Moder SQL, par Cédric Krier. Rencontre des Geeks Anonymes du 14 mars 2018

1. Modern SQL
Writing SQL query in 21th century
Cédric Krier
B2CK
http://www.b2ck.com/

2. 2
Cédric Krier @ B2CK
●
Tryton (ERP)
●
python-sql

3. 3
Structured Query Language
●
Domain Specific Language
– Data Query Language (SELECT)
– Data Definition Language (CREATE TABLE)
– Data Control Language (GRANT)
– Data Manipulation Language
(INSERT / UPDATE / DELETE)
●
Relational Database Management System

4. 4
Standard
●
SQL-86 SQL-89 SQL-92
●
SQL:1999 (SQL3)
– Common Table Expression
– GROUPING SETS, ROLLUP and CUBE
●
SQL:2003
– Window Function
– Filter
●
SQL:2006 (XML) SQL:2008 SQL:2011 (Temporal)
SQL:2016 (JSON, LISTAGG)

5. 5
Interoperability
●
PostgreSQL
●
Mimer SQL

6. 6
Data Query Language
SELECT <expression>, …
FROM <table>, …
WHERE <condition>, …
GROUP BY <grouping>, …
HAVING <expression>, …
ORDER BY <expression> ASC|DESC, …

7. 7
GROUPING SETS, ROLLUP and CUBE
GROUP BY GROUPING SETS
((<expression>, …), (…))

8. 8
GROUPING SETS, ROLLUP and CUBE
Example

9. 9
GROUPING SETS, ROLLUP and CUBE
GROUP BY ROLLUP (<e1>, <e2>, <e3>, …)
=
GROUP BY GROUPING SETS (
(<e1>, <e2>, <e3>, …),
(<e1>, <e2>),
(<e1>),
())

10. 10
GROUPING SETS, ROLLUP and CUBE
Example

11. 11
GROUPING SETS, ROLLUP and CUBE
GROUP BY CUBE (<e1>, <e2>, …)
=
GROUP BY GROUPING SETS (
(<e1>, <e2>),
(<e1>),
(<e2>, <e1>),
(<e2>)
(),
)

12. 12
GROUPING SETS, ROLLUP and CUBE
Example

13. 13
GROUPING SETS, ROLLUP and CUBE:
compatibility
●
DB2 ✔
●
MySQL ✘ (WITH ROLLUP)
●
Oracle ✔
●
PostgreSQL ✔
●
SQL Server ✔
●
SQLite ✘

14. 14
FILTER
SUM(<expression>) FILTER ( WHERE <condition> )

15. 15
FILTER
Example

16. 16
Filter: compatibility
●
DB2 ✘
●
MySQL ✘
●
Oracle ✔ (using WITHIN GROUP)
●
PostgreSQL ✔
●
SQL Server ✘
●
SQLite ✘

17. 17
Filter: Alternative
SUM(CASE WHEN <condition>
THEN <expression> END)
⚠ NULL: OK for most aggregate

18. 18
Filter: Alternative COUNT(*)
COUNT(CASE WHEN <condition> THEN 1 END)

19. 19
Window Function: PARTITION BY
SUM(<expression>)
OVER ( PARTITION BY <expression> )
PARTITION divides rows in groups with the same
value

20. 20
Window Function: PARTITION BY
Example

21. 21
Window Function: ORDER BY
RANK() OVER ( ORDER BY <expression> )
rows from the start up through the current row

22. 22
Window Function: ORDER BY
Example

23. 23
Window Function:
PARTITION BY ORDER BY
Example

24. 24
Window Function: compatibility
●
DB2 ✔
●
MySQL ✔
●
Oracle ✔
●
PostgreSQL ✔
●
SQL Server ✔
●
SQLite ✘

25. 25
Window Function: naming
SELECT
SUM(<expression>) OVER <name>,
AVG(<expression) OVER <name>
FROM <table>
WINDOW <name> AS (
PARTITION BY <expression>
ORDER BY <expression> )

26. 26
Window Function: BETWEEN
SUM(<expression>)
OVER ( <RANGE|ROWS>
BETWEEN <start> AND <end> )

27. 27
Window Function: BETWEEN
●
UNBOUNDED PRECEDING
●
<value> PRECEDING
●
CURRENT ROW
●
<value> FOLLOWING
●
UNBOUNDED FOLLOWING

28. 28
Window Function: BETWEEN ROW
CURRENT ROW
UNBOUNDED PRECEDING UNBOUNDED FOLLOWING
3 PRECEDING 2 FOLLOWING
1 PRECEDING 1 FOLLOWING
1 2 3 4 5 6 7 8 9

29. 29
Window Function: BETWEEN RANGE
CURRENT ROW
UNBOUNDED PRECEDING
UNBOUNDED FOLLOWING
1 2 3 4 5 6 7 8 9
10 15 20 25 25 25 25 30 40

30. 30
Window Function: BETWEEN
Default:
RANGE BETWEEN UNBOUNDED PRECEDING
AND CURRENT ROW

31. 31
Window Function: RANGE | ROWS
●
RANGE:
– CURRENT ROW:
●
<start>: first row of peer rows (from ORDER BY)
●
<end>: last row of peer rows (from ORDER BY)
– No <value> PRECEDING | FOLLOWING
●
ROWS:
– CURRENT ROW:
●
Always current row

32. 32
Window Function: BETWEEN
Example

33. 33
Common Table Expression
WITH <name> (<column>,…) AS
(SELECT …)
SELECT …

34. 34
Common Table Expression: multiple
WITH name1 AS(
SELECT …),
WITH name2 AS (
SELECT …
FROM name1)
SELECT …

35. 35
Common Table Expression: compatibility
●
DB2 ✔ (no subquery)
●
MySQL ✔ (> MySQL 8.0 & MariaDB 10.2)
●
Oracle ✔
●
PostgreSQL ✔
●
SQL Server ✔ (no subquery, insert)
●
SQLite ✔

36. 36
CTE Recursive
WITH RECURSIVE <name> (<column>, …) AS (
SELECT …
UNION ALL
SELECT … FROM <name> …
)
SELECT …

37. 37
CTE Recursive
Example

38. 38
CTE Recursive: compatibility
●
DB2 ✔
●
MySQL ✔ (> MySQL 8.0 & MariaDB 10.2)
●
Oracle ✔
●
PostgreSQL ✔
●
SQL Server ✔
●
SQLite ✔

39. 39
Questions?

40. 40
Links
●
https://www.postgresql.org/docs/
●
https://modern-sql.com/
