Abnormal moving objects detection is an essential issue for video surveillance. In order to judge whether the behavior of objects is abnormal, such as pedestrians walk back and forth, walk across the street, or scooters drive the wrong way, the main method is through computer vision technique to analyze objects as pedestrians, cars, and so on in video. Traditional abnormal moving objects detection aims at particular circumstances or requirement to predefine particular detection rules which the application of abnormal moving objects detection is restricted. Besides, if numerous abnormal moving objects are detected at the same time, surveillance system is overloaded with operation. Owing to this reason, in this paper, we expect to design a set of learning model which does not predefine abnormal rules and can detect a variety of abnormal moving objects automatically in different environments.
To achieve the above goal, the first thing is to detect the moving objects in video. The proposed method in this paper utilizes Gaussian Mixture Model (GMM) to detect foreground objects and remove shadows of objects by shadow removal. Then, adoptive mean shift algorithm with Kalman filter is proposed to track these moving objects. Finally, Kalman filter is used to smooth trajectory.
After collecting the trajectories of moving objects, abnormal moving object detection process proceeds. At first, for this trajectory information, take advantage of Self-Organizing Incremental Neural Network (SOINN) to learn and build a normal trajectory model which is a foundation to determine whether follow-up moving objects are abnormal. The average learning time is 7 to 55 seconds.
The experiment monitors and analyzes different circumstances, such as School campus, roads, and one-way street. The system based on the proposed method can detect abnormal moving objects with the accuracy 100% in school campus, 98.3% in roads, and 98.8% in one-way street. The overall execution time is short and about 0.033 to 0.067 seconds, and it can be executed in real-time.
