12. 서버 용량 산정
TPS
(Transaction Per Second / 초당처리량)
• 초당처리량(TPS)= 활성 사용자(Active User) / 평균 응답 시간(Average Response Time)
• 초당처리량(TPS)= 동시 사용자(Concurrent User) / 요청 주기(Request Interval)
• 활성 사용자(Active User) = TPS * 평균 응답 시간(Average Response Time)
• 활성 사용자(Active User) = 동시 사용자(Concurrent User) * 평균 응답 시간(Average Response Time)
/ 요청 주기 (Request Interval)
• 활성 사용자(Active User) = 동시 사용자(Concurrent User) * 평균 응답 시간(Average Response Time) /
[ 평균 응답 시간(Average Response Time) + 평균 Think 타임(Average Think Time) ]
13. 서버 용량 산정
• 활성 사용자 : 96.77
• 3000 * 0.5 / (0.5 + 15)
• 동시 사용자 * 평균 응답 시간 / [ 평균 응답 시간 + 평균 Think 타임 ]
• 필요 TPS : 193.56
• 50 / 0.5
• 초당처리량(TPS)= 활성 사용자 / 평균 응답 시간
동시 사용자 3000명, 목표 응답 시간 0.5초,
Think Time 15초 일 경우
14. 서버 용량 산정
그런데.. 구식…
Cloud 환경에서는 의미가 퇴색
On-Demand / AWS T2 instance / Scaling Group
15. 서버 용량 산정
일단 만들고
성능을 측정해본 다음
투입 서버 사양 / 개수 결정
이후 비용을 줄이기 위해 서버 최적화
16. 로드를 주는 방법?
스크립트 방식/폼 채워넣는 방식
ApacheBench? JMeter?
Gatling? nGrinder?
테스트는 어떻게?
17. 무제한 로드 부여 가능 / 대규모 테스트에 적합
컨트롤러 테스트 대상 서버
로드 생성기
부하제어
스크
립트
분산 테스트
테스트는 어떻게?
31. 스크립팅 – 트랜잭션
Gtest test = new Gtest(1, “통계1”)
MyTest object = new MyTest();
test.record(object, “sendMessageToGoogle”)
class MyTest {
public void sendMessageToGoogle() {
구글에 HTTP를 보내고, 결과 검증
}
….
}
통계 1을 준비하라
여기까지 왔으면 테스트가 성공한거다. 통계1에 트랜잭션을 하나 올려라
34. 테스트 준비시 고려사항
비용
(트래픽/스토리지)
외부 의존성
(블록킹 당할 수 있음)
캐시 효과
(주로 같은 유저 ID에 대한 지속적 호출시)
네트웍 딜레이 포함 여부
(에이전트를 타겟 네트웍과 같은 네트웍에 배치?)
Think Time 포함 여부
(제거시 동시사용자=활성사용자)
35. 테스트 준비시 고려사항
스트레스 테스트
• 주로 장기간 수행
그러나 초기에는 오류때문에
장기간 수행할 수 없을 것
• 개발서버 대상
• 외부 API는 Mock으로 대체
• 캐시 효과 크게 고려하지 않음
• 네트웍 딜레이 제거함
• Think Time 제거함
로드 테스트
• 주로 단기간 수행
• 개발서버+스테이징서버+
실서버 대상
• 외부 API 그대로 유지
• 캐시 효과 제거
• 네트웍 딜레이 제거는 유동적
• Think Time 제거함
51. 성능 테스트에서 주로 발견되는 문제
부적절한 Pool 개수
(작은 커넥션 풀 또는 WAS커넥션풀<DB커넥션풀)
락킹
(synchronized 구문)
Non-Tread Safe 코드에 의한 비정상 동작
(HashMap, ArrayList)
DB 인덱스 설정 오류 / 불필요한 DB 호출
지나친 로깅 또는 부적절 로거 설정
Full GC
(메모리 Leak / 리소스 Leak)
단순 로직 오류
52. 테스트 결과 분석 - Rule of Thumbs
테스트 도구를 의심하지 말것!
문제는 스크립트를 잘못 짰거나
서버가 잘못 동작하는 것임
53. 테스트 모니터링
ngrinder monitor – CPU/메모리/네트웍
[ec2-user ~]$ wget --content-disposition 링크주소
[ec2-user ~]$ tar xvf 모니터파일명.tar
[ec2-user ~]$ cd ngrinder-monitor && run-monitor-bg.sh
55. 테스트 모니터링
pinpont – 대규모 시스템 성능 모니터링
XX XX
https://github.com/naver/pinpoint
56. 사례1 – JVM 메모리 부족
• 부하를 생성하는 타겟으로
커넥션을 맺지 못함
• 서버의 CPU/MEM은 여유가
있는 상황
• 서버측에 CLOSE_WAIT된 소
켓이 존재할 거라 생각했지
만 원인이 아님
• JVM 모니터를 통해 Full GC
발생이 잦고 발생 시점에
TPS가 떨어지는 것을 확인
• JVM 메모리 증가후 증가시
켜 원하는 부하에서 응답을
줄 수 있도록 튜닝
57. 사례2 – ulimit
• 생각보다 성능이 않나오고,
vuser 를 증가시키더라도
추가된 vuser 는
접속 오류 발생
• CPU/메모리/네트웍은
놀고 있는 상황.
• Ulimit을 늘린후 성능 개선
