Network analyses are powerful methods for both visual analytics and machine learning but can suffer as their complexity increases. By embedding time as a structural element rather than a property, we will explore how time series and interactive analysis can be improved on Graph structures. Primarily we will look at decomposition in NLP-extracted concept graphs using NetworkX and Graph Tool.

1. Dynamics in Graph Analysis
Adding Time as Structure for Visual
and Statistical Insight
Benjamin Bengfort
@bbengfort
District Data Labs

2. Are graphs effective for analytics?
Or why use graphs at all?

3. Algorithm Performance
More understandable implementations
and native parallelism provide benefits
particularly to machine learning.
Visual Analytics
Humans can understand and interpret
interconnection structures, leading to
immediate insights.

4. “Graph technologies ease the modeling of
your domain and improve the simplicity
and speed of your queries.”
— Marko A. Rodriguez
http://bit.ly/2cthd2L

5. Construction
Given a set of [paths,
vertices] is a [constraint]
graph construction
possible?
Existence
Does there exist a [path,
vertex, set] within
[constraints]?
Optimization
Given several [paths,
subgraphs, vertices, sets] is
one the best?
Enumeration
How many [vertices, edges]
exist with [constraints], is it
possible to list them?

6. Traversals

7. Property Graphs

8. How do you model time?

9. Relational Database

10. Time Properties

12. Time Modifies Traversal

13. Example of Time Filtered Traversal: Data Model
Name: Emails Sent Network
Number of nodes: 6,174
Number of edges: 343,702
Average degree: 111.339

14. def sent_range(g, before=None, after=None):
# Create filtering function based on date range.
def inner(edge):
if before:
return g.ep.sent[edge] < before
if after:
return g.ep.sent[edge] > after
return inner
def degree_filter(degree=0):
# Create filtering function based on min degree.
def inner(vertex):
return vertex.out_degree() > degree
return inner
Example of Time Filtered Traversal

15. print("{} vertices and {} edges".format(
g.num_vertices(), g.num_edges()
))
# 6174 vertices and 343702 edges
aug = sent_range(g,
after=dateparse("Aug 1, 2016 09:00:00 EST")
)
view = gt.GraphView(g, efilt=aug)
view = gt.GraphView(view, vfilt=degree_filter())
print("{} vertices and {} edges".format(
view.num_vertices(), view.num_edges()
))
# 853 vertices and 24813 edges
Example of Time Filtered Traversal

16. What makes a graph dynamic?

17. Time Structures
Perform static analysis on dynamic
components with time as a structure.
Dynamic Graphs
Multiple subgraphs representing the
graph state at a discrete timestep.

20. Keyphrases over Time

21. Natural Language Graph Analysis: Data Ingestion

22. Natural Language Graph Analysis: Data Modeling
Name: Baleen Keyphrase Graph
Number of nodes: 2,682,624
Number of edges: 46,958,599
Average degree: 35.0095
Name: Sampled Keyphrase Graph
Number of nodes: 139,227
Number of edges: 257,316
Average degree: 3.6964

23. def degree_filter(degree=0):
def inner(vertex):
return vertex.out_degree() > degree
return inner
g = gt.GraphView(g, vfilt=degree_filter(3))
Name: High Degree Phrase Graph
Number of nodes: 8,520
Number of edges: 112,320
Average degree: 26.366
Natural Language Graph Analysis: Data Wrangling

24. Basic Keyphrase Graph Information
Vertex Type Analysis
Primarily keyphrases and documents.
Degree Distribution
Power laws distribution of degree.

25. Natural Language Graph Analysis: Data Wrangling
def ego_filter(g, ego, hops=2):
def inner(v):
dist = gt.shortest_distance(g, ego, v)
return dist <= hops
return inner
# Get a random document
v = random.choice([
v for v in g.vertices()
if g.vp.type[v] == 'document'
])
ego = gt.GraphView(
g, vfilt=ego_filter(g,v, 1)
)

27. The Centrality of Time

28. Extract Week of the Year as Time Structure
# Construct Time Structures to Keyphrase
h = gt.Graph(directed=False)
h.gp.name = h.new_graph_property('string')
h.gp.name = "Phrases by Week"
# Add vertex properties
h.vp.label = h.new_vertex_property('string')
h.vp.vtype = h.new_vertex_property('string')
# Create graph from the keyphrase graph
for vertex in g.vertices():
if g.vp.type[vertex] == 'document':
dt = g.vp.pubdate[vertex]
weekno = dt.isocalendar()[1]
week = h.add_vertex()
h.vp.label[week] = "Week %d" % weekno
h.vp.vtype[week] = 'week'
for neighbor in vertex.out_neighbours():
if g.vp.type[neighbor] == 'phrase':
phrase = h.add_vertex()
h.vp.vtype[vidmap[phrase]] = 'phrase'
h.add_edge(week, phrase)

29. PageRank Centrality
A variant of Eigenvector
centrality that has a scaling
factor and prioritizes
incoming links.
Eigenvector Centrality
A measure of relative
influence where closeness
to important nodes matters
as much as other metrics.
Degree Centrality
A vertex is more important
the more connections it
has. E.g. “celebrity”.
Betweenness Centrality
How many shortest paths
pass through the given
vertex. E.g. how often is
information flow through?

30. What are the central weeks and phrases?
Betweenness Centrality Katz Centrality

31. Keyphrase Dynamics

32. Create Sequences of Time Ordered Subgraphs

33. Animating Dynamics

34. Network Visualization

35. Layout: Edge and Vertex Positioning
Fruchterman
Reingold
SFDP (Yifan-Hu)
Force Directed
Radial Tree Layout
by MST
ARF Spring Block

36. Visual Properties of Vertices
Lane Harrison, The Links that Bind Us: Network Visualizations
http://blog.visual.ly/network-visualizations

37. Visual Properties of Edges
Lane Harrison, The Links that Bind Us: Network Visualizations
http://blog.visual.ly/network-visualizations

39. Visual Analysis

40. The Visual Analytics Mantra
Overview First Zoom and Filter Details on Demand

41. Questions?
