Schiller Automation is presenting at a conference in Hall 2 Level 2 booth C8. They are an automation company with over 30 years of experience in handling equipment for industries like photovoltaics, microelectronics, and thin films. Their portfolio includes selective etching equipment, testing and sorting equipment, and automation for solar cell and module production lines.

1. SCHILLER AUTOMATION
September 2010
Company Presentation
Meet us in Hall 2 Level 2 booth C8
We know how …
1 September 2010
© SCHILLER AUTOMATION

2. Company
SCHILLER AUTOMATION GmbH & Co. KG
We are the handling experts.
2 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

3. Company
Our profile
■ In more than 30 years, SCHILLER evolved into one of the most competent
automation companies in the business.
■ Our strength:
 Holistic consideration of all sorts of conceptual formulations
■ All from one source:
 Development
 Engineering
 Manufacturing
 Assembly
 Installation and start-up
 After sales support
■ SCHILLER is a 100% family-owned company.
3 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

4. Company
Our company structure
Company Management
Quality Management
Customer Center Engineering Production Internal Services
· Sales / Marketing · Mech./Electr. Engineering · Materials Administration · Controlling / PPS
· Project Management · Software Engineering / Document. · Manufacturing · Admin
· Customer Support · Research & Development · Assembly · Information Technology
4 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

5. Company
Facts & Figures
■ Foundation: 1978
■ Management:
 Stefan Schiller Managing Director
 Karl-Heinz Bahnmüller Customer Center
 Martin Speidel Engineering
 Hans-Peter Hennig Internal Services
 Herbert Höhn Key Account Manager
 Torsten Eymer Production
■ Certification : DIN ISO 9001:2010
5 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

6. Company
SCHILLER worldwide (equipments)
China:
Schiller Automation
System (Suzhou) Co. Ltd.
HQ
Germany:
Schiller Automation
GmbH & Co. KG
6 April 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

7. Company
References
7 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

8. Company
Our customers …
… produce and test on our equipment:
■ Photovoltaics Products
 Crystalline solar cells
 PV modules
 Thin film solar cells and modules
■ Microelectronics components
 automotive applications
 power modules
Moreover SCHILLER has extended experience in the
following fields of production automation:
■ Semiconductor products
■ Flat panel displays
■ Data storage products
■ Smart card modules
8 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

9. Company
Segments 2009
10%
13%
PV thin film
54%
PV crystalline
23%
Microelectronics
Services
9 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

10. Company
Photovoltaics
Crystalline solar cell production
 Tester & Sorter TS 3600
 Selective Etching SE 3600
 Quality control equipment
 Process automation & logistics
 Printing-lines and wet-bench automation
 Processes and automation for module
production
 …
10 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

11. Company
QC: Tester & Sorter
Equipment details TS 3600:
■ Throughput 3600 WPH
■ Up-time > 95 %
■ Yield > 99,7 %
■ Classes 48 (dynamic)
State-of-the-art inspections:
■ I-V measuring ■ Print inspection
■ IR shunt detection ■ Defect detection
■ Color detection ■ Electro Luminescence
11 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

12. Company
Process: Selective Etching for edge isolation
Equipment details SE 3600:
■ Throughput 3600 WPH
■ Up-time > 95 %
■ Yield > 99,8 %
■ Efficiency gain
■ Lowest COO
Reliable and robust: well established production technologies
Precise: High precision mechanics and online process control
Fully automated: Inline or Batch with carrier; PSG can be integrated
Flexible and scalable: Any wafer format and contour can be processed
12 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

13. Company
Photovoltaics
Thin film solar cell production
 FAB Automation for Frontend cell production
 FAB Automation for Backend module production
 Module Production process Equipment
 Junction Box mounting
 Framing system
 Line Control production logistics system
13 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

14. Company
Thin Film FAB Automation (Frontend)
14 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

15. Company
Thin Film FAB Automation (Backend)
FIFO double buffer
Process Station
Buffer with cooling function
Process Station
Corner turn unit
I/O Station
Buffer
Buffer content: 50 glass substrates or 25 modules
15 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016 © SCHILLER AUTOMATION

16. Company
Junction Box Mounting
Fully automatic assembly
 On the fly mounting
 Glue dispensing:
 faster
 reliable
 less waste
 …
16 September 2010 Alle Rechte nach ISO 16016 vorbehalten / All rights reserved acc. to ISO 16016

17. Company
… thank you for your attention
Dr. Andreas Reischl
Schiller Automation GmbH & Co. KG
Pfullinger Strasse 58
72820 Sonnenbühl
Germany
Tel: +49-7128-386-5755
Fax: +49-7128-386-299
info@schiller-automation.com
www.schiller-automation.com
Meet us in Hall 2 Level 2 Booth C8
