Managing a MySQL database server can become a full time job. What we need are tools that bundle a set of related tasks into a common utility. While there are several such utility libraries to choose, it is often the case that you need to customize them to your needs. The MySQL Utilities library is the answer to that need. It is open source so you can modify and expand it as you see fit. This is the presentation from OSCON 2011 in Portland.

1. <Insert Picture Here>
Python Utilities for Managing
MySQL Databases
Mats Kindahl, Lars Thalmann, Chuck Bell

2. THE FOLLOWING IS INTENDED TO OUTLINE OUR GENERAL
PRODUCT DIRECTION. IT IS INTENDED FOR INFORMATION
PURPOSES ONLY, AND MAY NOT BE INCORPORATED INTO
ANY CONTRACT. IT IS NOT A COMMITMENT TO DELIVER ANY
MATERIAL, CODE, OR FUNCTIONALITY, AND SHOULD NOT BE
RELIED UPON IN MAKING PURCHASING DECISION. THE
DEVELOPMENT, RELEASE, AND TIMING OF ANY FEATURES OR
FUNCTIONALITY DESCRIBED FOR ORACLE'S PRODUCTS
REMAINS AT THE SOLE DISCRETION OF ORACLE.
2

3. About the Speakers
• Mats Kindahl, PhD
• Replication Expert and Lead Developer
• mats.kindahl@oracle.com
• Lars Thalmann, PhD
• Development Director, Replication, and Backup
• lars.thalmann@oracle.com
• Chuck Bell, PhD (not present)
• MySQL Utilities and Replication
• chuck.bell@oracle.com
3

4. Topics
• Introduction to MySQL Utilities
• List of current utilities
• Architecture of MySQL Utilities
• Examples of usage
• Using the MySQL Utilities Python Library
4

5. What is MySQL Utilities?
• A collection of Python utilities for managing MySQL
databases
• Part of MySQL Workbench 5.2.31
• Available under the GPLv2 license
• Written in Python
• Easily enhanced using a growing code library
• Goal is to provide a Python library to grow solutions
for common administrative problems
5

6. List of Utilities
• mysqldbcompare – compare databases
• mysqldbcopy – copy databases between servers
• mysqldbexport – export metadata and data
• mysqldbimport – import metadata and data
• mysqldiff – compare object definitions
• mysqldiskusage – show disk usage for databases
• mysqlindexcheck – check for redundant indexes
• mysqlmetagrep – search metadata
• mysqlprocgrep – search process information
• mysqlreplicate – setup replication
• mysqlrplcheck – check replication configuration
6

7. List of Utilities
• mysqlserverclone – start a scratch server
• mysqlserverinfo – show server information
• mysqluc – console for utilities
• mysqluserclone – clone a user account
7

8. Utilities in MySQL Workbench
• Launch the MySQL Utilities command window:
– Click on the Plugins menu item
– Select “Start Shell for MySQL Utilities”
OR
• From the Workbench main window:
– Click on the drop down arrow icon to the right of the
main window
– Scroll through screens to find the MySQL Utilities icon
8

9. How do I access the utilities?
9

10. How do I access the utilities?
10

11. Structure of the MySQL Utilities
mysqlprocgrep
Scripts
Command Common
Module Module
mysql.utilities.command mysql.utilities.common
MySQL Utilities Library
11

12. mysqldbcompare – compare databases
• Find missing objects from either database
• Find objects that differ in definition
• Find differences in data among tables
• Print difference in formats differ, ndiff, or context
• Print output rows in GRID, TAB, CSV, or VERTICAL
formats
• Scenarios
• checking master and slave for consistency
• checking production and development databases for
consistency
• generating a difference report for expected differences
among new and old data
• comparing backups for differences
12

13. Sample execution
$ mysqldbcompare --server1=root@localhost --server2=root@backup_host:3310
> inventory:inventory --run-all-tests
# server1 on localhost: ... connected.
# server2 on localhost: ... connected.
# Checking databases inventory on server1 and inventory on server2
WARNING: Objects in server1:inventory but not in server2:inventory:
VIEW: finishing_up
VIEW: cleaning
Defn Row Data
Type Object Name Diff Count Check
---------------------------------------------------------------------------
TABLE supplier pass FAIL FAIL
Row counts are not the same among inventory.supplier and inventory.supplier.
Data differences found among rows:
--- inventory.supplier
+++ inventory.supplier
@@ -1,2 +1,2 @@
code,name
-2,Never Enough Inc. <user>:<password>@<host>:<port>:<socket>
+2,Wesayso Corporation
13

14. mysqlmetagrep – search objects
• Search for objects with names matching a pattern
• Match using SQL patterns or POSIX regular
expressions
• Search bodies of routines (procedures, events,
triggers)
• Generate SQL for executing the query
– Can be used in applications
– Can be stored in events or views
_”
14

15. Searching for objects by name
Searching a database for objects starting with “t”
mysqlmetagrep ­­pattern="t_" ­­server=mats@localhost
$ mysqlmetagrep ­­pattern="t_" ­­server=mats@localhost
+­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­+­­­­­­­­­­­­­+­­­­­­­­­­+
| Connection | Object Type | Object Name | Database | Field Type | Matches |
+­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­+­­­­­­­­­­­­­+­­­­­­­­­­+
| mats:*@localhost:3307 | TABLE | t1 | test | COLUMN | th |
| mats:*@localhost:3307 | TABLE | t1 | test | TABLE | t1 |
| mats:*@localhost:3307 | TABLE | t2 | test | TABLE | t2 |
| mats:*@localhost:3307 | TABLE | tt5 | test | COLUMN | t2,t1 |
+­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­+­­­­­­­­­­­­­+­­­­­­­­­­+
15

16. Searching routine bodies
Searching a database for objects containing “l_host”
mysqlmetagrep ­­body ­­pattern="%l_host%"
­­server=mats@localhost
$ mysqlmetagrep ­­body ­­pattern="%l_host%" ­­server root@localhost:3307
+­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­­­­­­+­­­­­­­­­­­+­­­­­­­­­­­­­+­­­­­­­­­­­­­­­­+
| Connection | Object Type | Object Name | Database | Field Type | Matches |
+­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­­­­­­+­­­­­­­­­­­+­­­­­­­­­­­­­+­­­­­­­­­­­­­­­­+
| root:*@localhost:3307 | PROCEDURE | switch_master | test | ROUTINE | switch_master |
+­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­­­­­­­­­­+­­­­­­­­­­­+­­­­­­­­­­­­­+­­­­­­­­­­­­­­­­+
16

17. mysqlprocgrep – search processes
• Search processes on multiple machines
• Match by PROCESSLIST fields
– Id, State, User, Host, Database, Command, State, Info
• Match by age
– Find long-running queries, or idle connections
• Get SQL for performing the query or action
– Put in application
– Put in events
• Kill queries or connections
– Option: ­­kill­query
– Option: ­­kill­connection
17

18. Sample usage
• Find queries by 'www-data' that have been executing
for more than 20 minutes
mysqlprocgrep ­­server=mats@example.com
­­match­user=www­data
­­match­state=executing
­­age=20m
+­­­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­+­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­+­­­­­­­­­­+­­­­­­­+­­­­­­­­­­­­+­­­­­­­­­­­­­­­­­­­­+
| Connection | Id | User | Host | Db | Command | Time | State | Info |
+­­­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­+­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­+­­­­­­­­­­+­­­­­­­+­­­­­­­­­­­­+­­­­­­­­­­­­­­­­­­­­+
| mats:*@example.com:3306 | 53 | mats | example.com | user | Query | 2040 | executing | select … |
+­­­­­­­­­­­­­­­­­­­­­­­­­­+­­­­­+­­­­­­­+­­­­­­­­­­­­­­+­­­­­­­+­­­­­­­­­­+­­­­­­­+­­­­­­­­­­­­+­­­­­­­­­­­­­­­­­­­­+
18

19. Sample usage
• Find queries by 'www-data' that have been executing
for more than 20 minutes
mysqlprocgrep ­­server=mats@example.com
m!
­­match­user=www­data
­­match­state=executing
The
­­age=20m ­­kill­query i ll
K
19

20. mysqlreplicate – setup replication
• Permits an administrator to start replication among
two servers.
• User have to provide:
– Login information to the slave
– Connection information for the master
• Example: Setup replication between two instances
mysqlreplicate --rpl-user=rpl_user:xyzzy
--master=root@localhost:3306 --slave=root@localhost:3307
20

21. mysqluc – MySQL Utilities Console
• User defined variables
• Help features
• Tab completion (names, parameters, options,
variables)
21

22. MySQL Utilities Python Library
• Major classes for:
• Database
• Replication
• Server
• Index
• Table
• User
• Also many helpful methods such as
• connect_servers()
• setup_common_options()
• format_tabular_list()
• find_running_servers()
22

23. Library Example
• Goal: create a utility that makes a copy of a running
server and copies all of the data and users.
• Steps
• Setup the parameters
• Connect to the original server
• Find all of the databases
• Find all of the users
• Make a clone of the original server
• Copy all of the databases
• Copy all of the users
23

24. Utility options
• Server to read from: ­­server
• Databases: ­­databases
• Data directory for new server: ­­new­data
• Port for new server: ­­new­port
• Server ID for new server: ­­new­id
24

25. Set up options
from optparse import OptionParser
parser = OptionParser()
parser.add_option("­­server",
action="store”, dest="server",
type="string", default="root@localhost:3306",
help="connection information for original server in "
"the form: <user>:<password>@<host>:<port>:<socket>")
parser.add_option("­d", "­­databases",
action="store", dest="dbs_to_copy”, type="string",
help="comma­separated list of databases "
"to include in the copy (omit for all "
" databases)”, default=None)
.
.
.
25

26. Library Example
• Parse the connection information
from mysql.utilities.common.options import parse_connection
try:
conn = parse_connection(opt.server)
except:
parser.error("Server connection values invalid or"
" cannot be parsed.")
• Connect to original server
from mysql.utilities.common.server import Server
server_options = {'conn_info’ : conn, 'role’ : "source"}
srv1 = Server(server_options)
srv1.connect()
26

27. Library Example
• Find all of the databases
db_list = [ (db[0],None) for db in srv1.get_all_databases() ]
• Find all of the users
_QUERY = """
SELECT user, host FROM mysql.user
WHERE user != 'root’ AND user != ''
"""
users = srv1.exec_query(_QUERY)
user_list = [ user[0] + '@' + user[1] for user in users ]
27

28. Library Example
• Make a clone of the original server
from mysql.utilities.command.serverclone import clone_server
res = clone_server(conn, opt.new_data, opt.new_port,
opt.new_id, "root", None, False, True)
28

29. Library Example
• Copy all of the databases
# Set destination server connection parameters
from mysql.utilities.command import dbcopy
dest = {
"user" : conn.get("user"),
"passwd" : "root",
"host" : conn.get("host"),
"port" : opt.new_port,
"unix_socket" : os.path.join(opt.new_data, "mysql.sock"),
}
# Set options for copy
options = {
"quiet" : True,
"force" : True,
}
dbcopy.copy_db(conn, dest, db_list, options)
29

30. Library Example
• Copy all of the users
from mysql.utilities.command.userclone import clone_user
options = {
"overwrite" : True,
"quiet" : True,
"globals" : True
}
for user in user_list:
res = clone_user(conn, dest_values, user,
(user,), options)
30

31. Enhancing the example
• Consistent copy?
– Locking tables
– Consistent snapshot (InnoDB)
• Copying all users?
– Users not related to the database?
– Users with only global privileges?
• Automatically start replication
• Killing connections?
31

32. Where To Go From Here
You can download MySQL Workbench from:
http://www.mysql.com/downloads/workbench/
You can also download the latest development source code
tree for the MySQL Workbench Utilities from:
http://launchpad/net/mysql­utilities
32

33. MySQL High Availability
Get it as free ebook: http://oreilly.com/go/ebookrequest
Valid this week, mention event “MySQL Replication
Update”
MySQL Support: www.mysql.com/contact
PHP under the hood Thu 10:40am
MySQL Technology Update Thu 2:30pm
MySQL Binlog API Fri 10:00am
Visit MySQL at Oracle booth 701!
33
