2. Dahua Technology Co. LTD is a professional manufacturer in the security About R&D
and surveillance field. Over the past 10 years’ development, Dahua Strong R&D department is essential for Dahua to innovate and stride for
Technology has been fully experienced in research and design of cutting- excellence! Dahua has about 800 engineers. Each year we invest 10% of our
edge technology surveillance equipments. Both hardware and software are sales income to research and development. Dahua keeps technology
modular-designed with flexibility for different configurations, various innovation and implementation in embedded structure applications,
scales of applications and future expansion. audio/video encoding/decoding arithmetic and network protocol research.
All of these bring us in the leading place in the industry and guarantee
Dahua took the lead in launching the 8-channel real-time embedded excellent performance of our products.
digital video recorder in 2002 and then released 16-channel real-time
embedded digital video recorder in 2003. Dahua now is leading the Marketing Strategy
development trend of embedded digital video recorder and becoming Oriented to the market requirements and keeping win-win cooperation as
No.1 brand in China. In 2006-2010, the launches of speed dome, decoding our guidance, Dahua is continuously devoted to seeking market expansion
card, network video server and network keyboard represented the Total and promotion, developing overseas customers, enhancing brand credit
Security and Surveillance Structure of Dahua. and reputation. Sharing the better products, service and interests, Dahua
and our cooperators will grow and get stronger together.
In 2011, Dahua's brand-new generation DVRs based on N6 platform (N6
platform adopts dual-core chip) finally had a shining debut. Once these Service system
DVRs came to public eyes, they’ve received popular positive feedbacks from Perfect service system and deep service consciousness are our guarantee to
distributors and direct customers around the world. It is also Dahua that meet the customers’ demands. Dahua has established the network for after
produced the world’s first full D1 32-Channel DVR. In addition to the accom- sales services all over the country. The qualified and experienced service
plishment achieved in the storage line, Dahua has also attached great experts provide the quickest and best services to you. Moreover, Dahua has
importance to research and development of camera products, such as IP been conducting the training for after sales service engineers through the
cameras (ranging from 1.3 megapixel to 5.0 megapixel), HD-SDI camera, regular training in the places of overseas partners. The headquarter also
Effio cameras (700TVL), speed domes and etc. With these wide-ranging provides the after sales service training to the buyers all over the world.
choices, you can definitely find the products that suit you the most. Dahua also provides service with customized features and offers
professional security and surveillance system solutions to meet various
Our products have passed ISO9001 quality management system certifica- customers’ demands.
tion, and some international certifications such as UL, CE, FCC. Our products
with high credit are sold in Europe, America, Japan as well as Taiwan and
are widely used in many fields such as banking, public security, energy
resources, intelligent-building and intelligent-transportation.
9. DH-NVR6000/6000D/6000DR
128 Channel Super Network Video Recorder
Technical Specifications
Model DH-NVR6000 DH-NVR6000D DH-NVR6000DR
System
Main Processor Intel® Core™ i5 Processors
Operating System Embedded LINUX
Motherboard Embedded Board (Support 7x24 operation)
Memory 4GB DDR3(up to 8GB)
Hot-dipped galvanized sheet steel(1.2mm thickened), High-precise
Case
aluminum alloy slide, Patented pull-out rack design
Fan Dual ball screw bearing fan, MTBF>100,000h, support replacement during operation
Interface Local GUI &WEB GUI
Video & Audio
Input 128ch@D1/64ch@720P/32ch@1080P
1080p i7 Transmission 128ch@D1/64ch@720P/32ch@1080P
Recording 128ch@D1/64ch@720P/32ch@1080P
5ch@1080P/10ch@720P/20ch@D1(Screen 1~2 )
Preview
+12ch@1080P/24ch@720P/48ch@D1(Screen 3~6) (Optional)
Features Playback 4ch@1080P/8ch@720P/16ch@D1 (Screen 1)
Recording Resolution 8M, 5M, 3M, 1080P, 720P, 960H, D1, CIF, QCIF, VGA
• Max 128ch IP cameras connection Audio 1ch audio & 1ch Mic in, 1ch audio out
• Up to 32 channel HD realtime transmission Recording
Manual, Schedule(Regular(Continuous), MD(Video detection:
• up to 128 channel@D1, 64 channel@720P, 32 channel@1080P realtime recording IRecording Mode
Motion detection, Camera blank, Video loss), Alarm), Stop
• Up to 6-screen output: 6 HDMI sync output/1 VGA+5 HDMI sync Alarm Recording Video loss, Camera blank, Motion detection, External alarm
Backup Mode Network download / USB HDD/USB CD&DVD-RW / eSATA Device
output (Default: 2 HDMI) Display
• Support 16 hot-swap SATA HDDs to better its scalability and flexibility Interface 6 HDMI, 1 VGA (Default: 2 HDMI)
Video Output 6 HDMI, or 1ch VGA(or built-in LCD) & 5ch HDMI sync video output
• Support RAID0/1/5(optional) The 1st screen: 1/4/6/8/9/16/32/64
Multi-screen Display
• Human-oriented Dahua UI The 2nd-6thscreens: 4
Privacy Masking Four customized zones for privacy masking for each area
• Compatible with Dahua SDK and seamless integrated to other platforms Hard Disk
• Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Hard Disk 16 SATAII
HDD Mode Single, Raid 0, Raid 1, Raid 5. (Support global HDD Hot-standby) (Optional)
Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, HDD Installation Independent HDD rack, support hot swap
Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc. Network
Interface 4 RJ-45 ports(10/100/1000M)
• ONVIF Version 2.0 conformance Ethernet Port 4 Ethernet ports joint working or 4 independent 1000M Ethernet ports
• Redundant power supply module adopted (DH-NVR6000DR) MD & Alarm
Motion Detection Zones: 396(22×18), Sensitivity: 1~6 (level 6 is highest)
• Front LCD display (DH-NVR6000D/DH-NVR6000DR) Alarm Input 16ch, low level effective, green terminal interface
Relay Output 8ch, Relay contact(1A@24VDC), NO/NC programmable, green terminal interface
Dimensions(mm) Interface
Front cover Support hot swap, 7" inch HD LCD (1920×1080/1280×1024/1024×768)(Model-D only)
USB 4 USB ports(2 on the front-panel, 2 on the rear panel)
eSATA 1 eSATA (Video Backup)
General
133.2mm
100V-240Vac, 47-63Hz,
Power Supply 100V-240Vac, 47-63Hz
Redundant
Power Consumption ＜240W（Include HDD）
Working Environment -10˚C~55˚C
485.0mm Working Humidity 10%~80% ( non-condensation)
Dimension (W×D×H) 485mm×448mm×133.2mm
Weight 35kg
Installation Rack-mounted
NVR
8
10. NVR3804/3808/3816
4/8/16 Channel 2U Network Video Recorder
Technical Specifications
Model DH-NVR3804 DH-NVR3808 DH-NVR3816
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video & Audio
IP Camera Input 4 channel 8 channel 16 channel
Two-way Talk 1 channel Input, 1 channel Output, RCA
Display
Interface 1 HDMI, 1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4 1/4/8/9 1/4/8/9/16
H.264/
es e l
Co ua
D1 720P 1080P OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
or
MJPEG
oc r
D
s
4/8/16CH Max 400/480fps Max 200/240fps Max 100/120fps
Recording
Pr
Compression H.264 / MJPEG
1080p Resolution 1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480)
eSATA Max 48TB HDMI / VGA
Record Rate 400/480fps@D1, 200/240fps@720P , 100/120fps@1080P
Bit Rate 48 ~ 8192kbps
Features Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
• Up to 4/8/16 channel with 1080p realtime live view Video Detection & Alarm
• H.264/MJPEG dual codec decoding Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
• Max 120fps@1080p, 240fps@720p,480fps@D1 preview & recording Alarm Input 4 channel 8 channel 16 channel
• HDMI / VGA simultaneous video output Relay Output 6 channel
Playback & Backup
• All channel synchronous realtime playback, Sync Playback 1/4 1/4/9 1/4/9/16
GRID interface & smart search Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera,
• Support Multi-brand network cameras: Dahua, Arecont Vision, Playback Function
Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Backup Mode USB Device / eSATA Device / Internal SATA burner/ Network
Network
Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc. Ethernet RJ-45 port (10/100M/1000M)
• ONVIF Version 2.0 conformance HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,
Network Function
DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.)
• 3D intelligent positioning with Dahua PTZ camera Max. User Access 20 users
• Support 8 SATA HDDs up to 32TB, 1 eSATA up to 16TB, 4 USB2.0 Smart Phone iPhone, iPad, Android, Windows Phone
Storage
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS Internal HDD 8 SATA ports (8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB
External HDD 1 eSATA port (Max 4 SATA HDDs), up to 16TB
System Connection Auxiliary Interface
USB 4 ports (2 Rear), USB2.0
RS232 1 port, For PC communication & Keyboard
RS485 1 port, For PTZ control
General
1 HDMI 1 VGA PTZ Control Power Supply AC 100~240V, 50/60 Hz
Power Consumption 25W 30W 40W
Network RS485 1 Mic Input
Network Camera Video Output / Output Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Dimension(W×D×H) 2U, 440mm × 460mm × 89mm
Weight 6kg(without HDD)
Network Alarm Input
/ Output
USB X 3 IR Remote Control
CMS: DSS/PSS Web Client Mobile Phone Network Keyboard 3 Sensor 1 Lighting/Siren USB Device/Mouse eSATA Device
9
11. NVR3204/3208/3216
4/8/16 Channel 1U Network Video Recorder
Technical Specifications
Model DH-NVR3204 DH-NVR3208 DH-NVR3216
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video & Audio
IP Camera Input 4 channel 8 channel 16 channel
Two-way Talk 1 channel Input, 1 channel Output, BNC
Display
Interface 1 HDMI, 1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4 1/4/8/9 1/4/8/9/16
H.264/
es e l
Co ua
D1 720P 1080P OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
or
MJPEG
oc r
D
s
4/8/16CH Max 400/480fps Max 200/240fps Max 100/120fps
Recording
Pr
Compression H.264 / MJPEG
1080p Resolution 1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480)
Max 8TB HDMI / VGA
Record Rate 400/480fps@D1, 200/240fps@720P , 100/120fps@1080P
Bit Rate 48 ~ 8192kbps
Features Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
• Up to 4/8/16 channel 1080P cameras realtime live view Video Detection & Alarm
• H.264/MJPEG dual codec decoding Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
• Max 120fps@1080p, 240fps@720p,480fps@D1 preview & recording Alarm Input 4 channel 8 channel 16 channel
• HDMI / VGA simultaneous video output Relay Output 3 channel
Playback & Backup
• All channel synchronous realtime playback, Sync Playback 1/4 1/4/9 1/4/9/16
GRID interface & smart search Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera,
• Support Multi-brand network cameras: Dahua, Arecont Vision, Playback Function
Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Backup Mode USB Device / Network
Network
Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc. Ethernet RJ-45 port (10/100M/1000M)
• ONVIF Version 2.0 conformance HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,
Network Function
DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.)
• 3D intelligent positioning with Dahua PTZ camera Max. User Access 20 users
• Support 2 SATA HDDs up to 8TB, 2 USB2.0 Smart Phone iPhone, iPad, Android, Windows Phone
Storage
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS Internal HDD 2 SATA ports
Auxiliary Interface
System Connection USB 2 ports (1 Rear), USB2.0
RS232 1 port, For PC communication & Keyboard
RS485 1 port, For PTZ control
General
Power Supply DC12V/3.3A
Power Consumption 20W(without HDD)
1 HDMI 1 VGA PTZ Control
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Network Network Camera Video Output RS485 Dimension(W×D×H) 1U, 375mm×285mm×50mm
Weight 2.3kg(without HDD)
Alarm Input
/ Output Network
USB X 2
IR Remote
16 Sensor 3 Lighting / Siren USB Device / Mouse Control CMS: DSS/PSS Web Client Mobile Phone
NVR
10
12. NVR3204-P/3208-P/3216-P
4/8/16 Channel 1U PoE Network Video Recorder
Technical Specifications
Model DH-NVR3204-P DH-NVR3208-P DH-NVR3216-P
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video & Audio
IP Camera Input 4 channel 8 channel 16 channel
Two-way Talk 1 channel Input, 1 channel Output, BNC
Display
Interface 1 HDMI, 1 VGA, 1 TV
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4 1/4/8/9 1/4/8/9/16
H.264/
es e l
Co ua
D1 720P 1080P OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
or
MJPEG
oc r
D
s
4/8/16CH Max 400/480fps Max 200/240fps Max 100/120fps
Recording
Pr
Compression
1080p
H.264 / MJPEG
Plug&Play Resolution 1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480)
Max 8TB HDMI / VGA
Record Rate 400/480fps@D1, 200/240fps@720P , 100/120fps@1080P
Bit Rate 48 ~ 8192kbps
Features Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
• Up to 4/8/16 channel 1080P cameras realtime live view Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
• H.264/MJPEG dual codec decoding Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips
• Max 120fps@1080p, 240fps@720p,480fps@D1 preview & recording Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 4 channel 8 channel 16 channel
• HDMI / VGA / TV simultaneous video output Relay Output 3 channel
• All channel synchronous realtime playback, Playback & Backup
Sync Playback 1/4 1/4/9 1/4/9/16
GRID interface & smart search Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
• Support Multi-brand network cameras: Dahua, Arecont Vision, Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera,
Playback Function
Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Backup Mode USB Device / Network
Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc. Network
Ethernet RJ-45 port (10/100M/1000M)
• ONVIF Version 2.0 conformance HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,
Network Function
• 3D intelligent positioning with Dahua PTZ camera DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.)
Max. User Access 20 users
• Support 2 SATA HDDs up to 8TB, 2 USB2.0 Smart Phone iPhone, iPad, Android, Windows Phone
• Support IPC UPnP, 4 PoE ports Storage
Internal HDD 2 SATA ports, up to 8TB
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS Auxiliary Interface
USB 2 ports (1 Rear), USB2.0
System Connection RS232
RS485
1 port, For PC communication & Keyboard
1 port, For PTZ control
General
NVR: DC12V
Power Supply
PoE port: DC48V
100/120fps@1080P, 4 PoE 1 HDMI 1 VGA PTZ Control NVR: 20W(without HDD)
Power Consumption
Video Input Video Output RS485 PoE Port: Max.15 (each)
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Dimension(W×D×H) 1U, 375mm×285mm×50mm
POE POR TS
Weight 2.3kg(without HDD)
Alarm Input
/ Output Network
USB X 2
IR Remote
16 Sensor 3 Lighting / Siren USB Device / Mouse Control CMS: DSS/PSS Web Client Mobile Phone
11
13. DH-NVR3404V/3408V/3416V
4/8/16 Channel 4HDD Vertical Network Video Recorder
Technical Specifications
Model DH-NVR3404V DH-NVR3408V DH-NVR3416V
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video & Audio
IP Camera Input 4 channel 8 channel 16 channel
Two-way Talk 1 channel Input, 1 channel Output, RCA
Display
Interface 1 HDMI, 1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4 1/4/8/9 1/4/8/9/16
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression H.264 / MJPEG
H.264/
es e l
Co ua
D1 720P 1080P Resolution 1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480)
or
MJPEG
oc r
D
s
4/8/16CH Max 400/480fps Max 200/240fps Max 100/120fps Record Rate 400/480fps@D1, 200/240fps@720P , 100/120fps@1080P
Pr
Bit Rate 48 ~ 8192kbps
1080p Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Max 32TB HDMI / VGA
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Features Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
• Up to 4/8/16 channel with 1080p realtime live view Alarm Input 3 channel
• H.264/MJPEG dual codec decoding Relay Output 1 channel
Playback & Backup
• Max 120fps@1080p, 240fps@720p,480fps@D1 preview & recording Playback Channel 1/4 1/4/9 1/4/9/16
• All channel simultaneous realtime playback, Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera,
GRID interface & smart search Playback Function
Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
• Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Backup Mode USB Device / eSATA Device / Network
Network
Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Ethernet RJ-45 port (10/100M/1000M)
Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc. Network Function
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,
DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS etc)
• ONVIF Version 2.0 conformance Max. User Access 20 users
• 3D intelligent positioning with Dahua PTZ camera Smart Phone iPhone, iPad, Android, Windows Phone
Storage
• Support 4 SATA HDDs up to 16TB, 1 eSATA up to 16TB, 3 USB2.0 Internal HDD 4 SATA ports, up to 16TB
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS External HDD 1 eSATA port (Max 4 SATA HDDs), up to 16TB
Auxiliary Interface
System Connection USB
RS232
3ports (1 Rear), USB2.0
1 port, For PC communication & Keyboard
RS485 1 port, For PTZ control
1 HDMI 1 VGA PTZ Control
General
1 Mic Input
Power Supply DC12V
Video Output RS485
/ Output
Power Consumption 20W(without HDD)
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
CMS: DSS/PSS
Dimension(W×D×H) 157.5mm×220mm×172mm
Weight 2.6kg(without HDD)
Network Network Web Client
Network Camera
Mobile Phone
Network Keyboard
Alarm Input USB X 3
/ Output
3 Sensor 1 Lighting/Siren USB Device/Mouse eSATA Device IR Remote Control
NVR
12
14. DH-NVR3404V-P/3408V-P/3416V-P
4/8/16 Channel 4HDD PoE Vertical Network Video Recorder
Technical Specifications
Model DH-NVR3404V-P DH-NVR3408V-P DH-NVR3416V-P
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video & Audio
IP Camera Input 4 channel 8 channel 16 channel
Two-way Talk 1 channel Input, 1 channel Output, RCA
Display
Interface 1 HDMI, 1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4 1/4/8/9 1/4/8/9/16
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression H.264 / MJPEG
H.264/
es e l
Co ua
D1 720P 1080P Resolution 1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480)
or
MJPEG
oc r
D
s
4/8/16CH Max 400/480fps Max 200/240fps Max 100/120fps
Record Rate 400/480fps@D1, 200/240fps@720P , 100/120fps@1080P
Pr
Bit Rate 48 ~ 8192kbps
1080p Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
eSATA Max 32TB HDMI / VGA
Plug&Play
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Features Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips
• Up to 4/8/16 channel with 1080p realtime live view Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 3 channel
• H.264/MJPEG dual codec decoding Relay Output 1 channel
• Max 120fps@1080p, 240fps@720p,480fps@D1 preview & recording Playback & Backup
Playback Channel 1/4 1/4/9 1/4/9/16
• All channel simultaneous realtime playback, Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
GRID interface & smart search Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera,
Playback Function
Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
• Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Backup Mode USB Device / eSATA Device / Network
Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Network
Ethernet RJ-45 port (10/100M/1000M)
Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc. PoE 4 ports (IEEE802.3af)
• ONVIF Version 2.0 conformance HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,
Network Function
DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS etc)
• 3D intelligent positioning with Dahua PTZ camera Max. User Access 20 users
• Support 4 SATA HDDs up to 16TB, 1 eSATA up to 16TB, 3 USB2.0 Smart Phone iPhone, iPad, Android, Windows Phone
Storage
• Support IPC UPnP, 4 PoE ports Internal HDD 4 SATA ports, up to 16TB
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS External HDD 1 eSATA port (Max 4 SATA HDDs), up to 16TB
Auxiliary Interface
System Connection USB 3ports (1 Rear), USB2.0
RS232 1 port, For PC communication & Keyboard
RS485 1 port, For PTZ control
General
1 HDMI 1 VGA PTZ Control
NVR: DC12V
Video Output RS485 1 Mic Input Power Supply
/ Output PoE Switch: DC48V
NVR: 20W(without HDD)
CMS: DSS/PSS
Power Consumption
PoE Port: Max.15 (each)
4 PoE Ports
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Network Network Web Client Dimension(W×D×H) 157.5mm×220mm ×172mm
Network Camera Weight 2.6kg(without HDD)
Mobile Phone
Network Keyboard
Alarm Input USB X 3
/ Output
3 Sensor 1 Lighting/Siren USB Device/Mouse eSATA Device IR Remote Control
13
15. NVR3204V/3208V/3216V
4/8/16 Channel 2HDD Vertical Network Video Recorder
Technical Specifications
Model DH-NVR3204V DH-NVR3208V DH-NVR3216V
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video & Audio
IP Camera Input 4 channel 8 channel 16 channel
Two-way Talk 1 channel Input, 1 channel Output, RCA
Display
Interface 1 HDMI, 1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4 1/4/8/9 1/4/8/9/16
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression H.264 / MJPEG
H.264/
es e l
Co ua
D1 720P 1080P
Resolution 1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480)
or
MJPEG
oc r
D
s
4/8/16CH Max 400/480fps Max 200/240fps Max 100/120fps
Record Rate 400/480fps@D1, 200/240fps@720P , 100/120fps@1080P
Pr
Bit Rate 48 ~ 8192kbps
1080p Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
eSATA Max 24TB HDMI / VGA
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Features Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips
• Up to 4/8/16 channel with 1080p realtime live view Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 3 channel
• H.264/MJPEG dual codec decoding Relay Output 1 channel
• Max 120fps@1080p, 240fps@720p,480fps@D1 preview & recording Playback & Backup
Playback Channel 1/4 1/4/9 1/4/9/16
• All channel simultaneous realtime playback, Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
GRID interface & smart search Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera,
Playback Function
Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
• Support Multi-brand network cameras: Dahua, Arecont Vision, Backup Mode USB Device / eSATA Device / Network
AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Network
Ethernet RJ-45 port (10/100M/1000M)
Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc. HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,
Network Function
• ONVIF Version 2.0 conformance DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS etc)
Max. User Access 20 users
• 3D intelligent positioning with Dahua PTZ camera Smart Phone iPhone, iPad, Android, Windows Phone
• Support 2 SATA HDDs up to 8TB, 1 eSATA up to 16TB, 3 USB2.0 Storage
Internal HDD 2 SATA ports, up to 8TB
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS External HDD 1 eSATA port (Max 4 SATA HDDs), up to 16TB
System Connection Auxiliary Interface
USB 3ports (1 Rear), USB2.0
RS232 1 port, For PC communication & Keyboard
RS485 1 port, For PTZ control
1 HDMI 1 VGA PTZ Control
General
1 Mic Input
Video Output RS485
/ Output Power Supply NVR: DC12V
Power Consumption 20W(without HDD)
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
OFF
eSATA
Dimension(W×D×H) 100mm×220mm×146mm
ON
Weight 1.6kg(without HDD)
HDMI
CMS: DSS/PSS
1 2 3 NO C RXTX A B
VGA
Network Network Web Client
Network Camera MIC OUT MIC IN
USB NET
Mobile Phone
Network Keyboard
Alarm Input USB X 3
/ Output
NVR
3 Sensor 1 Lighting/Siren USB Device/Mouse eSATA Device IR Remote Control
14
