Pull, don’t push: Architectures for monitoring and configuration in a microservices era
- 1. Pull, don’t push! Architectures for monitoring and configuration in a microservices era Julian Dunn, Director of Product Marketing, Chef @julian_dunn Fletcher Nichol, Senior Software Development Engineer, Chef @fnichol
- 3. • Modular, self-contained, pre-fabricated components • Neighbors share components • Complex shares services as a whole
- 7. An ordered set of operations Across a set of independent machines Connected to an orchestrator only via a network.
- 9. Humans acting on Microsoft Visio acting on machines Humans acting on code acting on machines
- 10. An ordered set of operations Defined in code Across a set of independent machines Connected to an orchestrator only via a network.
- 11. mylaptop:~$ ./disable-load-balancer.sh mylaptop:~$ ssh db01 do-database-migration.sh mylaptop:~$ for i in app01 app02; do > ssh $i do-deployment.sh > done mylaptop:~$ ./enable-load-balancer.sh
- 12. Problems with Orchestration Resilience Scalability Deployment Technical Operational Cognitive
- 13. Deployment Resilience for i in app01 app02 app03; do do-deploy.sh –server $i done
- 14. Deployment Resilience for i in app01 app02 app03; do do-deploy.sh –server $i if $? != 0; then failed=$i break end done # what goes down here? # roll back $failed? # roll back all others? # ignore it?
- 17. Operational Resilience Orchestration Backplane – must be up at all times! Application Plane – delegated resilience to the backplane
- 18. Operational Resilience Orchestration Backplane Application Plane Orchestration Backplane
- 22. Mainframes Time Sharing Client/Server Web 1.0 Web 2.0 Cloud Internet of Things Edge Time Distributed Centralized The Future Is Distributed
- 24. Distributed Devices Need Distributed Management • Adaptive Learning • Configuration Updates • Software Updates
- 25. Distributed, Autonomous Systems Make progress towards promised desired state Expose interfaces to allow others to verify promises Can promise to take certain behaviors in the face of failure of others
- 26. The Design of Sensu and The Design of Habitat
- 27. The Design of Sensu vs. Traditional “Monitoring” Nagios master Agent 1 Agent 2 1. Poll (orchestrate) 2. Run checks 1. Run checks Agent 1 Agent 2 Sensu Backend 2. Post data
- 28. Habitat supervisor in a nutshell •Network-connected supervision system •Like systemd+consul/etcd (process supervision with lifecycle hooks + shared state for reactive realtime change management) •Eventually-consistent global state using SWIM masterless (peer-to-peer) membership protocol
- 29. sensu- backend hab-sup sensu- backend hab-sup sensu- backend hab-sup backend.default sensu- agent hab-sup agent.default --bind sensu:backend.default Resolve symbol “sensu” in configs to properties of service group backend.default
- 30. Let’s See it in Action! Demo: Sensu running under Habitat
- 31. • Modern architectures demand a choreographed rather than an orchestrated approach • At scale, fleet management and cognitive complexity is the biggest problem • Habitat and Sensu are both examples of edge-centric, autonomous actor systems, and they work well together 😺
Editor's Notes
- Fletcher and I were part of the original team that launched Habitat by Chef in 2016; I was the product manager and Fletcher was one of the lead engineers. We both have technical backgrounds, except that we do different jobs now. Fletcher’s computer boots into Linux and mine boots into PowerPoint.
- So this is a talk about architecture and systems design, and if we’re going to talk about architecture maybe a good way to think about good architecture is via, well, actual architecture. One of the most famous buildings in the world is the Habitat 67 complex in Montreal, built, as you can see, for Expo 67, which was Canada’s 100th anniversary. Shout out, by the way, to the Canadians in the room, including Sean Porter, Sensu’s CTO; Fletcher and I are both Canadians so we have to make a pitch for the Great White North anytime we're up here. Universal health care! One year of paid maternity leave! Super-hot prime minister! Ok, that's enough of that Anyway, Habitat 67 was such an iconic building that Canada Post put it on the stamp for Canada’s 150th anniversary last year.
- Here’s another picture, in its full glory. Probably would have actually used shipping containers today but remember, TEU (standardized) containerization didn’t arrive until the late 1960’s. But the components were standardized as you can see from the middle versus the right One unit’s roof is the other neighbor’s garden Shopping, schools, common services built into the ground floor of each complex These things sound a lot like software architectural principles Every component is responsible for its own resiliency (like Bezos’ infamous memo) Components declare peer-to-peer level dependencies All components share a base substrate of services and management (e.g. deployment, monitoring, observability, etc.)
- The Habitat 67 complex is actually quite large
- I wanted to put the big pictures up of Habitat 67 because, well, architecture starts to look a lot like architecture, right? These are visual diagrams (probably several years old) of microservice architectures at Amazon and Netflix. When you have complex systems this big, there are architectural patterns you’ll need to put in place to deal with it. Because when you get to something big and complex, your issue isn’t adding more to it – your issue becomes how do you manage this. Today’s talk which is really about how you design complex systems so that you can _manage_ them. It’s better to design systems with these characteristics built-in up front rather than to try and bolt them on later.
- Which brings me to the patterns of management for complex systems. Traditionally, we have and in many scenarios we continue to try and manage things using a centralized approach, which I call “orchestration”. So does everyone else, unfortunately, so let me define what I mean by this.
- IBM Cloud Orchestrator HP Operations Orchestration VMWare vRealize Orchestrator
- But since I’m in the orchestration track I’d better try to define it so that I actually have a talk, right? Here is the definition I'll be using for the rest of the talk. And then I’m still going to tell you how and why that breaks down.
- This is a trivial example of orchestration. Last year I said I at least hope you’re doing your orchestration in code, if you’re doing orchestration, because this is pretty awful. And as you can see, it causes downtime because you need to wait for the previous thing to complete before you can proceed with the next one. You can add more fancy error checking and branching to orchestration to try and handle no-downtime deploys, but that orchestration gets really complicated – more complexity means more error conditions means more things that need to be handled.
- Resilience Deployment Operational Scalability Technical Cognitive
- Treating machines all connected via an unreliable network as an atomic unit to which updates must be applied in full, or not at all This *used* to work when you had a small fleet and/or your network was mostly reliable (e.g. on a LAN) - not so good in a cloud
- An atomic set that is assumed to succeed as a whole or not. What happens when it doesn't? A lot of complexity in failure conditions that need to be encapsulated and dealt with. Or more commonly, the approach is to drop this all off on the operator's lap and have them deal with it.
- Modern orchestration systems try to get around this fundamental issue by creating more disposability and just throwing away larger and larger parts of the infrastructure. The theory goes, let’s get the exact right “new” setup first, and then cut over to it. The problem is that while this mostly works, it is an incredibly complicated and slow way to make changes – you’re saying that for every config change or deployment I have to stand up a whole new production environment and cut over everything to it? For example, how do I do things like quiesce writes to a database? I think this creates more complexity even though the interfaces seem really attractive.
- Orchestration systems treat application components as dumb entities to be scheduled. Those entities don’t know about each other except through the orchestration system. This means that if components fail, they depend on the orchestration backplane (and here I’m picking on Kubernetes again) to manage their lifecycle. They also depend on the orchestration backplane to tell them where the other entities are (like where the database server is, if I’m the app server). The apps themselves are deliberately kept in the dark about their execution context.
- Now remember, we’re running in the cloud now – a place where machines and networks can go down at any time. And we’re trying to build reliable applications on top of that unreliable fabric.
- Now who does such a system design benefit? It only benefits the person or organization that is running the orchestration backplane – that is, if it’s external to the unreliable vagaries of the “cloud”. In other words, if it’s, say, a hosted service provided by your cloud vendor? Kubernetes and other orchestration systems soften you up for that approach so that when you run into the inherent resilience limitations, you outsource. Therefore I believe Google has never intended that you run a Kubernetes cluster on your own, but to buy it from someone (hopefully them) as a managed service. And don’t get me wrong, it’s an amazing business model, and, if you can offer your developers an experience on top of all this that’s just “push a container and it runs”, then that’s great. This is why there has been this Precambrian explosion of hosted Kubernetes solutions... Because these vendors know that this architectural model locks you into building applications on their platform. When your app is operationally dumb and the backplane is operationally smart, they have your money forever.
- I don’t have that much to say about this one other than that orchestration systems or operations become really difficult to understand the more entities you’re trying to address. In particular because an orchestration activity (“play”) is intended to run to completion, atomically, trying to debug failures halfway through and figure out what to do is really hard. When things go wrong, it’s easier for the human brain to try and understand a small part of the system – where the fault is – rather than the entire global state. We know this with computer programming (“locality of reference”) and that’s why we have techniques like “information hiding” (i.e. abstracting logic).
- We used to show this slide as part of old Opscode training materials when I first started at Chef. I’m sure you’ve seen slides like this before, where we talk about the # of nodes running applications, etc, and how they grow over time. While this is all true, I think these graphs neglect one key thing, which is not that the *quantity* of machines increases over time, but the fact that systems as a whole tend towards becoming more *distributed*. By "distributed" I mean that more of the computing runs at the "edge" if you will and not in a centralized way.
- It’s not a straight line, though. <Talk through the build> Cloud: ML, databases, etc. – now starting to centralize more stuff into the cloud. The more that our systems become distributed, the less a centralized approach makes sense. This is true not only for data processing (why can’t it happen at the edge), but also to configuration updates and even software upgrades.
- https://medium.com/@timanglade/how-hbos-silicon-valley-built-not-hotdog-with-mobile-tensorflow-keras-react-native-ef03260747f3 Tensorflow, Keras, React Native First version was centralized – too much latency So the final version runs an entire neural network on your phone.
- Nike HyperAdapt shoe Number of devices continues to increase Machine Learning, Analytics, AI Latency becomes currency At-scale problems will re-emerge just like they did with Client/Server and the Web Distributed devices need distributed management
- Sounds a lot like wherein we started with convergent configuration management and this guy, right? Everything old is new again.
- Using SWIM rather than something like RAFT, because SWIM is masterless
- This slide will be a build to show some of Habitat’s terminology, specifically: Service group Contains one or more entities that share a configuration template, but run the same workload Leaders and followers are in the same group Have a name Supervisors are responsible for [re-]writing configuration of the workload and restarting the process, possibly in coordination with other supervisors in that group Supervisors have a REST interface that allows you to modify their config (inject new configs as rumors into the network – they will be propagated. Can use any authorized supervisor as an entrypoint, doesn’t have to be the group we care about) External service groups can be subscribed to the configuration of this service group using binding Talk about communication protocol across the fleet – SWIM membership protocol/failure detector, with a gossip layer on top for distributed consensus Because we get asked a lot of questions about the protocol, it is an implementation of SWIM It's an implementation of SWIM+Infection+Suspicion for membership, and a ZeroMQ based newscast-inspired gossip protocol. Goals Eventually consistent. Over a long enough time horizon, every living member will converge on the same state. Reasonably efficient. The protocol avoids any back-chatter; messages are sent but never confirmed. Reliable. As a building block, it should be safe and reliable to use.
- Config changes: injected into any peer, ACL is checked, and if accepted, gossiped around the network. No SPOF.
