Power_Systems_Load Characteristics .pptx
1. LOAD CHARACTERISTICS
Badon, Joven M.
Biscocho, Jake B.
Garcia, Jammil Arvin
G.
Habig, Jhon Paul G.
Pelagio, Joshua A.
Rosales, Russian L.
2. The load characteristic plays an important role in:
๏ถ Determining the total power and energy requirements of the
system
๏ถ Planning the installed capacity of a power plant
๏ถ Selection of suitable generating capacity for each unit of the
plant
Load
Electrical power needed in kW or kVA
Demand
The power requirement (in kVA or kW) at the load
averaged over a specified interval (15 min or 30 min). Sometimes
it is given in amperes at a specified voltage level.
Demand Intervals
The time interval specified for demand (Di), usually 15 or
30 min. This is obtained from daily demand curves or load
duration curves.
Maximum Demand
3. Connected Load
The sum total of the continuous rating of all the apparatus,
equipment connected to the system
Demand Factor
The ratio of maximum demand to the total load connected to
the system
Utilization Factor
The ratio of maximum demand to the rated capacity of the
system
Load Factor
The ratio of average load in given interval of time to the
peak during the interval
Annual Load Factor
The ratio of total energy supplied in a year to annual peek
4. Diversity Factor ( Df )
The ratio of sum of the individual maximum demands of various
sub-divisions of the system to the maximum demand of the entire or
complete system.
Coincident Maximum Demand ( Dg )
Any demand that occurs simultaneously with any other demand
and also the sum of any set of coincident demands.
Coincidence Factor ( Cf )
This is usually referred to a group of consumer or loads. It is
defined as the ratio of coincident maximum demand Dg to sum total of
maximum demands of individual or group of loads.
Loss Factor
This is the ratio of average power loss in the system to power
loss during peak load period and referred to the variable power losses,
copper losses or power loss in conductors or windings but not to no
5. Load & Load Characteristics
A load or power requirement (also kVA) of a consumer varies
widely. But in general the consumers can be grouped into a few
categories as their needs and demands are the same.
Broad classifications of loads are:
๏ถ Domestic and residential loads
๏ถ Only lighting loads (such as for street lights )
๏ถ Commercial loads (shops, business establishments, hospitals)
๏ถ Industrial Loads Note: All these loads will have peak demands at
different times ad different durations Industrial and commercial
loads may have two peak load periods
๏ถ Agricultural loads are seasonal and vary very differently
๏ถ Lighting loads such as street lighting may have almost zero demand
during day time and constant
6. Another classification of electrical load is the billing categories
used by the electrical distribution authorities or State electricity
boards. This includes categories such as residential and domestic,
industrial, commercial, rural, HT consumers and others.
System Power Factor
In ac systems, kVA demand is more appropriate that kW and
load power factor is of importance. Typical p.f. of residential,
commercial and industrial loads are as follows.
๏ถ Fluorescent Lamps : 0.6
๏ถ Arc lamps and neon signs : 0.4 - 0.7
๏ถ Fans and small motors : 0.5 - 0.8
๏ถ Electronic gadgets : 0.6 - 0.8
๏ถ Domestic appliance : 0.6 โ 0.7
7. Domestic and Residential Loads
The important part in the distribution system is domestic and
residential loads as they are highly variable and erotic. These
consist of lighting loads, domestic appliances such as water heaters,
washing machines, grinders and mixes, TV and electronic gadgets
etc. the duration of these loads will be few minutes to few hours in
a day. The power factor of these loads in less and may vary
between of 0.5 to 0.7. In residential flats and bigger buildings, the
diversity between each residence will be less typically between of
1.1 to 1.15. the load factor for domestic loads will be usually 0.5
to 0.6.
8. Industrial Loads
Industrial loads are of greater importance in distribution
systems with demand factor 0.6 to 0.7. For heavy industries demand
factor may be 0.9 and load factor 0.7 to 0.8 Typical power range
for various loads Cottage and small-scale industries: 3 to 20 kW
Medium industries (like rice mills, oil mills, workshops, etc.) : 25 to
100kW Large industries connected to distribution feeders (33 kV and
below) :100 to 500kW.
Water supply and Agricultural Loads
Most of the panchayats, small and medium municipalities have
protected water system which uses pumping stations. They normally
operate in off peak time and use water pumps ranging from 10 hp to
9. Agricultural and Irrigation Loads
Most of the rural irrigation depends on ground water pumping
of lifting water from tanks or nearby canals. In most cases design
and pump selection is very poor with efficiencies of the order of
25%. Single phase motors are used (up to 10 hp) for ground water
level 15m in depth or less with discharge of about 20 l/sec while
multi stage submersible pumps with discharge of 800 to 1000 l/m
may require motors of 15 to 20 hp.
Sensitive and Important Loads
With computer applications in every area, computer loads and
computer controlled process loads are often non-linear and sensitive.
They require close tolerance limits for voltage and frequency
(voltage limit + 5% and frequency + 5% Hz with unbalance and wave
10. Load Curves and Load-Duration Curves
The consumption of electrical power or energy by any utility
varies from time to time in a day as well as during a week, month,
season or year. For example in summer fans, AC units, cooler etc
are used but not during winter or cold season. Industries working
during day time will consume only lighting load during night(10pm to
6am). Hence knowledge of variation of loads and their nature is
essential for distribution planning. The load characteristics are
usually presented as load curves and load duration curves.
a. Load Curves
The load (power requirement) of any concern or unit is
tabulated as the amount of power required or consumed during a
certain period in a day, week or a given season.
11. b. Load-Duration Curves
This is a graph obtained from load curve showing the load in
(kW) and duration over which it occurs in descending order of load
magnitudes.
Example: Typical 11 kV Line.
