Storage infrastructure using HBase behind LINE messages Presentation Transcript

  • 1. Storage infrastructure using HBase behind LINE messages NHN Japan Corp. LINE Server Task Force Shunsuke Nakamura @sunsuk7tp 13.1.21 Hadoop  Conference  Japan  2013  Winter 2
  • 2. To support ’s users, we have built message storage that is Large scale (tens of billion rows/day) Responsive (under 10 ms) High available (dual clusters)13.1.21 Hadoop  Conference  Japan  2013  Winter 3
  • 3. Outline •  About LINE•  LINE & Storage requirements•  What we achieved•  Today’s topics –  IDC online migration –  NN failover –  Stabilizing LINE message cluster•  Conclusion13.1.21 Hadoop  Conference  Japan  2013  Winter 4
  • 4. LINE - A global messenger powered by NHN Japan - Devices 5 different mobile platforms + Desktop support13.1.21 Hadoop  Conference  Japan  2013  Winter 5
  • 5. 13.1.21 Hadoop  Conference  Japan  2013  Winter 6
  • 6. 13.1.21 Hadoop  Conference  Japan  2013  Winter 7
  • 7. New year 2013 in Japan Number of requests in a HBase cluster Usual Peak Hours New Year 2013 X  3 (ploFed  by  1min) あけおめ! 新年好! 3  5mes  traffic  explosion   LINE  Storage  had  no  problems  :)   13.1.21 Hadoop  Conference  Japan  2013  Winter 9
  • 8. LINE on Hadoop Storages for service, backup and log For HBase, M/R and log archive Bulk migration and ad-hoc analysis For HBase and Sharded-Redis Collecting Apache and Tomcat logs KPI, Log analysis 13.1.21 Hadoop  Conference  Japan  2013  Winter 10
  • 9. LINE on Hadoop Storages for service, backup and log For HBase, M/R and log archive Bulk migration and ad-hoc analysis For HBase and Sharded-Redis Collecting Apache and Tomcat logs KPI, Log analysis 13.1.21 Hadoop  Conference  Japan  2013  Winter 11
  • 10. LINE service requirements LINE is a… Messaging Service - Should be fast Global Service - Downtime not allowedBut, not a Simple Messaging Service. Message synchronization b/w phone & PCs –  Messages should be kept for a while. 13.1.21 Hadoop  Conference  Japan  2013  Winter 12
  • 11. LINE’s storage requirements No     data  loss Eventual   Low   consistency latency HA Flexible   schema   Easy  scale-­‐ management out 13.1.21 Hadoop  Conference  Japan  2013  Winter 13
  • 12. Our selection is HBase •  Low latency for large amount of data•  Linearly scalable•  Relatively lower operating cost –  Replication by nature –  Automatic failover•  Data model fits our requirements –  Semi-structured –  Timestamp13.1.21 Hadoop  Conference  Japan  2013  Winter 14
  • 13. Stored rows per day in a cluster (billions/day) 10 8 6 4 2 13.1.21 Hadoop  Conference  Japan  2013  Winter 15
  • 14. What we achieved with HBase •  No data loss –  Persistent –  Data replication •  Automatic recovery from server failure•  Reasonable performance for large data sets –  Hundreds of billion rows –  Write: ~ 1 ms –  Read: 1 ~ 10 ms13.1.21 Hadoop  Conference  Japan  2013  Winter 16
  • 15. Many issues we had •  Heterogeneous storages coordination•  IDC online migration•  Flush & Compaction Storms by “too many HLogs”•  Row & Column distribution•  Secondary Index•  Region Management –  load, size balancing –  RS Allocation –  META region –  M/R•  Monitoring for diagnostics•  Traffic burst by decommission•  NN problems•  Performance degradation –  hotspot problem –  timeout burst –  GC problem•  Client bugs –  Thread Blocking on server failure (HBASE-6364)13.1.21 Hadoop  Conference  Japan  2013  Winter 17
  • 16. Today’s topics IDC online migration NN failover Stabilizing LINE message cluster13.1.21 Hadoop  Conference  Japan  2013  Winter 18
  • 17. IDC online migration NN failoverStabilizing LINE message cluster
  • 18. Why? •  Move whole HBase clusters and data•  For better network infrastructure•  Without downtime13.1.21 Hadoop  Conference  Japan  2013  Winter 20
  • 19. IDC online migration Before migration App Server dst-HBase write src-HBase 13.1.21 Hadoop  Conference  Japan  2013  Winter 21
  • 20. IDC online migration •  Write to both (client-level replication) write App Server dst-HBase write src-HBase 13.1.21 Hadoop  Conference  Japan  2013  Winter 22
  • 21. IDC online migration •  New data: Incremental replication•  Old data: Bulk migration•  dst’s timestamp equals src’s one write App Server dst-HBase write src-HBase 13.1.21 Hadoop  Conference  Japan  2013  Winter 23
  • 22. LINE HBase Replicator & BulkMigrator Replicator is for incremental replication BulkMigrator is for bulk migration 13.1.21 Hadoop  Conference  Japan  2013  Winter 24
  • 23. LINE HBase Replicator •  Our own implementation•  Prefer pull to push •  Throughput throttling •  Workload isolation of replicator and RS•  Rowkey conversion and filtering HBase  Replicator LINE  HBase  Replicator src-HBase src-HBase push pull dst-HBase dst-HBase 13.1.21 Hadoop  Conference  Japan  2013  Winter 25
  • 24. LINE HBase Replicator - A simple daemon to replicate local regions - 1.  HLogTracker reads a ckpt and selects next HLog. 2.  For each entry in HLog: 1.  Filter & convert a HLog.Entry 2.  Create Puts and batch to dst HBase •  Periodic checkpointing •  Generally, entries are replicated in seconds 13.1.21 Hadoop  Conference  Japan  2013  Winter 26
  • 25. Bulk migration 1.  MapReduce between any storages –  Map task only –  Read source, write destination –  Task scheduling problem depends on region allocation2.  Non MapReduce version (BulkMigrator) –  Our own implementation –  HBase → HBase –  On each RS, scan & batch by a region –  Throughput throttling –  Slow, but easy to implement and debug 13.1.21 Hadoop  Conference  Japan  2013  Winter 27
  • 26. IDC online migration NN failoverStabilizing LINE message cluster
  • 27. Background •  Our HBase has a SPOF: NameNode•  “Apache Hadoop HA Configuration” http://blog.cloudera.com/blog/2009/07/hadoop-ha-configuration/•  Furthermore, added Pacemaker –  Heartbeat can’t detect whether NN is running13.1.21 Hadoop  Conference  Japan  2013  Winter 29
  • 28. Previous: HA-NN DRBD + VIP + Pacemaker 13.1.21 Hadoop  Conference  Japan  2013  Winter 30
  • 29. NameNode failure in 2012.10 13.1.21 Hadoop  Conference  Japan  2013  Winter 31
  • 30. HA-NN failover failed •  Not NameNode process•  Incorrect leader election at network partitioning•  Complicated configuration –  Easy to mistake, difficult to control –  Pacemaker scripting was not straightforward –  VIP is risky to HDFS•  DRBD split-brain problem –  Protocol C –  Unable to re-sync while service is online13.1.21 Hadoop  Conference  Japan  2013  Winter 32
  • 31. Now: In-house NN failure handling •  Bye-bye old HA-NN –  Had to restart whole HBase clusters after NN failover•  Alternative ideas –  Quorum-based leader election (Using ZK) –  Using L4 switch –  Implement our own AvatarNode•  Safer solution instead of a little downtime13.1.21 Hadoop  Conference  Japan  2013  Winter 33
  • 32. In-house NN failure handling (1)  rsync  with  -­‐-­‐link-­‐dest  periodically  13.1.21 Hadoop  Conference  Japan  2013  Winter 34
  • 33. In-house NN failure handling (2) Bomb 13.1.21 Hadoop  Conference  Japan  2013  Winter 35
  • 34. In-house NN failure handling (3) 13.1.21 Hadoop  Conference  Japan  2013  Winter 36
  • 35. IDC online migration NN failoverStabilizing LINE message cluster
  • 36. Stabilizing LINE message cluster Case  1 “Too  many   HLogs”   H/W  Failure   RS  GC  Storm   Handling   Case  3 Case  2 META  region   Hotspot   workload   Performance   problems isola5on Case  4 Region   mappings   to  RS 13.1.21 Hadoop  Conference  Japan  2013  Winter 38
  • 37. Case1: “Too many HLogs” •  Effect –  MemStore flush storm –  Compaction storm•  Cause –  Different regions growth –  Heterogeneous tables in a RS•  Solution –  Region balancing –  External flush scheduler13.1.21 Hadoop  Conference  Japan  2013  Winter 39
  • 38. Case1: Number of HLogs Forced flushed shed N o flu Periodic flushed better case peak off-peak worse case Forced flushed Forced flushed flush storm Forced flushed 13.1.21 Hadoop  Conference  Japan  2013  Winter 40
  • 39. Case2: Hotspot problems •  Effect –  Excessive GC –  RS performance degradation (High CPU usage)•  Cause –  Get/Scan: •  Row or column, updated too frequently •  Row which has too many columns (+ tombstones)•  Solution –  Schema and row/column distribution are important –  Hotspot region isolation13.1.21 Hadoop  Conference  Japan  2013  Winter 41
  • 40. Case3: META region workload isolation •  Effect 1.  RS high CPU 2.  Excessive timeout 3.  META lookup timeout•  Cause –  Inefficient exception handling of HBase client –  Hotspot region and META in same RS•  Solution –  META only RS13.1.21 Hadoop  Conference  Japan  2013  Winter 42
  • 41. Case4: Region mappings to RS •  Effect –  Region mapping is not restored on RS restart –  Some region mappings aren’t restored properly after graceful restart •  graceful_stop.sh --restart --reload•  Cause –  HBase does not support it well•  Solution –  Periodic dump and restore it13.1.21 Hadoop  Conference  Japan  2013  Winter 43
  • 42. Summary •  IDC online migration –  Without downtime –  LINE HBase Replicator & BulkMigrator•  NN failover –  Simple solution for a person saying “What’s Hadoop?”•  Stabilizing LINE message cluster –  Improved response time of RS13.1.21 Hadoop  Conference  Japan  2013  Winter 44
  • 43. Conclusion We won 100M user adopting HBase LINE Storage is a successful example of a messaging service using HBase13.1.21 Hadoop  Conference  Japan  2013  Winter 45
