Azure Mobile Apps with Xamarin
- 3. “This weighty book gives clear guidance that will help you build quality apps, starting with architectural considerations, and then jumping into practical code strategies.” - Bryan Costanich, Vice President, Xamarin “Dan Hermes’ extraordinary book is the most intelligent work on cross-platform mobile development I’ve seen.” – Jesse Liberty, Director of New Technology Development, Falafel Software, Xamarin Certified Developer / Xamarin MVP
- 8. Everybody Apps! 189M downloads a day 200mins on phone 127mins in apps
- 9. The average app user has 36 apps installed on his or her phone.
- 10. Only 1/4 are used daily:
- 11. 1/4 of apps are never used! Why not?
- 12. Bad App Experiences • Slow or laggy • Crashes • Unintuitive & bad UX • Features not as advertised • Data not available when you need it
- 13. Your app craves connection more than you do.
- 16. No app is an island
- 20. A platform-as-a-service (PaaS) offering of Microsoft Azure A ready-made backend so the developer can focus on the app
- 23. • Azure Portal for configuration of entities • Server SDK in C# or Node.JS • Client SDKs for Xamarin and third-party products
- 24. Let’s add a backend
- 25. Create a new Azure Mobile App
- 26. Quick Start in Settings and Connect a DB
- 27. • Easy Tables • Entity Framework For the demo just click Create ToDoItem Table: Create your Tables
- 28. • Create a new Azure Mobile App backend • Build, upload, and test the server project • Create a client mobile application or Just Use Azure’s Built-in Table API Create a Table API using C#
- 29. Create a client mobile application
- 30. Create a Mobile Service MobileService = new MobileServiceClient( "https://myapp.azurewebsites.net");
- 31. Now let’s get to the data
- 32. Create Tables IMobileServiceSyncTable<Store> table; public async Task Init() { const string path = "syncstore.db"; var db = new MobileServiceSQLiteStore(path); db.DefineTable<Store>(); } var handler = new MobileServiceSyncHandler(); await MobileService.SyncContext.InitializeAsync(db, h); table = MobileService.GetSyncTable<Store>();
- 33. Get and Modify Data public async Task<IEnumerable<Store>> GetStoresAsync() { await table.PullAsync("allStores", table.CreateQuery()); return await table.ToEnumerableAsync(); } public async Task<Store> AddStoreAsync (Store store) { await table.InsertAsync (store); await table.PullAsync("allStores", table.CreateQuery()); await MobileService.SyncContext.PushAsync(); return store; }
- 34. Table-based SQL database Instances configurable using the Azure portal Data management in:
- 36. Data Store App Data Access Calls Data Access Calls Data Access Calls Courtesy of Microsoft
- 37. Data Store App Repository Create Read Update Delete Data Access Calls Data Access Calls Data Access Calls Courtesy of Microsoft
- 38. CRUD (Create, Read, Update, Delete) Create - Insert data Read - Query data Update - Change data Delete - Remove data await todoTable.InsertAsync(item); List<TodoItem> items = await todoTable.ToListAsync(); (or ToEnumerableAsync()) await todoTable.UpdateAsync(item); await todoTable.DeleteAsync(item);
- 41. Cloud Data ServiceMobile Device Local data store Cloud Data Service Cloud data store Courtesy of Microsoft
- 43. PushAsync PullAsync PurgeAsync Example: await mobileService.SyncContext.PushAsync();
- 46. Mobile Device SQLite Local data store Azure Mobile App SQL Database Cloud data store PushAsync PullAsync PurgeAsync MobileServicePushFailedException Courtesy of Microsoft
- 48. but wait, there’s more…
- 55. Lunch! Dan Hermes Xamarin MVP, Microsoft MVP Chief Executive Coder, Lexicon Systems dan@lexiconsystemsinc.com www.mobilecsharpcafe.com @danhermes
Editor's Notes
- Julie Larson-Green – Microsoft, Xbox Division
- Google survey
- 17
- Left: Online - connected Right: Offline - disconnected
- Extremely powerful You can do almost anything your backend would ever need to do with Azure. Data storage, authentication/authorization, push notifications, custom APIs, blob storage, etc. Flexible Need something lightweight? Azure is there. Need something robust and powerful? Azure is there. C# clients I’m a frontend developer, I care a lot about how easy this makes MY job (selfish) Many C# clients are written by Java developers, etc. Easy to use C# client Abstracts away much of pain of using a RESTful API C# Features Async / Await / TPL Uses C# idioms Properties, Fluent API Seems obvious, but not always true (first class citizen)
- Notes: App Service aims to automate the creation of very common line-of-business mobile and web functionality The developers can focus on developing the parts of the app that are unique as opposed to the boilerplate, typical scenarios that must be re-created for each application
- Notes: Azure Mobile Apps is an app type of Azure App Service (others types include Web Apps, API Apps, and Logic Apps) Users don’t really care (and usually don’t know) what a mobile app is using for it’s backend Users care most about enjoying the app experience Devs should therefore spend most of their time building the best client experience they can Azure Mobile Apps helps devs by providing common mobile app backend features in a turnkey manner Data storage powered by SQL Database (but you don’t have to be a Database Admin to use it) User Authentication and Data Authorization Push Notifications (using services built into Android, iOS, Windows, and more) Other topics not covered in this lesson: Backend job processing using the scheduler Backend Logic Image and text courtesy of Microsoft
- References: Image courtesy of Microsoft
- Notes: By following the step-by-step wizard-like process in App Service in the browser, you can add common functionality that’s pre-configured to work with your Azure instance and other apps and services you’ve built in your Azure instance
- Notes: Select New > Web + Mobile > Mobile App
- Notes: Select New > Web + Mobile > Mobile App 1 Connect to a Database (create a DB connection) 2 Create a table API (C# or Node.js) 3 Configure your client application
- What if a GetAll should only return favorites for that user.
- What if a GetAll should only return favorites for that user.
- Notes: You can download the solution to a Mac and open it in Xamarin Studio, or you can download the solution to a Windows computer and open it in Visual Studio using a networked Mac for building the iOS app. Extract the project that you downloaded, and then open it in Xamarin Studio or Visual Studio.
- Add Azure Nuget
- What if a GetAll should only return favorites for that user.
- What if a GetAll should only return favorites for that user.
- Notes: Calls to the data store can be made in the app directly from the places in the app that need data. This is a functional approach, but eventually can lead to unmaintainable, spaghetti code. In professional grade apps this is considered an anti-pattern, a programming practice to avoid. In formal terms this hard-coded approach violates Separation of Concerns (SOC)
- Notes: CRUD is the standard set of database transactions needed as an interface for most projects. Item is an object of type TodoItem. It must have an ID property for many of these transactions. Tip: When executing a query using an untyped table object, you must explicitly specify the OData query string by calling ReadAsync.
- Notes: Create and Read are good academic terms but a bit stodgy for method names. Let’s use New and Get instead. Initialization is done in the service’s constructor, AzureDataService (), or in an explicitly called initializer like Initialize().
- Notes: Create and Read are good academic terms but perhaps a bit stodgy for method names. Let’s use New and Get instead.
- Notes:
- Notes: Sync local SQLite database with Azure cloud data store (SQL Database). These are the ways: PushAsync - takes local changes to all tables and applies them to Azure cloud data store Push is executed on the whole context, not on particular tables. It’s implemented this way to maintain the relationships between rows in different tables, i.e. foreign keys. PullAsync - grab data from Azure and bring it local to the device – automatically pushes first This is the most commonly-used offline sync function. PurgeAsync - deletes items in local table that match the query param – automatically pushes first Generally used when ‘soft deletes’ not enabled on server.
- Notes: Azure Mobile Client SDK 3.0 brought some changes The SQLite Batteries initialization is now required for all Oses. For Android, the path folder for the MobileServiceClient call is not supplied. This must be determined manually. Generally this is done in the Android project and injected back into the Xamarin.Forms PCL. Define a SQLitePath class in the Xamarin.Forms project with a property called PathName. public class SQLitePath { public static string PathName { get; set; } = "localstore.db"; } In the AzureDataServicesSync contructor shown in the slide, replace the ‘store’ assignment with this code: var path = "localstore.db"; path = SQLitePath.PathName; var store = new MobileServiceSQLiteStore(path); In Android activity (such as MainActivity.cs) SQLitePath.PathName = Path.Combine(System.Environment.GetFolderPath(System.Environment.SpecialFolder.Personal), SQLitePath.PathName); if (!File.Exists(SQLitePath.PathName)) { File.Create(SQLitePath.PathName).Dispose(); } See detail in Lab 5.
- Notes: First PullSync parameter “allTasks” is a name given to the query generated by the next parameter. Second parameter creates query to select all rows in the TodoTable.
- Notes: PushAsync, PullAsync, PurgeAsync are the ways to sync data using the Azure Mobile Client API. More in the next slide. All writes go to the local SQLite database. Nothing goes to Azure unless we sync explicitly using PushAsync, PullAsync, or PurgeAsync. Sync errors throw MobileServicePushFailedException
- Notes:
- What if a GetAll should only return favorites for that user.
- Notes: There are two forms of auth and the first we’ll talk about is server auth This is a basic Oauth flow The client device calls a method in the SDK which opens a webview which goes to a specific auth provider The user authenticates The provider hands back information to the Mobile Service The Mobile Service creates an identity which it hands back to the client Future requests from the client contain that identity (though it needs to be cached locally for app restarts) The Mobile Service now has Graph access to the provider
- SO Hard! Azure makes it easy Huge value in having this integrated with data... you can just say fire a push IF
- Notes: Some of the items in the store are free and some are available for a fee. The fees charged can also be based on the level of service, frequently revolving around volume of use The items in the store are pieces of a larger or enterprise-level app that may be helpful Email sending/management with SendGrid or Office365 Enterprise-level third-party integration with services like SharePoint, SalesForce and QuickBooks API access for enterprise-level data services like Bing Search or Global Address Validation Some items are entire Azure-configured applications or content management systems (CMSes) like WordPress, Umbraco, Drupal, etc. This can speed up the application development process and save time and money Most of the items in the Azure Marketplace are built with cloud-computing and Azure in mind, removing some of the common Azure-related development tasks Azure Active Directory is Microsoft’s multi-tenant, cloud-based directory and identity management service. It provides single sign on access to all integrated apps and services. It includes identity management functionality such as multi-factor authentication, password management, role based access control, auditing and security monitoring and alerting More on the Azure Marketplace: https://azure.microsoft.com/en-us/marketplace/
- Notes: Azure Mobile Apps is an app type of Azure App Service (others types include Web Apps, API Apps, and Logic Apps) Users don’t really care (and usually don’t know) what a mobile app is using for it’s backend Users care most about enjoying the app experience Devs should therefore spend most of their time building the best client experience they can Azure Mobile Apps helps devs by providing common mobile app backend features in a turnkey manner Data storage powered by SQL Database (but you don’t have to be a Database Admin to use it) User Authentication and Data Authorization Push Notifications (using services built into Android, iOS, Windows, and more) Other topics not covered in this lesson: Backend job processing using the scheduler Backend Logic Image and text courtesy of Microsoft
