Modifying and
Enhancing the Core
Android OS
Arnav Gupta
Student, DTU
Android Framework Engineer, Cube26
A little about myself . . .
College
• Undergrad student, Electronics and Electrical
Engineering, Delhi Technological University.
• Expecting to graduate in 2016, (if I can survive
college for another 2 years)
Work – Cube26
• Joined - March ‘14
• Android Framework Engineer
• Working on projects of various clients like
Micromax, LAVA, Intex
• Developing and integrating smart gesture
based interaction methods into Android OS.
• Smart lockscreens, enhanced camera modes
for phones like Micromax Canvas A290, A310.
Work – Open Source
Community
• Contributor and developer on community
modded ROMs like CyanogenMod and AOKP
• Open source development partner with Sony
Mobile
• Making latest open source Android stack work
on Sony Xperia phones.
• Developing various software-based features
for these modified versions of Android.
Understanding the Android OS
Enhancing and modifying_the_core_android_os
Applications
• Everything opened from an
icon on the launcher is an app
• Almost every user-facing
interface in Android is an app
• Very generic in nature, and
rarely interdependent.
• Bundled in the form of .apk
files, like we can get from the
Play Store.
Framework : SystemUI
• Lockscreen, Status bar,
Notification pane, Navigation
bar
• Defines how Toasts, Dialog
boxes look like
• Lays out the basic look and
feel of the UI.
• Packaged as .apk, but is
device-dependent, and not
100% generic.
Framework : Providers & APIs
• User’s do not interact directly.
• To be used by 3rd party apps
• Access to various data, hardware, sensors, media,
audio, graphics etc of the device.
• Provides app developers uniform methods to interact
with lower stacks of the OS.
• Media, graphics, audio etc implementation could be
significantly different across different hardware.
• Provide and regulate access to contents and
services present on the device.
Dalvik / Android Runtime
• An implementation much similar to the Java Virtual
Machine.
• Dalvik – older runtime. Now being superseded by a
newer Android Runtime from Android L.
• Executes bytecode. Dalvik bytecode very much
similar to java bytecode.
• All applications, including the Framework, run on the
Dalvik VM. Each process is a fork of zygote.
Libraries
• Android contains a set of dynamically linkable
libraries (.so files, much like .dll of Windows) which
are required for various purposes.
• Libraries like libc contain core functions, used by
almost every process. There are OpenGLES libs for
graphics, security and cryptography related libs like
libcrypto, libssl. Almost all hardware related
subsystems are accessible by Hardware Abstraction
Layer libs.
• Apps are provided the features of libraries via the
APIs of the framework. Native code can link to them
directly.
Kernel
• Based on the Linux kernel, with a few differences in
implementation of memory and power management.
• CPU, IO, Crypto, Audio, Video etc are all same as
mainline Linux kernel.
• A major difference – absence of root rights to human
users, and read-only mode of /data partition
• The directory structure is pretty different from usual
Linux distros, divided into /system, /data, and /cache
partitions.
Building Android for your Phone
Getting a build machine ready
• 64-bit Linux or Mac, with minimum 4GB RAM. More
the horsepower, faster the build.
• Upwards of 40GB of free space. SSD recommended
over conventional HDD
• Sun/Oracle Java 6 JDK for building Android 4.4.4 or
below. Android L can be built with OpenJDK 7
https://source.android.com/source/initializing.html
Downloading the source
• About 9GB of source code for Android Kitkat.
• Spread across 400+ separate git repositories.
• Each app is maintained independently. The
framework is one large repository. All Apache
licensed.
• Most library stacks are independently maintained.
Many derived from original GNU/Linux libraries, and
modified to suit needs of Android.
https://source.android.com/source/downloading.html
Building the Android OS
• The linux kernel, over 150 libraries, 30+ apps, and
the android runtime and various framework packages
built and compressed into a ~250MB package.
• A makefile driven process, with no role of any IDE.
• Device and platform specific builds ( staying true to
it's embedded linux roots ) that are not cross-compatible
with other devices.
https://source.android.com/source/building-running.html
What can be modified ? And how ?
Modifying Android : Apps
• Basic apps like Phone, Contacts, Mms, Launcher,
Browser, Settings, Camera are part of the base OS.
• Functional additions, visual changes, or improved UX
in these apps are used as differentiating factor by
OEM-built Android flavours like TouchWiz, Sense,
MotoBlur or MIUI.
• App developers with few months of experience can
start taking a crack at this.
Modifying Android : Framework
• Improve UX by rethinking the core components like
notifications, lockscreen, navigation bar, recents.
• Refresh the look and feel by redesigning the UI
components and theme/style elements.
• Extend the ecosystem by adding your own APIs. Get
3rd party developers onto your ecosystem.
• More experiences Android developers with deeper
understanding of underlying APIs can start off.
Modifying Android : HAL & Libraries
• Lower level feature addition – often accompanied
with development of superior hardware technologies.
• Common examples include HDR mode photography,
audio equalisers and enhancements, high senstivity
touchscreens for glove mode.
• Improving algorithms for accuracy and sensitivity for
sensors.
Modifying Android : Kernel
• Interesting low-level implementations like ringing
Alarm in switched-off phone.
• Add support for custom hardware like heart rate
sensor, IR blaster etc.
• Improve performance, extend battery life – writing
efficient CPU/GPU governors, schedulers.
• Typical playground for (Embedded) Linux
enthusiasts.
A look at Open Source Community
maintained Custom Android
distributions :
AOKP
CyanogenMod
ParanoidAndroid
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Cube26 feature preview
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Contribute back to Google's
Android Open Source Project
(AOSP)
Source control in Android
• Android is maintained across 400+ git repositories.
Besides the platform, the ADT, Android Studio, the
ARM GCC cross compiler are also part of the
Android Open Source Project.
https://android.googlesource.com
• Code submissions pass through a code review
server called gerrit. Gerrit is a git code review
software written by Google to manage projects like
Android and Chromium.
https://android-review.googlesource.com
Submitting patches to Google
• Google tends to take only bugfixes from the
community. UX/UI features are developed in-house,
and code is dropped only during major releases.
(there are exceptions)
• Patches must be verified by the automatic buildbot,
and approved by at least one member from the
Android team.
• Moderate to advanced knowledge of git and gerrit is
essential to submit patches. (often involves rebasing
and manual conflict resolving).
Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Compatibility : A tiny caveat
Staying compatible with Android
• Android can be modified to any extent wanted.
• Beyond certain constraints, modifications may not
remain compatible.
• Compatibility is defined by Google as per the CDD
(Compatibility Definition Document)
• Compatibility Test Suite and CTS Verifier - set of
tests designed to test compatibility.
• Non-compliance with CDD disqualifies the OS to be
called as “Android”.
Goals of compatibility
• Providing uniform and stable environment to 3rd party
app developers.
• Level playing field across the whole ecosystem.
• Reduce fragmentation
• Quality control of the Android brand.
• Ease of use and familarity for users.
Why remain compatible ?
• Encash the brand value of Android
• Benefit from a rich ecosystem ( 1M+ apps, 50K+
developers )
• Benefit from using Google's APIs and services.
• Reduce cost of maintenance of code.
• Build a unique identity while remainging part of a
larger family.

More Related Content

What's hot

Android Internals
Android InternalsAndroid Internals
Android Internals
Opersys inc.

Android Platform Debugging and Development
Android Platform Debugging and DevelopmentAndroid Platform Debugging and Development
Android Platform Debugging and Development
Karim Yaghmour

Embedded Android Workshop with Marshmallow
Embedded Android Workshop with MarshmallowEmbedded Android Workshop with Marshmallow
Embedded Android Workshop with Marshmallow
Karim Yaghmour

Running Code in the Android Stack at ABS 2014
Running Code in the Android Stack at ABS 2014Running Code in the Android Stack at ABS 2014
Running Code in the Android Stack at ABS 2014
Opersys inc.

Android Platform Debugging and Development
Android Platform Debugging and DevelopmentAndroid Platform Debugging and Development
Android Platform Debugging and Development
Opersys inc.

Android Security Internals
Android Security InternalsAndroid Security Internals
Android Security Internals
Opersys inc.

Customizing Android's UI
Customizing Android's UICustomizing Android's UI
Customizing Android's UI
Opersys inc.

Android Treble: Blessing or Trouble?
Android Treble: Blessing or Trouble?Android Treble: Blessing or Trouble?
Android Treble: Blessing or Trouble?
Opersys inc.

Extending Android's Platform Toolsuite
Extending Android's Platform ToolsuiteExtending Android's Platform Toolsuite
Extending Android's Platform Toolsuite
Opersys inc.

Is Android the New Embedded Linux? at AnDevCon VI
Is Android the New Embedded Linux? at AnDevCon VIIs Android the New Embedded Linux? at AnDevCon VI
Is Android the New Embedded Linux? at AnDevCon VI
Opersys inc.

Brillo / Weave Internals
Brillo / Weave InternalsBrillo / Weave Internals
Brillo / Weave Internals
Opersys inc.

Android Things: Android for IoT
Android Things: Android for IoTAndroid Things: Android for IoT
Android Things: Android for IoT
Opersys inc.

Android's Multimedia Framework
Android's Multimedia FrameworkAndroid's Multimedia Framework
Android's Multimedia Framework
Opersys inc.

Android's HIDL: Treble in the HAL
Android's HIDL: Treble in the HALAndroid's HIDL: Treble in the HAL
Android's HIDL: Treble in the HAL
Opersys inc.

Brillo / Weave Internals
Brillo / Weave InternalsBrillo / Weave Internals
Brillo / Weave Internals
Opersys inc.

Embedded Android Workshop with Oreo
Embedded Android Workshop with OreoEmbedded Android Workshop with Oreo
Embedded Android Workshop with Oreo
Opersys inc.

Memory Management in Android
Memory Management in AndroidMemory Management in Android
Memory Management in Android
Opersys inc.

Embedded Android Workshop with Nougat
Embedded Android Workshop with NougatEmbedded Android Workshop with Nougat
Embedded Android Workshop with Nougat
Opersys inc.

Using and Customizing the Android Framework / part 4 of Embedded Android Work...
Using and Customizing the Android Framework / part 4 of Embedded Android Work...Using and Customizing the Android Framework / part 4 of Embedded Android Work...
Using and Customizing the Android Framework / part 4 of Embedded Android Work...
Opersys inc.


What's hot (19)

Android Internals
Android InternalsAndroid Internals
Android Internals

Android Platform Debugging and Development
Android Platform Debugging and DevelopmentAndroid Platform Debugging and Development
Android Platform Debugging and Development

Embedded Android Workshop with Marshmallow
Embedded Android Workshop with MarshmallowEmbedded Android Workshop with Marshmallow
Embedded Android Workshop with Marshmallow

Running Code in the Android Stack at ABS 2014
Running Code in the Android Stack at ABS 2014Running Code in the Android Stack at ABS 2014
Running Code in the Android Stack at ABS 2014

Android Platform Debugging and Development
Android Platform Debugging and DevelopmentAndroid Platform Debugging and Development
Android Platform Debugging and Development

Android Security Internals
Android Security InternalsAndroid Security Internals
Android Security Internals

Customizing Android's UI
Customizing Android's UICustomizing Android's UI
Customizing Android's UI

Android Treble: Blessing or Trouble?
Android Treble: Blessing or Trouble?Android Treble: Blessing or Trouble?
Android Treble: Blessing or Trouble?

Extending Android's Platform Toolsuite
Extending Android's Platform ToolsuiteExtending Android's Platform Toolsuite
Extending Android's Platform Toolsuite

Is Android the New Embedded Linux? at AnDevCon VI
Is Android the New Embedded Linux? at AnDevCon VIIs Android the New Embedded Linux? at AnDevCon VI
Is Android the New Embedded Linux? at AnDevCon VI

Brillo / Weave Internals
Brillo / Weave InternalsBrillo / Weave Internals
Brillo / Weave Internals

Android Things: Android for IoT
Android Things: Android for IoTAndroid Things: Android for IoT
Android Things: Android for IoT

Android's Multimedia Framework
Android's Multimedia FrameworkAndroid's Multimedia Framework
Android's Multimedia Framework

Android's HIDL: Treble in the HAL
Android's HIDL: Treble in the HALAndroid's HIDL: Treble in the HAL
Android's HIDL: Treble in the HAL

Brillo / Weave Internals
Brillo / Weave InternalsBrillo / Weave Internals
Brillo / Weave Internals

Embedded Android Workshop with Oreo
Embedded Android Workshop with OreoEmbedded Android Workshop with Oreo
Embedded Android Workshop with Oreo

Memory Management in Android
Memory Management in AndroidMemory Management in Android
Memory Management in Android

Embedded Android Workshop with Nougat
Embedded Android Workshop with NougatEmbedded Android Workshop with Nougat
Embedded Android Workshop with Nougat

Using and Customizing the Android Framework / part 4 of Embedded Android Work...
Using and Customizing the Android Framework / part 4 of Embedded Android Work...Using and Customizing the Android Framework / part 4 of Embedded Android Work...
Using and Customizing the Android Framework / part 4 of Embedded Android Work...


Similar to Enhancing and modifying_the_core_android_os

Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_osEnhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os
Arnav Gupta

Android ppt
Android pptAndroid ppt
Android Applications
Android ApplicationsAndroid Applications
Android Applications
Nazeer Hussain University

Android ppt
Android ppt Android ppt
Android Seminar BY Suleman Khan.pdf
Android Seminar BY Suleman Khan.pdfAndroid Seminar BY Suleman Khan.pdf
Android Seminar BY Suleman Khan.pdf
NomanKhan869872

Android Application Development Training by NITIN GUPTA
Android Application Development Training by NITIN GUPTA Android Application Development Training by NITIN GUPTA
Android Application Development Training by NITIN GUPTA
NITIN GUPTA

Android technology
Android technology Android technology
Android technology
vikas malviya

Android
AndroidAndroid
Android
Tapan Khilar

Android App Developement
Android App DevelopementAndroid App Developement
Android App Developement
Aayush Gupta

document
documentdocument
document
Joyful Vino

Mobile Application Development powerpoint
Mobile Application Development powerpointMobile Application Development powerpoint
Mobile Application Development powerpoint
JohnLagman3

Introduction to android
Introduction to androidIntroduction to android
Introduction to android
Aravindharamanan S

Android 130923124440-phpapp01
Android 130923124440-phpapp01Android 130923124440-phpapp01
Android 130923124440-phpapp01
rajesh kumar

My androidpresentation
My androidpresentationMy androidpresentation
My androidpresentation
niteshnarayanlal

Chapter 1 Introduction to android.ppt pl
Chapter 1 Introduction to android.ppt plChapter 1 Introduction to android.ppt pl
Chapter 1 Introduction to android.ppt pl
ENBAKOMZAWUGA

Introduction to android sessions new
Introduction to android   sessions newIntroduction to android   sessions new
Introduction to android sessions new
Joe Jacob

Introduction to android
Introduction to androidIntroduction to android
Introduction to android
krishnastudent88

Android ppt
Android pptAndroid ppt
Android ppt
Hari Krishna

Android
AndroidAndroid
Android
Rohith Rg

Android OS
Android OSAndroid OS
Android OS
Nitin Ramchandani


Similar to Enhancing and modifying_the_core_android_os (20)

Enhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_osEnhancing and modifying_the_core_android_os
Enhancing and modifying_the_core_android_os

Android ppt
Android pptAndroid ppt
Android ppt

Android Applications
Android ApplicationsAndroid Applications
Android Applications

Android ppt
Android ppt Android ppt
Android ppt

Android Seminar BY Suleman Khan.pdf
Android Seminar BY Suleman Khan.pdfAndroid Seminar BY Suleman Khan.pdf
Android Seminar BY Suleman Khan.pdf

Android Application Development Training by NITIN GUPTA
Android Application Development Training by NITIN GUPTA Android Application Development Training by NITIN GUPTA
Android Application Development Training by NITIN GUPTA

Android technology
Android technology Android technology
Android technology

Android
AndroidAndroid
Android

Android App Developement
Android App DevelopementAndroid App Developement
Android App Developement

document
documentdocument
document

Mobile Application Development powerpoint
Mobile Application Development powerpointMobile Application Development powerpoint
Mobile Application Development powerpoint

Introduction to android
Introduction to androidIntroduction to android
Introduction to android

Android 130923124440-phpapp01
Android 130923124440-phpapp01Android 130923124440-phpapp01
Android 130923124440-phpapp01

My androidpresentation
My androidpresentationMy androidpresentation
My androidpresentation

Chapter 1 Introduction to android.ppt pl
Chapter 1 Introduction to android.ppt plChapter 1 Introduction to android.ppt pl
Chapter 1 Introduction to android.ppt pl

Introduction to android sessions new
Introduction to android   sessions newIntroduction to android   sessions new
Introduction to android sessions new

Introduction to android
Introduction to androidIntroduction to android
Introduction to android

Android ppt
Android pptAndroid ppt
Android ppt

Android
AndroidAndroid
Android

Android OS
Android OSAndroid OS
Android OS


Recently uploaded

Biography And Tributes of the Late Mrs Stella Atsupui Eddah Amedorme.pdf
Biography And Tributes of the Late Mrs Stella Atsupui Eddah Amedorme.pdfBiography And Tributes of the Late Mrs Stella Atsupui Eddah Amedorme.pdf
Biography And Tributes of the Late Mrs Stella Atsupui Eddah Amedorme.pdf
amgratefulkhid

What is the Meaning of the Word Biscuit?
What is the Meaning of the Word Biscuit?What is the Meaning of the Word Biscuit?
What is the Meaning of the Word Biscuit?
Mona Rathore

bangalore Girls call 👀 XXXXXXXXXXX 👀 Cash Payment With Room DeliveryDelivery
bangalore Girls call  👀 XXXXXXXXXXX 👀 Cash Payment With Room DeliveryDeliverybangalore Girls call  👀 XXXXXXXXXXX 👀 Cash Payment With Room DeliveryDelivery
bangalore Girls call 👀 XXXXXXXXXXX 👀 Cash Payment With Room DeliveryDelivery
Jasmine Rawat

RMIT degree offer diploma Transcript
RMIT degree offer diploma TranscriptRMIT degree offer diploma Transcript
RMIT degree offer diploma Transcript
sozta

Celebrity Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And ...
Celebrity Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And ...Celebrity Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And ...
Celebrity Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And ...
dizzycaye

Girls Call Marol Naka 9910780858 Provide Best And Top Girl Service And No1 in...
Girls Call Marol Naka 9910780858 Provide Best And Top Girl Service And No1 in...Girls Call Marol Naka 9910780858 Provide Best And Top Girl Service And No1 in...
Girls Call Marol Naka 9910780858 Provide Best And Top Girl Service And No1 in...
margaretblush


Recently uploaded (6)

Biography And Tributes of the Late Mrs Stella Atsupui Eddah Amedorme.pdf
Biography And Tributes of the Late Mrs Stella Atsupui Eddah Amedorme.pdfBiography And Tributes of the Late Mrs Stella Atsupui Eddah Amedorme.pdf
Biography And Tributes of the Late Mrs Stella Atsupui Eddah Amedorme.pdf

What is the Meaning of the Word Biscuit?
What is the Meaning of the Word Biscuit?What is the Meaning of the Word Biscuit?
What is the Meaning of the Word Biscuit?

bangalore Girls call 👀 XXXXXXXXXXX 👀 Cash Payment With Room DeliveryDelivery
bangalore Girls call  👀 XXXXXXXXXXX 👀 Cash Payment With Room DeliveryDeliverybangalore Girls call  👀 XXXXXXXXXXX 👀 Cash Payment With Room DeliveryDelivery
bangalore Girls call 👀 XXXXXXXXXXX 👀 Cash Payment With Room DeliveryDelivery

RMIT degree offer diploma Transcript
RMIT degree offer diploma TranscriptRMIT degree offer diploma Transcript
RMIT degree offer diploma Transcript

Celebrity Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And ...
Celebrity Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And ...Celebrity Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And ...
Celebrity Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And ...

Girls Call Marol Naka 9910780858 Provide Best And Top Girl Service And No1 in...
Girls Call Marol Naka 9910780858 Provide Best And Top Girl Service And No1 in...Girls Call Marol Naka 9910780858 Provide Best And Top Girl Service And No1 in...
Girls Call Marol Naka 9910780858 Provide Best And Top Girl Service And No1 in...


Enhancing and modifying_the_core_android_os

  • 1. Modifying and Enhancing the Core Android OS Arnav Gupta Student, DTU Android Framework Engineer, Cube26
  • 2. A little about myself . . .
  • 3. College • Undergrad student, Electronics and Electrical Engineering, Delhi Technological University. • Expecting to graduate in 2016, (if I can survive college for another 2 years)
  • 4. Work – Cube26 • Joined - March ‘14 • Android Framework Engineer • Working on projects of various clients like Micromax, LAVA, Intex • Developing and integrating smart gesture based interaction methods into Android OS. • Smart lockscreens, enhanced camera modes for phones like Micromax Canvas A290, A310.
  • 5. Work – Open Source Community • Contributor and developer on community modded ROMs like CyanogenMod and AOKP • Open source development partner with Sony Mobile • Making latest open source Android stack work on Sony Xperia phones. • Developing various software-based features for these modified versions of Android.
  • 8. Applications • Everything opened from an icon on the launcher is an app • Almost every user-facing interface in Android is an app • Very generic in nature, and rarely interdependent. • Bundled in the form of .apk files, like we can get from the Play Store.
  • 9. Framework : SystemUI • Lockscreen, Status bar, Notification pane, Navigation bar • Defines how Toasts, Dialog boxes look like • Lays out the basic look and feel of the UI. • Packaged as .apk, but is device-dependent, and not 100% generic.
  • 10. Framework : Providers & APIs • User’s do not interact directly. • To be used by 3rd party apps • Access to various data, hardware, sensors, media, audio, graphics etc of the device. • Provides app developers uniform methods to interact with lower stacks of the OS. • Media, graphics, audio etc implementation could be significantly different across different hardware. • Provide and regulate access to contents and services present on the device.
  • 11. Dalvik / Android Runtime • An implementation much similar to the Java Virtual Machine. • Dalvik – older runtime. Now being superseded by a newer Android Runtime from Android L. • Executes bytecode. Dalvik bytecode very much similar to java bytecode. • All applications, including the Framework, run on the Dalvik VM. Each process is a fork of zygote.
  • 12. Libraries • Android contains a set of dynamically linkable libraries (.so files, much like .dll of Windows) which are required for various purposes. • Libraries like libc contain core functions, used by almost every process. There are OpenGLES libs for graphics, security and cryptography related libs like libcrypto, libssl. Almost all hardware related subsystems are accessible by Hardware Abstraction Layer libs. • Apps are provided the features of libraries via the APIs of the framework. Native code can link to them directly.
  • 13. Kernel • Based on the Linux kernel, with a few differences in implementation of memory and power management. • CPU, IO, Crypto, Audio, Video etc are all same as mainline Linux kernel. • A major difference – absence of root rights to human users, and read-only mode of /data partition • The directory structure is pretty different from usual Linux distros, divided into /system, /data, and /cache partitions.
  • 14. Building Android for your Phone
  • 15. Getting a build machine ready • 64-bit Linux or Mac, with minimum 4GB RAM. More the horsepower, faster the build. • Upwards of 40GB of free space. SSD recommended over conventional HDD • Sun/Oracle Java 6 JDK for building Android 4.4.4 or below. Android L can be built with OpenJDK 7 https://source.android.com/source/initializing.html
  • 16. Downloading the source • About 9GB of source code for Android Kitkat. • Spread across 400+ separate git repositories. • Each app is maintained independently. The framework is one large repository. All Apache licensed. • Most library stacks are independently maintained. Many derived from original GNU/Linux libraries, and modified to suit needs of Android. https://source.android.com/source/downloading.html
  • 17. Building the Android OS • The linux kernel, over 150 libraries, 30+ apps, and the android runtime and various framework packages built and compressed into a ~250MB package. • A makefile driven process, with no role of any IDE. • Device and platform specific builds ( staying true to it's embedded linux roots ) that are not cross-compatible with other devices. https://source.android.com/source/building-running.html
  • 18. What can be modified ? And how ?
  • 19. Modifying Android : Apps • Basic apps like Phone, Contacts, Mms, Launcher, Browser, Settings, Camera are part of the base OS. • Functional additions, visual changes, or improved UX in these apps are used as differentiating factor by OEM-built Android flavours like TouchWiz, Sense, MotoBlur or MIUI. • App developers with few months of experience can start taking a crack at this.
  • 20. Modifying Android : Framework • Improve UX by rethinking the core components like notifications, lockscreen, navigation bar, recents. • Refresh the look and feel by redesigning the UI components and theme/style elements. • Extend the ecosystem by adding your own APIs. Get 3rd party developers onto your ecosystem. • More experiences Android developers with deeper understanding of underlying APIs can start off.
  • 21. Modifying Android : HAL & Libraries • Lower level feature addition – often accompanied with development of superior hardware technologies. • Common examples include HDR mode photography, audio equalisers and enhancements, high senstivity touchscreens for glove mode. • Improving algorithms for accuracy and sensitivity for sensors.
  • 22. Modifying Android : Kernel • Interesting low-level implementations like ringing Alarm in switched-off phone. • Add support for custom hardware like heart rate sensor, IR blaster etc. • Improve performance, extend battery life – writing efficient CPU/GPU governors, schedulers. • Typical playground for (Embedded) Linux enthusiasts.
  • 23. A look at Open Source Community maintained Custom Android distributions : AOKP CyanogenMod ParanoidAndroid
  • 75. Contribute back to Google's Android Open Source Project (AOSP)
  • 76. Source control in Android • Android is maintained across 400+ git repositories. Besides the platform, the ADT, Android Studio, the ARM GCC cross compiler are also part of the Android Open Source Project. https://android.googlesource.com • Code submissions pass through a code review server called gerrit. Gerrit is a git code review software written by Google to manage projects like Android and Chromium. https://android-review.googlesource.com
  • 77. Submitting patches to Google • Google tends to take only bugfixes from the community. UX/UI features are developed in-house, and code is dropped only during major releases. (there are exceptions) • Patches must be verified by the automatic buildbot, and approved by at least one member from the Android team. • Moderate to advanced knowledge of git and gerrit is essential to submit patches. (often involves rebasing and manual conflict resolving).
  • 80. Compatibility : A tiny caveat
  • 81. Staying compatible with Android • Android can be modified to any extent wanted. • Beyond certain constraints, modifications may not remain compatible. • Compatibility is defined by Google as per the CDD (Compatibility Definition Document) • Compatibility Test Suite and CTS Verifier - set of tests designed to test compatibility. • Non-compliance with CDD disqualifies the OS to be called as “Android”.
  • 82. Goals of compatibility • Providing uniform and stable environment to 3rd party app developers. • Level playing field across the whole ecosystem. • Reduce fragmentation • Quality control of the Android brand. • Ease of use and familarity for users.
  • 83. Why remain compatible ? • Encash the brand value of Android • Benefit from a rich ecosystem ( 1M+ apps, 50K+ developers ) • Benefit from using Google's APIs and services. • Reduce cost of maintenance of code. • Build a unique identity while remainging part of a larger family.
