pdf/08-039.pdf
THE INFLUENCE OF ORGANISATIONAL STRUCTURE ON SOFTWARE QUALITY:

AN EMPIRICAL CASE STUDY
http://research.microsoft.com/pubs/70535/tr-2008-11.pdf
The colors and fonts are inspired by Phil Hawksworth
http://hawksworx.com/
THIS WORK IS LICENSED UNDER A CREATIVE COMMONS
ATTRIBUTION-NONCOMMERCIAL-NODERIVS 3.0 UNPORTED LICENSE

More Related Content

Similar to ConwaysLawRevisited

STUDY OF AGENT ASSISTED METHODOLOGIES FOR DEVELOPMENT OF A SYSTEM
STUDY OF AGENT ASSISTED METHODOLOGIES FOR DEVELOPMENT OF A SYSTEMSTUDY OF AGENT ASSISTED METHODOLOGIES FOR DEVELOPMENT OF A SYSTEM
STUDY OF AGENT ASSISTED METHODOLOGIES FOR DEVELOPMENT OF A SYSTEM
International Journal of Technical Research & Application

Week 7 Github - SI- Architecture.pptx
Week 7 Github - SI-  Architecture.pptxWeek 7 Github - SI-  Architecture.pptx
Week 7 Github - SI- Architecture.pptx
ArjayBalberan1

Abstract
AbstractAbstract
Abstract
emaye

CORE: Cognitive Organization for Requirements Elicitation
CORE: Cognitive Organization for Requirements ElicitationCORE: Cognitive Organization for Requirements Elicitation
CORE: Cognitive Organization for Requirements Elicitation
Scott M. Confer

Elangovan Arumugayya
Elangovan ArumugayyaElangovan Arumugayya
Elangovan Arumugayya
Elangovan Arumugayya

An agent based approach for building complex software systems
An agent based approach for building complex software systemsAn agent based approach for building complex software systems
An agent based approach for building complex software systems
Icaro Santos

Creating An Incremental Architecture For Your System
Creating An Incremental Architecture For Your SystemCreating An Incremental Architecture For Your System
Creating An Incremental Architecture For Your System
Giovanni Asproni

Is The Architectures Of The Convnets ) For Action...
Is The Architectures Of The Convnets ) For Action...Is The Architectures Of The Convnets ) For Action...
Is The Architectures Of The Convnets ) For Action...
Sheila Guy

Intro sad
Intro sadIntro sad
Intro sad
abhijeetdavane

Production and Operations management - assignment 1 - defining a system
Production and Operations management - assignment 1 - defining a systemProduction and Operations management - assignment 1 - defining a system
Production and Operations management - assignment 1 - defining a system
Kerrie Noble

PatternDynamics Operating System Workbook v3.5.2
PatternDynamics Operating System Workbook v3.5.2PatternDynamics Operating System Workbook v3.5.2
PatternDynamics Operating System Workbook v3.5.2
Tim Winton

A Framework For Creating Hybrid-Open Source Software Communities
A Framework For Creating Hybrid-Open Source Software CommunitiesA Framework For Creating Hybrid-Open Source Software Communities
A Framework For Creating Hybrid-Open Source Software Communities
Joe Andelija

Creativity And Inovation
Creativity And InovationCreativity And Inovation
Creativity And Inovation
Nor Azri Nor Hashim

TED Talk - "Lean STS" - Christis
TED Talk - "Lean STS" - ChristisTED Talk - "Lean STS" - Christis
TED Talk - "Lean STS" - Christis
Sociotechnical Roundtable

Enterprise transformation - What is transformed?
Enterprise transformation - What is transformed?Enterprise transformation - What is transformed?
Enterprise transformation - What is transformed?
Frederick Halas

76 May 2007Vol. 50, No. 5 COMMUNICATIONS OF THE ACM COMMUNIC.docx
76 May  2007Vol. 50, No. 5 COMMUNICATIONS OF THE ACM COMMUNIC.docx76 May  2007Vol. 50, No. 5 COMMUNICATIONS OF THE ACM COMMUNIC.docx
76 May 2007Vol. 50, No. 5 COMMUNICATIONS OF THE ACM COMMUNIC.docx
evonnehoggarth79783

Recommender systems in the scope of opinion formation: a model
Recommender systems in the scope of opinion formation: a modelRecommender systems in the scope of opinion formation: a model
Recommender systems in the scope of opinion formation: a model
Marcel Blattner, PhD

Test Load File
Test Load FileTest Load File
Test Load File
Pongsaa

Approach to composition of mis
Approach to composition of misApproach to composition of mis
Approach to composition of mis
Yatendra Paliwal

Rethinking Software Engineering
Rethinking Software EngineeringRethinking Software Engineering
Rethinking Software Engineering
Ian Sommerville


Similar to ConwaysLawRevisited (20)

STUDY OF AGENT ASSISTED METHODOLOGIES FOR DEVELOPMENT OF A SYSTEM
STUDY OF AGENT ASSISTED METHODOLOGIES FOR DEVELOPMENT OF A SYSTEMSTUDY OF AGENT ASSISTED METHODOLOGIES FOR DEVELOPMENT OF A SYSTEM
STUDY OF AGENT ASSISTED METHODOLOGIES FOR DEVELOPMENT OF A SYSTEM

Week 7 Github - SI- Architecture.pptx
Week 7 Github - SI-  Architecture.pptxWeek 7 Github - SI-  Architecture.pptx
Week 7 Github - SI- Architecture.pptx

Abstract
AbstractAbstract
Abstract

CORE: Cognitive Organization for Requirements Elicitation
CORE: Cognitive Organization for Requirements ElicitationCORE: Cognitive Organization for Requirements Elicitation
CORE: Cognitive Organization for Requirements Elicitation

Elangovan Arumugayya
Elangovan ArumugayyaElangovan Arumugayya
Elangovan Arumugayya

An agent based approach for building complex software systems
An agent based approach for building complex software systemsAn agent based approach for building complex software systems
An agent based approach for building complex software systems

Creating An Incremental Architecture For Your System
Creating An Incremental Architecture For Your SystemCreating An Incremental Architecture For Your System
Creating An Incremental Architecture For Your System

Is The Architectures Of The Convnets ) For Action...
Is The Architectures Of The Convnets ) For Action...Is The Architectures Of The Convnets ) For Action...
Is The Architectures Of The Convnets ) For Action...

Intro sad
Intro sadIntro sad
Intro sad

Production and Operations management - assignment 1 - defining a system
Production and Operations management - assignment 1 - defining a systemProduction and Operations management - assignment 1 - defining a system
Production and Operations management - assignment 1 - defining a system

PatternDynamics Operating System Workbook v3.5.2
PatternDynamics Operating System Workbook v3.5.2PatternDynamics Operating System Workbook v3.5.2
PatternDynamics Operating System Workbook v3.5.2

A Framework For Creating Hybrid-Open Source Software Communities
A Framework For Creating Hybrid-Open Source Software CommunitiesA Framework For Creating Hybrid-Open Source Software Communities
A Framework For Creating Hybrid-Open Source Software Communities

Creativity And Inovation
Creativity And InovationCreativity And Inovation
Creativity And Inovation

TED Talk - "Lean STS" - Christis
TED Talk - "Lean STS" - ChristisTED Talk - "Lean STS" - Christis
TED Talk - "Lean STS" - Christis

Enterprise transformation - What is transformed?
Enterprise transformation - What is transformed?Enterprise transformation - What is transformed?
Enterprise transformation - What is transformed?

76 May 2007Vol. 50, No. 5 COMMUNICATIONS OF THE ACM COMMUNIC.docx
76 May  2007Vol. 50, No. 5 COMMUNICATIONS OF THE ACM COMMUNIC.docx76 May  2007Vol. 50, No. 5 COMMUNICATIONS OF THE ACM COMMUNIC.docx
76 May 2007Vol. 50, No. 5 COMMUNICATIONS OF THE ACM COMMUNIC.docx

Recommender systems in the scope of opinion formation: a model
Recommender systems in the scope of opinion formation: a modelRecommender systems in the scope of opinion formation: a model
Recommender systems in the scope of opinion formation: a model

Test Load File
Test Load FileTest Load File
Test Load File

Approach to composition of mis
Approach to composition of misApproach to composition of mis
Approach to composition of mis

Rethinking Software Engineering
Rethinking Software EngineeringRethinking Software Engineering
Rethinking Software Engineering


More from Jens Himmelreich

Auto, Maschine, Buch
Auto, Maschine, BuchAuto, Maschine, Buch
Auto, Maschine, Buch
Jens Himmelreich

kundenorientierte vertikalisierung
kundenorientierte vertikalisierungkundenorientierte vertikalisierung
kundenorientierte vertikalisierung
Jens Himmelreich

Software-Hygiene
Software-HygieneSoftware-Hygiene
Software-Hygiene
Jens Himmelreich

Schnittmuster
SchnittmusterSchnittmuster
Schnittmuster
Jens Himmelreich

Der pathologische Programmierer
Der pathologische ProgrammiererDer pathologische Programmierer
Der pathologische Programmierer
Jens Himmelreich

Lean Startup
Lean StartupLean Startup
Lean Startup
Jens Himmelreich

Skalierungsprobleme im eCommerce
Skalierungsprobleme im eCommerceSkalierungsprobleme im eCommerce
Skalierungsprobleme im eCommerce
Jens Himmelreich

Das agile Ich (extended version)
Das agile Ich (extended version)Das agile Ich (extended version)
Das agile Ich (extended version)
Jens Himmelreich

Agile Softwareentwicklung nach Winston Royce
Agile Softwareentwicklung nach Winston RoyceAgile Softwareentwicklung nach Winston Royce
Agile Softwareentwicklung nach Winston Royce
Jens Himmelreich

Agilität und Mikropolitik
Agilität und MikropolitikAgilität und Mikropolitik
Agilität und Mikropolitik
Jens Himmelreich

Muster in Webcontrollern
Muster in WebcontrollernMuster in Webcontrollern
Muster in Webcontrollern
Jens Himmelreich

Fremde Domänen verstehen - eine philosophische Randnotiz
Fremde Domänen verstehen - eine philosophische RandnotizFremde Domänen verstehen - eine philosophische Randnotiz
Fremde Domänen verstehen - eine philosophische Randnotiz
Jens Himmelreich

Die Dinge richtig tun - die richtigen Dinge tun
Die Dinge richtig tun - die richtigen Dinge tunDie Dinge richtig tun - die richtigen Dinge tun
Die Dinge richtig tun - die richtigen Dinge tun
Jens Himmelreich

Das agile Ich
Das agile IchDas agile Ich
Das agile Ich
Jens Himmelreich


More from Jens Himmelreich (15)

Auto, Maschine, Buch
Auto, Maschine, BuchAuto, Maschine, Buch
Auto, Maschine, Buch

kundenorientierte vertikalisierung
kundenorientierte vertikalisierungkundenorientierte vertikalisierung
kundenorientierte vertikalisierung

Software-Hygiene
Software-HygieneSoftware-Hygiene
Software-Hygiene

Schnittmuster
SchnittmusterSchnittmuster
Schnittmuster

Der pathologische Programmierer
Der pathologische ProgrammiererDer pathologische Programmierer
Der pathologische Programmierer

Lean Startup
Lean StartupLean Startup
Lean Startup

Skalierungsprobleme im eCommerce
Skalierungsprobleme im eCommerceSkalierungsprobleme im eCommerce
Skalierungsprobleme im eCommerce

Das agile Ich (extended version)
Das agile Ich (extended version)Das agile Ich (extended version)
Das agile Ich (extended version)

Agile Softwareentwicklung nach Winston Royce
Agile Softwareentwicklung nach Winston RoyceAgile Softwareentwicklung nach Winston Royce
Agile Softwareentwicklung nach Winston Royce

Das Leben als Projekt
Das Leben als ProjektDas Leben als Projekt
Das Leben als Projekt

Agilität und Mikropolitik
Agilität und MikropolitikAgilität und Mikropolitik
Agilität und Mikropolitik

Muster in Webcontrollern
Muster in WebcontrollernMuster in Webcontrollern
Muster in Webcontrollern

Fremde Domänen verstehen - eine philosophische Randnotiz
Fremde Domänen verstehen - eine philosophische RandnotizFremde Domänen verstehen - eine philosophische Randnotiz
Fremde Domänen verstehen - eine philosophische Randnotiz

Die Dinge richtig tun - die richtigen Dinge tun
Die Dinge richtig tun - die richtigen Dinge tunDie Dinge richtig tun - die richtigen Dinge tun
Die Dinge richtig tun - die richtigen Dinge tun

Das agile Ich
Das agile IchDas agile Ich
Das agile Ich


Recently uploaded

The Power of Visual Regression Testing_ Why It Is Critical for Enterprise App...
The Power of Visual Regression Testing_ Why It Is Critical for Enterprise App...The Power of Visual Regression Testing_ Why It Is Critical for Enterprise App...
The Power of Visual Regression Testing_ Why It Is Critical for Enterprise App...
kalichargn70th171

Liberarsi dai framework con i Web Component.pptx
Liberarsi dai framework con i Web Component.pptxLiberarsi dai framework con i Web Component.pptx
Liberarsi dai framework con i Web Component.pptx
Massimo Artizzu

Unlock the Secrets to Effortless Video Creation with Invideo: Your Ultimate G...
Unlock the Secrets to Effortless Video Creation with Invideo: Your Ultimate G...Unlock the Secrets to Effortless Video Creation with Invideo: Your Ultimate G...
Unlock the Secrets to Effortless Video Creation with Invideo: Your Ultimate G...
The Third Creative Media

Assure Contact Center Experiences for Your Customers With ThousandEyes
Assure Contact Center Experiences for Your Customers With ThousandEyesAssure Contact Center Experiences for Your Customers With ThousandEyes
Assure Contact Center Experiences for Your Customers With ThousandEyes
ThousandEyes

Modelling Up - DDDEurope 2024 - Amsterdam
Modelling Up - DDDEurope 2024 - AmsterdamModelling Up - DDDEurope 2024 - Amsterdam
Modelling Up - DDDEurope 2024 - Amsterdam
Alberto Brandolini

一比一原版(USF毕业证)旧金山大学毕业证如何办理
一比一原版(USF毕业证)旧金山大学毕业证如何办理一比一原版(USF毕业证)旧金山大学毕业证如何办理
一比一原版(USF毕业证)旧金山大学毕业证如何办理
dakas1

一比一原版(sdsu毕业证书)圣地亚哥州立大学毕业证如何办理
一比一原版(sdsu毕业证书)圣地亚哥州立大学毕业证如何办理一比一原版(sdsu毕业证书)圣地亚哥州立大学毕业证如何办理
一比一原版(sdsu毕业证书)圣地亚哥州立大学毕业证如何办理
kgyxske

Enhanced Screen Flows UI/UX using SLDS with Tom Kitt
Enhanced Screen Flows UI/UX using SLDS with Tom KittEnhanced Screen Flows UI/UX using SLDS with Tom Kitt
Enhanced Screen Flows UI/UX using SLDS with Tom Kitt
Peter Caitens

Transforming Product Development using OnePlan To Boost Efficiency and Innova...
Transforming Product Development using OnePlan To Boost Efficiency and Innova...Transforming Product Development using OnePlan To Boost Efficiency and Innova...
Transforming Product Development using OnePlan To Boost Efficiency and Innova...
OnePlan Solutions

14 th Edition of International conference on computer vision
14 th Edition of International conference on computer vision14 th Edition of International conference on computer vision
14 th Edition of International conference on computer vision
ShulagnaSarkar2

Superpower Your Apache Kafka Applications Development with Complementary Open...
Superpower Your Apache Kafka Applications Development with Complementary Open...Superpower Your Apache Kafka Applications Development with Complementary Open...
Superpower Your Apache Kafka Applications Development with Complementary Open...
Paul Brebner

Boost Your Savings with These Money Management Apps
Boost Your Savings with These Money Management AppsBoost Your Savings with These Money Management Apps
Boost Your Savings with These Money Management Apps
Jhone kinadey

WMF 2024 - Unlocking the Future of Data Powering Next-Gen AI with Vector Data...
WMF 2024 - Unlocking the Future of Data Powering Next-Gen AI with Vector Data...WMF 2024 - Unlocking the Future of Data Powering Next-Gen AI with Vector Data...
WMF 2024 - Unlocking the Future of Data Powering Next-Gen AI with Vector Data...
Luigi Fugaro

8 Best Automated Android App Testing Tool and Framework in 2024.pdf
8 Best Automated Android App Testing Tool and Framework in 2024.pdf8 Best Automated Android App Testing Tool and Framework in 2024.pdf
8 Best Automated Android App Testing Tool and Framework in 2024.pdf
kalichargn70th171

美洲杯赔率投注网【​网址​🎉3977·EE​🎉】
美洲杯赔率投注网【​网址​🎉3977·EE​🎉】美洲杯赔率投注网【​网址​🎉3977·EE​🎉】
美洲杯赔率投注网【​网址​🎉3977·EE​🎉】
widenerjobeyrl638

Kubernetes at Scale: Going Multi-Cluster with Istio
Kubernetes at Scale:  Going Multi-Cluster  with IstioKubernetes at Scale:  Going Multi-Cluster  with Istio
Kubernetes at Scale: Going Multi-Cluster with Istio
Severalnines

A Comprehensive Guide on Implementing Real-World Mobile Testing Strategies fo...
A Comprehensive Guide on Implementing Real-World Mobile Testing Strategies fo...A Comprehensive Guide on Implementing Real-World Mobile Testing Strategies fo...
A Comprehensive Guide on Implementing Real-World Mobile Testing Strategies fo...
kalichargn70th171

TMU毕业证书精仿办理
TMU毕业证书精仿办理TMU毕业证书精仿办理
TMU毕业证书精仿办理
aeeva

Photoshop Tutorial for Beginners (2024 Edition)
Photoshop Tutorial for Beginners (2024 Edition)Photoshop Tutorial for Beginners (2024 Edition)
Photoshop Tutorial for Beginners (2024 Edition)
alowpalsadig

The Rising Future of CPaaS in the Middle East 2024
The Rising Future of CPaaS in the Middle East 2024The Rising Future of CPaaS in the Middle East 2024
The Rising Future of CPaaS in the Middle East 2024
Yara Milbes


Recently uploaded (20)

The Power of Visual Regression Testing_ Why It Is Critical for Enterprise App...
The Power of Visual Regression Testing_ Why It Is Critical for Enterprise App...The Power of Visual Regression Testing_ Why It Is Critical for Enterprise App...
The Power of Visual Regression Testing_ Why It Is Critical for Enterprise App...

Liberarsi dai framework con i Web Component.pptx
Liberarsi dai framework con i Web Component.pptxLiberarsi dai framework con i Web Component.pptx
Liberarsi dai framework con i Web Component.pptx

Unlock the Secrets to Effortless Video Creation with Invideo: Your Ultimate G...
Unlock the Secrets to Effortless Video Creation with Invideo: Your Ultimate G...Unlock the Secrets to Effortless Video Creation with Invideo: Your Ultimate G...
Unlock the Secrets to Effortless Video Creation with Invideo: Your Ultimate G...

Assure Contact Center Experiences for Your Customers With ThousandEyes
Assure Contact Center Experiences for Your Customers With ThousandEyesAssure Contact Center Experiences for Your Customers With ThousandEyes
Assure Contact Center Experiences for Your Customers With ThousandEyes

Modelling Up - DDDEurope 2024 - Amsterdam
Modelling Up - DDDEurope 2024 - AmsterdamModelling Up - DDDEurope 2024 - Amsterdam
Modelling Up - DDDEurope 2024 - Amsterdam

一比一原版(USF毕业证)旧金山大学毕业证如何办理
一比一原版(USF毕业证)旧金山大学毕业证如何办理一比一原版(USF毕业证)旧金山大学毕业证如何办理
一比一原版(USF毕业证)旧金山大学毕业证如何办理

一比一原版(sdsu毕业证书)圣地亚哥州立大学毕业证如何办理
一比一原版(sdsu毕业证书)圣地亚哥州立大学毕业证如何办理一比一原版(sdsu毕业证书)圣地亚哥州立大学毕业证如何办理
一比一原版(sdsu毕业证书)圣地亚哥州立大学毕业证如何办理

Enhanced Screen Flows UI/UX using SLDS with Tom Kitt
Enhanced Screen Flows UI/UX using SLDS with Tom KittEnhanced Screen Flows UI/UX using SLDS with Tom Kitt
Enhanced Screen Flows UI/UX using SLDS with Tom Kitt

Transforming Product Development using OnePlan To Boost Efficiency and Innova...
Transforming Product Development using OnePlan To Boost Efficiency and Innova...Transforming Product Development using OnePlan To Boost Efficiency and Innova...
Transforming Product Development using OnePlan To Boost Efficiency and Innova...

14 th Edition of International conference on computer vision
14 th Edition of International conference on computer vision14 th Edition of International conference on computer vision
14 th Edition of International conference on computer vision

Superpower Your Apache Kafka Applications Development with Complementary Open...
Superpower Your Apache Kafka Applications Development with Complementary Open...Superpower Your Apache Kafka Applications Development with Complementary Open...
Superpower Your Apache Kafka Applications Development with Complementary Open...

Boost Your Savings with These Money Management Apps
Boost Your Savings with These Money Management AppsBoost Your Savings with These Money Management Apps
Boost Your Savings with These Money Management Apps

WMF 2024 - Unlocking the Future of Data Powering Next-Gen AI with Vector Data...
WMF 2024 - Unlocking the Future of Data Powering Next-Gen AI with Vector Data...WMF 2024 - Unlocking the Future of Data Powering Next-Gen AI with Vector Data...
WMF 2024 - Unlocking the Future of Data Powering Next-Gen AI with Vector Data...

8 Best Automated Android App Testing Tool and Framework in 2024.pdf
8 Best Automated Android App Testing Tool and Framework in 2024.pdf8 Best Automated Android App Testing Tool and Framework in 2024.pdf
8 Best Automated Android App Testing Tool and Framework in 2024.pdf

美洲杯赔率投注网【​网址​🎉3977·EE​🎉】
美洲杯赔率投注网【​网址​🎉3977·EE​🎉】美洲杯赔率投注网【​网址​🎉3977·EE​🎉】
美洲杯赔率投注网【​网址​🎉3977·EE​🎉】

Kubernetes at Scale: Going Multi-Cluster with Istio
Kubernetes at Scale:  Going Multi-Cluster  with IstioKubernetes at Scale:  Going Multi-Cluster  with Istio
Kubernetes at Scale: Going Multi-Cluster with Istio

A Comprehensive Guide on Implementing Real-World Mobile Testing Strategies fo...
A Comprehensive Guide on Implementing Real-World Mobile Testing Strategies fo...A Comprehensive Guide on Implementing Real-World Mobile Testing Strategies fo...
A Comprehensive Guide on Implementing Real-World Mobile Testing Strategies fo...

TMU毕业证书精仿办理
TMU毕业证书精仿办理TMU毕业证书精仿办理
TMU毕业证书精仿办理

Photoshop Tutorial for Beginners (2024 Edition)
Photoshop Tutorial for Beginners (2024 Edition)Photoshop Tutorial for Beginners (2024 Edition)
Photoshop Tutorial for Beginners (2024 Edition)

The Rising Future of CPaaS in the Middle East 2024
The Rising Future of CPaaS in the Middle East 2024The Rising Future of CPaaS in the Middle East 2024
The Rising Future of CPaaS in the Middle East 2024


ConwaysLawRevisited

  • 1. SOZIALE SYSTEME MICROSERVICES AGILITÄT CONWAYS LAW REVISITEDJens Himmelreich - XPDays 2015
  • 3. HOW DO COMMITTEES INVENT?by MELVIN E. CONWAY That kind of intellectual activity which creates a useful whole from its diverse parts may be called the design of a system. Whether the particular activity is the creation of specifica- tions for a major weapon system, the formation of a rec- ommendation to meet a social challenge, or the program- ming of a computer, the general activity is largely the same. Typically, the objective of a design organization is the creation and assembly of a document containing a coherent- ly structured body of information. We may name this information the system design. It is typically produced for a sponsor who usually desires to carry out some activity guided by the system design. For example, a public official may wish to propose legislation to avert a recurrence of a recent disaster, so he appoints a team to explain the catas- trophe. Or a manufacturer needs a new product and desig- nates a product planning activity to specify what should be introduced. The design organization may or may not be involved in the construction of the system it designs. Frequently, in public affairs, there are policies which discourage a group's acting upon its own recommendations, whereas, in private industry, quite the opposite situation often prevails. It seems reasonable to suppose that the knowledge that one will have to carry out one's own recommendations or that this task will fall to others, probably affects some design choices which the individual designer is cailed upon to make. Most design activity requires continually making choices. Many of these choices may be more than design decisions; they may also be personal decisions the designer makes about his own future. As we shall see later, the incentives which exist in a conventional management en- vironment can motivate choices which subvert the intent of the sponsor.! stages of design The initial stages .of a design effort are concerned more with structuring of the design activity than with the system itsel£.2 The full-blown design activity cannot proceed until certain preliminary milestones are passed. These include: 1. Understanding of the boun9aries, both on the design activity and on the system to be designed, placed by the sponsor and by the worltl's realities. 2. Achievement of a preliminary notion of the system's organization so that design task groups can be mean- ingfully assigned. We shall see in detail later that the very act of organiz- 1 A related, but much more comprehensive discussion of the behavior of system-designing organizations is found in John Kenneth Galbraith's, The New Industrial State (Boston, Houghton Mifflin, 1967). See especially Chapter VI, "The Technostructur<!." 2 For o discussion of the problems which may arise when the design activity takes the form of o project in a functional environment, see C. J. Middleton, "How to Set Up o Project Organization," Harvard Business Review, March-April, 1967, p. 73. 28 design organization criteria ing a design team means that certain design decisions have already been made, explicitly or otherwise. Given any design team organization, there is a class of design alterna- tives which cannot be effectively pursued by such an organization because the necessary communication paths do not exist. Therefore, there is no such thing as a design group which is both organized and unbiased. Once the organization of the design team is chosen, it is possible to delegate activities to the subgroups of the organization. Every time a delegation is made and some- body's scope of inquiry is narrowed, the class of design alternatives which can be effectively pursued is also nar- rowed. Once scopes of activity are defined, a coordination prob- lem is created. Coordination among task groups, although it appears to lower the productivity of the individual in the small group, provides the only possibility that the separate task groups will be able to consolidate their efforts into a unified system design. Thus the life cycle of a system design effort proceeds through the following general stages: 1. Drawing of boundaries according to the ground rules. 2. Choice of a preliminary system concept. 3. Organization of the design activity and delegation of tasks according to that concept. 4. Coordination among delegated tasks. 5. Consolidation of subdesigns into a single design. It is possible that a given design activity will not pro- ceed straight through this list. It might conceivably reorga- nize upon discovery of a new, and obviously superior, design concept; but such an appearance of uncertainty is unflattering, and the very act of voluntarily abandoning a creation is painful and expensive. Of course, from the Dr. Conway is manager, pe- ripheral systems research, at Sperry Rand's Univac Div., where he is working on recog- nition of continuous speech. He has previously been a research associate at Case Western Re- serve Univ., and a software consultant. .He has an MS in physics from CaiTech and a PhD in math from Case. :C»ATAMATION
  • 4. HOW DO COMMITTEES INVENT?Melvin Conway - Datamation, April 1968
  • 5. ORGANIZATIONS WHICH DESIGN SYSTEMS ARE CONSTRAINED TO PRODUCE DESIGNS WHICH ARE COPIES OF THE COMMUNICATION STRUCTURES OF THESE ORGANIZATIONS. MELVIN CONWAY
  • 6. IF YOU HAVE FOUR GROUPS WORKING ON A COMPILER,
 YOU'LL GET
 A 4-PASS COMPILER. HACKERDICTIONARY
  • 7.
  • 10. ?
  • 11. A B C
  • 12. A B C
  • 17. ORGANISATIONist eine Hypothese für die DOMÄNE
  • 20. GIVEN ANY DESIGN TEAM ORGANIZATION, THERE IS A CLASS OF DESIGN ALTERNATIVES WHICH CANNOT BE EFFECTIVLEY PURSUED BY SUCH AN ORGANIZATION … MELVIN CONWAY
  • 21. BECAUSE THE DESIGN WHICH OCCURS FIRST IS ALMOST NEVER THE BEST POSSIBLE … THEREFORE, FLEXIBILITY OF ORGANIZATION IS IMPORTANT TO EFFECTIVE DESIGN. MELVIN CONWAY
  • 24. Copyright © 2007, 2008, 2011 by Alan MacCormack, John Rusnak, and Carliss Baldwin Working papers are in draft form. This working paper is distributed for purposes of comment and discussion only. It may not be reproduced without permission of the copyright holder. Copies of working papers are available from the author. Exploring the Duality between Product and Organizational Architectures: A Test of the “Mirroring” Hypothesis Alan MacCormack John Rusnak Carliss Baldwin Working Paper 08-039
  • 25. EXPLORING THE DUALITY BETWEEN
 PRODUCT AND ORGANIZATIONAL ARCHITECTURES:
 A TEST OF THE MIRRORING HYPOTHESISAlan McCormick, John Rusnak, Carliss Baldwin Harvard Business School Working Paper, 27 Mar 2008
  • 26. MIRRORING HYPOTHESES „Loosely-coupled organizations
 will tend to develop products with more modular architecture
 than tightly-coupled organizations.“
  • 27. MIRRORING HYPOTHESES „Loosely-coupled organizations
 will tend to develop products with more modular architecture
 than tightly-coupled organizations.“
  • 28. MIRRORING HYPOTHESES „Loosely-coupled organizations
 will tend to develop products with more modular architecture
 than tightly-coupled organizations.“
  • 29. MIRRORING HYPOTHESES „Loosely-coupled organizations
 will tend to develop products with more modular architecture
 than tightly-coupled organizations.“
  • 30. MIRRORING HYPOTHESES „Loosely-coupled organizations
 will tend to develop products with more modular architecture
 than tightly-coupled organizations.“
  • 32. GNUCASH MYBOOKS ABIWORD STARWRITER GNUMERIC STARCALC LINUX 2.1.32 SOLARIS LINUX 2.6.8 XNU MYSQL BERKELEY DB 7,74% 47,14% 8,25% 41,77% 23,62% 54,31% 7,18% 22,59% 7,21% 24,83% 11,3% 43,23%
  • 33. IN ALL PAIRS WE EXAMINE, THE LOOSELY-COUPLED ORGANIZATION DEVELOPS A PRODUCT WITH A MORE MODULAR DESIGN THAN THAT OF THE TIGHTLY-COUPLED ORGANIZATION. MACCORMACK, RUSNACK, BALDWIN
  • 35. THE INFLUENCE OF ORGANIZATIONAL STRUCTURE ON SOFTWARE QUALITY: AN EMPIRICAL CASE STUDY Nachiappan Nagappan Microsoft Research Redmond, WA, USA nachin@microsoft.com Brendan Murphy Microsoft Research Cambridge, UK bmurphy@microsoft.com Victor R. Basili University of Maryland College Park, MD, USA basili@cs.umd.edu ABSTRACT Often software systems are developed by organizations consisting of many teams of individuals working together. Brooks states in the Mythical Man Month book that product quality is strongly affected by organization structure. Unfortunately there has been little empirical evidence to date to substantiate this assertion. In this paper we present a metric scheme to quantify organizational complexity, in relation to the product development process to identify if the metrics impact failure-proneness. In our case study, the organizational metrics when applied to data from Windows Vista were statistically significant predictors of failure-proneness. The precision and recall measures for identifying failure-prone binaries, using the organizational metrics, was significantly higher than using traditional metrics like churn, complexity, coverage, dependencies, and pre-release bug measures that have been used to date to predict failure-proneness. Our results provide empirical evidence that the organizational metrics are related to, and are effective predictors of failure-proneness. Categories and Subject Descriptors D.2.8 [Software Engineering]: Software Metrics – complexity measures, performance measures, process metrics, product metrics. General Terms Measurement, Reliability, Human Factors. Keywords Organizational structure, Failures, Code churn, People, Empirical Studies. 1. INTRODUCTION Software engineering is a complex engineering activity. It involves interactions between people, processes, and tools to develop a complete product. In practice, commercial software development is performed by teams consisting of a number of individuals ranging from the tens to the thousands. Often these people work via an organizational structure reporting to a manager or set of managers. The intersection of people [9], processes [29] and organization [33] and the area of identifying problem prone components early in the development process using software metrics (e.g. [13, 24, 28, 30]) has been studied extensively in recent years. Early indicators of software quality are beneficial for software engineers and managers in determining the reliability of the system, estimating and prioritizing work items, focusing on areas that require more testing, inspections and in general identifying “problem-spots” to manage for unanticipated situations. Often such estimates are obtained from measures like code churn, code complexity, code coverage, code dependencies, etc. But these studies often ignore one of the most influential factors in software development, specifically “people and organizational structure”. This interesting fact serves as our main motivation to understand the intersection between organizational structure and software quality: How does organizational complexity influence quality? Can we identify measures of the organizational structure? How well do they do at predicting quality, e.g., do they do a better job of identifying problem components than earlier used metrics? Conway’s Law states that “organizations that design systems are constrained to produce systems which are copies of the communication structures of these organizations.” [8]. Similarly, Fred Brooks argues in the Mythical Man Month [6] that the product quality is strongly affected by org structure. With the advent of global software development where teams are distributed across the world the impact of organization structure on Conway’s law [15] and its implications on quality is significant. To the best of our knowledge there has been little or no empirical evidence regarding the relationship/association between organizational structure and direct measures of software quality like failures. In this paper we investigate this relationship between organizational structure and software quality by proposing a set of eight measures that quantify organizational complexity. These eight measures provide a balanced view of organizational complexity from the code viewpoint. For the organizational metrics, we try to capture issues such as organizational distance of
  • 36. THE INFLUENCE OF ORGANISATIONAL STRUCTURE ON SOFTWARE QUALITY:
 AN EMPIRICAL CASE STUDYNachiappan Nagappan, Brendon Murphy, Victor R. Basili Microsoft Research TechReport, January 2008
  • 37. IN THIS PAPER WE PRESENT A METRIC SCHEME TO QUANTIFY ORGANIZATIONAL COMPLEXITY, IN RELATION TO THE PRODUCT DEVELOPMENT PROCESS TO IDENTIFY IF THE METRICS IMPACT FAILURE-PRONENESS. NAGAPPAN, MURPHY, BASILI
  • 38. ORGANIZATIONAL STRUCTURE CODE CHURN CODE COMPLEXITY DEPENDENCIES CODE COVERAGE PRE-RELEASE BUGS 86,2% 78,6% 79,3% 74,4% 83,3% 73,8% 84,0% 79,9% 66,0% 69,9% 54,4% 62,9% PRECISION RECALL
  • 39. THE PRECISION AND RECALL MEASURES FOR IDENTIFYING FAILURE-PRONE BINARIES, USING THE ORGANIZATIONAL METRICS, WAS SIGNIFICANTLY HIGHER THAN USING TRADITIONAL METRICS. NAGAPPAN, MURPHY, BASILI
  • 41. 1
  • 42. CD
  • 52. 2
  • 53. SHOP
  • 60. 3
  • 61. SHOP
  • 62. SHOP
  • 73. DWAWII SH FRONT OP RECO TR SEA NEWS SEO ATTR BILD PROD FEATURE (BILD) FEATURE (PREIS)
  • 77. KUNDE PRODUKT BILD SUCHE WARENKORB NAVIGATION EMPFEHLUNG DETAILSEITE MEINKONTO REDUNDANZ
  • 83. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN KUNDENORIENTIERUNG
  • 84. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN TIME-TO-MARKET
  • 85. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
  • 86. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN
  • 87. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN DB DB DB DB DB HTML HTML HTML HTML HTML A B C A B C A B C A B C A B C
  • 88. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN DB DB DB DB DB HTML HTML HTML HTML HTML VARIANTE PRODUKT
 KNOTEN PRODUKT WARENKORB
 POSTITION ARTIKEL
  • 89. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN DB DB DB DB DB HTML HTML HTML HTML HTML A B C A B C A B C A B C A B C HTML DETAIL HTML NAVIGATION HTML EMPFEHLUNG HTML MINIWARENKORB HTML ANREDE STYLEGUIDE
  • 90. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN DB DB DB DB DB HTML HTML HTML HTML HTML A B C A B C A B C A B C A B C HTMLHTML HTML HTML HTML RWD APP INSTORE
  • 92. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN FACHLICHE ISOLATION Bounded Context
  • 93. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN ORGANISATORISCHE ISOLATION Separates Scrumteam
  • 94. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN TECHNISCHE ISOLATION Keine synchrone Kopplung
  • 96. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN REST-INTEGRATION smart endpoints and dump pipes
  • 98. SUCHEN ENTDECKEN BEWERTEN KAUFEN STEUERN PAGER PAGER PAGER PAGER PAGER BETRIEBLICHE ISOLATION You Built it - you run it!
  • 102. ORGANISATION SYSTEM Wie spiegelt sich meine Organisation im technischen System?
  • 103. DOMÄNE ORGANISATION Welche Hypothese über die Domäne stellt meine Organisation dar?
  • 105. QUELLEN HOW DO COMMITTEES INVENT? http://www.melconway.com/Home/pdf/committees.pdf EXPLORING THE DUALITY BETWEEN PRODUCT AND ORGANIZATIONAL ARCHITECTURES:
 A TEST OF THE MIRRORING HYPOTHESIS http://www.hbs.edu/research/pdf/08-039.pdf THE INFLUENCE OF ORGANISATIONAL STRUCTURE ON SOFTWARE QUALITY:
 AN EMPIRICAL CASE STUDY http://research.microsoft.com/pubs/70535/tr-2008-11.pdf The colors and fonts are inspired by Phil Hawksworth http://hawksworx.com/ THIS WORK IS LICENSED UNDER A CREATIVE COMMONS ATTRIBUTION-NONCOMMERCIAL-NODERIVS 3.0 UNPORTED LICENSE
