Information For Learning  Object eXchange (ILOX) David Massart, EUN
Licensed under IMS LODE License <ul><li>Creative Commons Attribution-Share Alike 3.0 United States License </li></ul><ul><...
Disclaimer <ul><li>The work described in this presentation is partially supported by the European Community eContent plus ...
Outline <ul><li>Materialization </li></ul><ul><li>Functional Requirements for Bibliographic Records (FRBR) </li></ul><ul><...
<ul><li>An abstraction mechanism (conceptual modeling)  </li></ul><ul><li>The relationship between a class of categories (...
Materialization (cont.) <ul><li>Supports some sort of attribute-propagation mechanism </li></ul><ul><li>I.e., many attribu...
Functional Requirements for Bibliographic Records – FRBR [fɝbɚ]

FRBR Is an Example of Materialization

Learning Object Copies
FRBR and LOM <ul><li>Some LOM data elements are typical of one FRBR aspect of learning objects </li></ul><ul><li>Some LOM ...
FRBR and LOM
Describing LOs at Different FRBR Levels <ul><li>General Principle </li></ul><ul><li>Describing a learning object as a </li...
General Principle <ul><li>Describe each FRBR level with </li></ul><ul><ul><li>Optional Identifier </li></ul></ul><ul><ul><...
Describing an LO as a FRBR Work
Describing with Metadata
Work-Level Metadata <ul><li>Metadata elements typical of a work </li></ul><ul><li>LOM examples: </li></ul><ul><ul><li>Gene...
Description Facets <ul><li>Content Provider Metadata </li></ul><ul><li>Folksonomies </li></ul><ul><li>Translation </li></u...
License as a Facet <ul><li>Identifier: A URI (e.g.,  http://creativecommons.org/licenses/by-sa/2.0/be/ ) </li></ul><ul><li...
License Facet <ul><li>Can be  present at any FRBR-level </li></ul><ul><li>License applied to an object at one level </li><...
Describing an LO as a FRBR Expression
Expression-Level Metadata <ul><li>Metadata elements typical of an Expression </li></ul><ul><li>LOM examples: </li></ul><ul...
Describing an LO as a FRBR Manifestation
Manifestation Names & <Parameters> <ul><li>Preview (will require best practice) </li></ul><ul><li>Thumbnail  of <Mime Type...
Package in <format> <ul><li>Vocabulary:  http://imsglobal.org/vdex/imscp_terms_resource.xml </li></ul><ul><li>Note: Look a...
Manifestation-Level Metadata <ul><li>Metadata elements typical of a Manifestation </li></ul><ul><li>LOM examples: All the ...
Describing an LO as a FRBR Item
Item Location <ul><li>URI (resolvable location: e.g., a URL or a persistent identifier for  a copy of the LO - handle, DOI...
Item-Level Metadata <ul><li>Metadata elements typical of an Item </li></ul><ul><li>LOM example: Technical.location  </li><...
Digital Right Management @ LRE
Digital Right Management @ LRE
LRE DRM and Item Location <ul><li>How does the Requestor find the LRE DRM Service?  item.location.URI </li></ul><ul><li>Ho...
Metadata Description In Practice <ul><li>Best practice rather than strict rules </li></ul><ul><li>Selecting the right leve...
Selecting The Right Level <ul><li>Work: One result entry by learning object (LO): No immediate distinction between the LO ...
What Goes In A Description:   Context <ul><li>Harvesting: Full metadata record(s) attached to the selected level  </li></u...
What Goes In A Description: FRBR Level
What Goes In A Description: FRBR Level
What Goes In A Description: FRBR Level
What Goes In A Description: FRBR Level
What Goes In A Description: FRBR Level  (cont.) Selected Level /Description Work Expression Manifestation Item Work Work E...
What Goes In A Description:  Informational Needs
Handling LOM (instead of LOs) <ul><li>Work </li></ul><ul><ul><li>Meta-metadata.identifier </li></ul></ul><ul><ul><li>Meta-...
ILOX versus OAI-ORE <ul><li>OAI-ORE and ILOX are orthogonal </li></ul><ul><li>Conceptually,  </li></ul><ul><ul><li>OAI-ORE...
Kill (more than) Two Birds With One Stone <ul><li>ILOX is a conceptually clean solution for </li></ul><ul><li>Selecting fr...
