    NoSQL meetup July 2011 NoSQL meetup July 2011 Presentation Transcript

    • NoSQL meetup
      July 2011
      Real-Time processing with In-Memory-Data-Grid and NoSQL
      Shay Hassidim
      Deputy CTO
      GigaSpaces Inc.
      shay@gigaspaces.com
    • Agenda
      Slides – 30 min
      Live Demos – 45 min
      Q&A – 15 min
      2
    • Real-Time Processing Use Cases
      Risk – Calculation engines
      Call Center Management
      E-commerce – auction monitoring , inventory
      Gaming – Multi-user , on-line gaming
      On-line marketing – Improve conversion rate
      Weather reporting
      Traffic analysis
      Supply-Chain optimization
      Manufacturing - Quality management in
      Shipment & Delivery Monitoring
      Fraud Detection
      3
    • Note the Time dimension
      4
    • Data resolution & processing models
      5
    • Traditional Processing - RDBMS
      Scale-up Database
      Use traditional RDBMS
      Stored procedure
      Flash memory to reduce I/O
      Read-only replica
      Limitations
      Doesn’t scale on write
      Extremely expensive (HW + SW)
      6
    • Traditional Processing - CEP
      Process the data as it comes
      Maintain a small fraction of the data in-memory
      Pros:
      Low-latency
      Relatively low-cost
      Cons
      Hard to scale (Mostly limited to scale-up)
      Not agile - Queries must be pre-generated
      Fairly complex
      7
    • In-Memory Database
      Scale up
      Pros
      Scale both on write & read
      Fits the event-driven model (CEP style) , ad-hoc query model
      SQL
      Cons
      • Cost of memory vs. disk
      • Memory capacity is limited
      • SQL
      8
    • NoSQL DB
      Distributed database
      Hbase, Cassandra, MongoDB
      Pros
      Scale on write/read
      Elastic
      Cons
      High latency on Read (tunable)
      Consistency tradeoffs are hard
      Non-Transactional
      9
    • Hadoop Map/Reduce
      Distributed batch processing
      Pros
      Designed to process massive amount of data
      Mature
      Low cost
      Cons
      Not real-time
      New Programming Model
      HDFS must be carefully tuned to improve data locality
      10
    • So what’s the bottom line?
      One size fit all model doesn’t cut it..
      The solution has to be a combination of several technologies and patterns...
      11
    • About GigaSpaces XAP…
      MW
      • Application Platform
      • Java, .Net, C++
      • Real-Time processing
      Free Edition
      • All Functionality
      • Limited Capacity
      Open
      • Entire client side source code provided
      12
    • GigaSpaces
      GigaSpaces delivers software middleware that provides enterprises and ISVs with end-to-end application scalability and cloud-enablement for mission-critical applications for hundreds of tier-1 organizations worldwide.
      13
    • GigaSpaces XAP Components
      Java-.Net-C++
      Ruby-Groovy-Jython-Spring JPA-JMS JDBC
      Schema-Free
      Customize Application Management Rules & Workflows
      1 Clustering Model for all components
      Run entire application in-memory… transaction -safe
      In-Memory
      Data Grid
      Real-Time Automated Deployment
      Monitoring
      Management
      Virtualize All Middleware Components
      14
    • Other Solutions…
      App Server
      Weblogic , websphere, Jboss AS , Tomcat …
      Orchestration
      Cheff, Pupet, Rightscale, Nolio ..
      JMS
      AQ , MQ , Active MQ…
      CEP
      Esper , Aleri , StreamBase…
      Caching
      • Alachi Soft
      • IBM extreme scale
      • Microsoft Velocity
      • Oracle Coherence
      • JBoss Infinispan
      • ScaleOut Software
      • Terracotta-EHCache
      • Tibco ActiveSpaces
      • Vmware GemFire
      • Gridgain
      • hazelcast
      15
    • RT Processing with IMDG and NoSQL DB
      - In Memory Data Grid
      - RT Processing Grid
      • Light Event Processing
      • Map-reduce
      • Event-driven
      • Execute code with data
      • Transactional
      • Secured
      • Elastic
      Event
      Sources
      Write
      behind
      NoSQL DB
      • Low-cost storage
      • Write/Read scalability
      • Dynamic scaling
      • Raw Data and aggregated Data
      Analytics Application
      Generate Patterns
      16
    • Use Case
      Calculation Engine Design Patterns
      With XAP
      17
    • Main Features Used
      Data Partitioning: Transparent content-based data partitioning to evenly and intelligently distribute data across your data-grid cluster
      Querying: Sophisticated query engine with support for SQL and example based queries
      Indexing: Predefined and ad-hoc property indexing for blazing fast data access
      Write Behind: Asynchronous and reliable propagation of data to any external data source
      Locking Support: Locking and transaction isolation for robust and hassle-free data access
      Master-Worker Support: Intuitive and highly scalable master-worker implementation for distributing computation-intensive tasks
      Distributed Code Execution: Dynamic code shipment and map/reduce execution across the grid for optimized processing and data access
      Content Based Routing: Routing of events to relevant cluster members based on their content
      Workflow Support: Implement complex workflows using event propagation and sophisticated event filtering
      Admin API: Comprehensive and intuitive API for monitoring and controlling every aspect of your cluster and application
      18
    • Elastic Calculation Engine - Colocated Logic
      Step 2 - The Task reads all the Trade objects and performs the NPV calculation for each Task. Result sent back into the client for final aggregation
      Step 1 - The client sends calculation Task to each partition with the specific Trade IDs required.
      Step 3 - The Calculation Task searches for all Trades. Any missing Trades are loaded in a lazy manner from the DB in one bulk query.
      The Data-Grid and the calculations Grid scale together
      Step 4 - Intermediate results retrieved from each partition and reduced.
      19
    • Elastic Calculation Engine - Remote Logic
      Step 3 - The Calculation logic searches for all Trades. Any missing Trades are loaded in a lazy manner from the DB in one bulk query and written into the space to be reused later.
      Step 2 - Each Calculation engine consumes a different Request , processes it and writes the Result back into the space. Using local cache for reference data.
      Step 1 - The client sends calculation Requests to the space cluster.
      Scales on demand separately from the Data-Grid
      The Data Grid and the calculations Grid scale independently
      Step 4 - The client consumes all the calculation results and performs final aggregation.
      20
    • Demos
      Simple IMDG Operations
      IMDG write,read,execute…
      IMDG and NoSQL DB Integration
      Cassandra
      MongoDB
      Calculation Engine
      Small scale Demo
      Large scale Demo – on the Cloud
      21
    • 22
