The document contains architectural floor plans and sections for the ground floor level of a building project. It includes layouts and dimensions for floor slabs, walls, ramps, and other structural elements. Technical information like thickness of concrete elements and level heights are provided. The drawings reference section cuts through various areas of the floor plan.
Raft Foundation Plan, section details ans steel schedule for a proposed art gallery extension in Ballyglunin Railway Station.
Raft foundation designed for a wall timber frame 300mm twin studs @ 600mm centres (double 38mm x 89mm timber stud set 122mm apart each other) surrendered externally with 417mm a hemp and lime (hempcrete) building material, external finish 20mm lime render and internal finis 13mm lime plaster
Raft Foundation Plan, section details ans steel schedule for a proposed art gallery extension in Ballyglunin Railway Station.
Raft foundation designed for a wall timber frame 300mm twin studs @ 600mm centres (double 38mm x 89mm timber stud set 122mm apart each other) surrendered externally with 417mm a hemp and lime (hempcrete) building material, external finish 20mm lime render and internal finis 13mm lime plaster
