Web Runtime à la Symbian
sami.j.viita
            nen@noki
                     a.co              m
                      ...
Agenda
  Day1
     • Welcome!
     • Forum Nokia
     • WRT widget in nutshell
     • Towards an excellent UX
     • Going...
Web Runtime
 and Nokia
Our Developer Offering: elegantly
                          connected services

     Services Level



        Apps Level
...
Cross-platform evolution expands opportunities
  Next
                                  Desktop                          ...
S60 Internet evolution




                                                                            Widgets + Platform
...
Definition of widget
 • Lightweight mobile applications that give users easy access to the web
 • The easiest way to bring...
Platform services
Widgets and platform services
• Framework for abstracting access to a set of services
• Runtime specific bindings and secu...
Home screen
What is home screen content?
Nokia N97 onwards
Dynamic, user configurable content on
   home screen
Size depending on devi...
What about home screen widget?
Home screen content vs. home screen widget?
   •  Widget for developers…
   •  Content for ...
Devices
Nokia widgets compatible devices




http://www.forum.nokia.com/devices/matrix_webruntime_1.html
Towards an excellent UX
Designing widgets –
            usability guidelines for widgets

   How to design the widget so that it can best
        ...
Know your users
 •  Find out who will use the widget, what they will use it for, and which mobile
    devices they have?
 ...
Design for small screens
  • Small screen size: only relevant content
            •  240 x 320 pixels portrait
           ...
Design for multiple screen sizes
   • Relate the position and size of each control to the
     dimensions of the display.
...
Design for changing screen orientation
 • Support for screen rotation: adapt content to it’s best on
   portrait and lands...
Intuitive ways of moving
• You can use different navigation
  modes on mobile - five way
  navigation:
   • Cursor navigat...
Design for limited input methods
  •  eypad
   K
    • Softkeys (platform or custom)
    • Navigation on screen (cursor, t...
Responsiveness and power management
Keep response times short
• Latency can cause delays in user interaction: frustrated e...
S60 WebKit
Open source browser engine: WebKit
                       S60 Browser and Web Runtime are based on WebKit


   Native C/C+...
Web Runtime
S60 Browser engine:
   •  Comprising core components such as the
      XML engine, HTML parser, JavaScript    ...
S60 WRT widget
   dissolved
WRT widget ingredients
                                               Widget
                                             ...
HTML
                                         <html>

 Defines the
                                        <head>
        ...
info.plist
                                               ...
                                               <plist versio...
CSS                           // Class selector to define
                               common style for similar
        ...
JavaScript

     Event handling
               XMLHttpRequest
   DOM manipulation
          UI effects
               UI t...
How do I code then?
Aptana Studio and Nokia WRT plugin

Nokia’s WRT 2.2 plugin for Aptana
  Studio:
   •  Creation, editing,
      testing, an...
WRT JavaScript extensions – widget object

      URL + application launching
    identifier    simple text key storing
   ...
WRT JavaScript extensions - Menu
                       menu and MenuItem:
Localization support
    Language directories
                         CSS    display name
                          strin...
Packaging and distribution

          Zip the files
            …rename to .wgz


                     MIME type
         ...
Communication - AJAX
   WRT Widgets
    single HTML file

  Perform operations
   update UI
      maintain UI responsivene...
HTTP request – how to?




                         XMLHttpRequest
                                 html
                 ...
Libraries – easier approach
 jQuery




  MooTools
Deployment / Testing

 Target device
  Bluetooth
       Web
  USB          SDK Emulator
                Desktop browser
Home screen:
the implementation
Home screen or full screen?

WRT widget enabled to home screen (HS)         Home
  screen
  view
   Full
  screen
  v...
Creating and designing home screen content
Dynamic content but
   •  Remove animations, videos etc.
   •  Use JavaScript t...
Better UX for widgets – observing network status
  • Widget needs to know if network available or not:
     • Hiding nasty...
How to observe changes?
• Register handler: window.ononline/window.onoffline!
• Use window.navigator.onLine to check the s...
Network status – what does it mean?
                                                NetworkNotAllowe
                     ...
No network connection allowed
        NetworkNotAllowed
                                    info.plist!
           1)   <k...
Access allowed – no active connection
        NetworkAccessAllowed
                                    info.plist!
       ...
Access allowed - active connection established
                                               Active Internet
            ...
Platform Services
WRT 1.0 vs. WRT 1.1
• 1.0 offering limited due to security considerations
• 1.1 available 5th Edition onwards (also for so...
WRT 1.0 – system info for widgets
HTML:
<embed
type="application/x-
systeminfo-widget”
hidden="yes”>!
</embed>!

JavaScrip...
WRT 1.1 – comprehensive set of APIs




http://library.forum.nokia.com/topic/Web_Developers_Library/
   GUID-46EABDC1-37CB...
Best of both worlds
      WRT+Qt
Our vision: Web into any application
     Now   Web browser             Web Runtime widget     Now




                   ...
Interact with Web Services
QtWebKit allows
  •  Intuitive use of network resources
  •  Exposing QWidget to HTML and QObje...
QWebView and QWebPage classes
QWebView inherited from QWidget
   •  Renders the content in QWebPage
                      ...
Hybrid - combining the best of both worlds
    So you can run JS and HTML inside Qt application…
           What are the d...
Webview demo
Pure JS content run on top of Webkit
Demonstrates different applications &
look and feel
   •  In the demo th...
Examples and exercises


     62
Upcoming SlideShare
Loading in...5
×

Forum Nokia Dev. Camp - WRT training Paris_17&18 Nov.

3,127

Published on

Published in: Technology
0 Comments
1 Like
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
3,127
On Slideshare
0
From Embeds
0
Number of Embeds
1
Actions
Shares
0
Downloads
67
Comments
0
Likes
1
Embeds 0
No embeds

No notes for slide

Transcript of "Forum Nokia Dev. Camp - WRT training Paris_17&18 Nov."

  1. 1. Web Runtime à la Symbian sami.j.viita nen@noki a.co m Paris, 17.- 18 .1 1 .0 9 © 2009 Nokia Corporation
  2. 2. Agenda Day1 • Welcome! • Forum Nokia • WRT widget in nutshell • Towards an excellent UX • Going inside the widget Day2 • Exercises
  3. 3. Web Runtime and Nokia
  4. 4. Our Developer Offering: elegantly connected services Services Level Apps Level Platform Level Nokia platforms Desktop OSs
  5. 5. Cross-platform evolution expands opportunities Next   Desktop Series 40* Symbian Maemo Enables  rich  service  crea9on  on   supported  pla2orms  using   Web  Web  eb                               standard    W        technology                                    Web  Run.me               Flash Flash Flash Lite Flash Java   Java SE Java ME Enables  fast  applica.on  and  UI   development  across  mobile  and   Native Web desktop  pla2orms   Qt Web Runtime and Qt close the gap between mobile and desktop development 5 Web  Run9me  and  Qt  have  only  limited  use  on  Series  40   *      selected  Series  40  devices
  6. 6. S60 Internet evolution Widgets + Platform Full HTML browser Widgets offer focused, Mobile-optimized sites Services offer lets mobile consumers optimized front-ends to serve specific needs seamless integration of experience the Web-based information and tasks the Web with personal complete Web and services context
  7. 7. Definition of widget • Lightweight mobile applications that give users easy access to the web • The easiest way to bring web-based business to millions of Nokia mobile devices   Develop WRT widgets using standards-based web technologies (e.g. HTML, CSS, Javascript, AJAX)   Install and run on Nokia devices like any native application   Provide an optimised web experience accessible with a single click Application like delivery Visible in the UI Familiar HTML, Javascript, and CSS
  8. 8. Platform services
  9. 9. Widgets and platform services • Framework for abstracting access to a set of services • Runtime specific bindings and security management • Access Platform Services through JavaScript • Example use cases: • Combine Web-based data with local context to deliver personalized, relevant services • Save critical Web-based contacts and events locally to create reliable, dependable reminders
  10. 10. Home screen
  11. 11. What is home screen content? Nokia N97 onwards Dynamic, user configurable content on home screen Size depending on device •  Nokia N97: 309x85 pixels End-user controls the home screen layout •  What content is show •  Layout of the shown content Note! Some content defined as mandatory by the device
  12. 12. What about home screen widget? Home screen content vs. home screen widget? •  Widget for developers… •  Content for consumers! Content can be published by Symbian C++ application or S60 Web Runtime widget End-user interaction: •  Add / remove home screen content •  Tap content to open widget full screen view
  13. 13. Devices
  14. 14. Nokia widgets compatible devices http://www.forum.nokia.com/devices/matrix_webruntime_1.html
  15. 15. Towards an excellent UX
  16. 16. Designing widgets – usability guidelines for widgets How to design the widget so that it can best serve its users? • Various form factors: • Multiple screen sizes • Support for different input methods and ways to use (touch, non-touch, QWERTY, ITU-T…) • Home screen, sensors, tactile feedback…
  17. 17. Know your users •  Find out who will use the widget, what they will use it for, and which mobile devices they have? •  Analyse user and their tasks: combine data and platform services to provide perfect end-user experience •  Supported devices? •  Designing for a specific context of use •  More info? See also ’Usability in a mobile application development project’ http://library.forum.nokia.com/topic/ Design_and_User_Experience_Library/GUID-D4AFE068-97E8-487A- A79B-CE1422127623.html
  18. 18. Design for small screens • Small screen size: only relevant content •  240 x 320 pixels portrait •  320 x 240 pixels landscape •  360 x 640 pixels portrait •  640 x 360 pixels landscape •  800 x 352 pixels landscape (Nokia E90) • One or more displays in single device • Use JavaScript to determine the size – relative positions
  19. 19. Design for multiple screen sizes • Relate the position and size of each control to the dimensions of the display. • Cascading style sheet (CSS) to specify relative measurements: fonts, margins, images… .button { .button { width: 116px; width: 80px; height: 37px; height: 25px; background: background: url(images/small_button_bg.png) url(images/button_bg.png) no-repeat; no-repeat; color: #ffffff; color: #ffffff; font-size: 14px; font-size: 20px;
  20. 20. Design for changing screen orientation • Support for screen rotation: adapt content to it’s best on portrait and landscape • Reacting to change: JavaScript ’onresize’ function • Calculate the effective area e.g. from ’window.innerHeight’
  21. 21. Intuitive ways of moving • You can use different navigation modes on mobile - five way navigation: • Cursor navigation • Tab navigation • Customized navigation • Avoid scroll and type • One hand usage
  22. 22. Design for limited input methods •  eypad K • Softkeys (platform or custom) • Navigation on screen (cursor, tab or custom navigation) • Typing (text or numbers) • Selecting items in lists (e.g. HTML ’select’) •  ouch T • Checking touch support • Touch areas needs to be big enough: finger usability • JavaScript ’onClick’ handler (e.g. with image buttons) • Tactile feedback
  23. 23. Responsiveness and power management Keep response times short • Latency can cause delays in user interaction: frustrated end- user • Indicators for progress Save battery time • Timers • Network connections
  24. 24. S60 WebKit
  25. 25. Open source browser engine: WebKit S60 Browser and Web Runtime are based on WebKit Native C/C++ Web S60 Browser UI Widget Runtime Widgets “Web Capable” Browser S60 plug-ins, incl. Flash Lite, SVG, and Browser control API audio. WebCore JavaScript Platform Services UI S60 Core Integration features WebKit KHTML KJS (LGPL+BSD) (LGPL) OS adaptations Memory manager More information about Webkit: http://www.webkit.org
  26. 26. Web Runtime S60 Browser engine: •  Comprising core components such as the XML engine, HTML parser, JavaScript Native C/C+ + Widgets Web engine, CSS processor, rendering engine “Web Capable” Browser etc. Web Run-Time Web Tech Web applications and Widgets as client applications Platform Libraries and Middleware Symbian OS JavaScript as application programming Hardware language •  Access to Platform Services (Calendar, Location, Media files…)
  27. 27. S60 WRT widget dissolved
  28. 28. WRT widget ingredients Widget properties info.plist (mandatory) + [name].html (mandatory) HTML backbone icon.png [name].css [name].js PNG icon + CSS layout Root + folder! js logic 28
  29. 29. HTML <html> Defines the <head> .. </head> <body id="body"> structure of <div id=‘mainView’> </div> <span class=‘title’>Front view</span> the widget. <div id=‘subView1’ class=‘subView’> <p class=‘title’>Back view</p> </div> <div id=‘subView2’ class=‘subView’> <p class=‘title’>Config view</p> </div> </body> </html> Views can be constructed with static HTML elements or can be dynamically created by JavaScript at runtime.
  30. 30. info.plist ... <plist version="1.0"> The heart of <dict> <key>DisplayName</key> the widget <string>AccuWidget</string> <key>Identifier</key> <string>com.nokia.forum.accuwidget </string> <key>MainHTML</key> <string>accuwidget.html</string> <key>AllowNetworkAccess</key> <true /> ... Info.plist file defines the widget. It is a XML text file providing information about the components and features of this specific widget.
  31. 31. CSS // Class selector to define common style for similar components .title { Style and layout font-size: 26px; color: blue; information } .subView { display: none • Defines how to } // Id selector to define a unique style for a unique display HTML component #mainView { font-size: 16px; element: position, color: red; text-align: center; } color, background // Pseudo-class selector to color etc. design a pattern style div.subview div { margin: 10px 0 0 0; CSS information can be } padding: 20px 20px 20px 20px; . . . embedded in the HTML file or imported from an external styleheet
  32. 32. JavaScript Event handling XMLHttpRequest DOM manipulation UI effects UI tweaking
  33. 33. How do I code then?
  34. 34. Aptana Studio and Nokia WRT plugin Nokia’s WRT 2.2 plugin for Aptana Studio: •  Creation, editing, testing, and deployment of WRT widgets www.aptana.com/nokia
  35. 35. WRT JavaScript extensions – widget object URL + application launching identifier simple text key storing display orientation navigation model basic view switch animation show/hide events widget.openApplication(0x100058F8, ""); widget.openURL("http://www.S60.com");
  36. 36. WRT JavaScript extensions - Menu menu and MenuItem:
  37. 37. Localization support Language directories CSS display name strings resources (e.g. images) Auto detection for locale Default files in widget package root
  38. 38. Packaging and distribution Zip the files …rename to .wgz MIME type Server: x-nokia-widget Pre-installed WRT widgets
  39. 39. Communication - AJAX WRT Widgets single HTML file Perform operations update UI maintain UI responsiveness Async communication facilities needed
  40. 40. HTTP request – how to? XMLHttpRequest html XML text JSON
  41. 41. Libraries – easier approach jQuery MooTools
  42. 42. Deployment / Testing Target device Bluetooth Web USB SDK Emulator Desktop browser
  43. 43. Home screen: the implementation
  44. 44. Home screen or full screen? WRT widget enabled to home screen (HS) Home  screen  view   Full  screen  view   implements 2 views •  Home screen view •  Full screen view HS communicates to widget when end- user interacts with HS •  onload() and onresize() as widget side interface functions •  JavaScript code to determine current view size – correct view rendered
  45. 45. Creating and designing home screen content Dynamic content but •  Remove animations, videos etc. •  Use JavaScript timers to refresh Indicate when refreshed last time Consider handling of error cases Limit the amount of shown data •  Optimized content improves UX •  Appealing HS content: end-user goes to full screen view! Be scalable – use relative values
  46. 46. Better UX for widgets – observing network status • Widget needs to know if network available or not: • Hiding nasty ‘cannot access…’ situations from end-user • Better UX, providing info about the content validity: • Is content up-to-date? • Is widget able to refresh the content at the moment? • New APIs available (with WRT 7.x): • Observe status changes: window.ononline! window.onoffline • Retrieve the current status: window.navigator.onLine
  47. 47. How to observe changes? • Register handler: window.ononline/window.onoffline! • Use window.navigator.onLine to check the status function init()! {! window.ononline = accessHandler;! window.onoffline = accessHandler;! ...! function accessHandler()! {! switch (window.navigator.onLine) {! case 0:! ! ! noNetwork();! ! break;! case 1:! ! networkAvailable();! ...!
  48. 48. Network status – what does it mean? NetworkNotAllowe d info.pli st! <key>AllowNetworkAccess</key> ! <false/>! • API for requesting current network status: window.navigator.onLine! • Info can be used to e.g. modify the home NetworkAccessAllowe d info.pli st! <key>AllowNetworkAccess</key> ! <false/>! screen content based on network availability • Returns Nokia specific values: NetworkAccessible info.pli !window.navigator.NetworkNotAllowed ! st! <key>AllowNetworkAccess</key> ! <false/>! !window.navigator.NetworkAccessAllowed ! !window.navigator.NetworkAccessible! • Enum, can be used with switch – case
  49. 49. No network connection allowed NetworkNotAllowed info.plist! 1) <key>AllowNetworkAccess</key> ! <false/>! 2) 3) (1 || 2 || 3) == true!
  50. 50. Access allowed – no active connection NetworkAccessAllowed info.plist! 1) <key>AllowNetworkAccess</key> ! <true/>! 2) 3) (1 && 2 && 3) == true!
  51. 51. Access allowed - active connection established Active Internet connection NetworkAccessible info.plist! 4) 1) <key>AllowNetworkAccess</key> ! <true/>! 2) 3) (1 && 2 && 3 && 4) == true!
  52. 52. Platform Services
  53. 53. WRT 1.0 vs. WRT 1.1 • 1.0 offering limited due to security considerations • 1.1 available 5th Edition onwards (also for some 3rd. Ed. devices) • What’s Nokia Platform Services 2.0 then? • JavaScript API wrapper on top of the WRT 1.1 API: even easier and extended access to platform services
  54. 54. WRT 1.0 – system info for widgets HTML: <embed type="application/x- systeminfo-widget” hidden="yes”>! </embed>! JavaScript:
  55. 55. WRT 1.1 – comprehensive set of APIs http://library.forum.nokia.com/topic/Web_Developers_Library/ GUID-46EABDC1-37CB-412A-ACAD-1A1A9466BB68.html
  56. 56. Best of both worlds WRT+Qt
  57. 57. Our vision: Web into any application Now Web browser Web Runtime widget Now Open source WebKit is the foundation and common engine Widget + Now platform services Native application Next
  58. 58. Interact with Web Services QtWebKit allows •  Intuitive use of network resources •  Exposing QWidget to HTML and QObject to JavaScript •  Calling JavaScript from C++ Based on the Open Source WebKit engine: www.webkit.org
  59. 59. QWebView and QWebPage classes QWebView inherited from QWidget •  Renders the content in QWebPage QWebView •  Easy to embed wherever widget could be used QWebPage provides access to the document QWebPage structure in a page •  Frames QWebFrame •  Navigation history •  Undo/redo stack for editable content Each QWebpage has one QWebFrame object as its main frame HTML documents can be nested using frames QWebView *view = new QWebView( parent ); view->load(QUrl(“http://www.nokia.com”)); view->show();
  60. 60. Hybrid - combining the best of both worlds So you can run JS and HTML inside Qt application… What are the differences compared to a WRT widget? WRT Widget running on top of webkit Qt application Webkit QWebView running webkit Widgets HTML, CSS, Same HTML, CSS, JavaScript JavaScript Platform Services Native APIs Native APIs incl. Qt Mobility APIs Platform Services “Platform implementation Services” implementation
  61. 61. Webview demo Pure JS content run on top of Webkit Demonstrates different applications & look and feel •  In the demo there’s BBC News, games like Rock-Paper- Scissors and Tic-Tac-Toe, Calculator and Bubble •  Anything from web can be pulled to the hybrd container Statistics: Browser/ •  300 lines of C++ code (flick support ~200 lines) Standalone Qt C++ Hybrid Web runtime Application •  Size of .sis file: 20 kB Application *) Services written in HTML, CSS, •  Development time: approx. 5 hours Qt C++, Declarative JavaScript UI, Access to Qt
  62. 62. Examples and exercises 62
