MongoDB Days Silicon Valley: Jumpstart: The Right and Wrong Use Cases for MongoDB
- 1. The Right and Wrong Use Cases for MongoDB Sigfrido “Sig” Narváez Sr. Solution Architect, MongoDB sigfrido@mongodb.com @SigNarvaez
- 2. Data Demands for Today’sApplications
- 3. Factors Driving Modern Applications Data • 90% data created in last 2 years • 80% enterprise data is unstructured • Unstructured data growing 2X rate of structured data Mobile • 2 Billion smartphones by 2015 • Mobile now >50% internet use • 26 Billion devices on IoT by 2020 Social • 72% of internet use is social media • 2 Billion active users monthly • 93% of businesses use social media Cloud • Compute costs declining 33% YOY • Storage costs declining 38% YOY • Network costs declining 27% YOY
- 6. SQL, NoSQL, or MongoDB?
- 7. How Databases Stack Up Requirement RDBMS Key/value Wide column MongoDB Hierarchical data Poor Poor Good Great Dynamic schema Poor Poor Poor Great Native OOP language Poor Great Great Great Software cost Poor Great Great Great Performance Poor Great Great Great Scale Poor Great Great Great Data consistency Great Poor Poor Great Rich querying Great Poor Poor Great Ease of use Good Good Poor Great VALUE OF SQL
- 8. Requirement RDBMS Key/value Wide column MongoDB Hierarchical data Poor Poor Good Great Dynamic schema Poor Poor Poor Great Native OOP language Poor Great Great Great Software cost Poor Great Great Great Performance Poor Great Great Great Scale Poor Great Great Great Data consistency Great Poor Poor Great Rich querying Great Poor Poor Great Ease of use Good Good Poor Great How Databases Stack Up VALUE OF NOSQL
- 9. Requirement RDBMS Key/value Wide column MongoDB Hierarchical data Poor Poor Good Great Dynamic schema Poor Poor Poor Great Native OOP language Poor Great Great Great Software cost Poor Great Great Great Performance Poor Great Great Great Scale Poor Great Great Great Data consistency Great Poor Poor Great Rich querying Great Poor Poor Great Ease of use Good Good Poor Great How Databases Stack Up VALUE OF MONGODB
- 10. Nexus Architecture Relational NoSQL Expressive Query Language Strong Consistency Secondary Indexes Flexibility Scalability Performance
- 11. Mobile HR App One of largest HCM solution providers builds app for single view of HR, serving 1M+ users globally Problem Why MongoDB ResultsProblem Solution Results Able to serve 1M users and 41K companies across 17 countries 99.999% uptime (5.26 min/yr) Top iOS Business App
- 12. Data Model
- 15. Internet Of Things Expands 3M car pilot to 300M cars Problem Why MongoDB Results https://www.mongodb.com/use-cases/internet-of-things Before MongoDB Rigid Schemas New Devices and Data Scale-Up Limits Horizontal Scalability Inadequate Query Performance In-Place Analytics
- 16. The JSON Document Data Model
- 17. Documents are Rich Data Structures { first_name: ‘Paul’, surname: ‘Miller’, cell: 447557505611, city: ‘London’, location: [45.123,47.232], Profession: [‘banking’, ‘finance’, ‘trader’], cars: [ { model: ‘Bentley’, year: 1973, value: 100000, … }, { model: ‘Rolls Royce’, year: 1965, value: 330000, … } ] } Fields can contain an array of sub- documents Fields Typed field values Fields can contain arrays Fields can be indexed at any level
- 18. Do More With Your Data { first_name: ‘Paul’, surname: ‘Miller’, city: ‘London’, location: [45.123,47.232], cars: [ { model: ‘Bentley’, year: 1973, value: 100000, … }, { model: ‘Rolls Royce’, year: 1965, value: 330000, … } } } Rich Queries Find Paul’s cars Find everybody in London with a car built between 1970 and 1980 Geospatial Find all of the car owners within 5km of Trafalgar Sq. Text Search Find all the cars described as having leather seats Aggregation Calculate the average value of Paul’s car collection Map Reduce What is the ownership pattern of colors by geography over time? (is purple trending up in China?)
- 19. Solve problems in ways not possible before
- 20. Time Series Row-based Approach http://blog.mongodb.org/post/65517193370/schema-design-for-time-series-data-in-mongodb { timestamp: ISODate("2013-10-10T23:06:37.000Z"), type: ”memory_used”, value: 1000000 }, { timestamp: ISODate("2013-10-10T23:06:38.000Z"), type: ”memory_used”, value: 15000000 } Simple schema … however: • Lots of records! (Disk) • Large indexes! (RAM) • Expensive aggregations! (CPU)
- 21. Time Series Document Approach http://blog.mongodb.org/post/65517193370/schema-design-for-time-series-data-in-mongodb { timestamp_minute: ISODate("2013-10-10T23:06:00.000Z"), type: “memory_used”, values: { 0: 999999, … 37: 1000000, 38: 1500000, … 59: 2000000 }, avg: 1700000 } Rich Schema: • Single record per X (m, h, d, etc) • More Updates, Less Inserts • Smaller Indexes • Store aggregates too! (e.g. avg)
- 22. Document Approach Multi-Dimensional! http://blog.mongodb.org/post/65517193370/schema-design-for-time-series-data-in-mongodb { timestamp_hour: ISODate("2013-10-10T23:00:00.000Z"), type: “memory_used”, values: { 0: { 0: 999999, 1: 999999, …, 59: 1000000 }, 1: { 0: 2000000, 1: 2000000, …, 59: 1000000 }, …, 58: { 0: 1600000, 1: 1200000, …, 59: 1100000 }, 59: { 0: 1300000, 1: 1400000, …, 59: 1500000 } } } db.metrics.update( { timestamp_hour: ISODate("2013-10-10T23:00:00.000Z"), type: “memory_used” }, {$set: {“values.59.59”: 2000000 } } )
- 23. Seismic Modeling • 2000 x 2000 x 2000 cubic data set • 8 billion floats • Relational model can take several minutes for some calculations • MongoDB query performs in ~1 second (4M docs or 2000x2000) { "_id": ObjectId("55e7358e1a317d0fb177b31e"), "x": 100, "y": 25, "z": [0.8506244646719524, 0.18891124618195854, 0.14090160846138955, ... ] }
- 24. Molecular Similarity Database • Store Chemical Compound Fingerprints • Find compounds which are “close” to a given compound • Tanimoto association coefficient compares two compounds based on their common fingerprints • Aggregation framework $setIntersection Source: Chemical Similarity Search in MongoDB by Matt Swain 01001011 [2, 5, 7, 8, …]
- 25. MongoDB At Scale
- 26. Replica Sets High Availability Replica Set – 2 to 50 copies Self-healing shard Data Center Aware Addresses availability considerations: High Availability Disaster Recovery Maintenance Workload Isolation: operational & analytics
- 27. Data Hub for Large Investment Bank Feeds & Batch data • Pricing • Accounts • Securities Master • Corporate actions Real-time Real-time Real-time Real-time Real-time Real-time Real-time Each represents • Less hardware $ • Less license $ • No penalty $ • & many less problems MongoDB Secondaries MongoDB Primary
- 28. Automatic Sharding High Scalability Three types: hash-based, range-based, location-aware Increase or decrease capacity as you go Automatic balancing
- 30. Measuring Scale 250M Ticks/Sec 300K+ Ops/Sec 500K+ Ops/SecFed Agency Performance 1,400 Servers 1,000+ Servers 250+ Servers Entertainment Co. Cluster Petabytes 10s of billions of objects 13B documents Data Asian Internet Co. https://www.mongodb.com/mongodb-scale
- 31. Case Study Results Competitive Edge in Trading Space Built single platform for all financial data on MongoDB – open sourced! 60% less disk, 40% savings w/commodity SSDs 100x faster data retrieval 250M ticks per second - 25x! Measuring Scale
- 32. Case Study Results Competitive Edge in Trading Space Built single platform for all financial data on MongoDB – open sourced! 60% less disk, 40% savings w/commodity SSDs 100x faster data retrieval 250M ticks per second - 25x! UK gov’s “Digital Strategy” – up to 2 years each to deliver new tax services Pluggable micro-services, supporting CD Accelerated to 40-50 releases per week New tax services developed in 3 weeks New Paperless Tax Notifications saved £3M/month Measuring Scale
- 33. Case Study Results Competitive Edge in Trading Space Built single platform for all financial data on MongoDB – open sourced! 60% less disk, 40% savings w/commodity SSDs 100x faster data retrieval 250M ticks per second - 25x! UK gov’s “Digital Strategy” – up to 2 years each to deliver new tax services Pluggable micro-services, supporting CD Accelerated to 40-50 releases per week New tax services developed in 3 weeks New Paperless Tax Notifications saved £3M/month Modern Instruments vs. Legacy Databases Schema holds-up research by 3-6 months Flexible Schema removes impedance New tests in weeks not months Reduced time to introduce new drugs – a big difference to patients Measuring Scale
- 34. Case Study Results Competitive Edge in Trading Space Built single platform for all financial data on MongoDB – open sourced! 60% less disk, 40% savings w/commodity SSDs 100x faster data retrieval 250M ticks per second - 25x! UK gov’s “Digital Strategy” – up to 2 years each to deliver new tax services Pluggable micro-services, supporting CD Accelerated to 40-50 releases per week New tax services developed in 3 weeks New Paperless Tax Notifications saved £3M/month Modern Instruments vs. Legacy Databases Schema holds-up research by 3-6 months Flexible Schema removes impedance New tests in weeks not months Reduced time to introduce new drugs – a big difference to patients SQL Server instances per game Single flexible DB spanning all titles Cost center became Profit center: DBaaS for 3rd Party 3-week queries 2 mins Insights fed into game behavior in real time Measuring Scale
- 35. What does MongoDB do well? … and less well?
- 36. What MongoDB does well Agile development in most programming languages High Availability and automatic failover High performance on mixed workloads of reads, writes and updates Operational data analytics in real time Scale horizontally on demand at your data center or the cloud
- 38. What MongoDB does less well Graph traversal beyond two degrees of separation – NEO4J? Search Engine – SOLR/LUCENE? Transactions over multiple documents and multiple collections – SQL? Joins across collections 3.2 has left-outer joins! Massive large-scale parallel batch processing - HADOOP? Beyond 99.999% < 5.26 minutes/year Nanosecond latency writes – IN-MEMORY?
- 39. However…
- 42. ETL RDBMSPrimary
- 43. 3.2
- 44. Dynamic Lookup Data Governance & Intelligence Schema Validation BI Connector
- 45. More Workloads via Storage Engines In-Memory (beta) Encrypted
- 46. APM Integration Advanced Tools Query Profiling & Tuning Schema Discovery & Query Builder
- 47. What is your GIANT idea?
- 48. What does your GIANT IDEA need? • Develop AGILE applications • 99.999% availability • Deploy rapidly and SCALE on demand • Real time analysis in the database, under load • GEOSPATIAL querying • Processing in REAL TIME, not in batch • Deploy over commodity computing and storage architectures • Point in Time RECOVERY • Need strong data consistency • Advanced SECURITY
- 50. Q&A Sigfrido “Sig” Narváez Sr. Solutions Architect, MongoDB sigfrido@mongodb.com @SigNarvaez
