15. COOK - TORRANCE
• 퐁 모델을 개량한 물리기반 조명들 중에 하나
• 표면의 거친정도(Roughness)를 표현할수있는 반사모델의 한 종류
• 금속 표면을 표현하는데 적절
• 계산부하는 당연히 높아짐
16.
17.
18. COOK – TORRANCE EQUATION
BeckMann Or Gauss
??
미세면이 통계적으로 법선에 대해
19. 미세면(MICROFACET)
• 물체의 표면을 미세면의 집합이라 표현
• 퐁반사에서는 이들을 반사지수로 대충 처리
• 하이라이트가 희미해지는것은 표면에 차이 (거침, 매끈함)
• 이들 미세면이 한방향이 아니기에 희미해진다라는 것이 Torrance 와 Sparrow의
제안
20. 기하 감쇠율
• 미세면에 입사한 빛이 다른 미세면에 그림자를 만드는 효과
• E ┴ N or L ┴ N 일때 효과가 커짐
21. 미세면 분포함수
• 미세면이 법선에 대해 어떻게 어긋나 있는가를 통계적으로 나타낸 함수
Beckmann
• 미세면이 거칠다면 훨씬 더 여러방향으로 분포 됨
Gauss
22. 프레넬 항
• 낮은 각도에서 같은 광원이라 할지라도 스펙큘러가 훨씬 밝게 보이는 현상
빛의 반사는 전자와 전자파의 상호작용에 의해 생기는데 빛은 가시광선의 파장을 가지는
35. 디퍼드 엔진에서??
• Roughness 정보를 따로 저장하기 위해서 렌더타겟이 하나 더 필요
• Crytek에서 사용하는 R8G8B8에 법선을 때려넣고 A 에 Roughness와 Speclular를
저장
• 7비트만을 Specular로 사용 1비트로 Roughness 처리 (Specular <-> Roughtness 역
함수 관계)
