Hi there! :-)
Ogres = Onions
= Web Standards?
LAYERS!
Common Frontend
Development knows
     3 Layers
The 5 Layers of
Web Accessibility
    YDN Tuesday 5.5.2009
       Dirk Ginader

       http://ginader.com
   http://twitte...
The Markup
is the most important
      Layer of all
Source order
      =
  tab order
Best matching HTML
Element for the job?
Is the page
understandable and
usable without CSS?
Interaction using links,
  forms and reloads
CSS can make
inaccessible too
display:none
          and
  visibility:hidden
hide from everyone
:hover
only works for a mouse
:focus to the rescue!
always use them combined:
   a:hover, a:focus{
      /*awesome CSS*/
   }
CSS is for Design
not for Interaction
Javascript is the icing
     on the cake
Does anything, you need
 the user to do, work
  without Javascript?
then we can
add some Magic
hijack existing
interaction elements
create new buttons for
  JS only interactions
Screenreaders do know
JS. They often just don’t
 know what happens...
focus() to the rescue!
mind the tab order
focus() to the rescue!
tabindex=0
  makes even divs
keyboard accessible
tabindex=-1
for JS only tab access
yeah focus()
Ajax = delays
 = tricky to
communicate
inform about what
     happens!
you guessed it:
   focus()
Screenreaders update
 their Virtual Buffer
     “regularly”
while in Forms Mode
they update in realtime
use the Forms Mode to
update the Buffer when
      you need to
another layer:
   different CSS if
Javascript is available
Change the interface
 for the JS version
CSS is much faster than
       Javascript
Tell CSS that there’s JS:
 document.documentElement.className += ” js”;
.module{
    /* nice CSS for the non JS Layout */
}
.js .module{
    /* awesome CSS for the JS Layout*/
}
How does your CSS
react when the text
   size changes?
Screen Magnifier only
show a very small part
     of the screen
make sure everybody
knows what happens
     right now
yellow fades + focus()
    help to find and
      understand
the last Layer
the new Hotness
WAI-ARIA maps existing
   and well known OS
   concepts to custom
Elements in the Browser
Adds semantics to non
  semantic Markup
provides instant
  updates and
  notifications
Roles
• alert
• banner
• button
• menuitem
• slider
Document Landmark
     Roles
• application
• banner
• complementary
• contentinfo
• main
• navigation
• search
States and Properties
• aria-valuemin
• aria-valuemax
• aria-valuenow
• aria-valuetext
• aria-labelledby
Live Regions
informing about
     changes
• off
• polite
• assertive
• (rude)
You can use it today
• it does no validate
• you can simply add the properties using
  Javascript as it depends on it anyway
• everybody can add Landmark roles now
• aria-required=”true” makes a dream come
  true
Don’t rely on it
• There are no stats but we know that still a
  lot of Screenreader users are stuck on old
  versions without ARIA support...
Examples
without Javascript




 http://finance.yahoo.com/currency-converter
without Javascript




 http://finance.yahoo.com/currency-converter
without Javascript




 http://finance.yahoo.com/currency-converter
with Javascript




http://finance.yahoo.com/currency-converter
with Javascript




http://finance.yahoo.com/currency-converter
with Javascript




http://finance.yahoo.com/currency-converter
http://uk.tv.yahoo.com/
more

• http://cli.gs/wai-aria
• http://cli.gs/accessible-tabs
• http://cli.gs/accessibilitytips
• http://cli.gs/wai-aria-...
http://ginader.com
http://twitter.com/ginader
