This project proposal outlines a home automation system for the Baan K.Prae project that includes lighting, door phone, curtain, and temperature controls. The system would use command switches, scenario switches, touch screens, iPod/computer controls, and video touch screens to control different zones and groups of lights, blinds, and motors throughout the home. The proposal also discusses product and service support options.

1. PROJECT PROPOSAL
For Home Automation System
Project proposal for home automation of the
Baan K.Prae project.
Proposal includes lighting system, door phone, curtain control
and temperature control in beautiful finished cover plates.

12. Command Switch Controls
Command Switch
•Control lights from point
to point

13. Scenario Controls
Scenario Switch
•Able to control group
of lights, blinds, motors
into one touch

14. Touch Screen Controls
3.5” touch screen
Able to control all the
system in one point
•light
•blinds
•Motors
•scenario

15. Ipod Touch Controls

16. Computer Controls
VIDEO TOUCH SCREEN INTERNET
•enables users to remain constantly in
• 15” touch screen control
• Portable control from a single touch with their home, even when they’re
• featuring maps or photos of all spaces in away.
the home
•A telephone call or simple Internet
connection

17. Communication
Entrance Video station

21. 1 floor – Type A
st
Scenario
•4 Scene Control
Switch Switch
•2 On-Off Control •3 On-Off Control

22. 1 floor – Type A
st
Touch Screen
Scenario
•4 Scene Control
Switch
•2 Curtain Control
Switch
•2 On-Off Control
Switch
•3 On-Off Control

23. 2nd
floor – Type A
Switch
•2 On-Off Control Switch
•3 On-Off Control
Scenario
•4 Scene Control
Switch
•1 On-Off Control
•1 Master On-Off
Control Switch
•2 Curtain Control

24. 2 nd
floor – Type A
Switch
•2 On-Off Control
Touch Screen
Switch
•3 On-Off Control
Switch
•2 Curtain Control
Switch
•1 On-Off Control
•1 Master On-Off
Control

25. Product and Service Support
All BTicino My Home systems include:
 2 years product warranty
 1 year service warranty
 Additional Maintenance and Service Warranties are
available upon request
