This document summarizes the specifications of the PW-5350-1A wireless router/AP module. It supports both wired and wireless connections with a maximum wireless transmission rate of 150Mbps. It uses the Ralink RT5350 chipset and has external/internal antenna options. It complies with IEEE 802.11b, 802.11g, and 802.11n wireless standards and has a working temperature range of -0°C to 40°C.

1. PW-5350-1A
(产品型号展示优化词：Wireless Router/AP Moudle PW-5350-1A)
Features：
A wireless router WIFI
module
Supports both wireline
and wireless connection.
Wireless transmission
rate can reach up to
150Mbps, which effectively improves performance, rate,
stability, coverage of the wireless transmission.
Supports remote monitoring and remote dual channel monitoring but needs lowest costs.
Specifications:
Item Description
MajorChipset RalinkRT5350
HostInterface 1unit1*4,1unit1*7
Antennatype External/Internalantenna(Option)
Dimension(L*W*H) 20*53mm
Standard IEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.3,IEEE802
.3u,
CSMA/CA,CSMA/CD,TCP/IP,DHCP,ICMP,NAT,PPPoE
FrequencyRange 2.4~2.4835GHz
Channel 1~11(USA,Canada),1~13(China,Europe),1~14(Japan)
Modulationtype 802.11b:DSSS(CCK,DQPSK,DBPSK)
802.11g/n:OFDM(BPSK,QPSK,16QAM,64QAM)
DataTransferRate 802.11b:11,5.5,2,1Mbps;802.11g:54,48,36,24,18,12,9,6Mbps
802.11n:150Mbps(Max.)
Txpower 802.11b11Mbps：13±1dBm
802.11g54Mbps：10±15dBm
802.11n135Mbps：10±15dBm
Sensitivity@PER 135M:-66dBm@10%PER;54M:-70dBm@10%PER;
11M:-84dBm@8%PER;6M:-88dBm@8%PER;1M:-
90dBm@8%PER
Thetransmitdistance 10/100MRJ45reachupto100meters
Powersupply DC5.5V500mA
LEDindicator WIFI(wirelessindicator)USBadapterindicator
www.ttbvision.com

2. NetworkMedia 10Base-T:UTPcategory3,
3ecable100Base-TX:UTPcategory5cable
Management LAN,Internet
Environment Workingtemperature:-0°C~40°C
Workinghumidity:10%~90%non-condensing
Storagetemperature:-20oC~70oC;
Storagehumidity:5%~90%non-condensing
Otherproperties Optionalspectrumbandwidth:20MHz,40MHz,auto
Item Description
MajorChipset RalinkRT5350
HostInterface 1unit1*4,1unit1*7
Antennatype External/Internalantenna(Option)
Dimension(L*W*H) 20*53mm
Standard IEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.3,IEEE802
.3u,
CSMA/CA,CSMA/CD,TCP/IP,DHCP,ICMP,NAT,PPPoE
FrequencyRange 2.4~2.4835GHz
Channel 1~11(USA,Canada),1~13(China,Europe),1~14(Japan)
Modulationtype 802.11b:DSSS(CCK,DQPSK,DBPSK)
802.11g/n:OFDM(BPSK,QPSK,16QAM,64QAM)
DataTransferRate 802.11b:11,5.5,2,1Mbps;802.11g:54,48,36,24,18,12,9,6Mbps
802.11n:150Mbps(Max.)
Txpower 802.11b11Mbps：13±1dBm
802.11g54Mbps：10±15dBm
802.11n135Mbps：10±15dBm
Sensitivity@PER 135M:-66dBm@10%PER;54M:-70dBm@10%PER;
11M:-84dBm@8%PER;6M:-88dBm@8%PER;1M:-
90dBm@8%PER
Thetransmitdistance 10/100MRJ45reachupto100meters
Powersupply DC5.5V500mA
LEDindicator WIFI(wirelessindicator)USBadapterindicator
NetworkMedia 10Base-T:UTPcategory3,
3ecable100Base-TX:UTPcategory5cable
Management LAN,Internet
Environment Workingtemperature:-0°C~40°C
Workinghumidity:10%~90%non-condensing
Storagetemperature:-20oC~70oC;
Storagehumidity:5%~90%non-condensing
Otherproperties Optionalspectrumbandwidth:20MHz,40MHz,auto
