The Libo LUL-09 series puck light features line voltage operation and is dimmable with most standard wall dimmers, providing over 200 lumens per puck without requiring a driver. It is made from zinc alloy and aluminum, ensuring durability, and is available in various finishes with a color temperature range of 2,700k to 6,000k. Each puck has a lifespan of 50,000 hours and comes with installation accessories, with a 3-year limited warranty.

1. 15.07.22
PUCK LIGHT
2,700K - 6,000K LEDs
LINE VOLTAGE, DIMMABLE
LUL-09 SERIES
cETLus LISTED
Product Description
Features
Ÿ Line voltage, without the need for a driver
Ÿ Dimmable with most wall/box dimmers
Ÿ Link up to 20 pucks to a single power supply
Ÿ 90+ CRI, the absolute best in the industry
Ÿ Zinc alloy light housing with aluminum heat sink
Ÿ The fitting is supplied with a collar and can be either surface or recess mounted
Ÿ Seoul LEDs, over 85% less energy used when comparing to halogen - save money on electricity bills
Ÿ cETLus listed
Construction
Lens: Polycarbonate
Finish
Available in White / Black / Stain Nickel / Bronze
Electrical
Lamping
LED's are 2,700K-6,000K non-replaceable. Rated for 50,000 hrs. 90+ CRI.
Certification
Warranty
Recommended Locations
The following accessories are included with each fixture:
Single puck kits include: Three puck kits include: Five puck kits include:
(1) 6’ power cord with roll switch (1) 6’ power cord with roll switch (1) 6’ power cord with roll switch
(1) pucks with 6” lead wire and mounting screws (2) pucks with 6” lead wire and 6” tail wire (4) pucks with 6” lead wire and 6” tail wire
(1) puck with a 6” lead wire (1) puck with a 6” lead wire
(2) 12” linking cables and mounting screws (4) 12” linking cables and mounting screws
Specifications and dimensions subject to change without notice.
Spcifications
Code LEDs Input Power Watt Lumens CRI Color Temperature Dimensions Accessories (Ordered Separately)
LUL-10 Seoul 110V 4W 200-240 90+ 2,700K-6,000K Φ 2 3/4" X 7/8" Junction Box (Black & White)
12-72" Jumper Connector
No.21, Guanhenan Road, Nanhai district of Foshan, Guangdong, China • P: +86 20 2383 2267 • F: +86 757 8576 7586 • Libo-lighting.com
Limited warranty: This fixture is free from defects in materials and
workmanship for a period of 3 years from date of purchase.
cETLus listed for dry locations.
LIBO LIGHTING
Housing: Zinc Alloy Trim with Steel Collar
LIBO LUL-09 Series Puck Light has 12 super bright LEDs and can be recessed or surface mounted in any
direction. It's Line voltage, high performing, easy to install feature offer over 200 lumens per puck without
the need for a driver.
This unit is wired for 120V operation. This LED fixture contains a Triac dimmable driver.
Dimmable with most standard wall dimmers. On/off switch included.
