Messaging Patterns in the
Cloud
Radu Vunvulea
iQuest Group
@RaduVunvulea
http://vunvulearadu.blogspot.com

Private &
Public CloudHuge thanks to our sponsors!

Private &
Public Cloud
• World of Messages
• On-Premise and Cloud solutions
• Messaging Patterns
• Costs, Benefits and Limitations
Agenda

WORLD OF MESSAGES

Private &
Public CloudWorld of Messages

Private &
Public CloudWorld of Messages
Message
Message
Message

Private &
Public CloudEnterprise Service Bus

Private &
Interaction and communication between
software applications

Private &
Topic
Subscriptions

ON-PREMISE AND CLOUD
SOLUTIONS

Private &
Public Cloud
• Pro
– Open Source
– Flexible
– Good price
– Transactional queue read/write
– Flexible load distribution
• Cons
– No queue management
– Document not up to date
– Only one queue technology supported (MSMQ)
NService Bus

Private &
Public Cloud
• Pro
– Free for commercial use
– Supports MSMQ and RabittMQ
– Open Source
– Good administration console
• Cons
– No commercial support
– Not as fast as NServiceBus
MassTransit

Private &
Public Cloud
• Pro
– Scalable
– Lots of features
– Good administration console
– Support
– Cross platform and multiple environments
• Cons
– Is not free
– Latency
Azure Service Bus

MESSAGING PATTERNS

Private &
Public CloudMessage Filter

Private &
Public CloudMessage Filter
Topic
Subscriptions

Private &
Public Cloud
• Custom rules based on message attributes
• Add attributes to message
Message Filter
BrokeredMessage msg = new BrokeredMessage(messageContent);
msg.Properties["colorCode"] = 1;
• Create subscription with custom rule
RuleDescription rule = new RuleDescription()
{
// 1 - green, 2 - orange
Filter = new SqlFilter("colorCode = 1");
}
namespaceManager.CreateSubscription(
"itcamp", "greensubscription", rule);

Private &
Public CloudMessage Splitter

Private &
Public CloudMessage Splitter
Topic
Subscriptions

Private &
Public Cloud
• Group messages based on session
Message Splitter
MessageSession msgSession =
msgReceiver.AcceptMessageSession();
BrokeredMessage message;
while ((message = msgSession.Receive()) != null)
{
// Process message
}
msgSession.Complete()
BrokeredMessage message = new BrokereMessage(content);
message.SessionId = "sessionId";
• Consume messages based on session id

Private &
Public CloudMessage Aggregator

Private &
Public CloudMessage Aggregator
Topic
Subscriptions

Private &
Public Cloud
• Group messages based on session
Message Aggregator
message.SessionId = "sessionId";
• Use correlation id and filters
BrokereMessage message = new BrokereMessage(content);
message.CorrelationId = “CJ"
topic.Send(message);
namespaceManager.CreateSubscription(
“itcamp”,
“iquestsubscriptioncar”,
new CorrelationFilterExpression(“CJ"));

Private &
Public CloudMessage Resequencer

Private &
Topic
Subscriptions
1
2
3
4
1
2
3
4
1234

Private &
Topic
Subscriptions
1
2
3
4
1
2
3
4
3412

Private &
Public Cloud
• Session, message index and message count
Message Resequencer
• Mark message as dead letter when in
incorrect order
• Iterate dead letter queue to access a
message with a lower index
message.Properties["index"] = 2;
message.Properties["count"] = 10
message.SessionId = “CJ-15-IQU";

Private &
MessageSession messageSession =
queueClient.AcceptMessageSession();
int currentIndex = 1;
while(true)
{
BrokeredMessage message = messageSession.Receive();
if(int.Parse(message.Properties[“index”]) != currentIndex)
{
message.DeadLetter();
continue;
}
…
message.Complete();
if(int.Parse(messsage[“count”]) == currentIndex)
{
break;
}
currentIndex++;
}

Private &
Public CloudMessage Recipient
Topic
Subscriptions

Private &
Public Cloud
• Use a property to specific the list of groups
Message Recipient
• Define custom filters using LIKE operator
BrokeredMessage message = new BrokeredMessage(content);
message.Properties[“groups”] = “orange magenta”;
SqlFilter filter = new SqlFilter(
“groups LIKE „%orange%‟”);
topic.AddSubscription(“subscription3”, filter);
• OR different properties for each group type
“EXISTS orange”);

Private &
Public Cloud
• Use a property to specific the list of groups
Message Recipient
• Define custom filters using LIKE operator
BrokeredMessage message = new BrokeredMessage(content);
message.Properties[“groups”] = “orange magenta”;
“groups LIKE „%orange%‟”);
• OR different properties for each group type
• Use only one property and a prime number
for each group

Private &
Public CloudContent-Based Router
Topic
Subscriptions

Private &
Public CloudScatter-Gather
Topic
Subscriptions
Queue

Private &
Public CloudDynamic Router
Topic
Subscriptions

Private &
Public Cloud
• [key, values] properties
• Store properties
• Decorate properties
Dynamic Router

COSTS, BENEFITS AND
LIMITATIONS

Private &
Public Cloud
• What are the costs of processing:
– 24kB message size
– 10M messages
– 1 Topic
- 8 hours
Costs

Private &
Public Cloud
• 10$ Sending
• 27.46$ Bandwidth (sending)
Costs

Private &
Public Cloud
• 10$ Sending
• 10 $ Receiving
• 0 $ Bandwidth (receiving)
Costs

Private &
Public Cloud
• 10$ Sending
• 10 $ Receiving
• 47.46$ Costs related to Service Bus
Costs

Private &
Public Cloud
• 10$ Sending
• 10 $ Receiving
• 47.46$ Costs related to Service Bus
• 8.64$ 4 Medium Worker Roles used to
consume messages
• 56.1$ Total cost
Costs

Private &
Public Cloud
• Cheap
• 99.9% Uptime
• Extremely scalable and flexible
• No message is lost
• Filters and actions support
• REST API
• Death-letter and transaction support
• Same API for on-premise and cloud
Benefits

Private &
Public Cloud
• Not for real-time application
• When processing more than 1M messages
on the same topic in a 30 minutes time
interval latency increases
• You need to pay for each send/receive
command
• Batch maximum size – 100 messages
Limitations

Q & A

THANK YOU
