3. The measurements, and sin-
cos-tan of the angles
Right triangles are a special kind of triangle which has one angle that
is 90 degrees, and the other two angles sum up to 90 degrees to
get 180 degrees, the total number of degrees in a triangle
Within right triangles, there are 2 special types of right triangles that
have very specific (and helpful) rules and ratios. They are the 45-45-
90 triangle, and the 30-60-90 triangle. These are the breakdowns of
the degrees for both triangle types:
4. 45-45-90 triangle
Like its name suggests, a 45-45-90 triangle consists of 2 angles that are 45
degrees and the third which has 90. Because the 2 angles are congruent,
the opposite sides to both these angles have to be congruent as well. If the
hypotenuse of the 45-45-90 triangle is 1, then the other 2 sides each have a
measure of the square root of 2 divided per 2
We can use the Pythagorean Theorem to confirm this:
A2 + B2 = C2
5. 45-45-90 triangle
The hypotenuse is 1, so C2 would equal 1. If we take the square of (root
2)/2, we get 2/4 which can be simplified to ½. Since A and B are the
same, ½ + ½ = 1, meaning the lengths of A and B are accurate. Let’s try to
find the sine, cosine, and tangent of the angles that are 45 degree
For a quick recap, sine is calculated using opposite/hypotenuse,
cosine is calculated using adjacent/hypotenuse, and tangent is
calculated using opposite/adjacent
6. 45-45-90 triangle
If we take angle B and want to find the sine,
we identify the opposite side, which has a
measure of (root 2)/2, and we divide it by
the hypotenuse, which is 1, so sine would
just be (root 2)/2
The cosine would also be (root 2)/2
because the adjacent side is the same as
the opposite side. The tangent would be 1
because we divide the opposite by the
adjacent
A
B
C
45
90
45
8. 30-60-90 triangle
The next type of special right triangle is a 30-60-90 triangle.
Like its name suggests, a 30-60-90 triangle consists of 1 angle that is 30
degrees, one angle that is 60 degrees, and the one which is 90
If the hypotenuse of the 30-60-90 triangle is 1, then the side opposite to
the 30 degree angle has a length of ½ and the side opposite to the 60
degree angle has a length of (root 3)/2
We can use the Pythagorean Theorem to confirm this:
A2 + B2 = c2
9. 30-60-90 triangle
The hypotenuse is 1, so C2 would equal 1. If we take the square of (root
3)/2, we get ¾. If we take the square of ½, we get ¼. 3/4 + 1/4 = 1,
meaning the lengths of A and B are accurate. Let’s try to find the sine,
cosine, and tangent of the 30 and 60 degree angles
10. 30-60-90 triangle
If we take angle A and want to find the sine, we
identify the opposite side which has a measure of
½ and we divide it by the hypotenuse which is 1,
so sine would just be 1/2. The cosine would be
(root 3)/2 because the adjacent side has a length
of
(root 3)/2
Tangent would be 1/(root 3) because you divide
½ by (root 3)/2. If we want to find the sine, cosine,
and tangent of Angle B (the 60 degree angle),
you would swap the sine and cosine values of
angle A to get sine and cosine for angle B, and
you would find the reciprocal of tan (A) to get tan
(B)
B
A
C
60
90
30
11. CREDITS: This presentation template was created by Slidesgo, including icons
by Flaticon and infographics & images by Freepik and content by Swetha Tandri
Thanks!
Do you have any questions?
youremail@freepik.com
+91 620 421 838
yourwebsite.com
Please keep this slide for attribution
12. Alternative resources
Here’s an assortment of alternative resources whose style fits the one of this template:
Vectors:
✸ Math chalkboard background
13. Resources
Did you like the resources in this template? Get them for free at our other
creative websites:
Vectors:
✸ Modern duotone start-up tips facebook post
✸ Math chalkboard background I
✸ Math chalkboard background II
✸ Hand drawn scientific formulas on chalkboard
14. Instructions for use
If you have a free account, in order to use this template, you must credit Slidesgo by keeping the Thanks slide. Please
refer to the next slide to read the instructions for premium users.
As a Free user, you are allowed to:
● Modify this template.
● Use it for both personal and commercial projects.
You are not allowed to:
● Sublicense, sell or rent any of Slidesgo Content (or a modified version of Slidesgo Content).
● Distribute Slidesgo Content unless it has been expressly authorized by Slidesgo.
● Include Slidesgo Content in an online or offline database or file.
● Offer Slidesgo templates (or modified versions of Slidesgo templates) for download.
● Acquire the copyright of Slidesgo Content.
For more information about editing slides, please read our FAQs or visit our blog:
https://slidesgo.com/faqs and https://slidesgo.com/slidesgo-school
15. As a Premium user, you can use this template without attributing Slidesgo or keeping the "Thanks" slide.
You are allowed to:
● Modify this template.
● Use it for both personal and commercial purposes.
● Hide or delete the “Thanks” slide and the mention to Slidesgo in the credits.
● Share this template in an editable format with people who are not part of your team.
You are not allowed to:
● Sublicense, sell or rent this Slidesgo Template (or a modified version of this Slidesgo Template).
● Distribute this Slidesgo Template (or a modified version of this Slidesgo Template) or include it in a database or in
any other product or service that offers downloadable images, icons or presentations that may be subject to
distribution or resale.
● Use any of the elements that are part of this Slidesgo Template in an isolated and separated way from this
Template.
● Register any of the elements that are part of this template as a trademark or logo, or register it as a work in an
intellectual property registry or similar.
For more information about editing slides, please read our FAQs or visit our blog:
https://slidesgo.com/faqs and https://slidesgo.com/slidesgo-school
Instructions for use (premium users)
16. This presentation has been made using the following fonts:
Inter Tight
(https://fonts.google.com/specimen/Inter+Tight)
Barlow
(https://fonts.google.com/specimen/Barlow)
Fonts & colors used
#191919 #ffffff
#285eff #f428d7
17. Create your Story with our illustrated concepts. Choose the style you like the most, edit its colors, pick
the background and layers you want to show and bring them to life with the animator panel! It will
boost your presentation. Check out how it works.
Storyset
Pana Amico Bro Rafiki Cuate
18. You can easily resize these resources without losing quality. To change the color, just ungroup the resource and click
on the object you want to change. Then, click on the paint bucket and select the color you want. Group the resource again
when you’re done. You can also look for more infographics on Slidesgo.
Use our editable graphic resources...
19.
20.
21. JANUARY FEBRUARY MARCH APRIL MAY JUNE
PHASE 1
PHASE 2
Task 1
Task 2
Task 1
Task 2
JANUARY FEBRUARY MARCH APRIL
PHASE 1
Task 1
Task 2
22.
23.
24. You can resize these icons without losing quality.
You can change the stroke and fill color; just select the icon and click on the paint bucket/pen.
In Google Slides, you can also use Flaticon’s extension, allowing you to customize and add even more icons.
...and our sets of editable icons
31. Add the title here
Text 1 Text 2 Text 3
Text 4 Text 5 Text 6
2016 2017 2018 2019 2020
“Despite being red,
Mars is actually a
very cold place”
“Mercury is the
smallest planet in
the Solar System”
“Neptune is the
farthest planet from
the Sun”
“Saturn is a gas
giant and has
several rings”
“Venus is the
second planet from
the Sun and is
terribly hot”
Premium infographics
32. “Despite being red,
Mars is actually a
very cold place”
“Jupiter is the
biggest planet in the
entire Solar System”
“Saturn is a gas
giant and has
several rings”
75%
Premium infographics
“Mercury is the
smallest planet in the
Solar System”
TITLE 1
75%
