2. Introduction
• Present when horizontal deviation change
in magnitude from up gaze to downgaze
• Type of Incomitant strabismus
• Described using alphabets
Alphabetical pattern
4. Defination:
• Measured in Primary gaze, 25 degree
upgaze, 35 degree downgaze
• V pattern: difference of ≥15 PD
• A-pattern: difference of ≥10 PD
Depending on primary gaze :
V or A Esotropia / Exotropia
7. PREVALANCE
A or V pattern: 12.5% -50 %
V-Esotropia – most common pattern associated
with Infantile Strabismus.
A pattern-most commonly seen in XT (Trisomy
21, Spina bifida)
9. 1. HORIZONTAL THEORY
• Horizontal rectus muscles are the culprits
‘V’ ET – over action of MR
‘V’ XT – over action of LR
‘A’ ET – Under action of LR
‘A’ XT –under action of MR
10.
11. 2.Oblique muscle dysfunction:
• Actions of Oblique muscle?
IO OA or SO underaction: V pattern
IO underaction or SO OA: A pattern
12. 3.Vertical rectus muscle dysfunction
SR underaction: less
adduction on elevation
IR overaction: more
adduction in depression
V-pattern
13. 4.Anatomical anomalies of orbits:
Cause dysfunction of Oblique Muscles
• Mongoloid features: IO underaction – A-pattern
• Antimongoloid features: IO overaction: V-pattern
14.
15. • The trochlea acts as the functional
origin of superior oblique
• Sagittalisation– anterior positioning
of trochlea. Oblique muscles
become more parallel to the
antero-posterior axis
• De- sagittalisation– posterior
positioning of trochlea. Oblique
muscles become more parallel to
coronal plane
16. V pattern
SO weakening
IO overaction
De-sagittalisation
Plagiocephaly
A pattern
SO overaction
Sagittalisation
Hydrocephalus
Frontal bossing
17. 5. The Pulley effect
DISPLACED MUSCLE : Action BECOME WEAKER
Upward displacement of LR: weak abduction on elevation- A pattern
Downward displacement of LR: V pattern
18. Craniofacial anomaly with associated pattern:
Crouzon’s syndrome (mid facial hypoplasia)
This boy shows the classic “V” pattern seen in
Crouzon’s syndrome. There is overelevation and
underdepression of each eye in adduction.
19. Clinical presentation:
• Intermittent transient diplopia:
• Asthenopic symptoms: mainly during near work in V-Eso and
A-Exo
• Abnormal head posture : to attain BSV
V-Eso:
V-Exo:
A-Eso:
Chin depressed
Chin elevated
Chin elevated
20. WORK-UP
Routine squint evaluation
Measurement in 9 cardinal gaze.
25 degree up and 35 degrees down gaze.(33cm)
‘V’ -15 Prism difference between up and down gaze.
‘A’ -10PD difference between up and down gaze.
Clinical significance-Depends on with which it
interferes with normal binocular function in the
physiologically important positions of gaze
21. All cases of exo or eso deviations should be checked for A or V
patterns
A. Measurement of deviation
von Noorden’s technique
- 33 cm fixation distance
- full refractive correction
- 25 degree elevation &
35 degree depression
22. B. Version test
- most important for planning and management of A-
V pattern.
- overactions and underactions of oblique muscles
noted.
C. BSV in the primary and downward positions of gaze
23. Management
Treatment of refractive error and amblyopia if present.
Indications for the surgery
1. To improve , maintain or regain binocular single vision
2. Cosmetic improvement
3. Chin elevation or depression.
24. 1. OBLIQUE MUSCLE SURGERY :
• Done in presence of oblique muscle overaction
• V- pattern : weakening of overacting IO muscle
• A- pattern : weakening of overacting SO muscle
25. IO weakening
• Disinsertion
• Myectomy
• Recession
• Anterior transposition if
associated with DVD
SO weakening
• Tenotomy
• Recession
• Silicon expander
• Translational recession
28. 2.Horizontal Muscle surgery
Combined with vertical transposition of
their insertion.
Principle: to shift the muscle in the
direction you want to weaken them
29. • V- pattern :
LR shifted upwards and MR downwards
• A- pattern :
MR shifted upwards and LR downwards.
Editor's Notes
X-pattern in Type 1 DRS (upshot and downshoot) because of tight LR and nothing to do with IO and SO In Y pattern its concern to parents as they look up…can look like IOOA but its mainly d/t aberrant innervation of LR in upgaze…Can operate with LR supratransposition lambda pattern has typical SOOA, weaken SO
This wide range is because ethnic and systemic factors influence the incidence of pattern strabismus and the make-up of each series.
Aesthonic symptoms occur as eyes has to be maintained in a certain gaze for long to aquire BSV
The pitfall in dealing with oblique weakening procedure in adult patient with fusional capability is that they might develop torsional diplopia not being able to compensate for the torsional effect of weakened muscle
