Presentation / Workshop which will teach you the core patterns, concepts and visualisation options of D3.js (v4). Accompanying exercises can be found here: https://github.com/josdirksen/d3exercises
3. BEFORE WE START
Get the code from:
You need a webserver for some of the examples:
IntelliJ supports this (right click on HTML and run)
Easiest is with python: check if you can run:
https://github.com/josdirksen/d3exercises
python -m SimpleHTTPServer (for Python 2)
python3 -m http.server (for Python 3)
If not download the mongoose webserver, and you have
4. WHO AM I
Love writing, and talking about technology (frontend as well
as backend). Writing about stuff for Packt and Manning
Twitter:
Github:
Contact me:
Blog at:
@josdirksen
http://www.github.com/josdirksen
jos.dirksen@gmail.com
www.smartjava.org
Plug: Expert Data Visualization with D3.js (Q1 2017)
5. WHAT ARE WE GOING TO DO
I'll introduce a subject (couple of minutes)
I'll Explain the exercise
You can fill in the blanks in the provided code.
// Step 2. We can also select multiple elements. Use d3.select and
// d3.selectAll to see the difference when selecting all the
// <li> elements, and use either classed or attr to set the class
// of these elements to 'step2'.
// d3.selectAll(...).classed(..., ...)
Halfway during the exercise I'll push an answer to git and
Don't hesitate to ask questions!
6. WE'RE GOING TO TRY AND COVER...
Learn how D3.js binds data to DOM elements.
Make basic charts and diagrams
Visualize hierarchical data
Show connected graphs
Combine gis/geo information with opendata
Make art with voronois
7. WHAT AREN'T WE GOING TO COVER
D3.js is big, very big. We'll explore the basics for data
visualization, but there is a whole lot more. Most important
stuff we skip:
User interaction, mouse events, drag events.
Animations
Zooming & dragging
Streaming data
loading and queue data
Typescript, ES6, Scale.js bindings
...
9. WHAT IS D3.JS
"D3.js is a JavaScript library for manipulating documents
based on data. D3 helps you bring data to life using
. D3's emphasis on web standards gives you the
full capabilities of modern browsers without tying yourself to
a proprietary framework, combining powerful
and a to DOM
manipulation." --- d3js.org
HTML,
SVG, and CSS
visualization
components data-driven approach
10. WHAT IS IT NOT
Not a charting library: But provides the building blocks
(see nvd3.js, Rickshaw.js, c3.js).
Not a drawing library: Doesn't draw data itself, uses SVG
for visualization.
Not an SVG abstraction layer: Manipulates the DOM and
SVG directly.
Not a Canvas/WebGL library: Minimal support for Canvas,
for WebGL use Three.js.
Not a framework: Can be used with Angular 1/2, React,
Vue.js, , is just a (very extensive) library.
11. ONLINE INFORMATION
Lots of online resources,
Most for v3. current version is v4.
API:
Bit overwhelming..
But won't be in about 80 minutes
https://github.com/d3/d3/blob/master/API.md
12.
13. WORK BY EXAMPLE
Usually easier to work from examples
Best starting point:
Most examples still use v3 however..
https://bl.ocks.org/
16. HELLOWORLD OF D3.JS
Goal of this first example, is to learn how you can select
elements with D3.js, append new ones, remove elements, and
set basic properties on the elements.
17. SELECTIONS
d3.select and d3.selectAll
Uses the W3C selection syntax: uses querySelector
and querySelectorAll
Examples:
d3.selectAll('p') // Select all p elements in the document.
d3.select('p') // Select first p element in the document.
// Selects 1st span element of all <p> in the document
d3.selectAll('p').select('span')
d3.select('#id') // select on id
d3.select('.classname') // select on css class
18. WE CAN CHANGE THE PROPERTIES
OFF THESE SELECTIONS
attr(), style(), html(), text(), classed()
Value can also be a function:
d3.selectAll('img.thumb').attr('height', 50)
d3.selectAll('span').style('color', 'steelblue')
d3.selectAll('span').html('<strong>d3.js</strong>')
d3.selectAll('span').text('content')
// conditionally set or remove classes
d3.select('div').classed('container', true)
// d is bound data, i is the index
d3.selectAll('img').attr('src', function(d, i) {
return 'image' + i + '.png';
});
19. MODIFY THE SELECTION
append(): Append child to each element of selection
remove(): Remove all the elements in the selection
insert(): Insert an element before another element
d3.selectAll('p').append('span').
// remove the first li of every lu
d3.selectAll('ul').select('li').remove()
// insert a new span as the first element of the p
d3.selectAll('p').insert('span', ':first-child');
Selections are immutable, these actions return new
selections, so we can chain them!
20. BUT JQUERY CAN DO...
With you manipulate elements from a selection,
with you bind data (next example)
has many data visualization utils and APIs and
focusses on web app related plugins.
But there is a big overlap
both are libraries
have
and use a .
Similar to D3.js: Raphael.js and Processing.js
jQuery
D3.js
D3.js
jQuery
DOM manipulation
CSS/W3C selectors
fluent API
21. LET'S GET STARTED
$ git clone https://github.com/josdirksen/d3-exercises
$ python -m SimpleHTTPServer
Once again, if you don't have python, you can use
mongoose:
View at http://localhost:8000/src/exercise-01/E01.html
22.
23. EXERCISE 1: LEARNING D3.JS
Follow steps described in:
<ROOT>/src/exercise-01/js/E01.js
Use d3.select(), d3.selectAll(), class(),
attr(), append(), remove(), html(), text()
If needed reference D3.js select API:
You'll get approximately 5 minutes.
https://github.com/d3/d3-selection
Should you have question? Please ask.
25. D3.JS DATA BINDING
Learn how to create data driven document by usin the basic
select(), enter(), merge(), remove() cycle when
binding data to a selection
26. BASIC DATABINDING
Bind data to a selection with data(...)
<!-- Input Dom -->
<span></span>
<span></span>
<span></span>
<span></span>
var values=['a', 'b', 'c'];
d3.selectAll('span')
.data(values)
.text(function(d) {return d});
<!-- Output Dom -->
<span>a</span>
<span>b</span>
<span>c</span>
<span></span>
27. DATA DRIVEN ELEMENTS
Assume an empty DOM
var values=['a', 'b', 'c'];
var selection = d3.selectAll('span').data(values)
A selection is actually more than just the found elements
enter(): placeholder selection for unbound data
// for all unbound data append a span attribute
selection.enter().append('span').text(function(d) {return d});
exit(): placeholder selection for le over elements
// remove all the leftover elements
selection.exit().remove()
28. LEADS TO THIS PATTERN
function update(values) {
// select all the current span elements and assign the data
var selection = d3.selectAll('span').data(values)
// for the unbound data, create a new span, and attach a class
var newElements = selection.enter()
.append('span')
.attr('class', 'someClass');
// Merge combines two selections. For the combined selection
// set the value of the span to the bound datum.
newElements.merge(selection).text(function(d) {return d});
// and remove the now obsolete elements
selection.exit().remove();
}
This is the basic pattern you use to bind data, add new DOM
elements, updated existing ones, and remove obsolete ones.
29. WHICH PROVIDES US WITH
An easy way to let our data determine our elements.
Reduces unnecessary creation of elements.
Allow all kinds of hooks e.g. for animations.
// assume values contains some random numbers
function update(values) {
var selection = d3.selectAll('circle').data(values)
var newElements = selection.enter()
.append('circle')
.attr('class', 'someClass')
.attr('cx', function(d, i) {return i * 50})
.attr('cy', function() {return 50})
.merge(selection)
.transition().duration(2000)
.attr('r', function(d, i) {return d});
// and remove the now obsolete elements
selection.exit().remove();
}
31. EXERCISE 2: DATABINDING
Follow steps described in:
<ROOT>/src/exercise-02/js/E02.js
Use (same as previous) and enter(), exit(),
append(), remove()
If needed reference D3.js select API:
If time permits look at transistions API:
You'll get approximately 5 minutes.
https://github.com/d3/d3-selection
https://github.com/d3/d3-selection
Should you have question? Please ask.
33. BASIC CHARTS AND ELEMENTS
Learn how to create basic charts and elements using scales
and generators.
34. SVG, GROUPS AND POSITIONING
Absolute positioning:
<rect x="100", y="100"></rect>
<circle cx="100", cy="100"></circle>
Provides a g element for grouping
g doesn't have an x or y like attribute, uses transform
All attributes on this element apply on children
<g transform="translate(50 200)">...</g> <!-- positioning -->
<g transform="scale(0.5 0.3)">...</g> <!-- sizing -->
<g transform="rotate(45)">...</g> <!-- rotate the g -->
These actions can be combined
But positioning is still difficult
35. POSITIONING WITH SCALES
A scale translates an input domain to an output range
Different scales ( )
: continuous input to continuous output
scalePow, scaleLog, scaleTime
: continuous input to interpolator
scaleQuantize: continuous input to discrete range
scaleQuantile: sampled input to discrete range
scaleThreshold: scaleQuantize with thresholds
scaleOrdinal: discrete input to discrete range
, scalePoint
Lots of useful helper functions
https://github.com/d3/d3-scale
scaleLinear
scaleSequential
scaleBand
36. SCALELINEAR: CONTINUOUS INPUT
TO CONTINUOUS OUTPUT
var x = d3.scaleLinear()
.domain([10, 130]) // e.g the min and max of your data
.range([0, 960]); // the width of your chart
x(20); // 80
x(50); // 320
var color = d3.scaleLinear()
.domain([10, 100])
.range(["brown", "steelblue"]);
color(20); // "#9a3439"
color(50); // "#7b5167"
37. WHAT CAN WE INTERPOLATE?
The domain must be numbers, the range can be any of this:
And if this doesn't match, you can create your own.
38. SCALESEQUENTIAL: CONTINUOUS
INPUT TO INTERPOLATOR
var color = d3.scaleSequential(d3.interpolatePlasma).domain([0, 100]);
color(30); // #8f0da4
color(60); // #e16462
color(80); // #fca636
Many interpolators available:
39.
40. HOW WOULD YOU USE THIS?
// say our values contains data from 1984 to 2014
var min = d3.min(values, function (d) { return d.value; });
var max = d3.max(values, function (d) { return d.value; });
// evenly divide the years along the xAxis
var xScale = d3.scaleLinear().domain([1984,2014]).range([0, 1080]);
// evenly divide the values along the yAxis
var yScale = d3.scaleLinear()
.domain([min, max]).range([0, 700]);
// get a color
var col = d3.scaleSequential(d3.interpolatePlasma).domain([0, 100]);
d3.selectAll("rect").data(values).enter()
.append("rect")
.attr("x", xScale) // xScale = (d: any) => Numeric
.attr("y", function(d) {return yScale(d)}) // alternatively
.attr("fill", col)
41. SCALES AND AXIS
D3 provides easy way to create an axis:
https://github.com/d3/d3-axis
var min = d3.min(values, function (d) { return d.value; });
var max = d3.max(values, function (d) { return d.value; });
var yScale = d3.scaleLinear()
.domain([min, max]).range([0, 700]);
// s denotes that we want to use international system of units
// to display axis values
var bottomAxis = d3.axisBottom().scale(yScale).ticks(20, "s");
Results in:
43. BEFORE WE START
D3.js support easy loading csv, tsv, json, xml
name,sex,amount
Emma,F,20355
Olivia,F,19553
...
d3.csv('data/yob2015.txt',
function (d) { return {
name: d.name,
sex: d.sex,
amount: +d.amount };
},
function (data) {
}
44. ALSO FOR MULTIPLE FILES
d3.queue()
.defer(d3.json, "./data/world-110m.v1.json")
.defer(d3.csv, "./data/worldbank_popular_2014.csv")
.defer(d3.csv, "./data/iso-mapping.csv")
.await(function (error, topoData, worldbank, mapping) {
}
45. EXERCISE 3: WORKING WITH SCALES
Follow steps described in:
<ROOT>/src/exercise-03/js/E03.js
If needed reference D3.js APIs:
You'll get approximately 8 minutes.
https://github.com/d3/d3-scale
https://github.com/d3/d3-axis
Should you have question? Please ask.
46. USING SVG FOR CHARTS
SVG provides a large number of elements:
But limited primitive shapes: <circle>, <ellipse>,
<line>, <path>, <polygon>, <polyline>, <rect>
https://developer.mozilla.org/en-US/docs/Web/SVG
47. THE PATH ELEMENT IS VERSATILE
the d attribute describes a path:
<path class="arc" d="M136.86141570725613,-17.69047457265137A138,138,
0,0,1,124.60150267951192,59.31665474390461L62.948628653284814,28.
257214134993035A69,69,0,0,0,68.61145448511735,-7.312203049469534Z"
style="fill: rgb(252, 160, 130);"></path>
M, L, A, C, A, Q, T ... for lines, arcs, curves
Hard to determine the correct values yourself
D3.js provides generators for complex shapes
48. THE ARC GENERATOR
We'll create an arc segment, a part of a pie chart
var arc = d3.arc()
.outerRadius(height/2 * 0.6).innerRadius(height/2 * 0.3);
// create the right half of a pie chart
arc({
startAngle: 0,
endAngle: Math.PI
});
// "M1.469576158976824e-14,-240A240,240,0,1,1,1.469576158976824e-14,
// 240L7.34788079488412e-15,120A120,120,0,1,0,7.34788079488412e-15,
// -120Z"
49. COMBINED WITH THE PIE FUNCTION
Piechart: d3.pie() to generate config for d3.arc
var arc = d3.arc()
.outerRadius(height/2 * 0.6).innerRadius(height/2 * 0.3);
var data = [{count:10}, {count:20}, {count:30}]
var pie = d3.pie()
.padAngle(0.04)
.value(function (d) { return d.count; });
var arcs = pie(data)
// "[{"data":{"count":10},"index":2,"value":10,
// "startAngle":5.215987755982988,
// "endAngle":6.283185307179586,"padAngle":0.04},
// {"data":{"count":20},"index":1,"value":20,
// "startAngle":3.121592653589793,
// "endAngle":5.215987755982988,"padAngle":0.04} ...
selectAll("path").data(arcs).enter()
.append("path").attr("d", arc);
50. ANOTHER STANDARD PATTERN
1. Define generator which creates paths based on properties.
(d3.arc)
2. Define generator which creates config for other generators
(d3.pie)
3. Pass data to step 2, result is enriched data with config.
4. Use the normal selectAll(), enter(), merge(),
exit() pattern
52. EXERCISE 4, CREATE A PIE CHART
Follow steps described in:
<ROOT>/src/exercise-04/js/E04.js
If needed reference D3.js APIs:
You'll get approximately 5 minutes.
https://github.com/d3/d3-shape
60. ALL FOLLOW SAME APPROACH
1. Load the data (d3.csv,d3.tsv,d3.json etc.)
2. Convert the data into a tree stucture
3. Pass it through a generator
4. Use the output from the generator to draw the chart
61. NESTED DATA: D3.STRATISFY
d3.stratisfy() can follow ids in your data
id,parentId,name,description
180580,,Felidae,cats
180581,552363,Lynx,lynxes
180582,180581,rufus,Bobcat
180583,180582,rufus,bobcat
180584,180581,lynx,Eurasian Lynx
180585,180581,canadensis,Canada lynx`
var stratify = d3.stratify();
var root = stratify(data);
62. NESTED: D3.NEST / D3.HIERARCHY
d3.nest() can group data (multiple times) based on a key
"Country (en)";"Country (de)";"Country (local)";"Country code";"Continent"
"Afghanistan";"Afghanistan";"Afganistan/Afqanestan";"AF";"Asia";
"Egypt";"Ãgypten";"Misr";"EG";"Africa";
var entries = d3.nest()
.key(function (d) {return d.Continent; })
.entries(data);
var root = d3.hierarchy({values: entries},
function(d) { return d.values; })
63. USE A GENERATOR
With data in the correct structure, we can use a generator
// normal node tree
var tree = d3.tree()
.size([height, width])
.separation(function(a, b) {
return (a.parent === b.parent ? 5 : 13)
});
// create a treemap
var tree = d3.treemap()
.size([width, height])
.padding(2)
.tile(d3.treemapSquarify.ratio(1))
// enrich the root
tree(root)
64. WHICH ENRICHES THE STRUCTURE
root.leaves() // return all the nodes without children
root.descendants() // return array of this and all descendants
chart.selectAll(".node")
.data(root.descendants())
.enter(..)
66. EXERCISE 5, CREATE A TREEMAP
Follow steps described in:
<ROOT>/src/exercise-05/js/E05.js
If needed reference D3.js APIs:
You'll get approximately 8 minutes.
https://github.com/d3/d3-hierarchy
69. FORCE LAYOUT FOR GRAPHS
API:
A graph is a set of nodes.
Define forces which are applied:
to nodes
to links
Run a simulation
https://github.com/d3/d3-force
70. CAN APPLY DIFFERENT FORCES
forceCenter: keeps nodes in the center
forceCollide: nodes have a radius, avoid collisions
forceLink: push/pull nodes together based on distance
forceManyBody: simulate attraction or repulsion
between nodes
forceX: force nodes towards specific position
forceY: force nodes towards specific position
71. BASIC SETUP
var graph = ...
// define forces
var simulation = d3.forceSimulation()
.force("link", d3.forceLink().id(function(d) { return d.id; }))
.force("charge", d3.forceManyBody())
.force("center", d3.forceCenter(width / 2, height / 2));
// run a simulation
simulation
.nodes(graph.nodes)
.on("tick", ticked);
// do something on each tick
function ticked() {...}
84. QUICK NOTE ON PROJECTIONS
Projection defines how the coordinates from the source are
projected to a flat canvas. The projection:Sinu Mollweide
Example
86. HOW TO LOAD DATA
Most common format for GIS data is ArcGIS shapefile.
binary format
Use QGis, Mapshaper, OGR to convert to open formats
D3.js can work with:
GeoJSON: A standard supported by many applications.
TopoJSON: A specific optimized format for smaller files.
87. GEOJSON AND TOPOJSON FORMATS
Can contain multiple geometries.
Each geometry is described (usually) as a path.
Can contain additional properties
population, unemployment rate, etc.
one file for everything
Try to work with TopoJSON, since it's much smaller
{"type":"Topology","objects":{"cb_2015_us_county_500k": {"type":
"GeometryCollection","geometries":[{"type":"Polygon","properties":
{"GEOID":"01005","NAME":"Barbour"},"id":"01005","arcs":[[0,1,2,3
,4,5,6,-7,6,7,8,9,10,11,12,13,14 ...
88. WORKING WITH TOPO DATA IN D3.JS
(pretty much the same way as we did before)
1. Setup a path generator and projection
2. Load the data
3. Use the projection to generate path segments
89. LOAD THE DATA
(this is prepared data, where value contains percentage of
internet users)
{"type":"Topology","objects":{"countries":{"type":"GeometryCollection"
"geometries":[{"type":"Polygon","id":"004","arcs":[[0,1,2,3,4,5]],
"properties":{"value":"7","countryA":"AFG","name":"Afghanistan"}},
{"type":"MultiPolygon","id":"024","arcs":[[[6,7,8,9 ....
d3.json("./data/world-110m-inet.json", function(loadedTopo) {
// by using topojson.feature, we convert the topoJson to geojson,
// where each country is a single feature in the features array.
countries = topojson.feature(loadedTopo,
loadedTopo.objects.countries).features;
});
91. SETUP THE PATH GENERATOR
var projection = d3.geoNaturalEarth()
var path = d3.geoPath().projection(projection)
For all the supported projections see:
Pretty much any projection you can think off
Relatively easy to create your own one
https://github.com/d3/d3-geo/
https://github.com/d3/d3-geo-projection
92. WITH A GENERATOR AND THE DATA
var projection = d3.geoNaturalEarth()
var path = d3.geoPath().projection(projection)
d3.json("./data/world-110m-inet.json", function(loadedTopo) {
countries = topojson.feature(loadedTopo,
loadedTopo.objects.countries).features;
svg.selectAll('.country').data(countries).enter()
.append("path")
.classed('country', true)
.attr("d", path);
}
And that's it..
97. EXERCISE 7, RENDER THE US
ELECTION RESULTS
Follow steps described in:
<ROOT>/src/exercise-07/js/E07.js
If needed reference D3.js APIs:
You'll get approximately 10 minutes.
https://github.com/d3/d3-geo/
https://github.com/d3/d3-geo-projection
100. D3.JS SUPPORTS VORONOIS
In mathematics, a Voronoi diagram is a partitioning of a plane
into regions based on distance to points in a specific subset of
the plane. That set of points (called seeds, sites, or generators)
is specified beforehand, and for each seed there is a
corresponding region consisting of all points closer to that
seed than to any other.
104. ANY DEEPER BREAKS MY BROWSER
This is rendered as SVG elements
We could output to canvas as well
105. EXERCISE 7, PLAY AROUND WITH
THE VORONOI CODE
Not really an exercise, but allows you to experiment with
voronois.
Follow steps described in:
<ROOT>/src/exercise-08/js/E08.js
106. @josdirken ~ Exercises for this session: https://github.com/josdirksen/d3exercises
THANK YOU!
