How we can use open standards and specifications to design and build RESTful APIs that are easier to developer, maintain and use. Focusing on JSON-API (http://jsonapi.org/) and the Fractal php package (http://fractal.thephpleague.com/)

1. RESTMOREWITHJSON:APIAND
FRACTAL
Use open standards to build better and more
maintainable APIs
1

2. $>WHOAMI
$>BOYAN
Developer at Shtrak
Community cheerleader
Wannabe speaker and writer
Partialy-guilty for phpVarna
2 . 1

3. WHERETOFINDME
@specter_bg
boyanyordanov
boyanyordanov
2 . 2

4. WHATISREST?
REpresentational State Transfer
3 . 1

5. WHATISREST?
pretty URLs ?
HTTP verbs for actions ?
None of those ?
3 . 2

6. ACHIEVINGETERNALGLORY
Richardson Maturity Model post by Martin Fowler
3 . 3

7. SOAREWE...?
... probably NOT. But does it really matter?
3 . 4

8. OPENSTANDARDS
What makes an open standard ?
Cooperation
Adherence to Principles
Due process, Broad concensus, Transparency,
Balance, Openness
Collective Empowerment
Availability
Voluntary Adoption
4 . 1

9. EXAMPLESWEUSEEVERYDAY
HTTP
CSS, HTML, ECMAScript
C, C++, Java ( ), C#
PHP RFC process and PHP-Fig PSRs (sort of)
JCP
4 . 2

10. OPENSTANDARDSANDAPIS
Auth and security
Oauth 1/2, OpenID Connect, JWT
Documentation / helper
openapi/swagger, api blueprint, RAML json-
schema
Representation / content types
HAL, Problem JSON, Hydra and json-ld, JSON-
API
5

11. BENEFITSOFUSINGSTANDARDSFOR
APIS
easier to design and build
easier to maintain
easier to consume
easier to test
6 . 1

12. 6 . 2

13. 7

14. OVERVIEW
well-de ned conventions for listing, creating,
updating and deleting resources
recommendations for details not covered in the
main spec
server and client libraries in most popular
languages
8

15. 9

16. {
"links": { "self": "/meetups/1" },
"data": {
"type": "articles",
"id": "1",
"attributes": {
"title": "JSON API paints my bikeshed!"
},
"relationships": {
"author": {
"links": {"self": "...", "related": "..."},
"data": { "type": "people", "id": "9" }
}
}
}
}
10

17. THEMEDIATYPE
Client call
Server response
Accept: application/vnd.api+json
Content-Type: application/vnd.api+json
Content-type: application/vnd.api+json
11 . 1

18. DECONSTRUCTINGTHECOMPOUND
DOCUMENT
TOPLEVELATTRIBUTES
data
errors
meta
links
jsonapi
included
11 . 2

19. TYPESOFOBJECTS
resource object
link object
resource identi er object
error object
12 . 1

20. THERESOURCEOBJECT
{
"type": "meetups",
"id": "1",
"attributes": {
"name": "PHP Varna",
"description": "The php UG of Varna",
"next-meetup": "2017-05-18T19:30:00.200Z"
}
}
12 . 2

21. LINKSOBJECT
"links": {
"self": "/meetups/1"
}
...
"links": {
"related": {
"href": "/meetups/1/attendees",
"meta": {
"count": 50
}
}
}
12 . 3

22. RESOURCEIDENTIFIEROBJECT
{
"id": "1",
"type": "meetups",
"meta": {
"attendee-count": 50
}
}
12 . 4

23. RELATIONSHIPSOBJECT
"relationships": {
"location": {
"links": {
"self": "meetups/1/relationships/venue",
"related": "meetups/1/venue"
},
"data": { "type": "venues", "id": "1" }
}
}
12 . 5

24. PUTTINGITALLTOGETHER
GET /meetups HTTP/1.1
Accept: application/vnd.api+json
{
"data": {
"type": "meetups",
"id": "1",
"attributes": {
"name": "PHP Varna",
"description": "The php UG of Varna",
"next-meetup": "2017-05-18T19:30:00.200Z"
},
"relationships": {
"venue": {
"data": { "type": "venues", "id": "1" }
}
}
}
}
13

25. RELATIONSHIPS
Change the meetup place
PATCH /meetups/1/relationships/venue HTTP/1.1
Content-Type: application/vnd.api+json
Accept: application/vnd.api+json
{
"data": { "type": "venues", "id": "12" }
}
14 . 1

26. Remove the venue (untill we nd a new one?)
PATCH /meetups/1/relationships/venue HTTP/1.1
Content-Type: application/vnd.api+json
Accept: application/vnd.api+json
{
"data": null
}
14 . 2

27. SIDELOADINGRELATIONSHIPS(GETMEETUPANDVENUE)
GET /meetups/1?include=venue HTTP/1.1
HTTP/1.1 200 OK
Content-Type: application/vnd.api+json
{
"data": {
// resource object from previous slides
},
"included": [
{
"type": "venues",
"id": "1",
"attributes": {
"name": "VarnaLab",
"address": "ul. 'Pencho Slaveykov' 50"
}
}
]
14 . 3

28. ERROROBJECTS
HTTP/1.1 422 Unprocessable Entity
Content-Type: application/vnd.api+json
{
"errors": [
{
"status": "422",
"source": { "pointer": "/data/attributes/name" },
"title": "Invalid Attribute",
"detail": "Meetup name must contain at least three characters."
}
]
}
15

29. QUERYPARAMS
ltering
sorting
GET /meetups?filter[venue]="VarnaLab" HTTP/1.1
Accept: application/vnd.api+json
GET /meetups?sort=name HTTP/1.1
Accept: application/vnd.api+json
GET /meetups?sort=-name HTTP/1.1
Accept: application/vnd.api+json
16 . 1

30. sparse eldsets
GET /meetups?fields[meetups]=name HTTP/1.1
Accept: application/vnd.api+json
{
"data": [
{
"id": "1",
"type": "meetups",
"attributes": {
"name": "PHP Varna"
}
},
{
"id": "2",
"type": "meetups",
"attributes": {
"name": "WordPress Varna"
}
}
16 . 2

31. PAGINATION
GET /meetups?page[number]=3&page[size]=1 HTTP/1.1
Accept: application/vnd.api+json
16 . 3

32. {
"meta": {
"total-pages": 12
},
"data": [
{
"type": "meetups",
"id": "2",
"attributes": {
"name": "WordPress Varna",
"description": "The place for WordPress entusiasts",
"next-meetup": "",
}
}
],
"links": {
"self": "/meetups?page[number]=2&page[size]=1",
"first": "/meetups?page[number]=1&page[size]=1",
"prev": "/meetups?page[number]=2&page[size]=1",
"next": "/meetups?page[number]=4&page[size]=1",
"last": "/meetups?page[number]=12&page[size]=1"
}
}
16 . 4

33. RESOURCEOPERATIONS
listing
show 404 examples
get individual resource
create
show validation errors examples
update
delete
17

34. CREATEAMEETUP
POST /meetups HTTP/1.1
Content-Type: application/vnd.api+json
Accept: application/vnd.api+json
{
"data": {
"type": "meetups",
"attributes": {
"name": "JS Varna?",
"desription": "Does Varna need another meetup?"
},
"relationships": {//optional}
}
}
18

35. FRACTAL
Like a view layer for your
JSON/YAML/etc.
19

36. MAINCONCEPTS
Fractal Manager
Resource
Includes
Serializer
Transformer
Pagination
via paginator
via cursor
20

37. RESOURCES&TRANSFORMERS
Closure transformer
use LeagueFractalResourceItem;
$meetup = retrieveFromDB();
$meetupResource = new Item($meetup, function($m) {
return [
'id' => $meetup->id,
'name' => $meetup->name,
'description' => $meetup->description,
'next-meetup' => $meetup->events->getNext()->date
];
});
21 . 1

38. Class transformer
use LeagueFractalTransformerAbstract;
use LeagueFractalResourceCollection;
class MeetupTransformer extends TransformerAbstract
{
public function transform(Meetup $meetup)
{
return [
'id' => $meetup->id,
'name' => $meetup->name,
'description' => $meetup->description,
'next-meetup' => $meetup->events->getNext()->date
];
}
}
$data = new Collection($meetups, new MeetupTransformer);
21 . 2

39. De ning includes
use LeagueFractalTransformerAbstract;
use LeagueFractalResourceCollection;
class MeetupTransformer extends TransformerAbstract
{
protected $availableIncludes = ['venues'];
public function transform($meetup) { ... }
public function includeVenue($meetup)
{
$venue = $meetup->venue;
$transformer = new VenueTransformer;
return $this->item($venue, $transformer, 'venues');
}
}
$data = new Collection($meetups, new MeetupTransformer);
21 . 3

40. Creating a resource
use LeagueFractalSerializerJsonApiSerializer;
$manager = new LeagueFractalManager();
$baseUrl = 'http://meetup.dev';
$manager->setSerializer(new JsonApiSerializer($baseUrl));
// ORM call
$meetup = Meetup::find(1);
// Make a resource out of the data and
$resource = new Item($meetup, new MeetupTransformer, 'meetups');
// Run all transformers
$manager->createData($resource)->toArray();
21 . 4

41. Result
[
"data" => [
"type" => "meetups",
"id" => "1",
"attributes" => [
"name" => "PHP Varna",
"description" => "The php UG in Varna",
"next-meetup" => "2017-05-18T19:30:00.200Z"
]
],
"links" => [
"self" => "http://meetup.dev/meetups/1"
]
]
21 . 5

42. Using includes
use LeagueFractalSerializerJsonApiSerializer;
$manager = new LeagueFractalManager();
$baseUrl = 'http://meetup.dev';
$manager->setSerializer(new JsonApiSerializer($baseUrl));
// ORM call
$meetup = Meetup::find(1);
if (isset($_GET['include'])) {
$fractal->parseIncludes($_GET['include']);
}
21 . 6

43. WHATISMISSINGFROMTHESPEC?
ltering
sorting
sparse eldsets
pagination - present and usable but not spec
compliant
22 . 1

44. PAGINATION
use LeagueFractalResourceCollection;
use LeagueFractalPaginationIlluminatePaginatorAdapter;
use AcmeModelBook;
use AcmeTransformerBookTransformer;
$paginator = Meetup::paginate();
$meetups = $paginator->getCollection();
$resource = new Collection($meetups, new MeetupTransformer);
$resource->setPaginator(new IlluminatePaginatorAdapter($paginator));
22 . 2

45. SUPPORTEDADAPTERS
Laravel
Doctrine
Zend Framework
Phalcon
Pagerfanta
your own PaginatorInterface implementation
22 . 3

46. WHATISNOTINCLUDEDON
PURPOSE?
content negotiation
response code handling
error objects
22 . 4

47. HANDLINGERROROBJECTS
23

48. Use a base class
class JsonApiError extends Exception {
protected $status;
protected $title;
protected $detail;
protected $source;
protected $meta;
public function toArray() {...}
}
24 . 1

49. Extend it for speci c errors
class NotFoundError extends JsonApiError {
protected $status = 404;
protected $title = 'Resource not found';
}
24 . 2

50. EASIERFRACTAL
composer install spatie/fractalistic
A developer friendly wrapper around
Fractal
25 . 1

51. Fractal::create()
->collection($meetups)
->transformWith(new MeetupTransformer())
->includeVenue()
->toArray();
25 . 2

52. ALTERNATIVES
neomerx/json-api
resource transformation
query parameters handling
errors
26

53. RESOURCES
http://jsonapi.org/
http://fractal.thephpleague.com/
https://www.ics.uci.edu/~ elding/pubs/dissertation
Steve Klabnik's talk: past, present and future of json
https://youtu.be/Foi54om6oGQ
discussion: who's using json-api - https://github.com
api/issues/825
27

54. THANKYOU
28

55. QUESTIONS?
29
