This document provides information about the ID_SD and ID_SC pins on the Raspberry Pi. It states that these pins are reserved for connecting an I2C ID EEPROM that identifies an attached board and allows automatic setup of GPIO pins. It instructs the user not to use these pins for any other purpose besides connecting an I2C ID EEPROM, and to leave them unconnected if an ID EEPROM is not required.
