The AFCEA demonstration plan outlines several wireless technologies that will be showcased at a technet demonstration in January 2007, including a WiMAX point-to-point link between the convention center and Point Loma supporting video and IP telephony, a secure 802.11 mesh network on the convention center floor, and Ethernet over optical capability. It also describes demonstrating wireless convergence using private 802.11 and GSM networks and introducing a converged desktop solution from Nortel and Microsoft.

1. AFCEA Demonstration Plan
January 2007
CELL-TEL
GOVERNMENT SYSTEMS, INC.

2. TechNet Demonstration
> Working with SSC-San Diego, a WiMAX point-to-point link will be
operational between the Convention Center and Point Loma,
supporting both live Video and IP Telephony traffic
> Secure (FIPS 140-2) 802.11 mesh network will be active on the floor
of the Convention Center, providing distribution off the WiMAX link
> Ethernet over Optical capability will be operational to show the way
ahead for BLII networks.
> Wireless convergence will be demonstrated using a private
802.11a/b/g and GSM mobile telephony network.
> Converged desktop solution will be introduced (Nortel/Microsoft
collaboration).
2

3. Secure Wireless Demonstration
Interconnected PicoCells Using WiMAX Technology
>>Secure Wireless Mesh Technology
Secure Wireless Mesh Technology
• • Auto Discovery
Auto Discovery
• • Auto Configuration
Auto Configuration
• • Mesh Topology
Mesh Topology
• • Wireless Interconnection
Wireless Interconnection
• • Rapid Deployment
Rapid Deployment
• • Network Security
Network Security
5 Miles
5 Miles
Direct Line of Sight
Direct Line of Sight
3

4. Network Diagram
Convention
Center
WiMAX
Point Loma
802.11
MCS Client NGS Booth GSM PDA
PDA
WLAN AP
GSM Pico
FORTRESS
WLAN AP w/ CS1000
GSM BTS
& BS5520
SECTRA
MCS Client
Blackbox
MCS Client Booth Fortress
VoIP
Booth
4
