ULTRAFRESH New modular kitchen Presentation...

2. SHAPES OF KITCHEN

3. STRAIGHT KITCHEN

4. L SHAPE KITCHEN

5. U SHAPE KITCHEN

6. G SHAPE KITCHEN

7. PARALLEL KITCHEN

8. ISLAND KITCHEN

9. PENINSULA KITCHEN
Peninsula

10. TYPES OF CARCASS & SHUTTERS
 Ultra Classic (Mild Steel)
 Ultra Royal (Marine Ply)
 Ultra Modern (MDF)

11. Mild Steel also referred to as soft steel is a type of steel that contains
2 % percent carbon or less..
 Long life
 Very strong and flexible
 Eco-Friendly
 No odor
 Easy to clean
 Rust free
 Termite Proof
Ultra Classic (Mild Steel)

12. Plywood is a sheet material manufactured from thin layers or "plies" of
wood veneer that are glued together with adjacent layers having their
wood grain rotated up to 90 degrees to one another.
 Very strong
 Water Resistant
 Impact Resistance
 Good Surface Finish
 Weather Proof
 Durable.
Ultra Royal (Marine Ply)

13. Medium-density fiberboard (MDF) is an engineered wood product made
by breaking down hardwood or softwood residuals into wood fibers, often in
a deliberator, combining it with wax and a resin binder, and forming panels
by applying high temperature and pressure
 Excellent substrate or veneers.
 Economical
 Consistent in strength and
structure
 Flexible and Shapes well.
 Stable dimensions (won't
expand or contract like wood)
 Easy to finish (i.e. paint)
 lot of Design possible on MDF
Ultra Modern (MDF)

14. FINISH OF THE SHUTTERS
 Ultra Velvet (Acrylic Range)
 Ultra Glow (High Gloss / Designer Range)
 Ultra Satin (MS Painted)
 Ultra Glitter (High Gloss 4 Side Edge Bended)
 Ultra Marble (Standard Range)
 Ultra Pearl (MS Powder Coated)
 Ultra Matt (Matt 4 Side Edge Bended)

15. ULTRA VELVET (ACRYLIC RANGE)
High gloss Acrylic finishes for cabinet fronts are
becoming a popular choice with flat, reflective, scratch
resistant finish without the weight or expense of glass.
Features:
 Seamless finish
 Contemporary design
 Eco-friendly
 Mirror effect
 Vivid colors
 Scratch resistance
 Corrosion resistance
 Easy to clean
 Waterproof

16. ULTRA GLOW (HIGH GLOSS / DESIGNER RANGE)
Features:
 Multi-layered painted
finish
 Enhanced resistance to
scratches, chemical
agents and humidity
 Smooth surface will not
promote growth of germs
 Helps create hygienic
kitchen
 Good heat resistance
High gloss PVC foils gives superior and protective finish. Very natural and soft touch which is
very well comparable, there by giving a natural look and not a plastic appearance to the
shutters

17. ULTRA SATIN (MS PAINTED)
Features:
 Eco-friendly
 Rust free
 Temperature resistant
 Does not affect flavor of
foods.
 Easy to clean
 100% Termite Proof
 Long life
MS Painted Shutters come in nine different colors where a thin film of required color is pasted on
the Shutters.

18. ULTRA GLITTER (HIGH GLOSS 4 SIDE EDGE BENDED)
High Gloss 4 Side Edge Bended is about the most
durable laminate available. Perfect Composite
Shutter with 1mm HPL presses on 16mm waterproof
plywood on high pressure hot press.
Features:
 Impeccable finish
 Dirt resistance
 Weather resistance
 Elegant design
 Lustrous shine
 Stylish look
Array color available.

19. ULTRA MARBLE (STANDARD RANGE)
Standard range matt finish PVC foils gives superior and protective finish. Very natural and soft
touch which is very well comparable, there by giving a natural look and not a plastic appearance to
the shutters
Features:
 Impeccable finish
 Easy to Clean
 Design possible on shutters
 Stylish look
 Enhanced resistance to scratches,
chemical agents and humidity
 Smooth surface will not promote
growth of germs
 Helps create hygienic kitchen
 Good heat resistance

20. ULTRA PEARL (MS POWDER COATED)
Features
 Eco-friendly
 Rust free
 Temperature resistant
 Does not affect flavor of foods.
 Easy to clean
 100% Termite proof
 Long life
 Available in 4 Colors ( Red, Ivory,
Chocolate And Black.
Powder coating is the process of applying a dry powdered paint
compound made of pigments, specialized resins and fillers that melt
and fuse together during the curing process to form a painted finish.
The solid powder particles are electrostaticaly charged when exiting
the low-velocity air powered spray gun. This electrostatic charge
attracts paint particles to the work surface and holds them during the
high temperature curing process which can exceed 350 degrees.

21. ULTRA MATT (MATT 4 SIDE EDGE BENDED)
Shutter will be made with Water Proof ply on that Laminated, with 4 Sides Edge band. The
laminations will be applied by the 50ton hydraulic pressure, so durability is assured. Peeling off
problem will not be there. The Edge bands will be applied with the high temperature rollers. So,
easy to maintain.
Features: -
Elegant design
Stylish look
Durability
Free from Peeling off
 Impeccable finish
 Dirt resistance
 Weather resistance
Array color available

22. ACCESSORIES
 Category A
 Category B
 Category C

23. ACCESSORIES
 Category A
Innotech With Gallery Innotech With Gallery

24.  Innotech With Orga Flag  Innotech With Orga Wings
ACCESSORIES
 Category A

25. Innotech Plus Cutlery TrayInnotech Orga Tray Exclusive
ACCESSORIES
 Category A

26. Orga Store Basic cross wise railingOrga Flex Pre assembled under-
sink drawer
ACCESSORIES
 Category A

27. Orga Store200 OrgaTray 800
ACCESSORIES
 Category A

28. ACCESSORIES
 Category A
OrgaTray Plastic

29. S Carrousal Wicker Baskets
ACCESSORIES
 Category A

30. ACCESSORIES
 Category B
Thali Basket Grain Trolly

31. ACCESSORIES
 Category B
Partition Basket Cups & Saucer basket

32. ACCESSORIES
 Category B
MechanismPlate try

33. ACCESSORIES
 Category B
Multipurpose cutlery Basket
Adjustable Box Cutlery
Aluminum Composite
Board Cutlery Basket

34. ACCESSORIES
 Category B
Large Utensils Basket
Multipurpose Basket
Sheet Cutlery Basket

35. ACCESSORIES
 Category B
Large Utensils Basket
Multipurpose Basket
Sheet Cutlery Basket

36. ACCESSORIES
 Category B

37. Universal Magic Corner
ACCESSORIES
 Category B

38. Detergent Pullout Dish Rack
ACCESSORIES
 Category B

39. ACCESSORIES
 Category C
Plain Basket Cutlery Basket
Partition Basket Cup & Saucer Basket

40. ACCESSORIES
 Category C
Bottle Basket Large Utensils Basket
M S Partition Drawer M S Plain Drawer

41. ACCESSORIES
 Category C
Perforated Cutlery Basket Plate Rack
Adjustable Perforated Box Cutlery Basket Vegetable Basket

42. ACCESSORIES
 Category C
Plate Rack Thali Basket
Grain Trolly Plate Try & Glass Try

43. ACCESSORIES
 Category C
Bottle Basket Detergent Pull out
Under the Sink Try M S Plain Drawer
Detergent Holder

44. ACCESSORIES
 Category C

45. ACCESSORIES
 Category C
Kitchen Keeper Detergent Pullout Triple Shelf Corner

46. HARDWARE REQUIRED
Soft Closing Channel (German)
Uplift Hinges
Soft Closing Hinge
 Category A

47. Hydraulic Gas Shocker
Soft Closing Channel (Indian)
Telescopic Channel (German)
HARDWARE REQUIRED
 Category B

48. Dampner
Blind Corner Hinge
HARDWARE REQUIRED
 Category B

49. Dampner
Blind Corner Hinge
HARDWARE REQUIRED
 Category C
Telescopic Channel

50. Light Set
Cabinet Leg
Skirting Clamp
HARDWARE REQUIRED

51. HANDLES
H Type In Built Handle Profile Handel

52. OTHER REQUIREMENTS

53. CORNICE
Cornice molding is placed on the top of
the upper cabinet in the kitchen.
A cornice is generally any horizontal
decorative molding that crowns furniture
element.

54. SKIRTING
Skirting is use to cover the lowest
part of the kitchen cabinet.
Its purpose is to cover the legs and
the uneven edge of flooring.
It gives uniform look to the kitchen

55. SIDE PANELS
These panels are primarily used as covers for Cabinet sides.
The main purpose is to install
side panels because it gives the cabinet more “uniform” look.
Cabinets will require a panel to cover the exposed sides.

56. VALANCE
An attractive detail
hanging over a chimney
that joined to wall
cabinets is called a
valance. This is simply a
panel that “joins” the
wall cabinets together
and covers the area
over the Chimney.
