2. Course outline
The course contains three modules to cover your course curriculum.
Module 1: 1-5 lectures, each of 45 minutes
• Introduction to power system structure
• Basic principle of polyphaser power generation
• Circuit analysis for YY, YΔ, ΔΔ connection with balanced load
• Circuit analysis for unbalanced 3 phase system
• Power calculation for 3 phase system
• Problem solving
• Applications
• Class test/quizzes/assignment
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
2
3. Module 2: 6-9 lecturs
• Analysis of two port network
• Determination of Z parameters
• Y parameters
• h parameters
• Problem solving for each parameter type
• Applications
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
3
4. Module 3: 10-16 lectures
• Intro to electric filters and its classifications
• Understanding attenuation constant, cut off frequency, pass band and
stop band.
• Symmetric network and characteristic impedance
• Design principle of passive T section low pass filter
• Design principle of π section filter
• To understand M-derived filter
• Problem solving
• Applications
• Class test/quizzes/assignment
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
4
5. Reference sources
1. Alexander C. K. and Sadiku M. N. O, “Fundamental of Electric
Circuits”
2. Online resources if necessary.
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
5
6. • Introduction to power system
• Introduction to poly phase circuits
• Why 3 phase circuits
• Balanced Y source and Δ source
• Principle of 3 phase power generation
• Balanced 3 phase load Y and Δ
• Line voltage and phase voltages for YY connection
• Line current and phase currents for YY connection
4/10/2024
Part 1, even and part 2, Batch 2, odd Exam. 2020,
Department of EEE, R.U.
6
Module 1:
8. Poly phase circuits
Circuits or systems where more one source operates at same frequency
but maintains different phases then the circuits are said to be poly
phase circuits.
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
8
9. Principle of 3 phase power generation
4/10/2024
Part 1 even and p 2 odd Batch 2, Even Exam. 2029,
Department of EEE, R.U.
9
10. Y and Δ source
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
10
12. Y source
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
12
_
_
_
+
+
+
n
a
b
c
c
b
a
V0
V-120
V-240
Wye Connected
Source
14. YY system
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
14
Zl
Zl
Zl
ZL
ZL ZL
a
n
b
c
A
B C
N
(Alexander C.K and Sadiku M. N. O, chapter 12, pp509
15. Part 4 Batch 2, Even Semester Exam. 2019,
Department of EEE, R.U.
15
In
Ic
Ia
Ib
In
𝑣𝑎𝑏 = 𝑣𝑎𝑛 − 𝑣𝑛𝑏 = 𝑣𝑎𝑛 + 𝑣𝑏𝑛
𝑣𝑎𝑏 = 𝑣𝑝∠0 − 𝑣𝑝∠ − 120
𝑣𝑎𝑏=𝑣𝑝(cos0+jsin0-cos120+jsin120)
𝑣𝑎𝑏 = 3𝑣𝑝∠30
16. (Alexander C.K and Sadiku M. N. O, chapter 12, pp509
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
16
_
_
_
+
+
+
n
a
b
c
c
b
a
V0
V-120
V-240
A
B C
Z Z
Z
IaA ICA
IBC
IAB
Z
V
Z
V
V
I
V
Z
I
V
AB
bn
an
AB
bn
AB
an
,
0
CA
p
ca
BC
p
bc
AB
p
ab
V
V
V
V
V
V
V
V
V
210
|
|
3
90
|
|
3
30
|
|
3 ,
17. Power in 3 phase balanced system
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
17
26. Comparisons of power loss between single and 3 phase systems
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
26
Show that 33% more loss in single phase system
27. Complex power, real power and apparent power
We have average power 𝑃 =
1
2
𝑉
𝑚𝐼𝑚 cos 𝜃𝑣 − 𝜃𝑖
28. Average power, apparent power and power factor
• 𝑃 =
1
2
𝑉
𝑚𝐼𝑚 cos 𝜃𝑣 − 𝜃𝑖 which is average power in ac circuit. This can also be
written 𝑃 = 𝑉
𝑟𝑚𝑠𝐼𝑟𝑚𝑠 cos 𝜃𝑣 − 𝜃𝑖 watt, where S=𝑉
𝑟𝑚𝑠𝐼𝑟𝑚𝑠 is known as
apparent power i.e. VA.
• The average power in the circuit is the useful power absorbed by the load.
• Power facto pf is the dimensionless parameter which is the ratio between the
average power and the apparent power, therefore
𝑝𝑓 =
𝑃
𝑆
= cos 𝜃𝑣 − 𝜃𝑖
• The pf is the cosine of the phase difference between voltage and current in a
circuit.
• If current leads the voltage then pf is leading otherwise lagging.
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
29
29. From previous lecture
𝑝 = 3𝑣𝑝𝑖𝑝cos(θ𝑣 − θ𝑖)
FOR Y load
P ?
For Delta load p ?
For single phase ?
31. 3 phase power continued
Therefore, per phase
By analogy to single phase we can write
Alternatively
𝑆 = 𝑃 + 𝑗𝑄
Where
Average/ real power 𝑃 = √3𝑉𝐿𝐼𝐿 cos 𝜃𝑣 − 𝜃𝑖
Reactive power Q or VAR = √3𝑉𝐿𝐼𝐿sin 𝜃𝑣 − 𝜃𝑖
Apparent power =√3𝑉𝐿𝐼𝐿
40. 4/10/2024 Part 1 even part 2 odd , 2020, Department of EEE, R.U. 41
PF improvement (continued)
41. LO and home work
• LO 1?
• LO 2?
• LO3?
• An inductive load operating with pf=0.75, input rms voltage 220volt,
average power P= 0.25kwatt. Draw power triangle and determine
required circuit component for improving pf to 0.95.
4/10/2024 Part 1 even part 2 odd , 2020, Department of EEE, R.U. 42
[1] Reference textbook: Alexandar and Sadiku, “ Fundamental of Electric Circuits”, 5ed. Mc Graw Hill.
42. • Intro to two port network
• Why two port analysis
• Learning impedance method for two port analysis
4/10/2024 Part 1 even part 2 odd , 2020, Department of EEE, R.U. 43
Objectives
43. 3/or 2 wattmeter method for balanced 3phase system[1]
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
44
44. 2 Wattmeter method for balanced YY connection
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
45
45. Considering Y load and abc sequence
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
46
)
1
.......(
2
1 P
P
PT
)
30
cos(
)
30
cos(
1
L
L
a
ab I
V
I
V
P
)
30
cos(
)
30
cos(
2
L
L
c
cb I
V
I
V
P
Putting the values of P1 and P2 in Eq. (1) and after manipulation it reduces to
cos
3
cos
3 p
p
L
L
T I
V
I
V
P
46. Similarly for P1-P2
4/10/2024
Part 4 Batch 2, Even Semester Exam. 2019, Department of EEE,
R.U.
47
)
(
3
sin
3 1
2 P
P
I
V
Q L
L
T
sin
1
2 L
LI
V
P
P
