RedisConf17 breakout session

2. Operationalizing Redis
At Scale
At Square

7. The Dream
●Standard Setup & Deployment
●Security: SSL/mTLS
●High Availability
●Monitoring & Visibility

8. The Dream
●Standard Setup & Deployment
●Security: SSL/mTLS
●High Availability
●Monitoring & Visibility

9. LXC Container
Hardware
OS
LXC Container LXC Container LXC Container LXC Container

10. • Persistence not guaranteed
• Persistence provided by RDB and AOF do not satisfy our performance requirements
• LRU key eviction
• MAXMEMORY configured on a per application basis
• Treat Redis as an ephemeral in-memory cache
• Resque / Sidekiq “require” persistence
• Force jobs to be idempotent
• Rely on persistence in the form of slaves and failovers
• Asynchronous replication implies that there is always a possibility of lost data
Persistence & Durability

11. • RDB
• BGSAVE causes Redis process does a fork()
• Severe performance hit for larger datasets
• Can result in clients not being served
• Pressure from memory allocations of large data copies
• Potentially requires 2x memory on high write instances
• (Almost) Never perform on the active master
• Since any replica can be failed onto to become the new master, BGSAVEs
can only be reliably run on tertiary replicas
• Disable Redis automated BGSAVEs, opt for manual control instead
Persistence & Durability

12. ●AOF
○appendfsync everysec defaults to an fsync() every 1 second.
○Writes are still lost
○appendfsync always is required to guarantee the persistence we need
○Comes at the cost of speed
○Lower throughput
Persistence & Durability

13. Persistence & Replication

14. • RDB and AOF disabled by default
• If a Redis instance restarts, it will restart with an empty dataset
• That empty dataset will then get replicated across all of its replicas
• Never have Redis restart automatically
• Require manual intervention from DBA for startup
• runit service instead runs our special launch script
• Script will only start redis if a file exists
• /data/redis/redis-start
• Never automatically join clusters
Persistence & Replication

15. The Dream
●Standard Setup & Deployment
●Security: SSL/TLS
●High Availability
●Monitoring & Visibility

16. • Open-source, developed at Square
• Simple SSL/TLS proxy with mutual authentication for securing non-TLS services
• Authentication
• Enforce mutual authentication by always requiring a valid client certificate
• Certificate hotswapping
• Can reload certificates at runtime without dropping existing connections
• Automatic reloading
ghostunnel

17. app
redis-01
RW SIP

18. app
redis-01
RW SIP
ghostunnel-app
:6379
socket

19. app
redis-01
RW SIP
ghostunnel-app
:6379
socket
redis-02
socket
ghostunnel-app
:6379
RO SIP
ghostunnel-repl
:6380

20. $> slaveof localhost 6380
1) OK
$> info replication
# Replication
role:slave
master_host:127.0.0.1
master_port:6380
...
slave0:ip=/unixsocket,port=0,state=online,offset=12345,lag=1
...
GET @@HOSTNAME;

21. $> info server
# Server
...
run_id:1234567890abcdef
...
GET @@HOSTNAME;

22. ●Redis does not implement user access control
●redis.sock accessible only by root
○Available only to DBAs and other infrastructure engineers
●Connecting remotely will require usage of application SSL cert
User Access Control
openssl s_client
-connect $REDIS_HOST:$REDIS_PORT
-CAfile redis-app-1.ca.pem
-cert redis-app-1.crt
-key redis-app-1.key

23. The Dream
●Standard Setup & Deployment
●Security: SSL/mTLS
●High Availability
●Monitoring & Visibility

24. ●Pros
○Monitoring
○Notification
○Automated Failover
●Cons
○Plaintext communication required.
○Even if isolated to a single security zone, cross-DC failovers would not work.
Redis Sentinel

25. • Pros
• Great sharding tool
• High Availability in the event of outage due to its distributed design
• Cons
• Consistency not easy to achieve
• Can enforce consistency, but comes at the cost of performance
• Cannot enforce consistency in the case of network partition
• Does not support SSL/TLS
Redis Cluster

26. DC-1
DC-2
Topology

27. RW SIP
RO SIP
Topology

33. $> info replication
$ Replication
role:master
...
$> config get min-slaves-to-write
1) "min-slaves-to-write"
2) "0"
$> config set min-slaves-to-write 1000
1) OK
SET GLOBAL READ_ONLY=1;

34. $> info replication
$ Replication
role:slave
...
$> config get min-slaves-to-write
1) "min-slaves-to-write"
2) "1000"
SET GLOBAL READ_ONLY=1;

41. The Dream
●Standard Setup & Deployment
●Security: SSL/mTLS
●High Availability
●Monitoring & Visibility

44. Looking Forward
• SpinCycle Automation
• Native SSL/TLS Support
• Square Internal Patches

45. Q&A

46. Links
• https://www.percona.com/live/17/sessions/metrics-
collection-storage-visualization-scale
• https://github.com/square/ghostunnel
• https://github.com/square/p2
• https://github.com/square/spincycle

47. square.com
