This document provides information about ATI facilities and capabilities. It lists locations in Cudahy, WI, Portland, IN, Stalowa Wola, Poland, Irvine, CA, and Lebanon, KY. It also outlines markets served including aerospace, transportation, oil & gas, construction & mining, and defense. The document describes forging, machining, engineering, heat treatment and testing equipment and capabilities available across multiple locations.

1. © 2014 ATI. All Rights Reserved.

2. 2 © ATI 2014. All Rights Reserved.
Cudahy, WI
Portland, IN
Stalowa Wola, Poland
Irvine, CA
Lebanon, KY
Irvine, CA
Stalowa Wola, Poland
East Hartford, CT
Coon Valley, WI
Cudahy, WI
Lebanon, KY

3. © ATI 2014. All Rights Reserved.3
Aerospace
Aerospace
Transportation
Oil & Gas
Construction & Mining
KEY MARKETS
Defense
Agriculture

4. © ATI 2014. All Rights Reserved.4
Cudahy, WI
FACILITIES
Stalowa Wola, Poland
Portland, IN Lebanon, KY

5. © ATI 2014. All Rights Reserved.5
• Isothermal Presses
– 4,500t, 10,000t, 12,500t
– Parts up to 45” Ø x 2000 lbs
• Hot-Die Presses
– 1,500t, 6,000t, 15,000t
– Parts up to 36” Ø x 800 lbs
– Very high hot-die capabilities
• Hydraulic Presses
– 2,500t to 15,000t
• Screw Presses
– 1,600t to 2,500t
• Mechanical Presses
– 1,000t to 8,000t
FORGING EQUIPMENT

6. © ATI 2014. All Rights Reserved.6
• Counterblow Hammers
– Four units
– Two facilities
(Cudahy & Stalowa Wola)
– 50,000 to 125,000 MKG
– Parts up to 56,000 lbs
• Drop Hammers
– 2,000 to 50,000 lbs
– Three locations
(Cudahy, Portland &
Stalowa Wola)
• Upsetters
– 3” – 8” Upsetters
– Parts up to 10” Ø and 200 lbs
(Portland)
FORGING EQUIPMENT

7. © ATI 2014. All Rights Reserved.7
Milling Equipment
(3) 60” Niigata HN80 5-Axis CNC Machining Centers
(3) 42” Niigata HN63C 5-Axis CNC Machining Centers
(2) 39” Makino A-61 Axis Horizontal Machining Centers
(1) Deckel Maho MMC 160U Duo Block 5- Axis vertical & horizontal
(3) Akira-Seiki HV2100 Machining Center; 4 Axis, 50 Taper
(1) Kitamura My center HX 630i Pallet loader
Inspection
(2) Brown & Sharpe XCEL 12-20-10 CMM
(1) Brown & Sharpe Global 12-30-10 CMM
(1) Brown & Sharpe MicroXcel CMM
(1) IMS Premier 15-15-10 DCC CMM
Honing Equipment
(1) Sunnen 1800 Honing Machines
MACHINING EQUIPMENT
Turning Equipment
(3) 60” Toshiba TUE 15 CNC Lathes
(2) 57” Olympia V40 CNC Lathes, Fanuc 181 controls
(2) 42” Mazak Power Master Chuckers
(2) Johnsford ST60BH CNC Turning Center 38” swing
(2) Johnsford SL 500 23” swing, Olympia V40 CNC Lathes
Engineering
(7) Unigraphics NX7.5(1) Master Cam X - MR2
CATIA Version 5
(1) PGP Encryption software
(1) VERICUT - Process verification software

8. © ATI 2014. All Rights Reserved.8
• Die Manufacturing
• Computerized Heat Treatment
– Oil, Water, Fan Air Quench
• Super cooler™ Heat Treatment
– For Jet Engine Discs
• Drop Bottom Aluminum HT
– 286” Ø by 86” H for AL Rings
• CNC Machining
– Cudahy, Irvine, Lebanon, Stalowa Wola
• Destructive Testing
• Sonic
– Cudahy, Irvine, Poland
• Etch, MPI & FPI
– Cudahy, Lebanon, Portland, Stalowa Wola
SUPPORT EQUIPMENT
