Learn about the major concepts of Relay Modern

3. Nikolas Burk 👋
Developer at Graphcool
$ whoami
@nikolasburk

4. Launch Week 🚀
Product Hunt > 1000 upvotesHacker News #1

5. Getting Started with
Relay Modern

6. 1. Relay - A Brief History
2. Data Fetching
3. Mutations
4. More Features in Relay Modern
Agenda
@nikolasburk

7. Relay - A Brief History
@nikolasburk

8. Relay - A Brief History
@nikolasburk
01/2015
1st talk about Relay
@React.js Conf 2015
2012
FB starts using
GraphQL
02/2015
🗣
Announcing Relay will
be open-source
08/2015
Relay is
open-source 🎉
08/2016
🗣
Announcing plans
for “Relay 2”
04/2017
Introducing
Relay Modern

9. GraphQL Clients
- homegrown by Facebook
- main goal: performance
- learning curve
- community-driven
- main goal: flexibility
- easy-to-get-started
@nikolasburk

10. Data Fetching
@nikolasburk

11. Traditional Data Fetching with REST
1. construct & send HTTP request
(e.g. with fetch)
2. receive & parse server response
3. store data locally
4. display data in UI
😐
@nikolasburk

12. Declarative Data Fetching with GraphQL
1. describe data dependencies
2. display data in UI
😍
@nikolasburk

13. Relay’s core idea is to couple a view
component with its data dependencies
@nikolasburk

14. Example:
Simple Instagram App
@nikolasburk

15. Post Post
ListPage
App
@nikolasburk

16. class Post extends React.Component {
render () {
return (
<div>
<img
src={this.props.post.imageUrl}
/>
<div>
{this.props.post.description}
</div>
</div>
)
}
}
export default createFragmentContainer(Post, graphql`
fragment Post_post on Post {
id
description
imageUrl
}
`)
Post.js
@nikolasburk

17. class Post extends React.Component {
render () {
return (
<div>
<img
src={this.props.post.imageUrl}
/>
<div>
{this.props.post.description}
</div>
</div>
)
}
}
export default createFragmentContainer(Post, graphql`
fragment Post_post on Post {
id
description
imageUrl
}
`)
Post.js
@nikolasburk

18. class Post extends React.Component {
render () {
return (
<div>
<img
src={this.props.post.imageUrl}
/>
<div>
{this.props.post.description}
</div>
</div>
)
}
}
export default createFragmentContainer(Post, graphql`
fragment Post_post on Post {
id
description
imageUrl
}
`)
Post.js
@nikolasburk

19. class Post extends React.Component {
render () {
return (
<div>
<img
src={this.props.post.imageUrl}
/>
<div>
{this.props.post.description}
</div>
</div>
)
}
}
export default createFragmentContainer(Post, graphql`
fragment Post_post on Post {
id
description
imageUrl
}
`)
Post.js
@nikolasburk

20. class Post extends React.Component {
render () {
return (
<div>
<img
src={this.props.post.imageUrl}
/>
<div>
{this.props.post.description}
</div>
</div>
)
}
}
export default createFragmentContainer(Post, graphql`
fragment Post_post on Post {
id
description
imageUrl
}
`)
Post.js
@nikolasburk

21. class Post extends React.Component {
render () {
return (
<div>
<img
src={this.props.post.imageUrl}
/>
<div>
{this.props.post.description}
</div>
</div>
)
}
}
export default createFragmentContainer(Post, graphql`
fragment Post_post on Post {
id
description
imageUrl
}
`)
Post.js
@nikolasburk

22. export default createFragmentContainer(ListPage, graphql`
fragment ListPage_viewer on Viewer {
allPosts @connection(key: “ListPage_allPosts") {
edges {
node {
…Post_post # from Post.js
}
}
}
}
`)
class ListPage extends React.Component {
render () {
return (
<div>
{this.props.viewer.allPosts.edges.map(({node}) =>
<Post key={node.id} post={node} />
)}
</div>
)
}
}
ListPage.js
@nikolasburk

23. export default createFragmentContainer(ListPage, graphql`
fragment ListPage_viewer on Viewer {
allPosts @connection(key: “ListPage_allPosts") {
edges {
node {
...Post_post
}
}
}
}
`)
class ListPage extends React.Component {
render () {
return (
<div>
{this.props.viewer.allPosts.edges.map(({node}) =>
<Post key={node.id} post={node} />
)}
</div>
)
}
}
ListPage.js
@nikolasburk

24. export default createFragmentContainer(ListPage, graphql`
fragment ListPage_viewer on Viewer {
allPosts @connection(key: “ListPage_allPosts") {
edges {
node {
...Post_post
}
}
}
}
`)
class ListPage extends React.Component {
render () {
return (
<div>
{this.props.viewer.allPosts.edges.map(({node}) =>
<Post key={node.id} post={node} />
)}
</div>
)
}
}
ListPage.js
@nikolasburk

25. export default createFragmentContainer(ListPage, graphql`
fragment ListPage_viewer on Viewer {
allPosts @connection(key: “ListPage_allPosts") {
edges {
node {
...Post_post
}
}
}
}
`)
class ListPage extends React.Component {
render () {
return (
<div>
{this.props.viewer.allPosts.edges.map(({node}) =>
<Post key={node.id} post={node} />
)}
</div>
)
}
}
ListPage.js
@nikolasburk

26. export default createFragmentContainer(ListPage, graphql`
fragment ListPage_viewer on Viewer {
allPosts @connection(key: “ListPage_allPosts") {
edges {
node {
...Post_post
}
}
}
}
`)
class ListPage extends React.Component {
render () {
return (
<div>
{this.props.viewer.allPosts.edges.map(({node}) =>
<Post key={node.id} post={node} />
)}
</div>
)
}
}
ListPage.js
@nikolasburk

27. export default createFragmentContainer(ListPage, graphql`
fragment ListPage_viewer on Viewer {
allPosts @connection(key: "ListPage_allPosts") {
edges {
node {
...Post_post
}
}
}
}
`)
class ListPage extends React.Component {
render () {
return (
<div>
{this.props.viewer.allPosts.edges.map(({node}) =>
<Post key={node.id} post={node} />
)}
</div>
)
}
}
ListPage.js
@nikolasburk

28. The QueryRenderer
QueryRenderer is the root of a Relay tree.
It takes a query, fetches the data
and calls the render callback.
@nikolasburk

29. class App extends Component {
render() {
return (
<QueryRenderer
environment={environment}
query={AppAllPostQuery}
render={({error, props}) => {
if (error) {
return <div>{error.message}</div>
} else if (props) {
return <ListPage viewer={props.viewer} />
}
return <div>Loading</div>
}}
/>
)
}
}
const AppAllPostQuery = graphql`
query AppAllPostQuery {
viewer {
…ListPage_viewer
}
}
`
App.js
@nikolasburk

30. class App extends Component {
render() {
return (
<QueryRenderer
environment={environment}
query={AppAllPostQuery}
render={({error, props}) => {
if (error) {
return <div>{error.message}</div>
} else if (props) {
return <ListPage viewer={props.viewer} />
}
return <div>Loading</div>
}}
/>
)
}
}
const AppAllPostQuery = graphql`
query AppAllPostQuery {
viewer {
…ListPage_viewer
}
}
`
App.js
@nikolasburk

31. class App extends Component {
render() {
return (
<QueryRenderer
environment={environment}
query={AppAllPostQuery}
render={({error, props}) => {
if (error) {
return <div>{error.message}</div>
} else if (props) {
return <ListPage viewer={props.viewer} />
}
return <div>Loading</div>
}}
/>
)
}
}
const AppAllPostQuery = graphql`
query AppAllPostQuery {
viewer {
…ListPage_viewer # from ListPage.js
}
}
`
App.js
@nikolasburk

32. class App extends Component {
render() {
return (
<QueryRenderer
environment={environment}
query={AppAllPostQuery}
render={({error, props}) => {
if (error) {
return <div>{error.message}</div>
} else if (props) {
return <ListPage viewer={props.viewer} />
}
return <div>Loading</div>
}}
/>
)
}
}
const AppAllPostQuery = graphql`
query AppAllPostQuery {
viewer {
…ListPage_viewer
}
}
`
ListPage.js
@nikolasburk

33. class App extends Component {
render() {
return (
<QueryRenderer
environment={environment}
query={AppAllPostQuery}
render={({error, props}) => {
if (error) {
return <div>{error.message}</div>
} else if (props) {
return <ListPage viewer={props.viewer} />
}
return <div>Loading</div>
}}
/>
)
}
}
const AppAllPostQuery = graphql`
query AppAllPostQuery {
viewer {
…ListPage_viewer
}
}
`
ListPage.js
@nikolasburk

34. class App extends Component {
render() {
return (
<QueryRenderer
environment={environment}
query={AppAllPostQuery}
render={({error, props}) => {
if (error) {
return <div>{error.message}</div>
} else if (props) {
return <ListPage viewer={props.viewer} />
}
return <div>Loading</div>
}}
/>
)
}
}
const AppAllPostQuery = graphql`
query AppAllPostQuery {
viewer {
…ListPage_viewer
}
}
`
ListPage.js
@nikolasburk

35. class App extends Component {
render() {
return (
<QueryRenderer
environment={environment}
query={AppAllPostQuery}
render={({error, props}) => {
if (error) {
return <div>{error.message}</div>
} else if (props) {
return <ListPage viewer={props.viewer} />
}
return <div>Loading</div>
}}
/>
)
}
}
const AppAllPostQuery = graphql`
query AppAllPostQuery {
viewer {
…ListPage_viewer
}
}
`
ListPage.js
@nikolasburk

36. Mutations
@nikolasburk

37. Mutations in Relay Modern
const {commitMutation} = require('react-relay')
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
@nikolasburk

38. Mutations in Relay Modern
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
@nikolasburk

39. Mutations in Relay Modern
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
@nikolasburk

40. Mutations in Relay Modern
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
const mutation = graphql`
mutation CreatePostMutation($input: CreatePostInput!) {
createPost(input: $input) {
post {
id
description
imageUrl
}
}
}
`
@nikolasburk

41. Mutations in Relay Modern
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
}
)
@nikolasburk

42. Mutations in Relay Modern
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
const variables = {
input: {
description: “Nice Sunset”,
imageUrl: “www.example.org/sunset.jpg”,
}
}
@nikolasburk

43. Mutations in Relay Modern
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
}
)
@nikolasburk

44. Mutations in Relay Modern
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
}
)
@nikolasburk

45. Updating the Cache
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
updater: (proxyStore) => {
const createPostField = proxyStore.getRootField('createPost')
const newPost = createPostField.getLinkedRecord('post')
const viewerProxy = proxyStore.get(viewerId)
const connection =
ConnectionHandler.getConnection(viewerProxy, 'ListPage_allPosts')
ConnectionHandler.insertEdgeAfter(connection, newPost)
}
const mutation = graphql`
mutation CreatePostMutation($input: CreatePostInput!) {
createPost(input: $input) {
post {
id
description
imageUrl
}
}
}
`
@nikolasburk

46. Updating the Cache
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
updater: (proxyStore) => {
const createPostField = proxyStore.getRootField('createPost')
const newPost = createPostField.getLinkedRecord('post')
const viewerProxy = proxyStore.get(viewerId)
const connection =
ConnectionHandler.getConnection(viewerProxy, 'ListPage_allPosts')
ConnectionHandler.insertEdgeAfter(connection, newPost)
}
const mutation = graphql`
mutation CreatePostMutation($input: CreatePostInput!) {
createPost(input: $input) {
post {
id
description
imageUrl
}
}
}
`
@nikolasburk

47. Updating the Cache
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
updater: (proxyStore) => {
const createPostField = proxyStore.getRootField('createPost')
const newPost = createPostField.getLinkedRecord('post')
const viewerProxy = proxyStore.get(viewerId)
const connection =
ConnectionHandler.getConnection(viewerProxy, 'ListPage_allPosts')
ConnectionHandler.insertEdgeAfter(connection, newPost)
}
const mutation = graphql`
mutation CreatePostMutation($input: CreatePostInput!) {
createPost(input: $input) {
post {
id
description
imageUrl
}
}
}
`
@nikolasburk

48. Updating the Cache
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
updater: (proxyStore) => {
const createPostField = proxyStore.getRootField('createPost')
const newPost = createPostField.getLinkedRecord('post')
const viewerProxy = proxyStore.get(viewerId)
const connection =
ConnectionHandler.getConnection(viewerProxy, 'ListPage_allPosts')
ConnectionHandler.insertEdgeAfter(connection, newPost)
}
fragment ListPage_viewer on Viewer {
allPosts @connection(key: "ListPage_allPosts") {
edges {
node {
...Post_post
}
}
}
}
@nikolasburk

49. Updating the Cache
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
updater: (proxyStore) => {
const createPostField = proxyStore.getRootField('createPost')
const newPost = createPostField.getLinkedRecord('post')
const viewerProxy = proxyStore.get(viewerId)
const connection =
ConnectionHandler.getConnection(viewerProxy, 'ListPage_allPosts')
ConnectionHandler.insertEdgeAfter(connection, newPost)
}
fragment ListPage_viewer on Viewer {
allPosts @connection(key: "ListPage_allPosts") {
edges {
node {
...Post_post
}
}
}
}
@nikolasburk

50. Mutations in Relay Modern
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
}
)
@nikolasburk

51. Updating the Cache (Optimistically)
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
optimisticUpdater: (proxyStore) => {
const id = 'client:newPost:' + tempID++
const newPost = proxyStore.create(id, 'Post')
newPost.setValue(description, 'description')
newPost.setValue(imageUrl, 'imageUrl')
const viewerProxy = proxyStore.get(viewerId)
const connection =
ConnectionHandler.getConnection(viewerProxy, 'ListPage_allPosts')
ConnectionHandler.insertEdgeAfter(connection, newPost)
}
@nikolasburk

52. Updating the Cache (Optimistically)
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
optimisticUpdater: (proxyStore) => {
const id = 'client:newPost:' + tempID++
const newPost = proxyStore.create(id, 'Post')
newPost.setValue(description, 'description')
newPost.setValue(imageUrl, 'imageUrl')
const viewerProxy = proxyStore.get(viewerId)
const connection =
ConnectionHandler.getConnection(viewerProxy, 'ListPage_allPosts')
ConnectionHandler.insertEdgeAfter(connection, newPost)
}
@nikolasburk

53. Updating the Cache (Optimistically)
commitMutation(
environment: Environment,
config: {
mutation: GraphQLTaggedNode,
variables: Variables,
onCompleted: (response) => void,
onError: (error) => void,
updater: (store) => void,
optimisticUpdater: (store) => void,
},
)
optimisticUpdater: (proxyStore) => {
const id = 'client:newPost:' + tempID++
const newPost = proxyStore.create(id, 'Post')
newPost.setValue(description, 'description')
newPost.setValue(imageUrl, 'imageUrl')
const viewerProxy = proxyStore.get(viewerId)
const connection =
ConnectionHandler.getConnection(viewerProxy, 'ListPage_allPosts')
ConnectionHandler.insertEdgeAfter(connection, newPost)
}
@nikolasburk

54. More Features in Relay Modern
@nikolasburk

55. The Relay Environment 🌍
….bundles together the configuration, cache storage, and
network-handling that Relay needs in order to operate.
const environment = new Environment({
network,
store,
})
@nikolasburk

56. GraphQL Subscriptions ⚡
@nikolasburk
….allow to receive realtime events from the server.

57. Client Schema Extensions 💼
@nikolasburk
….allow to store client state.
extend type Post {
hasViewerSeen: Boolean
}

58. Garbage Collection 🗑
@nikolasburk
… removes objects from memory before the
JS Garbage Collector runs.

59. Compatibility Mode 🎯
@nikolasburk
… allows to incrementally update an application
from Relay Classic to Relay Modern.

60. Resources 📚
• Quickstart (Sample Code)
https://github.com/graphcool-examples/react-graphql/tree/master/quickstart-with-relay-modern
• 1st talk about Relay @ React.JS Conf 2015 (Video)
https://www.youtube.com/watch?v=9sc8Pyc51uU
• Introducing Relay and GraphQL (Article)
https://facebook.github.io/react/blog/2015/02/20/introducing-relay-and-graphql.html
• Building Relay Modern (Article)
https://wincent.com/blog/relay-modern
• Getting Started with Relay Modern (Tutorial)
https://www.graph.cool/docs/tutorials/relay-modern-getting-started-woodito7ug/
@nikolasburk

61. Community 🙌
• slack.graph.cool (> 2000 members)
• GraphQL Weekly Newsletter
• GraphQL Radio Podcast
@nikolasburk

62. We’re hiring!
www.graph.cool/jobs
@nikolasburk

63. Thank you! 🙇
… any questions?
@nikolasburk
