2. Discuss how multiple myeloma is diagnosed
and monitored from all aspects of the clinical
laboratory
Describe the etiology and pathogenesis of
multiple myeloma
Become familiar with various methods of
treatment for multiple myeloma
2
3. 75 yo. male presents
with acute onset of
severe left lateral lower
side and back pain
Past Medical History
◦ Hypertension
◦ Emphysema
◦ Benign prostatic
hyperplasia
◦ Pacemaker for history of
bradycardia
◦ Gout
◦ Patient is a former smoker
3
Image courtesy of: http://www.epainassist.com/back-pain/left-back-pain
4. Chest X-ray shows
serious left lateral
thickening in right chest
Chest CT:
◦ Soft tissue mass around
right 8th rib
◦ Fracturing with oval lytic
lesion at right 7th rib
Multiple small lucencies
within the thoracic spike
of T10.
Legions found on both
sides of kidney
4
Images courtesy of: http://www.pleuralthickening.org.uk/causes-of-pleural-
thickening
5. Physician suspected malignancy
Initial Laboratory Findings:
◦ Low RBC count, HB, and HCT
◦ Serum Protein Electrophoresis:
Normal IgM, IgA, IgG
Gamma M spike present
◦ Immunofixation
Monoclonal gammopathy with free Kappa paraprotein
◦ Extremely High Free Kappa Chain count
Patient presented with diagnosis of Kappa
Multiple Myeloma
5
6. According to the
American Cancer Society,
the etiology of multiple
has not yet been
determined.
Scientific Opinion:
Problem adaptive
immunity?
6
Image courtesy of: http://www.politicspa.com/if-corbett-didnt-run-who-might-
republicans-nominate/49473/silhouette-question-mark-3/
7. Somatic
Recombination (T-
Cell Independent):
◦ (V), (D), (J) segment
recombination at DNA
level
◦ B – Cell Maturation
◦ IgM production
◦ Enzymatically Driven by
IgH and IgK/L genes
7
Image courtesy of:, https://commons.wikimedia.org/w/index.php?curid=4329676
8. Mature B-cells
synthesize
antibodies specific
to foreign antigens:
◦ Somatic
Hypermutation:
Produces highly
affinitive antibodies
◦ Class Switching
Recombination
Heavy chain genes
rearrange to change
IgM to IgG, IgE, or
IgA
8Image courtesy of: https://i.ytimg.com/vi/ba68cC8h3Eo/maxresdefault.jpg
9. Anemia (Normocytic,
Normochromic)
◦ 75% of patients at diagnosis
◦ 100% of patients during course
of disease
Bone Disease (Two pronged
Attack)
◦ Osteoblasts inhibited by rapidly
cloning myeloma cells
◦ Osteoclasts put into overdrive
by osteoclastic activating
factors produced by myeloma
cells
◦ Associated with BONE PAIN
9
Image courtesy of:
http://www.clinicaloptions.com/Oncology/Treatment%20Updates/Bone%20Complications/Module/Tra
nscript/Pages/~/media/Oncology/Programs/Bone%20Complications/ASCO_BoneTU_Figure1.ashx
10. Hypercalcemia
◦ Kidney dysfunction & impairment of osteoclast-
osteoblast equilibrium leads to bone destruction
Large amount of Ca++ released into blood
Renal Disease (Myeloma Kidney)
◦ Bence Jones proteins present in huge amounts
overworks kidney’s filtering and reabsorptions
ability leading to chronic kidney disease
Amyloidosis
◦ Bence Jones proteins deposit themselves into
various tissue causing systemic issues
10
12. Based on many factors
◦ Disease progression rate
Asymptomatic vs. Symptomatic
Bone disease
M protein levels
Bence Jones Protein levels
Age
Scope of Case
◦ Patient is considered newly diagnosed elderly
patient not eligible for transplantation
12
13. Melphalan + Prednisone
◦ Primary therapy for MM in newly diagnosed elderly
patient
◦ Melphalan = DNA/RNA synthesis inhibitor
◦ Prednisone = Immunosuppression
13
Image Courtesy of:
https://en.wikipedia.org/wiki/Melphalan#/media/File:Melphalan_ball-and-stick.png
14. Velcade + dexamethasone
◦ Velcade (Bortezomib): Proteasome inhibitor
Proteasomes are cellular complexes that degrade
proteins over time
In myeloma cells the proteasomes outlast pro-
apoptotic proteins
14
Image courtesy of: http://www.velcade.com/Understanding-velcade/About-velcade
15. Anti-CD38 chemotherapy
◦ Developed in 2012
◦ Approved for FDA Fast Track Designation and
Breakthrough Therapy designation in 2013
15Image courtesy of
http://www.icpoep.com/PDF/TorbenPlesner_ICPOEP2015_PresentationSlides.pdf
16. Surprise! RBCs weakly express CD38
◦ What does this mean?
DARA causes plasma panreactivity in vitro
It invalidates the antibody screen and panel of plasma
and eluate
Solution?
◦ Treat patient plasma with Dithiothreitol (DTT)
◦ Caveat: DTT denatures Kell antigens. So K negative
units must be provided
16
17. 5% of patients with multiple myeloma are
positive for CD19 and Negative for CD56
Importance:
◦ CD19 expression has been correlated with poor
response to chemotherapy
17
18. Daratumumab VS. Patient’s MM
◦ Daratumumab is slowing the progression of the
disease, but not at all resolving it
Kappa light chain levels continue to rise
◦ Chronic Kidney Disease persists
Patient is almost completely refractory
18
19. Patient’s worsening condition displays
resilience of multiple myeloma
◦ Clonal plasma cells leads to
Stressed BM Normocytic/Normochromic Anemia
Bone Breakage
◦ Massive amounts of kappa light chains
Overwhelmed Kidney Chronic Kidney Disease
In conclusion we have
◦ Discussed the Diagnosis of MM
◦ Discussed MM etiology and pathophysiology
◦ Familiarized ourselves with various treatment for
MM
19
20. 1Gonzalez D, Burg M, Garcia-Sanz R. Immunoglobulin gene rearrangements and the pathogenesis of multiple
myeloma. J Blood [Internet]. 2007 July [Cited 2016 Feb 22]; 110 (9) 3112-3121.
Available from:http://www.bloodjournal.org/content/bloodjournal/110/9/3112.full.pdf?sso-checked=true
2Stevenson G. CD38 as a Therapeutic Target. Mol Med [Internet]. 2006 [Cited 2016 March 8]; Nov-Dec; 12(11-
12): 345-346
Available from: http://www.ncbi.nlm.nih.gov/pmc/articles/PMC1829201/
3 S Vincent Rajkumar, MD. Patient information: Multiple myeloma symptoms, diagnosis, and staging (Beyond the
Basics) [Internet]. UpToDate; [updated 2015 Nov 5];
Available from: http://www.uptodate.com/contents/multiple-myeloma-symptoms-diagnosis-and-staging-
beyond-the-basics
4Papadopoulou E, Batzios S, Dimitriadou M. Multiple myeloma and bone disease: pathogenesis and current
therapeutic approaches. Hippokratia [Internet]. 2010 Apr-Jun [Cited 2016 Feb 12]; 14(2): 76-81.
Available from: http://www.ncbi.nlm.nih.gov/pmc/articles/PMC2895290/
5Shah D, Seiter K. Multiple Myeloma Clinical Presentation [Internet]. New York (NY): The Medscape Journal of
Medicine; c2002 [updated 2016 Feb 5; cited 2016 Feb 12]. Available from:
http://emedicine.medscape.com/article/204369-clinical
6Mateo G, Montalban A, Vidriales, M. Prognostic Value of Immunophenotyping in Multiple Myeloma: A Study by
the PETHEMA/GEM Cooperative Study groups on Patients Uniformly Treated with High-Dose Therapy. J Clin Onc
[Internet]. 2008 Jun [Cited 2016 March 10]; 26(16) 2737-44.
Available from: http://jco.ascopubs.org/content/26/16/2737.full
20
21. 7Luiz A, Calheiros L, Kerbauy D. Multiples aberrant phenotypes in multiple myeloma patient
expressing CD56-, CD28+, CD19+. Rev Bras Hematol Hemoter [Internet]. 2012 [Cited 2016 Apr
21]; 34(1): 66-67.
Available from: http://www.ncbi.nlm.nih.gov/pmc/articles/PMC3459618/
8Phillips C, Chen Y, Gopalakrishnan S. Daratumumab and its potential in the treatment of
multiple myeloma: overview of the preclinical and clinical development. Ther Adv Hematol
[Internet]. 2015 June [Cited 2016 Feb 24]; 6(3): 120-127.
Available from: http://www.ncbi.nlm.nih.gov/pmc/articles/PMC4480519/
9Lokhorst HM, Plesner T, Laubach JP. Targeting CD38 with Daratumumab Monotherapy in
Multiple Myeloma, N Engl J Med [Internet]. 2015 Sep [Cited 2016 Feb 24]; 373: 1207-1219.
Available from: http://www.nejm.org/doi/full/10.1056/NEJMoa1506348
10Chapuy C, Nicholson R, Aguad M. Resolving the Daratumumab interference with blood
compatibility testing. Transfusion [Internet]. 2015 June [Cited 2016 Feb 24]; 55(6 pt 2): 1545-
54.
Available from: http://www.ncbi.nlm.nih.gov/pubmed/25764134
11McClure K. Rh, RHAG, and LW Blood Group Systems.
In: Gockel-Blessing EA, Pratt MM, Johns GS, editors. Clinical Laboratory Blood Banking and
Transfusion Medicine Principles and Practice. New York:
Pearson; 2015. p. 75-87.
21
22. 12E-pain-assist.com [Internet]. Tampa: Painassist Inc.; c2012-16 [updated 2016; cited 2016 April 20]. Available
from: http://www.epainassist.com/back-pain/left-back-pain
13Politics-PA.com[Internet]. Pennsylvania: PoliticsPA. 2013 Jul 16 [cited 2016 April 20]. Available from:
www.politicspa.com/if-corbett-didnt-run-who-might-republicans-nominate/49473/silhouette-question-
mark-3
14Wikimedia.org [Internet]. San Francisco: Gustavo Carra. 2008 Jul 6 – [cited 2016 April 20]. Available from:
https://commons.wikimedia.org/w/index.php?curid=4329676
15You-tube.com [Internet]. San Bruno: Alphabet Inc. c2005 [cited 2016 April 20]. Available from:
https://i.ytimg.com/vi/ba68cC8h3Eo/maxresdefault.jpg
16Clinical-Options.com[Internet]. Reston: Clinical Options; c2015 [updated 2016 April 20; cited April 20].
Available from:
http://www.clinicaloptions.com/Oncology/Treatment%20Updates/Bone%20Complications/Module/Transcript/Pa
ges/~/media/Oncology/Programs/Bone%20Complications/ASCO_BoneTU_Figure1.ashx
17Velcade.com [Internet]. Cambridge: Millennium Pharmaceuticals, Inc c2014 [cited 2016 April 20]: Available
from: http://www.velcade.com/Understanding-velcade/About-velcade
18Plesner T. Daratumumab for multiple myeloma: A journey from phase 1 towards approval for marketing. LI Ka
Shing Faculty of Medicine, The University of Hong Kong [Internet]. [Cited 2016 April 24]: Available from:
http://www.icpoep.com/PDF/TorbenPlesner_ICPOEP2015_PresentationSlides.pdf
22
I want a showing the first point if possible and lucencies
Recent studies lead many scientists to believe the problem has to do with the hallmark of the human immune system
Remember to mention CD38 and CD19
Also mention how the mutation in some cases (such as patient’s) leads to the overproduction of light chains
Somatic Hyper mutation:
Rearranged Ig genes mutate to produce highly affinitive antibodies
Anemia: Due to many factors including bone marrow replacement/dysfunction, Kidney damage, and/or because of the overwhelming amount of light chains diluting the blood
Bone disease
Melphalan = It’s targets are unable to survive
Prednisone = it helps deal with the immflammatory response that is due to death of cells
But none of them worked
Three Pronged attack mechanism
Direct apoptosis
Decreases T cell immunomodulation that activates myeloma cell transformation
Enzymatically inhibits CD38 cells
