基于  Google protobuf  的  webgame  网络协议设计 赖勇浩 http://laiyonghao.com 2010.8.28
Google Protopuf 2.3 <ul><li>http://code.google.com/p/protobuf/ </li></ul><ul><li>二进制协议描述语言 </li></ul><ul><li>C++ </li></ul...
人生苦短,我用  Python 。
基本流程 <ul><li>Define message formats in a .proto file. </li></ul><ul><li>Use the protocol buffer compiler. </li></ul><ul><l...
Quick Example <ul><li>message Person { </li></ul><ul><li>required int32 id = 1; </li></ul><ul><li>required string name = 2...
Use the protocol buffer compiler. <ul><li>protoc -I=$SRC_DIR --python_out=$DST_DIR $SRC_DIR/example.proto </li></ul>
<ul><li>class Person(message.Message): </li></ul><ul><li>__metaclass__ = reflection.GeneratedProtocolMessageType </li></ul...
Python protocol buffer API <ul><li>person = Person() </li></ul><ul><li>person.id = 10 </li></ul><ul><li>person.name = 'lai...
Exception <ul><li>person.no_such_field = 1  # raises AttributeError </li></ul><ul><li>person.id = &quot;1234&quot;  # rais...
<ul><li>with open('example.data', 'rb') as f: </li></ul><ul><li>data = f.read() </li></ul><ul><li>person = Person() </li><...
ActionScript 3.0 <ul><li>http://code.google.com/p/protoc-gen-as3/ </li></ul><ul><li>It has most protobuf 2.3 features, mor...
How to use it? <ul><li>protoc --plugin=protoc-gen-as3=path/to/protoc-gen-as3[.bat] --as3_out=output-path your.proto  </li>...
目标 <ul><li>as3 </li></ul><ul><ul><li>var sock:SdSocket = new SdSocket(...); </li></ul></ul><ul><ul><li>var p:Person = new ...
问题 <ul><li>客户端 / 服务器端怎么知道对方发过来的包是  Person ? </li></ul>
好问题! <ul><li>需要设计一个  header </li></ul><ul><li>message Header { </li></ul><ul><li>required uint32 length = 1; </li></ul><ul...
我在代码里没有看到  msg_id ! <ul><li>Person  的  msg_id  是什么? </li></ul><ul><li>msg_id <=> hash(Person.DESCRIPTOR.full_name) </li></...
消息分发是一件操蛋的事!
<ul><li>svr = TcpServer(Handler(Protocol('full_name_map_msg_id.xml'))) </li></ul><ul><li>svr.run_forever() </li></ul>
更进一步 <ul><li>class Handler extends Object { </li></ul><ul><ul><li>public function _handle_Person(p:Person):void { </li></u...
<ul><li>class Handler(object): </li></ul><ul><ul><li>def _handle_Person(self, person): </li></ul></ul><ul><ul><ul><li>prin...
开始像  RPC  了? 对的,这是我们更高的目标。
Thanks all ! Q&A 别提性能问题。
