China Turcon stepseal 2 k
The Turcon Stepseal 2K is a single-acting piston seal that provides high static and dynamic sealing with low friction. It has advantages like stick-slip-free operation, abrasion resistance, long service life, and compatibility with many temperatures and chemicals. The seal is recommended for injection molding machines, machine tools, presses, and floating piston accumulators. It uses a Turcon T46 seal ring and NBR or FKM o-ring depending on the application temperature.
China Turcon stepseal 2 k
- 1. TURCON STEPSEAL 2K -Single-Acting - - O—Ring-Energized Turcon® Slipper Seal Advantages - High static and dynamic sealing effect - Stick-slip-free operation for precise control - High abrasion resistance and high resistance to extrusion - Long service life - Simple groove design, one-piece piston possible - Wide range of application temperatures and high resistance to chemicals, depending on the choice of O—Ring material - Simple installation without seal edge deformation - Available for all diameters up to 106 inches (2,700 mm) - Low friction application engineers for assistance! Patented and patent pending geometry Application Examples The Turcon® Stepseal® 2K is the recommended sealing element for single-acting pistons in hydraulic components for: - Injection molding machines - Machine tools - Presses It is particularly recommended in floating piston accumulators as the primary seal on the oil side in combination with AQ-Seal® and AQ-Seal® 5. Materials Standard Application: - For hydraulic components in mineral oils containing zinc or medium with good lubricating performance Seal ring: Turcon® T46 Energizer: O—Ring NBR 70 Shore A or FKM 70 Shore A depending on the temperature Set reference: T46N or T46V Ordering example PSF000500 PSF000563
- 2.
- 3.
- 4.
- 5.
