9. Copyright (c) 2006 by Sasalak Tongkaw9
COMPUTER PROGRAMMING AND ALGORITH
โครงสร้างการตัดสินใจแบบทางเลือก
เดียว
• โครงสร้างการตัดสินใจแบบทาง
เลือกเดียว (single-alternative
decision) มีทางเลือกสำาหรับ
ตัดสินใจเพียงทางเดียวดังภาพ
Year=4 ?
Graduation
Routine
No Yes
Don’t Do
Anything
10. Copyright (c) 2006 by Sasalak Tongkaw10
COMPUTER PROGRAMMING AND ALGORITH
โปรแกรมภาษาซีที่มีทางเลือกเดียว
#include<stdio.h>
void main()
{
int age;
printf(“How old are you ”);
scanf(“%d”,&age);
if (age>=60)
printf(“You are oldn”);
printf(“Good Bye ! ”);
}
12. Copyright (c) 2006 by Sasalak Tongkaw12
COMPUTER PROGRAMMING AND ALGORITH
การเชื่อมต่อโดยการใช้ “และ”
• เป็นการตัดสินใจที่มีมากกว่า 1
เงื่อนไข เช่น
• ต้องการให้เงินค่าล่วงเวลาสำาหรับ
พนักงานที่ทำางานเกิน 40 ชั่วโมง
และเป็นพนักงานใน Class 1
• มี 2 เงื่อนไขคือ
– 1. ต้องทำางานเกิน 40 ชั่วโมง
– 2. ต้องเป็นพนักงานใน Class 1
13. Copyright (c) 2006 by Sasalak Tongkaw13
COMPUTER PROGRAMMING AND ALGORITH
ผังงานแสดงเงื่อนไขแบบ “และ”
Hour>40 ?
Class=1 ?
Overtime
Yes
Yes
No
No
Hour>40 ?
Class 1 ?
ข้อควรระวังในการสลับที่คือ
ประสิทธิภาพของการทำางาน
ข้อควรระวังในการสลับที่คือ
ประสิทธิภาพของการทำางาน
14. Copyright (c) 2006 by Sasalak Tongkaw14
COMPUTER PROGRAMMING AND ALGORITH
การเชื่อมต่อโดยการใช้ “หรือ”
• จะทำางานก็ต่อเมื่อเงื่อนไขหนึ่ง
เงื่อนไขใดเป็นจริงหรือเป็นจริงทั้ง
สองเงื่อนไขก็ได้ เช่น
• บริษัทจะให้โบนัสแก่พนักงานที่
เป็นพนักงานใน Class 1 หรือ
เป็นพนักงานใน Class 2
• โครงสร้างของผังงานแสดง
เงื่อนไขแบบ “หรือ”
15. Copyright (c) 2006 by Sasalak Tongkaw15
COMPUTER PROGRAMMING AND ALGORITH
โครงสร้างของผังงานที่มีเงื่อนไขแบบ
“หรือ”
Class =1?
Bonus
Yes
Yes
No
No
Class =2 ?
Bonus
ข้อควรระวังในการ
สลับที่คือ
ประสิทธิภาพของ
การทำางาน
เช่นเดียวกัน
ข้อควรระวังในการ
สลับที่คือ
ประสิทธิภาพของ
การทำางาน
เช่นเดียวกัน
16. Copyright (c) 2006 by Sasalak Tongkaw16
COMPUTER PROGRAMMING AND ALGORITH
การตัดสินใจโดยใช้ทั้งสองวิธีร่วมกัน
• สำาหรับภาษาซีสามารถจะใช้ทั้ง
สองวิธีที่กล่าวมาแล้วร่วมกันได้
• ใช้สัญลักษณ์ทางคณิตศาสตร์
ดังนี้
• && หมายถึง “และ” and
• || หมายถึง “หรือ” or
• ! หมายถึง “ไม่” not
17. Copyright (c) 2006 by Sasalak Tongkaw17
COMPUTER PROGRAMMING AND ALGORITH
ตัวอย่างผังงานการตัดสินใจแบบใช้
สองวิธีร่วมกัน
Hour>40
and Class
=1 ?
Overtime
YesNo Class =1 or
Class=2 ?
Bonus
YesNo
