dellemc-powerprotect-dd-presentation.pptx

Overview presentation
Dell PowerProtect
Data Domain
Appliances

Copyright © Dell Inc. All Rights Reserved.
2
Presentation Notes (PDF)
Double-click image above to open PDF
This page intentionally left blank

3 Copyright © Dell Inc. All Rights Reserved.
3
Agenda
• What is PowerProtect Data
Domain?
• Data Domain is Fast,
Efficient, Secure
• The Technology Difference
• The Dell Advantage

4
2024 Global Data Protection Index
Tracking data protection confidence levels of organizations for 10 years
75%
are concerned their existing data
protection may not be sufficient to
cope with malware and
ransomware threats
88%
of organizations agree that the
generative AI will create large
volumes of new data requiring
protection and security
40%
face challenges over data
security when maintaining
multicloud environments
1,500 IT and IT security decision makers from a wide range of public and private industries
across NA, EMEA, APJ and China conducted by Vanson Bourne
Global Data Protection Index Report | Dell USA
Data loss and downtime continues to be a business
concern

5
Protecting data is more challenging than ever
Multicloud
data
sprawl
Operation
al
complexity
Cyber
attacks
5

6
Build your
cyber resilient foundation
on the
#1 Purpose-Built Backup
Appliance

The ultimate protection storage appliance
Dell PowerProtect Data Domain
7
Market leading
Purpose-built
Backup software agnostic
Patented technology innovation

8
Why a Purpose-Built Backup
Appliance (PPBA)?
PBBAs are designed and optimized for
data protection and can deliver where
general-purpose storage cannot.
Mitigate risk and
prepare for cyber
attacks
Manage costs
Reduce the burden
of backups
8

9
Fast Efficient Secure
9
PowerProtect Data Domain

10
PowerProtect Data Domain Portfolio
S M A L L & M I D E N T E R P R I S E L A R G E E N T E R P R I S E
1
Maximum data ingest with DD Boost.
2
Logical capacity based on up to 50x deduplication (Data Domain All-Flash Ready Node, Data Domain Virtual Edition), up to 65x deduplication
(DD6410, DD9410, DD9910) includes additional hardware assisted data compression of typically 30%. Actual capacity & throughput depends on
application workload, deduplication and other settings.3 Total capacity with cloud tier for long-term retention.
4
TiB/PiB values adjusted for estimated DDOS overhead. DDOS overhead can vary depending on metadata required for customer workloads.
NEW! All-Flash
Ready Node
NEW!
DD6410 DD9410 DD9910
Backup Ingest1 Up to 56.4 TB/hr Up to 66.8 TB/hr Up to 75 TB/hr Up to 130 TB/hr
Logical Capacity2 Up to 11 PB
Up to 16.6 PB
Up to 49.9 PB3
Up to 49.9 PB
Up to 149.8 PB3
Up to 97.5 PB
Up to 293 PB3
Usable Capacity
220 TB
200 TiB4
12 TB - 256 TB
10.9 TiB – 232.8 TiB4
192 TB – 768 TB
170 TiB – 698.4 TiB4
576 TB – 1.5 PB
511 TiB – 1.33 TiB4
Usable Capacity
with Cloud Tier
N/A
Up to 768 TB
Up to 698.5 TiB4
Up to 2.3 PB
Up to 2 PiB4
Up to 4.5 PB
Up to 4 PiB4
Software-defined protection storage: PowerProtect Data Domain Virtual Edition (DDVE)
On-premises: scales up to 96 TB per instance
In-cloud: scales up to 256 TB per instance

11
220 TBu All-Flash
New! Dell PowerProtect Data Domain All-Flash Ready Node
11
1
Based on Dell internal testing comparing a PowerProtect Data Domain All-Flash Ready Node vs. a PowerProtect DD6410 appliance, February 2025. Actual results may vary.
2
Based on Dell analysis comparing a PowerProtect Data Domain All-Flash Ready Node vs a PowerProtect DD6410 appliance, both configured at maximum capacity.
3
Based on Dell internal testing and field telemetry data, February 2025. Actual results may vary.
Fast all-flash performance
for traditional and modern
workloads
Efficient operation with low
power, cost and cooling
footprint
Over
36%
Less power2
Typically
65:1
Data reduction3
Requires
5x
Less floor space2
All-flash delivers trusted data services for faster recovery, with a smaller space and power footprint
24x
Faster restores1
2x
NVMe SSDs Intel Xeon 40 Core CPUs
Over
61%
Fast Efficient
Fast

12
12 - 256 TBu
New! Dell PowerProtect Data Domain DD6410
12
Efficient
Fast
1
Based on Dell internal testing comparing a PowerProtect Data Domain DD6410 appliance vs a PowerProtect DD6400 appliance.
2
Based on Dell analysis comparing a PowerProtect DD6410 appliance vs. a PowerProtect DD6900 appliance, both at maximum capacity.
3
Fast performance for
traditional and modern
workloads
Efficient operation with low
power, cost and cooling
footprint
Over
7%
Less power2
Typically
65:1
Data reduction3
Requires
2.6x
Less floor space2
Up to
2x
Faster restores1
Trusted data services with enhanced performance
Up to
2.4x
Faster backups1
Up to
3.2x
Faster replication

13
Data Domain appliances
are built on the
Platform
Cyber resiliency and faster recovery, for when it matters
most.

14
Gain the confidence that you
can recover from the
unexpected. And, fast.
14
75%
Less downtime with
Dell PowerProtect
Cyber Recovery
*Based on a commissioned study conducted by Forrester Consulting on behalf of Dell Technologies
"The Total Economic Impact™ Of Dell PowerProtect Cyber Recovery, August 2023"

15
What puts your data
at risk?
Hint:
Threats come from many directions.
Comprehensive protection is critical to success.
People
Bad actors
Ransomware
Human error
Technology
Hardware failures
Software errors
Geography
Weather
Fire, earthquake
National security
15

16
* Cyber Recovery Guarantee and Data Protection Deduplication Guarantee. Terms and conditions apply
.
PowerProtect Data Domain Platform
Recover faster from the unexpected. Guaranteed.*
Data
services
for cyber
resiliency
Security Durability
Flexibility
Efficiency

17
Security to
ensure data is
not tampered
with or
corrupted
Transport Protocol – DD Boost
Encrypted, Secure, Authorized, Not Open
Secure System Clock | NTP Clock | Tamper Controls
Clock Change | Drift | Synchronization
End-to-End Encryption
Data in Flight TL2 1.2 256 Bit | Data at Rest FIPS 140-2 Crypto Libraries
File System - DDFS
Hashed Containers – not recognized by malware
Multi-factor Authentication (MFA)
Web UI, CLI, Security Officer, and iDRAC
Immutability
Retention Lock Compliance Mode | SEC 17a-4(f) Compliance | FDA 21 Part II
Zero Trust
Hardware Root of Trust | Secure Boot | RBAC | Secure Period

18 Copyright Dell Inc. All Rights Reserved.
Inline data
verification
Continuous fault
detection & self-healing
Recovery
verification
Stored
correctly
Stays correct
Recovered
correctly
Durability to ensure your data is always
there
Data Invulnerability Architecture (DIA) ensures that you can recover what you back up—every time
New data and metadata never
overwrite existing data
Continuous fault detection and self-
healing of data stored on disk
The filesystem is always consistent due
to an append-only architecture
Data is validated and verified to be correct even at
the point-of-origin when using the DD Boost protocol
Data errors are corrected immediately from
persistent memory, including in-flight data
100% data validation from end-to-end – Industry Exclusive

19
Up to
38%
faster backups*
Up to
44%
faster restores*
Flexibility to secure all your data,
anywhere
Core to edge to multicloud
All-flash or hard drive storage
Cloud Tier for long-term retention
Dell PowerStore & PowerMax integration
Extensive backup software partner ecosystem

20
20 Copyright Dell Inc. All Rights Reserved.
DD Boost: A Dell proprietary
deduplication technology
Far less network traffic
Less impact to backup clients
Accelerates overall system performance
Massively reduced storage requirements
Up to 65:1
Less than 1¢
data reduction1
per GB/month
cost to protect2
1
2
Based on ESG review commissioned by Dell, “Analyzing the Economic and Operational Benefits
of the Dell Data Protection Portfolio”, November 2022. Actual results will vary.
Efficiency for lower TCO

21
Data Domain appliances
are….
Fast. Efficient. Secure.

22
Fast
Shorter backup
windows. Faster
restores. When time
matters most.
22

23
Meet SLAs
Reduce impact to
production
Up to
38%
faster backups1
Up to
61%
faster restores2
Backup as much as you need to,
without worry
1
Based on Dell internal testing comparing a Dell PowerProtect DD9910 appliance vs. a PowerProtect DD9900 appliance, February 2024. Actual results may vary.
2
Based on Dell internal testing comparing a PowerProtect Data Domain All-Flash Ready Node vs. a PowerProtect DD6410 appliance. February 2025. Actual results may vary.

24
The advantages of a CPU-centric architecture
CPUs are faster than flash
Memory access is orders of magnitude
faster than primary storage – even flash
Advanced Memory Structures
Predictive Caching
Massively parallel high-speed
streaming
24

25
25
DD Boost
A Dell proprietary deduplication
algorithm with broad ecosystem
Deduplicated Data
API Management
Backup Server
Clients
Boost API
Reduce network impact
Less burden on client / server
Less impact to Data Domain
Reduce storage needed

26
Data Domain delivers advanced integration with backup software and applications
DD Boost ecosystem support

27
Efficient
Get the most out of
IT assets and
resources, at a lower
cost to protect.
27

28
More than 36%
5x
Up to 65:1
Less than 1¢
Free up IT budget and resources for
activities that deliver more value-
add
less power1
less rack space1
data reduction2
per GB/month
cost to protect3
28
1
Based on Dell analysis comparing a PowerProtect Data Domain All-Flash Ready Node vs.a PowerProtect DD6410
appliance, both configured at maximum capacity..
2
3
Based on ESG review commissioned by Dell, “Analyzing the Economic and Operational Benefits of the Dell Data
Protection Portfolio”, November 2022. Actual results will vary.

29
• Small segment size (8KB average)
• Variable length / sliding window
• Inline at high speed
29
Deduplication
Taking the micro view matters

30
• Protection copies can represent up to
95% of an organization’s data
• A 15% difference in deduplication
rate can lead to consumption of 4x
more protection storage
• It doesn’t matter what you save, but
what you consume
30
Minimizing storage consumption matters
5:1 65:1
Deduplication

31
Deduplication with Data Domain
improves operations
Right-sized
Solution
Shorter Backup
Windows
Faster
Replication
Retention Aligned
to Business Policy
Low Total Cost of
Ownership
No more chasing
capacity with
under-sized
solution
Faster backups
with less impact to
both LAN and
clients
Replication takes
less time & less
WAN bandwidth
for a better RPO
All your data where
you need it and no
hidden cloud costs
Less bandwidth,
storage, &
management
results in
lower TCO

32
1
Based on Dell internal testing comparing a Dell PowerProtect DD9910 appliance using an optional deep rack vs. a PowerProtect DD9900 appliance. March 2024.
2
Based on Dell analysis comparing a PowerProtect Data Domain Ready Node vs. a PowerProtect DD6410 appliance, both configured at maximum capacity.
Consolidate and get more out of your data center
Do more in less space
Up to 50% floor
space savings
when using an
optional deep rack1
(with DD9910)
Scale up to 1.5 Pbu
max configuration
in a single rack1
(with DD9910)
5x less rack space2
(with All-Flash Ready
Node)

33
Secure
Comprehensive
cyber resilience
wherever your data
lives.
33

34
Reduce the attack surface
Minimize the vulnerabilities and
entry points that can be exploited
to compromise the environment.
Detect and respond
to cyber threats
Actively identify and address
potential security incidents
and malicious activities.
Recover from
a cyber attack
Restore the organization to
a previous, known secure
and operational state after a
security incident.
Don’t let security risks stifle innovation
Advance cybersecurity
& Zero Trust maturity
34

35
Security to
ensure data is
not tampered
with or
corrupted
Transport Protocol – DD Boost
Encrypted, Secure, Authorized, Not Open
Secure System Clock | NTP Clock | Tamper Controls
Clock Change | Drift | Synchronization
End-to-End Encryption
Data in Flight TL2 1.2 256 Bit | Data at Rest FIPS 140-2 Crypto Libraries
File System - DDFS
Hashed Containers – not recognized by malware
Multi-factor Authentication (MFA)
Web UI, CLI, Security Officer, and iDRAC
Immutability
Retention Lock Compliance Mode | SEC 17a-4(f) Compliance | FDA 21 Part II
Zero Trust
Hardware Root of Trust | Secure Boot | RBAC | Secure Period

Secure boot
Hardware Root of Trust
iDRAC Root of Trust
(silicon-based)
iDRAC FW Boot
Authentication
Dell FW Updates
Authentication
Trusted Platform
Firmware
iDRAC Domain
BIOS Root of Trust
(silicon-based)
BIOS FW Boot
Authentication
UEFI Secure Boot
Trusted OS
Environment
BIOS/OS Domain
PCIe and Storage
Driver Authentication
Secure OS Boot
Loader Authentication
Chain
of
Trust
Authentication
Zero Trust
at work
Protect the boot process and
establish trustworthiness

37
Isolation
Physical & logical
separation of data
Intelligence
AI-based ML & analytics
identify threats
Immutability
Preserve original
integrity of data
Comprehensive cyber resilience

38
Improve on immutability by denying access
Cyber Recovery
Vault
Persistent Data path
Data Center
Production Backup
Public Cloud
Production Backup
Control
Management
Access
Data only
(When
unlocked)
Control path
Replication, R/W
Management via SSH, HTTPS
Non-persistent Data Path
Non-persistent Data path Replication
The importance of isolation

39
COMPREHENSIVE
INDEX
SECURITY
ANALYTICS
MACHINE
LEARNING
CORRUPTION
DETECTED
POST ATTACK
FORENSICS
How CyberSense Works
Analytics, machine learning and forensic tools to detect & recover from cyber attacks

40
Gain the confidence that
you can recover from the
unexpected.
Be prepared for
cyber events
Meet regulatory
compliance
2100+
customers use
PowerProtect
appliances in their
cyber recovery vault1
1
Based on Dell Technologies analysis, February 2024.
2
Based on a commissioned study conducted by Forrester Consulting on behalf of Dell Technologies "The Total Economic Impact™ Of Dell PowerProtect Cyber Recovery, August 2023..
Up to
75%
reduction in
downtime2

41
Gain the edge
Data Domain
technology.
It makes a
difference.
41

42
Reduce bandwidth requirements
Protect sensitive data when
replicating over untrusted networks
Consolidate backup and archive
data from hundreds of remote sites
42
Data Domain
Replicator
Create a secure and reliable
offsite copy
WAN

43
Available only in Dell
PowerProtect Data Manager
vCenter
ESX
TRANSPARENT
SNAPSHOTS
Transparent Snapshots simplifies VM image backups delivering
near-zero impact on VMs
Up to 5x faster backups1
| Up to 6x faster restores2
| Up to 5x reduction in VM latency3
1
When comparing PowerProtect Data Manager 19.13 with Transparent Snapshots backup performance to PowerProtect Data Manager with VADP backup performance. Based on Dell internal testing, June 2023.
2
When comparing PowerProtect Data Manager 19.13 with Transparent Snapshots restore performance to PowerProtect Data Manger with VADP VM latency performance. Based on Dell internal testing, June 2023.
3
When comparing PowerProtect Data Manager 19.13 with Transparent Snapshots VM latency performance to PowerProtect Data Manger with VADP VM latency performance. Based on Dell internal testing, June 2023.
Transparent Snapshots

44
Dell PowerMax*
Dell PowerStore
Native integration delivers fast,
efficient, and secure backup and
recovery
*Requires Dell PowerProtect Data Manager
Storage Direct
Protection
44

45
Dell APEX AIOps forecasting
& cyber security
• Capacity forecasting
• Security risk assessment,
notifications and recommendations
• Intelligent security advisories
45
See what’s happening, why and what
to do about it
Capacity Analytics
& Forecasting
Security Misconfiguration Risk
Levels & Recommendations
Security Advisories &
Recommendations

46
Multicloud
Rely on proven
multicloud data
protection to rapidly
recover from
data loss events.
46

47
Cloud Tier
Long-term retention
Simple
Automated, native
tiering to public, private
or hybrid cloud.
Cost-effective
Reduce TCO by
sending and receiving
only unique data.
Open
Broad ecosystem and
flexible deployment
options.
Long-term retention to cloud object storage

48
Dell Data Domain
Virtual Edition
(DDVE)
A virtual appliance with
Data Domain DNA
Operational efficiency &
resilience
Scale as you grow
Faster disaster recovery
Reduced costs with
long-term retention
Replicate between PowerProtect Data Domain appliances
and DDVE
ON PREM
/COLO

49
Orchestrated recovery to the cloud
Cloud disaster recovery
Orchestrated DR
End-to-end
orchestration for
disaster recovery to the
cloud and failback.
Efficient architecture
Eliminate DR data
center costs using
minimal cloud
infrastructure.
*According to Dell Internal Testing. March 2022
Simple operation
3 clicks failover, 2
clicks failback*, plus
direct in-cloud access

50
The Dell advantage
Access the full value
of the Dell portfolio.
50

51
Dell Technologies Services
For Dell PowerProtect Appliances
Choice and flexibility throughout the
lifecycle of your solution
Strategize
Implement
Adopt
Scale
51

52
Dell Data Protection Guarantees
Increase confidence in data recoverability, optimize storage efficiency and lower costs
Guaranteed
Recovery & Optimization
Dell Technologies Future-Proof Program

53
Data Domain is
backed by the
power of Dell
One-stop convenience
Leading end-to-end
solutions and
ecosystem partners
Global services &
secure supply chain
Strong channel and
direct salesforce
53

54
THANK YOU

55
Protection Storage
• Deduplication at the source
• Replication
• Immutability
• Virtual Synthetics
• Cloud Tiering
Data Management
• Backup policies
• Retention
• Client / workload integration
• Reporting
• Orchestration
Dell and
Commvault
integration
The combined solution
realizes the full capabilities
of Commvault Cloud data
management along with
the security, performance,
and efficiency of
protection storage

dellemc-powerprotect-dd-presentation.pptx

More Related Content

Similar to dellemc-powerprotect-dd-presentation.pptx

Recently uploaded

dellemc-powerprotect-dd-presentation.pptx

Editor's Notes
