2. Esta obra está bajo una licencia Reconocimiento 2.5 México de
Creative Commons. Para ver una copia de esta licencia, visite
http://creativecommons.org/licenses/by/2.5/mx/ o envíe una carta a
Creative Commons, 171 Second Street, Suite 300, San Francisco,
California 94105, USA.
3. Acerca de:
En la compilación de esta obra se utilizaron libros conocidos en el
ambiente Java, gráficas, esquemas, figuras de sitios de internet,
conocimiento adquirido en los cursos oficiales de la tecnología Java. En
ningún momento se intenta violar los derechos de autor tomando en
cuenta que el conocimiento es universal y por lo tanto se puede
desarrollar una idea a partir de otra.
La intención de publicar este material en la red es compartir el esfuerzo
realizado y que otras personas puedan usar y tomar como base el
material aquí presentado para crear y desarrollar un material mucho más
completo que pueda servir para divulgar el conocimiento.
Atte.
ISC Raúl Oramas Bustillos.
rauloramas@profesorjava.com
4. Java Language Basics
• Anatomy of a Simple Java Program
• Built-In Data Types
• Autoincrement/Decrement Operators
• Java Expressions
• Casting
• Block Structured Languages and the Scope of a Variable
• Controlling a Program’s Execution Flow.
• Exercises
5. Anatomy of a Simple Java Program.
Comments
main
method
class “wrapper”
18. Java Expressions.
An expression is a combination of one or more operators and operands.
Expressions usually perform a calculation. The value calculated does not have to
be a number, but it often is. The operands used in the operations might be
literals, constants, variables, or other sources of data.
Many programming statements involve expressions. Expressions
are combinations of one or more operands and the operators used
to perform a calculation.
20. Casting
• Java automatically casts implicitly to larger data types.
• When placing larger data types into smaller types, you must use explicit
casting to state the type name to which you are converting.
21. Casting
The rules governing automatic casting by the Java compiler are as follows when
considering two operands within an arithmetic expression:
– If either type is double, the other is cast to a double
– If either type is float, the other is cast to a float
– If either type is long, the other is cast to a long
– Else both operands are converted to int
22. Casting
int num1 = 53;
int num2 = 47;
byte num3 = (byte)(num1 + num2) //ok nhpp
int valor;
long valor2 = 99L;
valor = (int)valor2; //no hay pérdida de precisión
int valor;
long valor2 = 123987654321;
valor = (int)valor2; //el número se trunca
29. Block Structured Languages and the Scope of a Variable
Java is a block structured language. A “block” of code is a series of zero or more
lines of code enclosed within curly braces {…}
32. Conditional Statement Types: if-else
• An if-else statement is a conditional expression that must return a
boolean value
• else clause is optional
• Braces are not needed for single statements but highly recommended for
clarity
38. Controlling a Program’s Execution Flow. If-else: ?
• Shortcut for if-else statement:
(<boolean-expr> ? <true-choice> : <false-choice>)
• Can result in shorter code
–Make sure code is still readable
39. Controlling a Program’s Execution Flow. Switch
• Switch statements test a single variable for several alternative values
• Cases without break will “fall through” (next case will execute)
• default clause handles values not explicitly handled by a case
42. Looping Statement Types: while
• Executes a statement or block as long as the condition remains true
• while () executes zero or more times’
• do...while() executes at least once.
47. Looping Statement Types: for
• A for loop executes the statement or block { } which follows it
– Evaluates "start expression" once
– Continues as long as the "test expression" is true
– Evaluates "increment expression" after each iteration
• A variable can be declared in the for statement
– Typically used to declare a "counter" variable
– Typically declared in the “start” expression
– Its scope is restricted to the loop
49. for vs. while
• These statements provide equivalent functionality
– Each can be implemented in terms of the other
• Used in different situations
– while tends to be used for open-ended looping
– for tends to be used for looping over a fixed number of iterations
51. Branching statements
• break
– Can be used outside of a switch statement
– Terminates a for, while or do-while loop
– Two forms:
• Labeled: execution continues at next statement outside the loop
• Unlabeled: execution continues at next statement after labeled loop
53. Branching statements
• continue
– Like break, but merely finishes this round of the loop
– Labeled and unlabeled form
• return
– Exits the current method
– May include an expression to be returned
• Type must match method’s return type
• Return type “void” means no value can be returned
57. Abstraction and Modeling
• Simplification Through Abstraction
• Generalization Through Abstraction
• Reuse of Abstractions
• Inherent Challenges
• Exercises
57
58. Simplification Through Abstraction
Abstraction: a process that involves recognizing and focusing
on the important characteristics of a situation or object, and
filtering out or ignoring all of the unessential details.
– Is the process of ignoring details to concentrate on essential
characteristics
– Is the primary means of coping with complexity
– Simplifies user’s interaction with abstracted objects
58
61. Simplification Through Abstraction
As an abstraction, a road map represents those features of a given geographic
area relevant to someone trying to navigate with the map, perhaps by a car:
major roads and places of interest, obstacles such as major bodies of water, etc.
Of necessity, a road map cannot include every building, tree, street sign,
billboard, traffic light, fast food restaurant, etc. that physically exists in the real
world. If i did, then it would be so cluttered as to be virtually unusable; none of
the important features would stand out.
61
62. Simplification Through Abstraction
Compare a road map with a topographical map, a climatological
map, and a population density map of the same region: each
abstracts out different features of the real world – namely, those
relevant to the intender user of the map in question.
62
63. Simplification Through Abstraction
As another example, consider a landscape. An artist may look at the landscape
from the perspective of colors, textures, and shapes as a prospective subject for
a painting.
63
64. Simplification Through Abstraction
A homebuilder may look at the same landscape from the perspective of where
the best building site may be on the property, assessing how many trees will need
to be cleared to make way for a construction project.
64
66. Generalization Through Abstraction
If we eliminate enough detail from an abstraction, it becomes
generic enough to apply to a wide range of specific situations
or instances. Such generic
abstractions can often be
quite useful. For example,
a diagram of a generic cell
in the human body might
include only a few features
of the structures that
are found in an actual cell:
66
67. Generalization Through Abstraction
This overly simplified diagram doesn’t look like a real nerve cell, or a real
muscle cell, or a real blood cell; and yet, it can still be used in a educational
setting to describe certain aspects of the structure and function of all of these
cell types – namely, those features that the various cell types have in common.
67
68. Organizing Abstractions Into Classification Hierarchies
Even though our brains are adept at abstracting concepts such as road maps and
landscapes, that still leaves us with hundreds of thousands, if not millions, of
separate abstractions to deal with over our lifetimes. To cope with this aspect of
complexity, human beings systematically arrange information into categories to
established criteria; this process is known as classification.
68
71. Organizing Abstractions Into Classification Hierarchies
For example, science categorizes all natural objects as belonging to either the
animal, plant, or mineral kingdom. In order for a natural object to be classified
as an animal, it must satisfy the following rules:
It must be a living being
It must be capable of spontaneous movement
It must be capable of rapid motor response to stimulation
71
72. Organizing Abstractions Into Classification Hierarchies
The rules for what constitute a plant, on the other hand, are diferent:
It must be a living being (same as for an animal)
It must lack an obvious nervous system
It must possess cellulose cell walls
72
73. Organizing Abstractions Into Classification Hierarchies
Given clear-cut rules such as these, placing an object into the appropriate
category, or class, is rather straightforward. We can then “drill down”,
specifying additional rules which differentiate various types of animal, for
example, until we’ve built up a hierarchy of increasing more complex
abstractions from top to bottom.
73
74. Organizing Abstractions Into Classification Hierarchies
A simple example of an abstraction hierarchy is shown below.
Natural Objects
Plant Animal Mineral
Mammal Fish Bird Reptile Insect
Dog Cat Monkey
74
75. Organizing Abstractions Into Classification Hierarchies
When thinking about an abstraction hierarchy such as the one shown previously,
we mentally step up and down thehierarchy, automatically zeroing in on only the
single layer or subset of the hierarchy (known as a subtree) that is important
to us at a given point in time. For example, we may only be concerned with
mammals, and so can focus on the mammalian subtree:
Mammal
Dog Cat Monkey
75
76. Organizing Abstractions Into Classification Hierarchies
We temporarily ignore the rest of the hierarchy. By doing so, we automatically
reduce the number of concepts that we mentally need to “juggle” at any one
time to a manageable subset of the overall abstraction hierarchy; in the
simplistic example, we are now dealing with only four concepts rather than the
original 13. No matter how complex an abstraction hierarchy grows to be, it
needn’t overwhelm us if it is properly organized.
Mammal
Dog Cat Monkey
76
77. Organizing Abstractions Into Classification Hierarchies
Coming up with precisely which rules are necessary to properly classify an object
within an abstraction hierarchy is not always easy. Take for example, the rules
we might define for what constitutes a bird: namely, something which:
Has feathers
Has wings
Lays eggs
Is capable of flying
77
78. Organizing Abstractions Into Classification Hierarchies
Given these rules, neither an ostrich nor a penguin could be classified as a bird,
because neither can fly.
Birds Non-Birds
78
79. Organizing Abstractions Into Classification Hierarchies
If we attempt to make the rule set less restrictive by eliminating the “flight”
rule, we are left with:
Has feathers
Has wings
Lays eggs
According to this rule set, we now may properly classify both the ostrich and the
penguin as birds.
79
81. Organizing Abstractions Into Classification Hierarchies
This rule set is still unnecessarily complicated, because as it turns out, the “lays
eggs” rule is redundant: whether we keep it or eliminate it, it doesn’t change our
decision of what constitutes a bird versus a non-bird. Therefore, we simplify
the rule set once again:
Has feathers
Has wings
81
82. Organizing Abstractions Into Classification Hierarchies
We try to take our simplification process one step further, by eliminating yet
another rule, defining a bird as something which:
Has wings
We’ve gone too far this time: the abstraction of a bird is now so general that
we’d include airplanes, insects, and all sorts of other non-birds in the mix.
82
83. Organizing Abstractions Into Classification Hierarchies
The process of rule definition for purposes of categorization
involves “dialing in” just the right set of rules –not too general,
not to restrictive, and containing no redundancies- to define
the correct membership in a particular class.
83
84. Abstractions as the Basis for Software Development
When pinning down the requirements for an information systems development
project, we typically start by gathering details about the real world definition on
which the system is to be based. These details are usually a combination of:
Those that are explicitly offered to us as we interview the intended users of
the system
Those that we otherwise observe.
84
85. Abstractions as the Basis for Software Development
We must make a judgment all as to which of these details are relevant to the
system’s ultimate purpose. This is essential, as we cannot automate them all!.
To include too much details is to overly complicate the resultant system, making
it that much more difficult to design, program, test, debug, document, maintain,
and extend in the future.
As with all abstractions, all of our decisions of inclusions versus elimination when
building a software system must be made within the context of the overall
purpose and domain, or subject matter focus, of the future system.
85
86. Abstractions as the Basis for Software Development
Once we’ve determined the essential aspects of a situation we can prepare a
model of that situation. Modeling is the process by which we develop a pattern
for something to be made. A blueprint for a custom home, a schematic diagram
of a printed circuit, and a cookie cutter are all examples of such patterns.
86
87. Abstractions as the Basis for Software Development
A model is a simplification of the reality.
87
88. Abstractions as the Basis for Software Development
• Modeling achieves four aims:
– Helps you to visualize a system as you want it to be.
– Permits you to specify the structure or behavior of a system.
– Gives you a template that guides you in constructing a system.
– Documents the decisions you have made.
• You build models of complex systems because you cannot comprehend such a
system in its entirety.
• You build models to better understand the system you are developing.
88
89. Abstractions as the Basis for Software Development
The importance of modeling:
Less Important More Important
Paper Airplane Fighter Jet
89
90. Abstractions as the Basis for Software Development
• Many software teams build applications approaching the problem like they
were building paper airplanes
– Start coding from project requirements
– Work longer hours and create more code
– Lacks any planned architecture
– Doomed to failure
• Modeling is a common thread to successful projects
90
91. Abstractions as the Basis for Software Development
An object model of a software system is such a pattern. Modeling and
abstraction go hand in hand, because a model is essentially a physical or
graphical portrayal of an abstraction; before we can model something effectively,
we must have determined the essential details of the subject to be modeled.
91
92. Reuse of Abstractions
When learning about something new, we automatically search our “mental
archive” for other abstractions/models that we’ve previously built and mastered,
to look for similarities that we can build upon.
When learning to ride a two-wheeled
bicycle for the first time, for example,
you may have drawn upon lessons
that you learned about riding a
tricycle as a child.
92
93. Reuse of Abstractions
Both have handlebars that are used to steer; both have pedals that are used to
propel the bike forward. Although the Abstractions didn’t match perfectly –a
two– wheeled bicycle introduced the new challenge of having to balance oneself –
there was enough of a similarity to allow you to draw upon the steering and
pedaling expertise you already had mastered, and to focus on learning the new
skill of how to balance on two wheels.
93
94. Reuse of Abstractions
This technique of comparing features to find an abstraction
that is similar enough to be reused successfully is known as
pattern matching and reuse. A pattern reuse is an
important technique for object oriented software development
,as well, because it spares us from having to reinvent the
wheel with each new project. If we can reuse an abstraction
or model from a previous project, we can focus on those
aspects of the new project that differ from the old, gaining
a tremendous amount of productivity in the process.
94
98. Inherent Challenges
Despite the fact that abstraction is such a natural process for human beings,
developing an appropriate model for a software system is perhaps the most
difficult aspect of software engineering.
98
101. Objects and Classes
• What is an object?
• Methods
• Reuse of Abstractions
• Inherent Challenges
• Exercises
101
102. What Is an Object?
A class is a collection of objects with related properties and behaviours.
In real-life we group things into classes to help us reduce complexity
Example:
The set of all dogs forms the class Dog
Each individual dog is an object of the class Dog
Firulais, Terry and Rex are all instances of the class Dog
To some extent, we can interact with Firulais based on our knowledge of dogs
in general, rather than Firulais himself
102
104. What Is an Object?
What is a Waiter?
A Waiter is someone who has the following properties and behaviours:
Properties of a Waiter
Full Name
Behaviours of a Waiter
Bring menus
Take orders
Bring meals
This collection of properties and behaviours defines the class of Waiters
Because these behaviours are standardized, we can deal with any Waiter just
based on our “general knowledge” of Waiters
104
105. What Is an Object?
A class is a general description of the properties and behaviours of some
entities.
We described the class Waiter
giving the general description Name of
Waiter class
of what properties Waiters have
Properties
and what things Waiters can fullName
do.
bringMenu
Behaviours
takeOrder
bringMeal
105
106. What Is an Object?
An object is a specific member of a class.
An object belonging to the class of Waiters is an actual individual waiter
Pierre is an object of the class Waiter, and so is Bill and so is Jimmy –they
can all take orders, bring menus and bring meals
106
109. What Is an Object?
Classes in Java may have methods and attributes.
– Methods define actions that a class can perform.
– Attributes describe the class.
109
111. What Is an Object?
The phrase "to create an
instance of an object“ means
to create a copy of this object
in the computer's memory
according to the definition of
its class.
111
115. What Is an Object?
The class BankAccount
A bank account has the following properties:
An account number and account name
A balance
A bank account has the following behaviours:
Money can be credited to the bank account
Money can be debited from the bank account
115
117. What Is an Object?
Objects in Java are creating using the keyword new.
117
118. What Is an Object?
The arguments in the constructor are used to specify initial information about
the object. In this case they represent the account number and account name.
A constructor can have any number of arguments including zero.
Arguments
118
119. What Is an Object?
1. Declare a reference.
2. Create the object.
3. Assign values.
119
120. What Is an Object?
1. Declare a reference.
2. Create the object.
Two references to two
objects, with values
for their attributes.
120
122. What Is an Object?
size ‘u0000’
price 0.0
lSleeved false
AnotherShirt 0x334009 size ‘u0000’
myShirt 0x99f311 price 0.0
id lSleeved false
428802
Stack memory Heap memory
122
123. What Is an Object?
size ‘u0000’
price 0.0
lSleeved false
AnotherShirt X
0x334009
X size ‘u0000’
0x99f311 price 0.0
myShirt 0x99f311 lSleeved false
Stack memory Heap memory
123
124. What Is an Object. Examples.
Consider a class that represents a circle.
public class Circle {
int radius;
}
public class ShapeTester {
public static void main(String args[]) {
Circle x;
x = new Circle();
System.out.println(x);
}
}
124
125. What Is an Object. Examples.
Here is another example defining a Rectangle that stores a width and height as
doubles:
public class Rectangle {
double width = 10.128;
double height = 5.734;
}
public class ShapeTester {
public static void main(String args[]) {
Circle x;
Rectangle y;
x = new Circle();
y = new Rectangle();
System.out.println(x + " " + y);
}
} 125
126. What Is an Object. Examples.
public class ShapeTester {
public static void main(String args[]) {
Circle x;
Rectangle y, z;
x = new Circle();
y = new Rectangle();
z = new Rectangle();
System.out.println(x + " " + y + " " + z);
}
}
126
127. What Is an Object. Examples.
public class ShapeTester {
public static void main(String args[]) {
Circle x;
Rectangle y, z;
x = new Circle();
y = new Rectangle();
z = new Rectangle();
x.radius = 50;
z.width = 68.94;
z.height = 47.54;
System.out.println(x.radius + " " + y.width + " " + z.width);
}
}
127
130. Methods
The interesting part of OO-Programming is getting the objects to interact
together. This is obvious when we look at real world examples:
– A house not being lived in is not useful
– A BankAccount in which no money is deposited or withdrawn is not useful
either
– A CD without a CD Player is useless too.
Behaviour represents:
– the things you can do with an object (i.e., a command)
– information you can ask for from an object (i.e., a question)
130
131. Methods
By definition an instance is created from its class definition and so it only uses
the vocabulary defined in its own class. To help us understand object behaviour,
we should try to think of objects as being “living” entities. When we want to
"talk to" or "manipulate" an object, we must send it a message.
A message:
– is a set of one or more words (joined together as one) that is sent to an
object.
– is part of the "vocabulary" that an object understands.
may have additional information (parameters) which are required by the object.
You can send messages to objects, and they respond to you:
131
132. Methods
May have additional information (parameters) which are required by the object.
You can send messages to objects, and they respond to you:
Objects only respond if they understand what you say:
132
134. Methods
Thus, by defining behaviour, we simply add to the vocabulary of words (i.e.,
messages) that the object understands. Objects communicate by sending
messages back and forth to each other:
134
135. Methods
As we can see, many objects are often involved in a more difficult task. For
example, consider building a house. A person asks a house building company to
build them a house. In fact, the house building company then "sub-contracts"
out all of the work in that it then hires others to do all the work. So the house
builder actually co-ordinates the interactions with all of the contractors. The
contractors themselves contact suppliers to get their parts as well as other
helpers to help them accomplish their tasks:
135
137. Methods
To define a particular behaviour for an object, we must write a method
A method :
– is the code (expressions) that defines what happens when a message is
sent to an object.
– may require zero or more parameters (i.e., pieces of data):
• Parameters may be primitives or other objects
• Primitives are “passed-by-value” (the actual value is “copied” and
passed with the message)
• Objects are “passed-by-reference” (a pointer to the object is passed
with the message)
– may be either a class method or an instance method.
Methods are typically used to do one or more of these things:
get information from the object it is sent to change the object in some way
compute or do something with the object
obtain some result.
137
138. Methods
Methods are typically used to do one or more of these things:
– get information from the object it is sent to
– change the object in some way
– compute or do something with the object
– obtain some result.
138
140. Methods
Sending a message to an object is also known as calling a method. So the
method is actually the code that executes when you send a message to an
object. Some methods return answers, others may do something useful but do
not return any answer.
140
141. Methods
A method is calling by specifying
The target object, following by a dot
The method name
The method arguments (is there are any)
cheque.getBalance();
The target object is the one called cheque
The getBalance method has been called
There are no arguments for this method
The result will be returned to whoever called the method
141
147. Methods
In general, methods calls may
Send information to the target, or not
Receive information from the object, or not
The method signature tell us whether information is to be sent,
received or both.
147
152. Data Structures.
A data structure can be thought of as container that is used to
group multiple elements into a single representation, and is
used to store, retrieve, and manipulate the contained data.
152
153. Basic Data Structure Mechanisms.
Before the development of the Java2 platform, only a small set
of classes and interfaces were available in the supplied
Standard Class. Library for data store manipulation.
– Arrays
– Vector
– Stack
– Hashtable
– Properties
– BitSet
– Enumeration
153
154. The Vector Class.
• Contains a collection of object references.
• Can vary in size.
• Can hold objects of different types.
• The Vector class is more flexible than an Array:
154
166. Enumeration Interface.
The Enumeration interface allows the developer to traverse
collections at a high level, with little concern for the underlying
collection.
Used specifically when traversal order is not important.
Vector's elements() method and Hashtable's keys() and
elements() methods return Enumeration objects.
The Enumeration interface contains two methods:
hasMoreElements() and nextElement()
166
170. Set Interface.
• The Set interface adds no methods to the collection interface.
• Set collections add the restriction of no duplicates.
• boolean add(Object element) fails to update the collection and returns false if
the element already exists.
• Adds a stronger contract on the behavior of the equals and hashCode
operations, allowing Set objects with different implementation types to be
compared.
170
173. Iterator Interface.
The Iterator interface is used to traverse through each element
of a collection. This interface offers the same functionality as
the Enumeration interface, with an additional method that
enables us to remove an object. The presence of this
additional method makes it preferable over the Enumeration
interface.
• Object next()
• boolean hasNext()
• void remove()
173
175. List Interface.
A List is a collection of elements in a particular order. Also
referred to as a sequence, a List can contain duplicate
elements.
The List interface extends from the Collection interface an has
an index of elements. The index, which is an integer, denotes
the position of elements in the list. The index also helps us
include a new element into a list in the specific position
required.
175
183. Overview of Object Orientation.
• Technique for system modeling
• Models the system as a number of related objects that interact
• Similar to the way people view their environment
Object technology is a set of principles guiding software
construction together with languages, databases, and
other tools that support those principles. (Object
Technology: A Manager’s Guide, Taylor, 1997)
183
185. Identifying Objects.
• Object can be a sentence, bank account, number, or
car
• Objects are:
– Things
– Real or imaginary
– Simple or complex
An object is an entity with a well-defined boundary and
identity that encapsulates state and behavior.
185
186. Identifying Objects.
An object is an entity with a well-defined boundary and
identity that encapsulates state and behavior.
186
189. Identifying Objects.
• Objects have many forms:
– Tangible things (Airplane, Computer, Car)
– Roles (Doctor, Teacher)
– Incidents (Meeting)
– Interactions (Interview, Agreement)
189
190. Object definition. Case Study
• Throughout this course, a case study of a clothing catalog, DirectClothing,
Inc., will be used to illustrate concepts.
190
191. Object definition. Case Study
• Most projects start by defining the problem domain by gathering customer
requirements and by writing a statement of scope that briefly states what
you, the developer, want to achieve.
• For example, a scope statement for the DirectClothing project might be:
“Create a system allowing order entry people to enter and accept
payment for an order.”
• After you have determined the scope of the project, you can begin to identify
the objects that will interact to solve the problem.
191
192. Object definition. Case Study
• Object names are often nouns, such as “account” or “shirt.” Object
attributes are often nouns too, such as “color” or “size.” Object operations
are usually verbs or noun-verb combinations, such as“display” or “submit
order.”
• Your ability to recognize objects in the world around you will help you to
better define objects when approaching a problem using object-oriented
analysis.
Solution
192
193. Object definition. Case Study
• The problem domain of the DirectClothing, Inc. case study has the following
nouns. Each could be an object in the catalog’s order entry system.
catalog
clothing
subscribers
closeout items
monthly items
normal items
order
193
194. Object definition. Case Study
customer
CSR ( customer service representative)
order entry clerk
Supplier
Payment
warehouse
credit car
order entry
mail order
fax order
online order
194
195. Object definition. Case Study
inventory
back-ordered items
system
Internet
business
year
month
order form
check
195
196. Identifying Object Attributes and Operations
• Example:
– Cloud attributes: size, water content, shape
– Cloud operations: rain, thunder, snow
Attributes: an object’s characteristics
Operations: what an object can do
196
198. Identifying Object Attributes and Operations. Case Study
• When you are attempting to assign operations to an object, operations
performed on an object are assigned to the object itself. For example, in a
bank an account can be opened and closed, balanced and updated, receive
additional signers, and generate a statement. All of these would be the
Account object’s operations.
198
199. Identifying Object Attributes and Operations. Case Study
• For the Order object, the following attributes and operations could be
defined:
– Attributes: orderNumber, customerNumber, dateOrdered,
amountOwed
– Operations: whatCustomer, calcAmountOwed, printOrder,
payOrder
• What would be the attributes and operations for the Customer object?
199
200. Testing an Identified Object:
• Use the following criteria to test object validity:
– Relevance to the problem domain
– Need to exist independently
– Having attributes and operations
200
201. Relevance to the Problem Domain.
• Does it exist within the boundaries of the problem statement?
• Is it required in order for the system to fulfill its responsibility?
• Is it required as part of interaction between a user and the system?
• Can objects sometimes be a characteristic of other objects?
201
202. Testing an Identified Object. Case Study
• The Order object exists within the boundaries of the problem statement, it is
required for the system to fulfill its responsibilities, and as part of an
interaction between a user and the system. The Order object passes the test.
• Test the other candidate objects in the case study. What are the results?
202
203. Testing an Identified Object. Case Study
The following objects can probably be removed from the list:
• Internet, system, business – Not necessary within the boundaries of the
problem statement
• month, year – May be attributes of the date of an order being placed, but not
necessary as an object itself
203
204. Testing an Identified Object. Case Study
The following objects can probably be removed from the list:
• online order, fax order, mail order – Can probably be captured as special cases
of the order object, or you could have a type attribute on the order object to
indicate how the order was made. You may not want to eliminate here, but to
note these nouns are special cases.
• back-ordered items, closeout items, monthly sales item – Can probably be
captured as special cases of a normal item object. You may not want to
eliminate these nouns, but to note these are special cases.
204
205. Independent Existence.
• To be an object and not a characteristic of another object, the object must
need to exist independently
205
206. Independent Existence. Case Study
• Can an Order object exist without any of the other objects? It can, but in use,
it must have an associated Customer object.
• Address could be an attribute of Customer, but in this case study it is
advantageous for Address to be a separate object.
206
207. Attributes and Operations.
• An object must have attributes and operations
• If it does not, it is probably and attribute or operation of another object
207
208. Attributes and Operations. Case Study
• An object must have attributes and operations. If you cannot define attributes
and operations for an object, then it probably is not an object but an
attribute or operation of another object.
• The Order object has many attributes and operations defined, as do most of
the candidate objects.
208
209. Encapsulation.
• Encapsulation separates the external aspects of an object from the internal
implementation details
• Internal changes need not affect external interface
Hide
implementation
from clients.
Clients depend
on interface
209
211. Implementing Encapsulation.
• An object’s attributes and operations are its members
• The members of an object can be public or private
• In pure OO systems, all attributes are private and can be changed or accessed
only through public operations
211
213. Overview of Object Orientation.
• Technique for system modeling
• Models the system as a number of related objects that interact
• Similar to the way people view their environment
Object technology is a set of principles guiding software
construction together with languages, databases, and
other tools that support those principles. (Object
Technology: A Manager’s Guide, Taylor, 1997)
213
214. Class Overview.
• A class is a description of a set of objects that share the same attributes,
operations, relationships, and semantics.
– An object is an instance of a class.
• A class is an abstraction in that it Emphasizes relevant characteristics.
Suppresses other characteristics.
214
217. Class Overview.
• A class is an abstract definition of an object. It defines the structure and
behavior of each object in the class. It serves as a template for creating
objects.
• Classes are not collections of objects.
217
218. Class Overview.
• An attribute is a named property of a class that describes a range of values
that instances of the property may hold.
• A class may have any number of attributes or no attributes at all.
218
219. Class Overview.
• An operation is the implementation of a service that can be requested from
any object of the class to affect behavior.
• A class may have any number of operations or none at all.
219
220. Generalization
Generalization identifies and defines the common attributes
and operations in a collection of objects.
Example: Transport is a generalization of several classes that
provide transportation.
220
222. Inheritance
• Is a mechanism for defining a new class in terms of an existing class.
• Allows you to group related classes so that they can be managed collectively.
• Promotes reuse.
• Allows you to hide or override inherited members.
• Relevant terms: generalization, specialization, override.
222
228. Polymorphism
• Allows you to implement an inherited operation in a subclass
• Works only when the common operation gives the same semantic result
• Implementation of a polymorphic function depends on the object it is applied
to
• Can be used only with inheritance
228
232. Object Messaging.
• One object sends a message to another (the receiving object)
• The receiving object may send other messages, change its attribute, or read
in any other appropriate way.
• Messaging in handled by operations in the public interface of the receiving
object.
232
233. Association and Composition.
• Objects interact through one of two relationships: association or
composition.
• Association: Two independent objects collaborate to achieve some goal, like a
person using a computer (“uses a ” relationship)
• Composition: One object contains another, like a pencil that has a lead (“has
a” relationship)
233
248. Object-Oriented Analysis and Design.
• Unified Modeling Language (UML) is used to notate the design.
• UML diagrams:
– Use case diagram
– Sequence diagram
– Class diagrams
– Activity diagrams
248
249. Use Case Diagrams.
• A use case diagram contains use cases, actors, and relationship links
• A use case is an interaction of a user with the application in order to achieve a
desired result
• An actor is a role that a user plays when interfacing with the application
• Relationship links between use cases are “uses” and “extends.”
249
250. Use Case Diagrams.
• There are two types of relationship links that can be made in the diagram.
These are the extends and uses relationships between the use cases.
• The extends relationship links two use cases that are similar but one does a
little more than the other. It is implied that the actor who performs the first
use case will also perform the extension use case. This relationship is
indicated by <<extends>> on the link’s line.
250
251. Use Case Diagrams.
• The second type of link is the uses relationship, which occurs when there is a
behavior that is used by many use cases. To avoid repetition, make that
behavior a use case itself, and have other use cases “use” it. It is implied that
an actor does not perform the “used” use case, but that the base use case
does the performing.
• This relationship is indicated by <<uses>> on the link’s line.
251
252. Use Case Diagrams.
• An actor represents anything that interacts with the system.
• A use case is a sequence of actions a system performs that yields an
observable result of value to a particular actor.
252
255. Use Case Diagrams.
Follow these steps to create a use case diagram:
1. Identify each use case in your application. (It might help to identify events
you need to react to.)
2. Draw and label each of the actors of the application.
3. Draw and label the use cases of the application.
4. Draw the links from the actor to the use cases they perform.
5. Write a short description of each use case. The diagram and the description
together will give a representation of the functionality that must be
implemented in the system.
255
256. Example: Use Case Diagrams.
A use case specifies a set of scenarios
for accomplishing something
useful for an actor. In this
example, one use case is
"Buy soda."
256
257. Example: Use Case Diagrams.
Restocking a soda machine is an important use case.
257
258. Example: Use Case Diagrams.
Collecting the money
from a soda machine
is another
important use case.
258
260. Use Case Diagrams.
Use case diagrams describe what a system does from the
standpoint of an external observer. The emphasis is on what
a system does rather than how.
Use case diagrams are closely connected to scenarios. A
scenario is an example of what happens when someone
interacts with the system.
260
261. Use Case Diagrams.
Here is a scenario for a medical clinic:
"A patient calls the clinic to make an appointment for a
yearly checkup. The receptionist finds the nearest empty time
slot in the appointment book and schedules the appointment
for that time slot. "
261
262. Use Case Diagrams.
A use case is a summary of scenarios for a single task or
goal. An actor is who or what initiates the events involved in
that task. Actors are simply roles that people or objects play.
The picture below is a Make Appointment use case for the
medical clinic. The actor is a Patient. The connection between
actor and use case is a communication association (or
communication for short).
262
263. Use Case Diagrams.
A use case diagram is a collection of actors, use cases, and
their communications. We've put Make Appointment as part of
a diagram with four actors and four use cases. Notice that a
single use case can have multiple actors.
263
264. Use Case Diagrams.
A use case describes a single task or goal and is indicated by
an oval. The task or goal is written inside the oval and usually
it contains a verb.
264
265. Use Case Diagrams.
TIP: Start by listing a sequence of steps a user might take in
order to complete an action. For example a user placing an
order with a sales company might follow these steps.
1. Browse catalog and select items.
2. Call sales representative.
3. Supply shipping information.
4. Supply payment information.
5. Receive conformation number from salesperson.
265
267. Exercises: Use Case Diagrams.
Diseñar diagramas de casos de uso para las siguientes
situaciones:
• Comprar una paleta en la cafetería de la escuela.
• Cancelar una cita con el(la) novio(a) ó una salida con los amigos.
• Enviar un mensaje de correo electrónico.
• Enviar un mensaje de texto de un teléfono celular a otro.
• Copiar un archivo a la memoria USB.
• Imprimir un documento de Word en el centro de cómputo.
267
268. Use Case Relations.
<<extend>> (extensión) : Los casos de uso pueden
extenderse a otros casos de uso. Se recomienda utilizar
cuando un caso de uso es similar a otro (características).
268
269. Use Case Relations.
<<include>> (inclusión) : Los casos de uso pueden incluir a
otros casos de uso. Se recomienda utilizar cuando se tiene
un conjunto de características que son similares en más de
un caso de uso y no se desea mantener copiada la
descripción de la característica.
269
270. Use Case Relations.
<<include>>
Cuando un número de casos de uso comparten un
comportamiento común puede ser descrito por un caso de
uso que es utilizado por otros casos de uso.
270
271. Use Case Relations.
<<extends>>
Es una relación de dependencia donde un caso de uso
extiende otro caso de uso añadiendo acciones a un caso de
uso extendido.
271
272. Example: Use Case Diagrams.
Máquina Recicladora: Sistema que controla una máquina
de reciclamiento de botellas, tarros y jabas. El sistema debe
controlar y/o aceptar:
• Registrar el número de ítems ingresados.
• Imprimir un recibo cuando el usuario lo solicita:
• Describe lo depositado
• El valor de cada item
• Total
272
273. Example: Use Case Diagrams.
• Existe un operador que desea saber lo siguiente:
– Cuantos ítems han sido retornados en el día.
– Al final de cada día el operador solicita un resumen de todo lo
depositado en el día.
• El operador debe además poder cambiar:
– Información asociada a ítems.
– Dar una alarma en el caso de que:
• Item se atora.
• No hay más papel.
273
274. Example: Use Case Diagrams.
Actores que interactuan con el sistema:
274
275. Example: Use Case Diagrams.
Un Cliente puede depositar Items y un Operador puede
cambiar la información de un Item o bien puede Imprimir un
Informe.
275
276. Example: Use Case Diagrams.
Un item puede ser una Botella, un Tarro o una Jaba.
276
277. Example: Use Case Diagrams.
la impresión de comprobantes, que puede ser realizada
después de depositar algún item por un cliente o bien puede
ser realizada a petición de un operador.
277
279. Example: Use Case Diagrams.
Sistema de ventas. Un sistema de ventas debe interactuar
con clientes, los cuales efectúan pedidos. Además los clientes
pueden hacer un seguimiento de sus propios pedidos. El
sistema envía los pedidos y las facturas a los clientes. En
algunos casos, según la urgencia de los clientes, se puede
adelantar parte del pedido (pedidos parciales).
279
281. Exercises: Use Case Diagrams.
Encontrar los casos de uso para la biblioteca sencilla:
• De cada libro tengo uno o varios ejemplares.
• Cada usuario puede mantener un máximo de tres ejemplares en préstamo
de forma simultánea.
• Los usuarios pueden solicitar al bibliotecario un libro en préstamo (dando
el autor o el título, etc.) y el sistema debe determinar si hay al menos un
ejemplar en las estanterías. Si es así, el bibliotecario entrega un ejemplar
y registra el préstamo (usuario, fecha y ejemplar concreto).
281
282. Exercises: Use Case Diagrams.
• El préstamo es semanal y si se produce un retraso en la devolución, se
impone una multa en forma de días sin derecho a nuevos préstamos (3 días
por cada día de retraso).
• Antes de cualquier préstamo, el bibliotecario debe comprobar esta
situación.
282
283. Exercises: Use Case Diagrams.
Encontrar los casos de uso para las tareas uno y dos.
283
285. Sequence Diagrams.
• Capture the operations of a single use case and show how groups of objects
collaborate on those operations.
• Exist for each use case.
• Contains objects, objects lifelines, messages between objects, conditions,
iteration markers, activations, and object deletions.
285
286. Sequence Diagrams.
• A Sequence Diagram is an interaction diagram that emphasizes the time
ordering of messages.
• The diagram show:
– The objects participating in the interaction
– The sequence of messages exchanged
286
288. Sequence Diagrams.
:Sistema
:cajero
crearNuevaVenta()
ingresarItem(codItem, cant)
descripción, total
Bucle
*[más items]
finalizarVenta()
total con imptos.
realizarPago()
monto cambio, recibo
Un diagrama de secuencia del sistema muestra, para un escenario
particular de un caso de uso, los eventos externos que los actores
generan, su orden y los eventos inter-sistemas.
288
291. Sequence Diagrams.
Objetos participantes en la interacción
:Computer :PrintServer :Printer
print(arch) print(arch) [no queue] Condición
print(arch)
Mensaje
Mensaje
Sincrónico
Activación
Línea de
vida Retorno
Puede omitirse
291
292. Sequence Diagrams.
Flecha hacia un objeto
:ItemWindow índica creación del objeto.
NuevoItem(data)
crearItem(data)
:Item
:ItemWindow :Item
EliminarItem()
BorrarItem()
X
X indica destrucción del objeto
292
293. Sequence Diagrams.
Mensaje Simple / Sincrónico
No se dan detalles de la comunicación cuando no
son conocidos o no son relevantes.
Respuesta / Resultado
Mensaje Asincrónico
Sintaxis del mensaje:
Número de secuencia [condición] * [expresión iteración]
valor de retorno := nombre del mensaje (parámetros)
293
294. Sequence Diagrams.
a1:ClaseA b1:ClaseB
[x<0] Op1()
:ClaseC
[x>0] Op1()
X
u Una ramificación es mostrada por múltiples mensaje que
abandonan un mismo punto, cada una etiquetada con una
condición
u Si las condiciones son mutuamente excluyentes representan
condiciones; de otra manera representan concurrencia.
294
297. Sequence Diagrams.
Activation boxes represent the
time an object needs to
complete a task
297
298. Sequence Diagrams.
Messages are arrows that represent
communication between objects.
Use half-arrowed lines to represent
asynchronous messages.
Asynchronous messages are sent
from an object that will not wait for a
response from the receiver before
continuing its tasks.
298
299. Sequence Diagrams.
Lifelines are vertical dashed
lines that indicate the object's
presence over time.
299
300. Sequence Diagrams.
Objects can be terminated
early using an arrow labeled
"< < destroy > >" that points to
an X.
300
301. Sequence Diagrams.
A repetition or loop within a
sequence diagram is depicted
as a rectangle. Place the
condition for exiting the loop at
the bottom left corner in
square brackets [ ].
301
310. Sequence Diagrams.
Follow these steps to create a sequence diagram. (These are
General guidelines; to write a sequence diagram you must
make sure you check for all interactions among all objects.)
1. Select a use case.
2. Add the first object in the use case to the diagram.
3. Add its method, the message it sends to the next object, and the next
object.
4. Check whether the second object replies to the first or sends on another
message and add the appropriate elements.
310
311. Sequence Diagrams.
5. Repeat steps 3 and 4 as necessary.
6. Add any necessary elements mentioned in this section such
as conditions, iteration markers, or object deletions.
311
314. Collaboration Diagrams.
GENERAR EL DIAGRAMA DE StECUENCIA PARA LA
MAQUINA RECICLADOR
• Alternative to Sequence diagrams
• Objects are connected with numbered arrows showing the flow of the
information
• Arrows are drawn from the source of the interaction
• The object towards with the arrow points is known as the target
• Arrows are numbered to show the order in which they are used within the
scenario
• Also marked with a description of the task required of the target object
314
319. Declaring arrays.
• Group data objects of the same type.
• Declare arrays of primitive or class types:
char s[];
Point p[];
char[] s;
Point[] p;
• Create space for a reference.
• An array is an object; it is
created with new.
319
320. Declaring arrays.
• Use the new keyword to create an array object.
• For example, a primitive (char) array:
public char[] createArray() {
char[] s;
s = new char[26];
for ( int i=0; i<26; i++ ) {
s[i] = (char) (’A’ + i);
}
return s;
}
320
321. Initializing Arrays.
• Initialize an array element
• Create an array with initial values:
String names[];
names = new String[3];
names[0] = "Georgianna";
names[1] = "Jen";
names[2] = "Simon";
String names[] = { "Georgianna","Jen","Simon"};
MyDate dates[];
dates = new MyDate[3];
dates[0] = new MyDate(22, 7, 1964);
dates[1] = new MyDate(1, 1, 2000);
dates[2] = new MyDate(22, 12, 1964);
MyDate dates[] = { new MyDate(22, 7, 1964),new MyDate(1, 1, 2000), new MyDate(22, 12,
1964) };
321
322. Multidimensional Arrays.
• Arrays of arrays:
int twoDim [][] = new int [4][];
twoDim[0] = new int[5];
twoDim[1] = new int[5];
int twoDim [][] = new int [][4]; illegal
322
325. Multidimensional Arrays.
• Non-rectangular arrays of arrays:
twoDim[0] = new int[2];
twoDim[1] = new int[4];
twoDim[2] = new int[6];
twoDim[3] = new int[8];
• Array of four arrays of five integers each:
int twoDim[][] = new int[4][5];
325
326. Array Bounds.
• All array subscripts begin at 0:
int list[] = new int [10];
for (int i = 0; i < list.length; i++) {
System.out.println(list[i]);
}
326
327. Array Resizing.
• Cannot resize an array
• Can use the same reference variable to refer to an entirely new array:
int myArray[] = new int[6];
myArray = new int[10];
327
333. Single Inheritance
• When a class inherits from only one class, it is called single inheritance.
• Interfaces provide the benefits of multiple inheritance without drawbacks.
• Syntax of a Java class:
<modifier> class <name> [extends <superclass>] {
<declarations>*
}
333
336. Overriding Methods
• A subclass can modify behavior inherited from a parent class.
• A subclass can create a method with different functionality than the parent’s
method but with the same:
– Name
– Return type
– Argument list
336
338. The Super Keyword
• super is used in a class to refer to its superclass.
• super is used to refer to the members of superclass,both data attributes and
methods.
• Behavior invoked does not have
to be in the superclass; it can be
further up in the hierarchy.
338
339. Polymorphism
• Polymorphism is the ability to have many different forms; for example, the
Manager class has access to methods from Employee class.
• An object has only one form.
• A reference variable can refer to objects of different forms.
339
340. Virtual Method Invocation
• Virtual method invocation:
Employee e = new Manager();
e.getDetails();
• Compile-time type and runtime type
340
341. Rules About Overriding Methods
• Must have a return type that is identical to the method it overrides
• Cannot be less accessible than the method it overrides
341
342. Heterogeneous Collections
• Collections of objects with the same class type are called homogenous
collections.
MyDate[] dates = new MyDate[2];
dates[0] = new MyDate(22, 12, 1964);
dates[1] = new MyDate(22, 7, 1964);
• Collections of objects with different class types are called heterogeneous
collections.
Employee [] staff = new Employee[1024];
staff[0] = new Manager();
staff[1] = new Employee();
staff[2] = new Engineer();
342
344. Casting Objects
• Use instanceof to test the type of an object
• Restore full functionality of an object by casting
• Check for proper casting using the following guidelines:
– Casts up hierarchy are done implicitly.
– Downward casts must be to a subclass and checked by the compiler.
– The object type is checked at runtime when runtime errors can occur.
344
345. Overloading method names
• Use as follows:
– public void println(int i)
– public void println(float f)
– public void println(String s)
• Argument lists must differ.
• Return types can be different.
345
346. Overloading Constructors
• As with methods, constructors can be overloaded.
• Example:
public Employee(String name, double salary, Date DoB)
public Employee(String name, double salary)
public Employee(String name, Date DoB)
• Argument lists must differ.
• You can use the this reference at the first line of a constructor to call another
constructor.
346
348. The Object Class
• The Object class is the root of all classes in Java
• A class declaration with no extends clause, implicitly uses “extends the
Object”
public class Employee {
...
}
• is equivalent to:
public class Employee extends Object {
...
}
348
349. The == Operator Compared with the equals Method
• The == operator determines if two references are identical to each other (that
is, refer to the same object).
• The equals method determines if objects are “equal” but not necessarily
identical.
• The Object implementation of the equals method uses the == operator.
• User classes can override the equals method to implement a domain-specific
test for equality.
• Note: You should override the hashCodemethod if you override the equals
method.
349
350. The toString Method
• Converts an object to a String.
• Used during string concatenation.
• Override this method to provide information about a user-defined object in
readable format.
• Primitive types are converted to a String using the wrapper class’s toString
static method.
350
353. The Static Keyword
• The static keyword is used as a modifier on variables, methods, and nested
classes.
• The static keyword declares the attribute or method is associated with the
class as a whole rather than any particular instance of that class.
• Thus static members are often called “class members,” such as “class
attributes” or “class methods.”
353
354. Class Attributes
• Are shared among all instances of a class
• Can be accessed from outside the class without an instance of the class (if
marked as public)
354
355. Class Attributes
• You can invoke static method without any instance of the class to which it
belongs.
355
356. Static Initializers
• A class can contain code in a static block that does not exist within a method
body.
• Static block code executes only once, when the class is loaded.
• A static block is usually used to initialize static (class) attributes.
356
357. Abstract Classes
• An abstract class models a class of objects where the full implementation is
not known but is supplied by the concrete subclasses.
357
358. Interfaces
• A “public interface” is a contract between client code and the class that
implements that interface.
• AJava interface is a formal declaration of such a contract in which all methods
contain no implementation.
• Many unrelated classes can implement the same interface.
• A class can implement many unrelated interfaces.
• Syntax of a Java class:
<class_declaration> ::=
<modifier> class <name> [extends <superclass>]
[implements <interface> [,<interface>]* ] {
<declarations>*
}
358
361. Unit Objectives
After completing this unit, you should be able to:
Apply the concept of inheritance
Define a subclass and a superclass
Explain overriding methods
Describe the principle of dynamic binding
Explain polymorphism
Define abstract classes and interfaces
361
362. Review.
Classes in Java may have methods and attributes.
– Methods define actions that a class can perform.
– Attributes describe the class.
362
364. Review.
The phrase "to create an
instance of an object“ means
to create a copy of this object
in the computer's memory
according to the definition of
its class.
364
370. Inheritance.
• Is a mechanism for defining a new class in terms of an
existing class.
• Allows you to group related classes so that they can be
managed collectively.
• Promotes reuse.
• Allows you hide or override inherited methods.
• Relevant terms: generalization, specialization, override.
370
372. Inheritance.
Inheritance is often represented as a tree. Moving down the
tree, classes become more specialized, more honed toward
An application. Moving up the tree, classes are more
general;
they contain members suitable for many classes but are
often
not complete.
372
384. Dynamic Binding.
Dynamic Binding is when an operation and operands don't
find
each other until execution time.
Dynamic binding works with polymorphism and inheritance to
make systems more malleable.
Dynamic binding happens when the JVM resolves which
method to call at run time and is a form of polymorphism.
Dynamic binding is based on the type of the object, not the
type of the object reference.
384
392. Interfaces.
• Interfaces encapsulate a coherent set of services and
attributes, for example, a role.
• Objects in order to participate in various relationships,
need to state that they have the capability to fulfill a
particular role.
• All interfaces must have either public or default access.
• All methods (if any) in an interface are public, and
abstract (either explicitly or implicitly).
• All fields (if any) in an interface are public, static, and
final (either explicitly or implicitly).
392
397. Exceptions.
• An exception is an event or condition that disrupts the normal flow of
execution in a program
– Exceptions are errors in a Java program
– The condition causes the system to throw an exception
– The flow of control is interrupted and a handler will catch the exception
• Exception handling is object-oriented
– It encapsulates unexpected conditions in an object
– It provides an elegant way to make programs robust
– It isolates abnormal from regular flow of control
397
