![fabricated a PET detector ring system that enabled human
studies with short-lived tracers (e.g., 11
C and 15
O).
Since 1979 with the first commercial PET system develop-
ment by CTI, Inc., of Knoxville, TN, in collaboration with Hoff-
man and Phelps of UCLA, PET tomography development has
become a focus of industry with advances in resolution, volume
of body coverage, and sensitivity. Academic and government
research laboratories continue to explore innovations with the
first TOF system developed in 1982 (Ter-Pogossian et al., 1982)
increases in spatial resolution for human systems at 2.3 mm
FWHM (e.g., Derenzo et al., 1987) and hybrid systems such as
PET/CT (Beyer et al., 2000), PET/MRI (Shao et al., 1997) (Figure
A-12.38), and a combination of EEG, PET, and MRI (Jon Shah
et al., 2012). By 2013, there were over 3000 clinical PET systems.
Small-animal PET systems were developed in the mid-1990s at a
number of institutions (Bloomfield et al., 1995) and commer-
cially (Cherry et al., 1996).
1.01.7.4 TOF Positron Tomography
TOF PET was first investigated as a PhD thesis from Vanderbilt
University (Dunn, 1975). TOF was advanced as a solution to
limited statistics in nuclear medicine imaging in 1977
(Budinger, 1977) with more details of the advantages pre-
sented in the following years (Allemand et al., 1980). Instru-
ments were developed at Washington University (Ter-
Pogossian et al., 1982); at University of Texas, Houston
(Wong et al., 1984); and at Commissariat á l’Energie
Atomique-Laboratoire d’Electronique et de L’Informatique
[CEA-LETI] (Gariod et al., 1982; Mazoyer et al., 1990).
Chapter 1.07 of this volume is focused on TOF PET instrumen-
tation and reconstruction strategies. The principal value of TOF
PET is the potential improvement in sensitivity because the
statistical noise is significantly reduced by having the knowledge
of the region along a response line from which the annihilation
event arose. This improvement in terms of signal to noise
(square root of sensitivity) depends on the measurement accu-
racy of the time of arrival difference at the opposing detectors,
the speed of light, and the size of the body region being imaged.
The sensitivity improvement is theoretically proportional to two
times the object diameter divided by the product of the timing
resolution and the speed of light. Thus, for a 40 cm diameter
body and a timing capability of 500 ps (e.g.,current commercial
tomographs), the improvement is about 5, assuming the com-
parison is made to a non-TOF PET with similar scintillator
crystal efficiency. The first systems put into operation for patient
scans built at Washington University used cesium iodide (CsI)
and barium fluoride (BaF3) scintillation crystals. The perfor-
mance characteristics (e.g., density and light output) were low
compared to scintillation crystals of BGO and lithium orthosi-
licate. And this resulted in a sensitivity that was only partially
compensated for by the sensitivity improvement of TOF. After a
gap of 20 years, TOF PET interest was renewed because of the
availability of lanthanum fluoride (Ce-doped) (LaBr3), which
has good timing resolution, high efficiency, and high light
output (Van Loef et al., 2002). The fastest system under con-
struction in 2013 has a timing resolution of 325 ps that leads to
an eightfold improvement in sensitivity relative to conventional
PET (Moses W (2013) Personal communication.). See Chapters
1.07 and 1.08.
1.01.7.5 Reconstruction Tomography from Detected
Emission Data
The theme of detecting the internal structure of matter might
be dated to the work of crystallographers whose goal is to
determine the relative positions of atoms in a crystal. As Laue
realized that the wavelengths of x-rays were in the range of
expected atomic distances, he with his colleagues acquired the
first x-ray diffraction pattern from crystals (Friedrich et al.,
1912), and from these data taken at multiple angles, the inter-
nal structure of simple crystals could be obtained. This might
be considered the first solution of the inverse problem – that is,
from projections of information from different angles, deter-
mine the composition of the object that led to those
projections.
The major difference between tomography using transmit-
ted x-rays and that for nuclear medicine is the fact that in x-ray
tomography, the source strength and position are known and
the unknown is the electron density or material density, but in
nuclear medicine tomography, only the detected emissions
and direction of emissions are known. The unknowns are the
position and strength or concentration of sources. An addi-
tional unknown in nuclear medicine is the amount of attenu-
ation suffered by the emissions from the sources in the body.
SPECT and PET algorithms must calculate source strengths,
source positions, and attenuation – a much more difficult
problem than x-ray computed tomography.
Before the introduction of computational methods into x-
ray radiology and radionuclide nuclear medicine imaging,
astrophysics investigators demonstrated success in applications
of what we now call Fourier transform methods (Bracewell,
1956). It is now generally accepted that the Radon transform
and its inverse represent the underpinning mathematical con-
structs for solving the inverse problem. But developments in
medical computerized tomography did not originate with the
Radon transform (Figure A-2.3). One approach to approximat-
ing the 3D distribution of a radionuclide in an object from
projections of the emitted photons is to merely back project the
observed data into a matrix using optical or digital computer
methods. This method was first used by Kuhl and Edwards
(1963) in their pioneering SPECT. Another solution to finding
the most likely 3D distribution of electron density for radiol-
ogy or nuclear medicine is based on arithmetic approximations
by matching the observed projections to projections computed
from estimates of the actual distribution (i.e., the first could be
the back projection image). Based on differences between the
measured projections and the computed projections from the
estimated distribution, another estimate of the actual distribu-
tion is made using arithmetic or multiplicative weighing fac-
tors. This was the approach known as the arithmetic iterative
reconstruction technique (ART) (Gordon et al., 1970).
A similar mode of data manipulation was first used in phan-
tom and patient studies by Kuhl and Edwards (1968, 1973)
using an upgrade of their original SPECT tomograph. A form of
this iterative estimation process is to attempt a solution of
thousands of simultaneous equations where each projection
value is equal to the sum of all the picture elements along a ray
that projects to the observed value. If there are 100 projection
angles and an object of 100100 picture elements, the
number of unknowns for each equation varies from 140
12 History of Nuclear Medicine and Molecular Imaging
(c) 2015 Elsevier Inc. All Rights Reserved.](https://image.slidesharecdn.com/10302-250517073237-6e80659d/85/Comprehensive-Biomedical-Physics-1st-Edition-Brahme-Anders-38-320.jpg)
