Object Oriented Programming - Value Types & Reference Types
1. Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Value Types & Reference Types
Q3M1
Dudy Fathan Ali, S.Kom (DFA)
2015
CEP - CCIT
Fakultas Teknik Universitas Indonesia
2. Introduction
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
o The variables in a program are allocated memory at run
time in the system.
o Variables are referred in two ways, value type and
reference type.
o Value type variables contain data, whereas reference
type variables hold the reference to the memory
location where data is stored.
3. Describing Memory Allocation
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
The memory allocated to variables is referred to in two ways, value
types and reference types.
- OOP C#, NIIT Courseware MMSv2.
int Num1 = 50;
int Num2 = 100;
Example :
50
Value types are also called direct
types because they contain data.
100
Num1
Num2
Memory Allocated for Value Type Variable
4. Describing Memory Allocation
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
The memory allocated to variables is referred to in two ways, value
types and reference types.
- OOP C#, NIIT Courseware MMSv2.
int Num1 = 50;
int Num2 = Num1;
Console.WriteLine(Num1);
Console.WriteLine(Num2);
Another Example :
50
50
Num1
Num2
Value types are also called direct
types because they contain data.
Memory Allocated for Value Type Variable
5. Describing Memory Allocation
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
The memory allocated to variables is referred to in two ways, value
types and reference types.
- OOP C#, NIIT Courseware MMSv2.
int Num1 = 50;
int Num2 = Num1;
Console.WriteLine(Num1);
Num1++;
Console.WriteLine(Num2);
Another Example :
Output:
50
50
incrementing Num1 will have no effect on Num2
Value types are also called direct
types because they contain data.
Memory Allocated for Value Type Variable
6. Describing Memory Allocation
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
class Car
{
public int Model;
public void Display_Model()
{
Console.WriteLine (Model);
}
}
class Program
{
static void Main (string[] args)
{
Car Ford = new Car ();
Ford.Model = 10;
Car Mercedes = Ford;
Ford.Display_Model();
Mercedes.Display_Model ();
}
}
Memory Allocated for Reference Type Variable
****
Ford
****
Mercedes
10
**** Output:
10
10
7. Describing Memory Allocation
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
class Car
{
public int Model;
public void Display_Model()
{
Console.WriteLine (Model);
}
}
class Program
{
static void Main (string[] args)
{
Car Ford = new Car ();
Ford.Model = 10;
Car Mercedes = Ford;
Ford.Display_Model();
Ford.Model++;
Mercedes.Display_Model ();
}
}
Memory Allocated for Reference Type Variable
****
Ford
****
Mercedes
10
****
11
Incrementing Form.Model will changing the value
of Mercedes.Model.
8. Enumeration
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Enumeration is a value type data type, it allows you to assign symbolic
names to integral constants.
- OOP C#, NIIT Courseware MMSv2.
enum Days { Sat, Sun, Mon, Tue, Wed, Thu, Fri };
To declare an enumeration type called Days, where the values are restricted to the
symbolic names of the weekdays, use the following code:
Code :
Integral
Constant
0 1 2 3 4 5 6
Symbolic
Name
Sat Sun Mon Tue Wed Thu Fri
Representation :
9. Enumeration
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
class EnumTest
{
enum Days { Sat, Sun, Mon, Tue, Wed, Thu,
Fri };
static void Main(string[] args)
{
int First_Day = (int)Days.Sat;
int Last_Day = (int)Days.Fri;
Console.WriteLine(“Sat = ” + First_Day);
Console.WriteLine(“Fri = ” + Last_Day);
Console.ReadLine();
}
}
Integral
Constant
0 1 2 3 4 5 6
Symbolic
Name
Sat Sun Mon Tue Wed Thu Fri
Full Code :
Representation :
Output:
Sat = 0
Fri = 6
10. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
An array is a collection of values of the same data type. Array
elements are accessed using a single name and an index number
representing the position of the element within the array. Array is a
reference type data type.
Array Structure
11. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Declaring an Array
An array needs to be declared before it can be used in a program. You can declare
an array by using the following statement :
<data type>[] <array name>
Code Structure :
String[] DaftarNama;
Example Code :
String[] DaftarNama = new String[2];
DaftarNama[0] = “Bambang”;
DaftarNama[1] = “Suprapto”;
Initializing and Assigning Value :
12. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
string[] n1 = new string[5];
Data Dalam Memori :
Data Dalam Array :
i=0
Indeks di mulai
dari 0
Assigning Value
13. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
string[] n1 = new string[5];
Data Dalam Memori :
Data Dalam Array :
i=0
Masuk Nilai “1”
Assigning Value
14. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1
string[] n1 = new string[5];
n1[0] = “1”;
Data Dalam Memori :
i=0
a
1 a
Assigning Value
15. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1
string[] n1 = new string[5];
n1[0] = “1”;
Data Dalam Memori :
i=0
a
1 a
Masuk Nilai “5”
a
Assigning Value
16. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
a
b
Assigning Value
17. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
Masuk Nilai “7”
a
b
Assigning Value
18. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5 7
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
n1[2] = “7”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
c
i=2
7 c
a
b
c
Assigning Value
19. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5 7
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
n1[2] = “7”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
c
i=2
7 c
a
b
c
Masuk Nilai “3”
Assigning Value
20. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5 7 3
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
n1[2] = “7”;
n1[3] = “3”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
c
i=2
7 c
a
b
c
i=3
d
d
3 d
Assigning Value
21. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5 7 3
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
n1[2] = “7”;
n1[3] = “3”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
c
i=2
7 c
a
b
c
i=3
d
d
3 d
Masuk Nilai “9”
Assigning Value
22. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5 7 3 9
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
n1[2] = “7”;
n1[3] = “3”;
n1[4] = “9”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
c
i=2
7 c
a
b
c
i=3
d
d
3 d
e
e
e9
i=4
Assigning Value
23. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5 7 3 9
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
n1[3] = “7”;
n1[4] = “3”;
n1[5] = “9”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
c
i=2
7 c
a
b
c
i=3
d
d
3 d
e
e
e9
i=4
Bisa diisi lagi?
Assigning Value
24. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
1 5 7 3 9
string[] n1 = new string[5];
n1[0] = “1”;
n1[1] = “5”;
n1[3] = “7”;
n1[4] = “3”;
n1[5] = “9”;
Data Dalam Memori :
i=0
a
1 a
i=1
b
5 b
c
i=2
7 c
a
b
c
i=3
d
d
3 d
e
e
e9
i=4
Tidak! Karena
Array PENUH.
Assigning Value
25. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
x = 5
26. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
x = 5
i=0
27. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
x = 5
i=0 i < x
Y
28. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
x = 5
n[0] = 1i=0 i < x
Y
29. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
x = 5
n[0] = 1 Tampil “1”i=0 i < x
Y
30. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
n[0] = 1 Tampil “1” i = i+ 1i=0
x = 5
i < x
Y i yang baru = 1
31. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
x = 5
i=1 i < x
Y
32. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
x = 5
n[1] = 5i=1 i < x
Y
33. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
x = 5
n[1] = 5 Tampil “5”i=1 i < x
Y
34. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
n[1] = 5 Tampil “5” i = i+ 1i=1
x = 5
i < x
Y i yang baru = 2
35. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
x = 5
i=2 i < x
Y
36. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
x = 5
n[2] = 3i=2 i < x
Y
37. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
x = 5
n[2] = 3 Tampil “3”i=2 i < x
Y
38. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
n[2] = 3 Tampil “3” i = i+ 1i=2
x = 5
i < x
Y i yang baru = 3
39. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
x = 5
i=3 i < x
Y
40. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
x = 5
n[3] = 8i=3 i < x
Y
41. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
8
n[3] = 8 Tampil “8”i=3
x = 5
i < x
Y
42. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
8
n[4] = 4 Tampil “4” i = i+ 1i=3
x = 5
i < x
Y i yang baru = 4
43. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
8
i=4
x = 5
i < x
Y
44. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
8
n[4] = 4i=4
x = 5
i < x
Y
45. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
8
4
n[4] = 4 Tampil “4”i=4
x = 5
i < x
Y
46. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
8
4
n[4] = 4 Tampil “4” i = i+ 1i=4
x = 5
i < x
Y i yang baru = 5
47. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
8
4
i=5
x = 5
i < x
N
48. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Display Array Value
string[] n1 = new string[5]
n1[0] = 1;
n1[1] = 5;
n1[2] = 3;
n1[3] = 8;
n1[4] = 4;
int x,i;
x = n1.length();
i = 0;
for(i=0;i<x;i++)
{
Console.WriteLine(n1[i]);
}
Console.ReadLine();
Data array
int x,i
i++
Y
N
next
command
x = n1.length
i = 0
i < x
Tampil nilai “i”
1 5 3 8 4
i=0 i=1 i=2 i=3 i=4
Tampil Di Layar :
1
5
3
8
4
Data telah tampil semua
49. Array
Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Latihan Mandiri
1. Buatlah array untuk menyimpan sejumlah nama siswa (jumlah
siswa berdasarkan inputan user)
2. Buatlah 2 array untuk menyimpan angka ganjil dan angka genap
dari 0 – 20 dan
3. Jumlahkanlah isi dari array ganjil dan array genap
4. Jumlahkanlah array ganjil dan genap dengan index yang sama
kemudian masukkan hasil penjumlahannya ke dalam array yang
baru
5. Hasil dari ke empat latihan di atas harus bisa ditampilkan
50. Q3M1 – OOP C# Dudy Fathan Ali S.Kom
Thank You!
Dudy Fathan Ali S.Kom
dudy.fathan@eng.ui.ac.id
Credits array content by : Yaddarabullah S.Kom M.Kom
