IMPRESSION TECHNIQUES IN COMPLETE DENTURE
CONTENTS
Introduction
History
Basic requirements of impression making
Objectives of impression making
Theories in impression making
Recording the preliminary impressions
Spacer designs & tissue stops
Recording the final impressions
Border molding
Wash impression
Conclusion
References
INTRODUCTION
The journey towards successful complete denture fabrication begins with making accurate impressions.
All subsequent steps that are necessary for complete denture fabrication will be greatly diminished if the denture base does not fit due to inadequate impression.
DEFINITION
IMPRESSION:
An imprint or negative likeness of the teeth, of the edentulous areas where the teeth have been removed, or of both, made in a plastic material that becomes relatively hard or set while in contact with these tissues.
WINKLER
COMPLETE DENTURE IMPRESSION:
A negative registration of the entire denture bearing, stabilizing, and border seal areas present in the edentulous mouth.
HEARTWELL
HISTORY
Before the middle of the 18th century, no method was available for producing an impression of the alveolar ridge.
Ridges were painted with a dye and a block of ivory or bone was pressed on the ridge.
Areas of contacts were scraped away from the block until the best fit of the prosthesis was achieved.
In 1711, Mathian Gottfried Purman recorded the use of wax.
In 1728, Pierre Fauchard made dentures by measuring mouth with compasses and cut the bone to approximate shape for the space to be filled.
In 1736, Phillip Pfaff of Germany made impressions in wax sections of half of the mouth at a time.
1782 -William Rae said that “he got the measurement of the jaws in a piece of wax pushed into the gum, afterwards making a cast of it with plaster of paris.
1840 - Charles De loude (london) made one of the earliest reference to impression trays .
1842- Montgomery discovered gutta percha.
It was introduced as an impression material in 1848 by Colburn.
1844-Wescott, Dwinelle and Dunning used plaster of paris as an impression material.
1862 Franklin described the first correct impression.
1874 Modeling plastics was developed by S. S. White
1900 Green brothers introduced a method for manipulating the modeling plastics.
First to use the term "posterior dam" in describing the posterior palatal seal.
1915 Rupert Hall perfected the first moderate-heat modeling plastic for making individual impression trays.
1925 Poller used agar for dental impressions.
1930s Ward and Kelly used ZOE for impressions.
1939 Trapozzano described one of the early techniques using Zinc oxide eugenol paste.
1936 Alginate-type materials patent awarded.
1940s Write and Denen were first to use alginate impression for corrective wash procedures
1942- Pendleton suggested a fluid wax technique using asiatic or india
2. CONTENTS
Introduction
History
Basic requirements of impression making
Objectives of impression making
Theories in impression making
Recording the preliminary impressions
Spacer designs & tissue stops
Recording the final impressions
Border molding
Wash impression
Conclusion
References
3. INTRODUCTION
The journey towards successful complete denture fabrication begins with making
accurate impressions.
All subsequent steps that are necessary for complete denture fabrication will be greatly
diminished if the denture base does not fit due to inadequate impression.
4. DEFINITION
IMPRESSION:
An imprint or negative likeness of the teeth, of the edentulous areas where the teeth
have been removed, or of both, made in a plastic material that becomes relatively hard
or set while in contact with these tissues.
WINKLER
COMPLETE DENTURE IMPRESSION:
A negative registration of the entire denture bearing, stabilizing, and border seal areas
present in the edentulous mouth.
HEARTWELL
5. HISTORY
Before the middle of the 18th century, no method was available for producing an
impression of the alveolar ridge.
Ridges were painted with a dye and a block of ivory or bone was pressed on the ridge.
Areas of contacts were scraped away from the block until the best fit of the prosthesis
was achieved.
In 1711, Mathian Gottfried Purman recorded the use of wax.
Starke, E.N., Jr. A Historical Review of Complete Denture Impression
Materials. JADA 91:1037-1041,1975
6. In 1728, Pierre Fauchard made dentures by measuring mouth with compasses and
cut the bone to approximate shape for the space to be filled.
In 1736, Phillip Pfaff of Germany made impressions in wax sections of half of the
mouth at a time.
1782 -William Rae said that
“he got the measurement of the jaws in a piece of wax pushed into the gum,
afterwards making a cast of it with plaster of paris.
Starke, E.N., Jr. A Historical Review of Complete Denture Impression Materials.
JADA 91:1037-1041,1975
7. 1840 - Charles De loude (london) made one of the earliest reference to impression
trays .
1842- Montgomery discovered gutta percha.
It was introduced as an impression material in 1848 by Colburn.
1844-Wescott, Dwinelle and Dunning used plaster of paris as an impression material.
1862 Franklin described the first correct impression.
8. 1874 Modeling plastics was developed by S. S. White
1900 Green brothers introduced a method for manipulating the modeling plastics.
First to use the term "posterior dam" in describing the posterior palatal seal.
1915 Rupert Hall perfected the first moderate-heat modeling plastic for making
individual impression trays.
9. 1925 Poller used agar for dental impressions.
1930s Ward and Kelly used ZOE for impressions.
1939 Trapozzano described one of the early techniques using Zinc oxide eugenol
paste.
1936 Alginate-type materials patent awarded.
10. 1940s Write and Denen were first to use alginate impression for corrective wash
procedures
1942- Pendleton suggested a fluid wax technique using asiatic or indian paraffin
for the final mandibular impression.
Pierson in 1955 reported on a new elastic material of a polysulfide base. (thiokol)
Shortly there after silicone base materials were introduced.
11. BASIC REQUIREMENTS FOR IMPRESSION MAKING:
Knowledge of Basic anatomy.
Knowledge of basic reliable technique.
Knowledge and understanding of impression
materials .
Skill.
Patient management.
12. In an impression technique for complete dentures, the procedures must strive for
five primary objectives:
1) Preservation
2) Support
3) Stability
4) Esthetics
5) Retention
OBJECTIVES OF IMPRESSION MAKING :
13. PRESERVATION
DeVan (1952) stated that, “the preservation of that which remains is of utmost
importance and not the meticulous replacement of that which has been lost”.
Impressions should record the details of the basal seat and peripheral structures in an
appropriate form to prevent injury to the oral tissues.
Pressure in the impression technique is reflected as pressure in the denture base and
results in soft tissue damage and bone resorption.
14. SUPPORT
It is the foundation area on which a dental prosthesis rests - GPT:9
Denture support is the resistance to vertical forces of mastication and to occlusal or
other forces in a direction towards the basal seat.
It is thus necessary, to enhance the available support by utilizing maximum coverage
of all usable ridge bearing areas.
15. -Acc to Bernard Levin
Areas of support:
Primary
Secondary
Slight
16. PRIMARY:
These are the areas of the edentulous ridge that are at right angles to
occlusal forces and usually do not resorb easily.
MAXILLARY:
Posterior ridges and flat areas of the palate.
MANDIBULAR:
Buccal shelf area , posterior ridges and pear-shaped pad.
17. SECONDARY:
Areas of the edentulous ridge that are greater than at right angles to occlusal
forces or are parallel to them; also the areas of the edentulous ridge that are at
right angles to occlusal forces but tend to resorb under load.
MAXILLARY:
Anterior alveolar ridge and all ridge slopes.
MANDIBULAR:
Anterior alveolar ridge and all ridge slopes.
18. SLIGHT:
Areas of very displacable tissues, that is ; all the vestibular areas that
provide very little support but are needed for the very important peripheral
seal.
19. Methods To Improve Support
Surgical removal of pendulous tissue.
Use of tissue conditioning materials.
Surgical reduction of sharp or spiny mandibular ridge.
Surgical enlargement of ridge.
Implants.
20. RETENTION
That quality inherent in the prosthesis which resists the force of gravity,
adhesiveness of foods and the forces associated with the opening of the jaws.
-GPT:9
It is the resistance to removal in a direction opposite to that of insertion
21. FACTORS AFFECTING RETENTION
PHYSICAL
• Adhesion
• Cohesion
• Interfacial surface
tension
• Capillary attraction or
capillarity
• Atmospheric pressure
• Gravity
PHYSIOLOGICAL
• Saliva & it’s quality
• Intimate tissue
contact
• Border seal
ANATOMICAL
• Size of the denture
bearing area
• Quality of the denture
bearing area.
PSYCHOLOGICAL
SURGICAL
MUSCULAR
MECHANICAL
• Undercuts
• Parallel walls
• Retentive springs
• Magnetic forces
• Suction chambers
and suction discs
• Denture adhesives
RETENTION
21
22. STABILITY
The quality of a complete or removable partial denture to be firm, steady, or
constant, to resist displacement by functional horizontal or rotational stresses.
Factors affecting stability:
Vertical height of the residual ridge
Quality of soft tissue covering the ridge
Occlusal plane
Quality of the impression
Teeth arrangement
Contour of the polished surfaces
23. ESTHETICS
The role of esthetics in impression making refers to the development of the labial and
buccal borders so that they are not only retentive but also support the lips and cheeks
properly
The vestibular fornix should be filled, but not overfilled, to restore facial contour.
Impression should perfectly reproduce the width
and height of the entire sulcus for the
proper fabrication of the flanges.
25. Based On Mode Of Setting Reaction & Elasticity
RIGID ELASTIC
SET BY CHEMICAL
REACTION
• Impression plaster
• ZOE paste
• Alginate
• Non aqueous
elastomers
SET BY TEMPERATURE
CHANGE
• Impression compound • Agar hydrocolloid
25
26. Based On Type Of Impression & Area Of Use
a) Dentulous
Primary - Alginate
Secondary - Elastomers & Agar
b) Edentulous
Primary - Impression compound
Impression plaster
Alginate
Secondary - ZOE impression paste
Elastomers
26
27. Based On The Amount Of Pressure Applied
a) Muco-compressive - Impression compound
b) Muco-static - Impression plaster
Based On The Manipulation
a) Hand mixing
i) Kneading
Impression compound - wet kneading
Putty consistency elastomers
ii) Circular motion (with glass slab & spatula)
ZOE impression paste
Polysulfide
iii) Vigorous mixing
Alginate (figure of 8 motion)
b) Mechanical mixing
27
28. Based On The Tray Used For Impression
a) Stock tray
i) Based on types of tray
Rim locked perforated - Alginate & Elastomers
Water cooled - Agar
Plastic - Alginate
ii) Based on type of perforation
Perforated - Alginate
Elastomers putty wash
Non perforated - Impression compound
b) Special tray
Base plate wax - ZOE impression paste
Resin - Medium body
28
29. Based On Viscosity At Constant Shear Rate &
Temperature (23oc)
VERY HIGH
VISCOCITY
HIGH
VISCOCITY
MEDIUM
VISCOCITY
LOW
VISCOCITY
• Putty
elastomers
• Impression
compound
• Regular
elastomers
• Impression
plaster
• ZOE
impression
paste
• Hydrocolloid
a) Irreversible
b) Reversible
• Light body
elastomers
29
30. Classification Based On Wettability
a) Readily wettable - hydrophilic
Irreversible hydrocolloid
Reversible hydrocolloid
Poly ether
b) Resistant to wetting - hydrophobic
Poly sulphide
Poly vinyl siloxane
Condensation silicone
30
31. THEORIES IN IMPRESSION MAKING
The techniques used for impression making can be described into 4 categories:
Amount of pressure used
Based on position of the mouth while making the impression
Based on method of manipulation
Type of tray
31
32. AMOUNT OF PRESSURE USED
Four basic impression philosophies proposed over years for impression making based on
pressure application are:
Mucostatic technique
Mucocompressive technique
Minimal-pressure technique
Selective pressure technique
32
33. MUCOSTATIC TECHNIQUE
1946 Page gave the concept of mucostatic based on Pascal’s law.
According to this concept, the mucosa being more than 80% water, will
react like liquid in a closed vessel & thus cannot be compressed
According to the principle of mucostatics, the impression material should
record every detail of the mucosa without distortion.
34. Demerits of the theory
The lack of border molding reduces effective peripheral seal.
The short flanges may reduce support for the face, prevent the wider distribution of
masticatory stresses, would mean less lateral stability.
Furthermore the form of mucostatic denture minimizes the retentive role of the
musculature.
35. MUCOCOMPRESSIVE TECHNIQUE
This theory was proposed on assumption that tissues recorded under functional
pressure provided better support and retention for the denture.
Greene in 1896 gave this concept
36. Demerits of the theory
Excess pressure could lead to increase alveolar bone resorption.
Dentures which fit well during mastication tend to rebound when the tissue resume
their normal resting state.
Pressure on sharp bony ridges results in pain.
37. MINIMAL-PRESSURE TECHNIQUE
Is a compromise between mucostatic and mucocompressive techniques.
In this technique, the minimal possible pressure, i.e., little more than the weight of
free-flowing material is applied during recording denture-bearing tissues.
Limitation: There is lack of standardized protocol regarding the amount of pressure
to be applied during impression.
37
38. SELECTIVE PRESSURE TECHNIQUE
Advocated by Boucher in 1950 it combines the principles of both pressure and
minimal pressure technique.
The non stress bearing areas are recorded with the least amount of pressure and the
selective pressure is applied to certain areas of the maxilla and mandible that are
capable of withstanding the forces of occlusion.
39. Demerits
Cannot be used in flabby ridges
Some believe that different pressures cannot be applied to different areas at the
same time
40. BASED ON POSITION OF THE MOUTH WHILE MAKING THE IMPRESSION
Closed mouth technique
Open mouth technique
40
41. CLOSED MOUTH TECHNIQUE
Record the tissues in their functional position.
The patient applies pressure by closing against occlusal rims or teeth that are attached
to the impression trays.
In this closed jaw relation, the patient exerts pressure and executes muscle actions such
as swallowing, grinning, or pursing the lips while the impression material flows.
Materials used in this technique are impression compound, waxes, soft liners.
41
42. ADVANTAGES
Interferences of tray handles and
operator’s finger is eliminated.
Time saving: border molding, final
impression, jaw relation can be
completed in one time.
DISADVANTAGES
Rebound of tissues leads to denture
displacement.
Tendency for over-extension or under-
extension.
A constant pressure is exerted over
tissues, hence blood supply is
compromised leading to ridge
resorption.
42
43. OPEN MOUTH TECHNIQUE
Made with a tray that is held by the dentist.
Record the tissues in their undisplaced position.
Preferred because the operator can see whether the border molding is done properly.
The various muscle movements can be accomplished some what more easily.
43
44. BASED ON METHOD OF MANIPULATION
HAND MANIPULATION
The contour of the denture borders may be obtained by the dentist with the use of
manipulation of lips and cheeks within functional limits.
Patient’s tongue movements record the lingual borders.
44
45. FUNCTIONAL MOVEMENTS
The denture borders are also formed by having the patient make functional or
physiological movement such as swallowing, grinning, or pursing the lips.
Trench's neuromuscular concept values the functions of sucking and swallowing
while making the impression to bring the denture base into harmony with the
physiological behavior of the muscles.
45
46. TYPE OF TRAY
Stock tray
Some prefer to use the stock tray and an impression material such as alginate,
impression plaster, or impression compound.
Custom tray
On casts made from these primary impressions, special /
custom trays are fabricated
46
47. SELECTION OF MAXILLARY STOCK TRAY
An edentulous stock tray that is approximately 5 mm larger than the outside surface
of the residual ridge should be selected.
Place the tray - by centering the labial notch of the tray over the labial frenum.
The posterior extent of the tray relative to the posterior palatal seal area should be
maintained.
The handle should be dropped downward to permit
visual inspection.
Posteriorly – cover the hamular notches and vibrating line.
47
48. Areas of under extension need to be corrected with soft boxing wax before the
impression is made.
A common site for under extension is around the tuberosities and into the buccal
vestibules.
In addition, soft boxing wax can be used to line the entire border of the stock tray to
create a rim that helps adapt the borders of the tray to the limiting tissues.
The objective is to obtain a preliminary impression
that is slightly overextended around the borders.
48
49. SELECTION OF MANDIBULAR STOCK TRAY
Posteriorly the tray should cover the retromolar pad.
Anteriorly should be centralized with labial frenum with adequate clearance.
Common sites for under extensions are:–
Retromolar pads
Retromylohyoid fossae.
49
55. PRIMARY IMPRESSION MAKING IN MANDIBULAR ARCH
Choice of material - impression compound / high viscosity alginate.
Astringent mouthwash given to reduce the viscosity of the saliva.
55
57. PRELIMINARY/PRIMARY CAST
After making the preliminary impression, the preliminary casts are poured with
model plaster, irrespective of the impression material used.
To remove compound impressions, the cast with tray is immersed in warm slurry
water at 65°C for 5 minutes. The impression is then easily separated once the
material softens.
57
58. CASTS FOR ACRYLIC RESIN IMPRESSION TRAYS
To make an outline one must know how to interpret the anatomic
landmarks on the cast.
MAXILLARY CAST
58
60. CUSTOM TRAY
Construction of the custom tray
Baseplate wax, approx. 1 mm thick, is placed on the
primary cast within the outlined border to provide
space in the tray for the final impression material.
The posterior palatal seal area on the cast is not
covered with the wax spacer.
A wax spacer will not be used if a metallic oxide
impression paste has been selected for making the final
impression.
The custom tray should be 2 to 3 mm thick, with a
stepped handle in the anterior region of the tray.
60
61. Refining the custom tray:
When the custom tray is removed from the preliminary cast, the wax spacer is left
inside the tray.
The spacer allows the tray to be properly positioned in the mouth during border
molding procedures.
For border molding to be carried out successfully, space must be created for the
border molding material.
Therefore the flanges of the custom tray should be reduced until they are 2 mm
short of the reflections.
The tray must contain both hamular notches and extend approximately 2 mm
posterior to the vibrating line.
61
62. THE CLASSIFICATION OF SPACER DESIGNS
1. FULL SPACERS: It is made to cover the whole residual ridge except PPS area in maxilla
and buccal shelf and retromylohyoid area in the mandible. Thus, providing space for
impression material.
2. PARTIAL SPACERS: Based on clinical needs. It is made to cover specific areas only.
Like the T shape and I Shaped Spacer.
3. SPACERS WITH TISSUE STOPPERS: Tissue stoppers/ windows are made bilaterally
at the canine and the molar region mostly 2mm in width. They help in proper vertical
seating of the impression tray and control the thickness of the impression material.
R Jain, A., & Dhanraj, M. (2016). A Clinical Review of Spacer Design for Conventional Complete Denture.
Biology and Medicine, 8(5).
62
63. MATERIALS USED FOR MAKING SPACERS
Tin foil: as recommended
by Roy mac Gregory in the
region of incisive papilla
and mid -palatine raphe.
Casting wax: as
recommended by Neil. In
thickness of 0.9mm to be
adapted all over except
PPS area.
Base-plate wax: used as a
spacer mostly when
acrylic resin is used for
custom tray fabrication.
64. THICKNESS OF THE WAX SPACER
i) 2 mm spacer with tissue stops and 0.5 mm spacer: used when impression plaster or
zinc oxide eugenol is being used for making impression in cases of non undercut ridges.
ii) 3 mm spacer with tissue stops: used with alginate for non undercut and undercut
ridges.
iii) 1.5 mm spacer with tissue stops: used with polysulphide elastomeric impression
material for undercut or non undercut ridges.
iv) 3mm spacer: used with silicones for undercut and non undercut ridges.
v) miscellaneous: in cases of different clinical situations and demands the spacer
thickness and design varies. Like for displaceable tissues.
64
65. TISSUE STOPS
They provide even thickness of the impression materials in the custom tray.
Tissue stops are made by removing wax at a 45 degree angle to the occlusal surface
which will have a tripod or quadrangular arrangement on the arch.
This provides stability to the tray and will help center the tray during insertion.
65
67. BOUCHER’S:
Based on selective-pressure technique the placement of 1 mm base-plate wax on
the entire basal seat area except PPS area.
According to him, PPS will act as guiding stop to position the tray properly
during impression procedures.
1 mm thick base-plate wax covers mandibular ridge except buccal shelf area and
retromolar pad.
He says a wax spacer must not be used in cases when metallic oxide impression
paste has been selected for making final impressions.
67
68. MORROW, RUDD, AND RHOADS:
Based on minimal-pressure technique, recommend blocking out undercut areas with
wax and then adapting a full wax spacer 2 mm short of the resin special tray border
all over.
Then they recommend placement of three tissue stops (4˟4mm) equidistant from
each other.
68
69. J. J. SHARRY’S:
Based on minimal-pressure technique, recommends adaptation of a layer of base-
plate wax over the whole area outlined for tray (even in PPS area).
He recommends the placement of four tissue stops (2 mm in width located in molar
and cuspid regions which should extend from palatal aspect of the ridge to the
mucobuccal fold) and one vent hole in the incisive papilla region before making the
final impression with the metallic oxide impression material.
69
70. BERNARD:
Based on selective pressure technique, recommends a layer of pink base-plate wax
(about 2 mm thick) attached to the areas of the cast that usually have the areas of
softer tissues.
He recommends the placement of wax spacer all around, except the posterior part of
the palate, which according to him are at high angles to the occlusal forces.
Not employed as midpalatine raphe, not relieved, and exposed palatal area acts as a
stopper.
70
71. HALPERIN:
Recommended the “custom tray” with peripheral relief.
He suggested the custom trays be provided with 1 mm thick wax relief over the peripheral
extensions and buccal slope regions of tray including PPS region and that the custom tray
be in intimate contact with basal seat areas.
This provides the internal finish line that forms a butt joint of the compound to the tray after
border molding is completed.
No secondary wash impression is needed as tray surface and border-molded areas acts as
final impression surface.
A master cast is directly poured into border molded trays without using wash impression.
71
72. ROY MAC GREGOR’S:
Based on selective pressure technique, recommends placement of a sheet of metal
foil in the region of incisive papilla and midpalatine raphe.
He also says that the other areas that may require relief are maxillary rugae, areas of
mucosal damage, and buccal surface of the prominent tuberosities.
Finally, he concludes that the relief should not be used routinely in the dentures.
72
74. HEARTWELL:
Mentions two techniques for achieving selective pressure for maxillary impressions.
In the first technique, he makes the primary impression with impression compound
in a nonperforated stock tray; the borders are refined.
Later, space is provided in selected areas by scraping of the impression compound.
In the second technique, he recommends the fabrication of a custom tray.
Border molding is done with low fusing compound.
He recommends the placement of five relief holes on the palatal region (three in the
rugae area and two in the glandular region) before making the secondary impression
with zinc oxide eugenol (ZOE) paste.
74
75. SHELDON:
Describes two techniques:
In the first technique, the primary impression is made with low-fusing modelling
compound (kerr white cake compound).
The borders are refined with kerr green stick compound. Once the operator is
satisfied with the retention, selective relief is accomplished by scraping in the region
of incisive papilla, rugae, and mid palatal areas.
75
76. In the second technique, he describes of making an alginate primary impression.
A primary cast is poured. After analysis of cast contours, undercuts are blocked out.
Later, he recommends the placement of spacer or pressure control.
Border molding is done with green stick compound before making the secondary
impression with ZOE paste based on selective-pressure technique used on high
arched palate.
76
77. SHETTY:
Described a technique in which a thin sheet of wax (0.4 mm major connector wax)
is required to be placed in all areas except the PPS area, as this area needs to be
compressed during the border-molding procedures.
A 1.5 mm thick layer of modelling wax is applied on top of the already adapted wax
sheet.
The modelling wax is removed in the region of the crest of the alveolar ridge and the
horizontal palate, as these are stress-bearing areas.
77
78. DALE E. SMITH’S DESIGN:
1 mm thick base-plate wax covers the ridge and midpalatine raphe.
Two tissue stops, each at the canine region and exposed hard palate, help in proper
vertical seating of the tray and control the thickness of impression material.
78
79. OTHER DESIGNS:
Miscellaneous design for maxillary arch:
Based on minimal-pressure technique, a 1 mm base-plate wax is placed over the
basal area except right and left posterior hard palate.
Four tissue stoppers, each at canine and molar regions and the exposed areas act as
stoppers.
79
80. Miscellaneous design for mandibular arch:
Based on selective-pressure technique, a 1 mm thick base-plate wax is placed over
the entire alveolar ridge except at the retromolar pad area.
Tissue stops are placed, each at canine region, bilaterally.
Full coverage with tissue stops provides uniform thickness of impression material.
The exposed retromolar pad acts as the stress-bearing area.
80
81. SPACER DESIGN FOR UNDESIRABLE CLINICAL SITUATION
Partial spacers covers the specific tissues.
I-spacer:
In maxillary arch, based on selective-pressure technique, covers the incisive papilla
and midpalatine raphe when it is prominent.
81
82. T-spacer:
Covers the anterior residual alveolar ridge in maxilla when it is resorbed and flabby.
It is based on selective-pressure technique.
It also covers the prominent incisive papilla, rugae and midpalatine raphe, and the
exposed areas act as stoppers.
Partial spacer designs in the mandible cover only the anterior residual alveolar ridge
when it is atrophic, resorbed, or flabby.
82
83. CONTRAINDICATION FOR SPACER:
In cases of highly resorbed ridges, spacer is not used as a solid tray is easier to
manage.
In such cases, carbide bur can be used to remove about 1 mm of the custom tray
material from the crest of ridge area.
R Jain, A., & Dhanraj, M. (2016). A Clinical Review of Spacer Design for
Conventional Complete Denture. Biology and Medicine, 8(5).
83
84. Checking the custom trays intraorally
Before border molding, the custom tray is placed in the mouth and checked for the
following and trimmed, if necessary:
The borders of the trays should be 2 mm short of the sulcus and should provide
adequate clearance for the frenum.
The posterior extension of the maxillary tray should cover the hamular notch and
extend up to the posterior vibrating line.
The mandibular tray should cover the retromolar pads posteriorly.
If a spacer is placed, it should be removed only after border molding.
84
86. SECONDARY IMPRESSION MAKING
It includes:
Border molding
Tray preparation after border molding
Making the wash impression
Recording the posterior palatal seal
Checking for errors in the posterior palatal seal
86
87. BORDER MOLDING (PERIPHERAL TRACING)
Border molding: Is the shaping of an impression material along the border
areas of an impression tray by functional or manual manipulation of the soft
tissue adjacent to the borders to duplicate the contour and size of the vestibule.
Two techniques for border molding:
1. Single step or simultaneous border molding
2. Incremental or sectional border molding
87
88. SINGLE STEP BORDER MOLDING:
In this method, the entire periphery of the tray is refined in a single step.
The border molding material is placed around the entire border in a single step
and molded similar to sectional technique all at once.
Putty or heavy body elastomeric impression materials are ideal for this method.
88
89. INCREMENTAL BORDER MOLDING:
In this method, sections of the periphery of the tray are refined individually,
according to the anatomic landmark in that area.
The material of choice for this procedure is greenstick compound (low fusing
impression compound).
Putty or heavy body elastomeric impression materials can also be used.
89
90. There are two methods of manipulating the peripheral tissues to mold them:
1. Active method: the patient performs various functions related to the concerned
areas to manipulate the borders.
2. Passive method: the dentist physically manipulates the tissues to mold them.
3. Either of these methods or a combination of both is used to mold the borders.
90
96. TRAY PREPARATION AFTER BORDER MOULDING
The wax spacer is removed to provide space for the impression material.
The material over the posterior palatal seal is not removed.
Green stick compound removed using a scalpel.
The thickness of the flanges & the border should be 2.5-3mm.
Vent holes are drilled into the impression tray to allow escapement of the
impression material.
96
97. ESCAPE/VENT HOLES
After removing wax spacer from inside of the tray, a series of holes are prepared, about
12.5 mm apart in the center of alveolar groove and in the retro molar fossa with no. 6
round bur.
The relief holes provide escape way for the final wash impression material and relieve
pressure over crest of the residual ridge and in the retro molar pads when the final
impression is made.
97
98. MAKING FINAL IMPRESSION OF MANDIBLE
Final impression of choice is mixed according to the manufacturer’s instruction
and evenly distributed within the tray and covering the borders also.
The tray is rotated into the mouth in the horizontal plane with the anterior handle
until it is over residual ridge.
98
99. At this time, the patient is asked to raise the tongue slightly, and the tray is
moved downward its final position.
The operator’s index fingers of each hand are placed on top of the posterior
handles and with altering gentle pressure, the tray is seated until the buccal
flanges come into contact with the mucosa covering the buccal shelf.
99
100. The tongue must be kept forward touching the upper lip, while the impression
material sets.
When the material is set, the tray is removed and inspected.
If it needs to be remade, it is carefully removed with care to preserve the border
molding.
100
101. MAKING FINAL IMPRESSION OF MAXILLA
Material of choice – zinc oxide eugenol impression paste.
Impression material is manipulated & loaded onto the tray. The patient made to sit in
an upright position. Operator stands towards the rear or the side of the patient.
Tray is placed in the patients mouth using the labial notch as a guide.
101
102. Tray is seated into position by applying alternating pressures on the right & left
molar regions using index fingers.
Tray is maintained in this position by placing a finger in the palatal region of the
tray, immediately anterior to the posterior palatal seal.
Passive movements are made.
After material has set, the tray is removed in a single jerk.
Impression inspected for deficiencies & voids and is repeated if necessary.
102
103. POSSIBLE ERRORS WHICH LEAD TO REMAKING THE IMPRESSION
A thick lingual border on one side with a thin lingual border on the opposite side.
This indicates that the lower tray was out of position in the direction of the thin
border.
A thin anterior lingual border with the tray showing on the inside surface of the
lingual flange. This suggests that the lower tray was too far forward in relation to the
residual ridge. This will be accompanied by a thick labial border.
103
104. OTHER REASONS
Voids or discrepancies that are too large to be corrected accurately.
Incorrect consistency of the final impression material when the tray was positioned in
the mouth.
Movement of the tray while final impression was setting.
Incorrect border molding procedures.
Use of either too much or too little material.
104
105. The different material used for final impression are:
Impression plaster (rarely used)
Zinc oxide eugenol paste – 2mm
Reversible hydrocolloids – 6mm
Elastomeric impression materials – 4mm, 2mm
Mouth temperature waxes
105
106. CONCLUSION
The main objective of impression making is to construct dentures, having maximum
retention and stability, without causing any damage to the supporting structures.
A good impression often favorably impresses and relieves the anxieties of the
patient.
Thus it is the responsibility of the dentist, to select the best possible procedure,
based on sound knowledge, for achieving, the best possible results for the patient.
106
107. REFERENCES
Zarb. Bolender, Prosthodontic treatment for edentulous patients, 12th Edition.
Boucher’s Prosthodontic treatment for edentulous patients, 9th Edition.
Sheldon Winkler, Essentials of complete denture prosthodontics, 2nd Edition.
Charles M. Heartwell, Textbook of complete dentures, 5th Edition.
Kenneth J. Anusavice, Phillips’ science of dental materials, 11th Edition.
Robert G. Craig, Restorative dental materials, 11th Edition.
R jain, A., & Dhanraj, M. (2016). A clinical review of spacer design for conventional
complete denture. Biology and medicine, 8(5).
Singla s. Complete denture impression techniques: evidence-based or philosophical.
Indian J dent res 2007;18:124-7.
107
108. Posterior palatal seal area
Impressions in compromised conditions
Disinfection of the impressions
Position of the patient and the operator while making impressions
Review of literature
110. Q: What are the basic objectives of impression
making?
a) Preservation of the alveolar ridge
b) Retention
c) Stability
d) Support
e) Esthetics
110
111. Q: Oral tissues are best recorded in functional state
by---------impression technique?
Selective pressure technique
111
112. Q: What is the purpose of shortening the borders of
the secondary impression tray (in complete denture
construction)?
To perfect the borders of the tray on the patient.
Softened compound is added to the tray to capture the
mucobuccal and mucolingual folds.
112
113. Q: Most common reason to repeat impression is?
a) Improper positioning of tray
b) Too less or excess material
c) Voids that are irreparable
d) Improper mixing
113
114. Q: What is the purpose of tissue stops?
The tissue stops in the custom trays prevents the
apical displacement of the tray while making the final
impression and helps to reseat the custom tray during
the final impression.
114
115. Q: While taking final impression tray should be
seated first?
a) Anteriorly
b) Posteriorly
c) Anteriorly and posteriorly simultaneously
115
116.
117. Boucher’s Prosthodontic treatment for edentulous patients, 9th Edition.
Sheldon Winkler, Essentials of complete denture prosthodontics, 2nd Edition.
Charles M. Heartwell, Textbook of complete dentures, 5th Edition.
Mushtaq MA, Khan MWU., An overview of dental impression disinfection techniques-a
literature review., J Pak Dent Assoc 2018;27(4):207-12.
Bhandari A et al., Int J Dent Health Sci 2015;2(5):1261-1267.
Mariyam, A., Saurabh, C., Verma, A., Naeem, A., & Anuj, S. Posterior Palatal Seal
(PPS): A brief review., Journal of Scientific and Innovative Research 2014;3(6):602-605.
118. D. krishna & mehra, divya & prasad d. anupama. Prosthodontic management of
compromised ridges and situations. Nitte university journal of health sciences
2014;(4):141-8.
Prasad d. anupama & d. Krishna & hedge. chethan. Prosthodontic rehabilitation of a
patient with oral submucous fibrosis and microstomia: a case report. Journal of health
and allied sciences 2012;(02):68-71.
Jain. vaibhav & Prakash. poonam & R. vijay & udayshankar. vishvnathe. Impressing
for excellence: special impression techniques for compromised ridges: case report.
International journal of contemporary medical research [IJCMR] 2019;(6):18-21.
Rashid H, vohra FA, haidry TZ, karmani GD. Stabilizing mandibular complete
dentures using the neutral zone impression technique. J pak dent assoc 2013;22(2):154-
159.
Editor's Notes
Impression making consumes a significant portion of the dentist's time during denture construction. Therefore a good impression will help to insure that complete denture is stable, retentive and comfortable. So, the knowledge of different impression techniques are very important for us to achieve a good impression
A negative likeness or copy in reverse of the surface of an object; an imprint of the teeth and adjacent structures for use in dentistry ’
He used wax for the preliminary impression followed by a plaster of paris as wash impression.
Hall used a specially prepared hard black modeling plastic for making a custom tray in which a very thin mix of impression plaster was placed for correction.
Acc to Levin B
Knowledge of Basic anatomy.
Knowledge of basic reliable technique.
Knowledge and understanding of impression materials .
Skill.
Patient management.
M. M. De Van’s dictum, “It is more important to preserve what already exists than to replace what is missing” has never been challenged or disapproved.
Preservation of the remaining residual ridges is one objective. – It is physiologically accepted that with the loss of stimulation of the natural teeth the alveolar ridge will atrophy or resorb. This process varies in individual
This process can be hastened or retarded by local factors. – Pressure in the impression technique is reflected as pressure in the denture base and results in soft tissue damage and bone resorption.
Hence, in impression making, this rule is followed by not using heavy pressure and by not covering as much of the supporting areas as possible to minimize the possibility of the soft tissue abuse and bone resorption. – Bernard Levin
Other factors such as
• Occlusion
• Interocclusal distance
• Centric relation in harmony with centric occlusion are of great importance.
Denture support is the resistance to vertical forces of mastication and to occlusal or other forces applied in a direction towards the basal seat. – Bernard Levin
When the natural teeth are missing, the alveolar ridge and their coverage of mucosal tissues become the supporting elements. , it is necessary to enhance the available support by utilizing maximum coverage of all usable ridge bearing areas
Maximum coverage provides the “snowshoe” effect, which distributes applied forces over as wide an area as possible. – This helps in preservation, stability and retention
Areas of support • Divided into » Primary » Secondary » Slight – Bernard Levin,
Primary support • Areas of edentulous ridge that are at right angles to occlusal forces do not resorb easily. • Maxillary:- Posterior ridges and flat areas of the palate. – Bernard Levin
Mandibular:- Buccal shelf area, posterior ridges and the pear shaped pad. The pear shaped pad is sometimes soft and can be a poor area of support but must be covered so the important retromylohyoid flange is complete and the buccal shelf is covered. – Bernard Levin
Secondary support : Areas of the edentulous ridge that are greater than at right angles to occlusal forces or are parallel to them; also the areas of the edentulous ridge that are at right angles to occlusal forces tend to resorb under load. • For example, the anterior ridge is known to resorb at a much faster rate than the posterior ridge areas where it is subjected to load. – Bernard Levin
Maxillary:- anterior ridge and all ridge slopes • Mandibular:- anterior ridge and all ridge slopes. – Bernard Levin
Slight – Areas of very displaceable tissues, i.e, all the vestibular areas that provide very little support but are needed for the the very important peripheral seal. – Bernard Levin
Since support is important it should be improved whenever possible. There are five basic methods.
If the ridge is wide 10 mm r more surgery can be considered if it is narrow 8mm r less surgery is contraindicated.
Retention increases with increase in size of denture bearing area.The size of maxillary denture bearing area is about 24 sqcm and that of mandible is about 14 sqcm
Tissues displaced during impression making will lead to tissue rebound during denture use, leading to loss of retention.
Muscular factors:
The muscles apply supplementary retentive forces on the denture.
It is most effective in the neutral zone.
The factors that affect retention are:
Adhesion
Cohesion
Interfacial surface tension
Mechanical locking into undercuts
Peripheral seal and atmospheric pressure
Oral and facial musculature
The stability of a denture is its ability to remain securely in place when it is subjected to horizontal movements. – The latter occurs during the functional forces of chewing, talking, singing, whistling, kissing, etc – all the orofacial activities needed for normal everyday living. – Bernard Levin
To be stable, a denture requires
• Good retention
• Noninterferening occlusion
• Proper tooth arrangement
• Proper form and contour of the polished surface
• Proper orientation of the occlusal plane
• Good control and coordination of the patient’s musculature
Occlusion : No matter how skillfully the impressions were made, the dentures will eventually loosen and cause irritation if there are interfering occlusal contacts
A common occurrence is an interfering contact in the second area that may cause the mandibular denture to rotate upward and forward
Occlussal plane : Ideally the occlusal plane is parallel to and anatomically oriented to the ridges.
• If the occlusal plane is tipped, there will be a shunting effect and a loss of stability.
Border thickness should be varied with the needs of each patient in accordance with the extent of residual ridge loss.
The vestibular fornices (fornix vestibuli superi-oris and inferioris) form the superior and inferior margins of the oral vestibule, where the mucosa of the cheeks and lips reflect back onto the alveolar mucosa. The furrow formed by the vestibular fornices is also known as the vestibular sulcus.
Four basic impression philosophies proposed over years for impression making based on pressure application are: mucostatic, mucocompressive, minimal pressure, and selective-pressure impressions
The Mucostatic principle concerned the Pascal’s law, which stated that pressure on a confined liquid will be transmitted throughout the liquid in all directions.
so that the complete denture would fit all minute elevations and depressions.
Impression is made with oversized tray with spacer. Border moulding is not performed hence flanges r shorter dan other techniques impression material of choice fr dis technique is impression plaster
Suited for sharp, thin, flat & flabby ridges
Because denture retention is tested most severely during mastication, many dentists formerly considered it essential for the tissues to remain in contact with the denture during chewing
Many of the proponents of pressure impressions advocate the use of de closed mouth technique.
It advocates application of minimal possible pressure which is supposed to be little more than the weight of free flowing material.
But the questionable part is, "How to decide this minimal pressure clinically?"
Limitation of this technique is that there is lack of standardized protocol regarding the amount of pressure to be applied during impression.
Forming an impression by neuromuscular concept develops a completely passive contact of all impression borders to the basal seat tissues, passively fills all marginal spaces and develops basal seat area coverage that is compatible with function.
The beginning of the good impression staSpace available in the mouth for the upper impression is studied carefully by observation of the width and height of the vestibular spaces with the mouth partway open and the upper lip held slightly outward and downward.
rts with the selection of the correct stock tray
Primary impressions r made with stock trays
Such impressions are generally overextended and serve as primary impressions
Custom tray
The tray is tried in the mouth and modified and the final impressions are made using zinc oxide eugenol or elastomeric impression materials and others.
Imp material with high viscosity preferred allowing the material to compensate for any deficiencies in the tray.
Because of their high viscosities, however, these impression materials will often displace the soft tissues of the vestibules, resulting in an overextended impression and resulting cast.
Impression compound softened in water bath at 140º F, then it should be kneaded to achieve uniform consistency without wrinkles or folds (it should not be used where the ridge is displaceable, fluid alginate or impression plaster are preferable).
It is formed into a suitable size ball and placed over the center of the tray.
The compound is molded and spread to fill the tray in order to develop a trough to accommodate the ridge crest. This is best accomplished by molding the compound with both thumbs holding the tray from the rear end.
For insertion, the tray should be held with the handle in the operator’s right hand pointing towards the patient’s right. The operator uses index and middle finger of left hand to retract the upper lip and tray is rotated into the mouth.
The labial frenum is used as a guide to center the tray.
The patient is instructed to slightly close the mouth, while the upper lip is lifted upwards and forwards.
Seat the tray anteriorly such that the alveolar process presses the compound and excess flows into the labial sulcus.Then Seat the tray posteriorly until the impression contacts the ridge.
Apply an upward and backward force with index finger of each hand placed under the tray until the material flows into the vestibule and posteriorly.
Borders are refined by asking the pt. to suck down into the tray, move the mandible side to side & then open wide. This record the labial & buccal vestibules & influence of coronoid process on the shape of the buccal vestibules.
Once the material has set, the cheeks & upper lip are lifted away from the borders to allow for air entry. Tray is then removed from the mouth in one motion & inspected for any deficiency.
The tray should be extended if needed with modeling or boxing wax. Wax can also be added to the vault area of the tray in case of high palatal vaults.
A clearance of 2-3 mm is sufficient for alginates.
The posterior palatal seal area is wiped with gauze to remove any excess saliva.The powder and liquid are mixed to a slightly thicker consistency and loaded onto a perforated stock tray up to the border.
A small quantity is placed on the palatal vault and buccal vestibule.
Tray is inserted as described for impression compound and as the material sets, the patient is instructed to keep eyes open, relax, breath through the nose and bend the head down a little to prevent impression from running down the throat.
Tray should be held in the mouth.
Labial and buccal borders should be molded.
All elastic impressions should be removed in a snap. It is rinsed in tap water, dried and then evaluated for any deficiencies.
The impression must be remade if any deficiencies exist.
It should be poured immediately.
Compound is placed in hot water (60°C) and is kneaded to achieve uniform consistency without wrinkles or folds.• It is formed into a suitable size roll (1.5 cm in diameter) and placed in the tray with enough bulk extending beyond the flanges such that there is no restriction in flow when pressed over the ridge.• A trough is indented in the compound with a finger to receive the crest of the alveolar ridge. It should be deeper posteriorly and shallow anteriorly and molding should begin from the midline and proceed distally.
It is again placed in hot water, tempered and inserted in the patient’s mouth.
For insertion, the tray is first placed in the left side of the mouth at right angles to the final position, and then rotated in a clockwise manner to engage the right side after retracting the angle of the mouth on that side.• Once the tray is in position, the patient is instructed to slightly close the mouth and raise the tongue, while vertical pressure is applied on the tray in the molar region.• The cheeks are stretched to ensure that they are not trapped in the tray.• Labial and buccal flanges are border molded and patient is asked to move the tongue from side to side and then protrude it slightly.
As the room temperature may be less than intraorally, the material sets from the tray towards the tissues.
Due to poor thermal conductivity, it will take longer time for the material in contact with the tissues to set as compared to those outside of tray.
Sufficient time should be given after the external material sets to remove the tray, thereby, preventing distortion.
To remove the tray, the patient is asked to close the mouth partially, cheeks are retracted to break the seal, the handle of the tray is held between the thumb and index and the middle fingers of the right hand, and an upward and backward force is applied.
The impression is evaluated for extension, reproduction of anatomical landmarks, tray exposure and wrinkles or voids.
Alginate requires support from the tray because of its poor tear-resistance. The tray should be extended if needed with modelling or boxing wax.
A clearance of 2-3mm is sufficient for alginates.
The powder and liquid are mixed to a slightly thicker consistency and loaded onto a perforated stock tray up to the border.
A small quantity is placed on the retromylohyoid area and labial vestibules to displace any air pockets and the impression is made.
Tray is inserted and removed as described for impression compound.
All elastic impressions should be removed in a snap.
It is then rinsed in tap water, dried and evaluated for any deficiencies. The impression must be remade if any deficiencies exist.
It should be poured immediately.
On the primary cast outline should be drawn to make the custom tray.
With an indelible pencil, draw a line transversely across the posterior border connecting the two hamular notches, Points A, in such a manner that the connecting line passes just posterior to the fovea palatinus. Point B. (Note: This is not a straight line, but one that follows the hard palate.)
Draw a line outlining the mucobuccal fold at the point where the buccal reflection leaves the lateral wall of the alveolar ridge. Carry the outline well above the frenum attachments, Points C.
All trays are subject to refinement in the mouth when tissue is displaced by the borders. Displacement should be checked in the patient’s mouth prior to making the border refining impression.
1. With an indelible pencil, draw a line distal to the retromolar pad, Points A. Continue this line buccally in an inferior and anterior direction following the masseter groove to the beginning of the external oblique ridge, Points B.
2. Progressing anteriorly, follow the oblique ridge to the buccal frenum attachment.
3. Carry outline well above the frenum attachment and end at the buccal frenum, Points C.
4. Connect Point C with Point C on the opposite side, following the mucolabial reflection and allowing space for the labial frenum attachment, Point D.
5. On the lingual border area drop a line inferiorly from Point A to the lingual tuberosity. Point E.
6. From Points E extend line anteriorly and inferiorly to the mylohyoid ridge but 2 or 3 mm short of the mucous membrane floor of the mouth reflection to a point opposite the cuspid eminence. Points F.
7. Connect Point F with Point F on the opposite side, following the sublingual mucous membrane reflection and allowing space for the lingual frenum attachment. Point G
Therefore the completed custom tray will contact the mucous membrane across the posterior palatal border, and additional stress placed here during the making of the final impression will help achieve a posterior border seal.
In addition, this part of the tray will act as a guiding stop to help position the tray properly during the impression procedure.
The custom tray should be 2 to 3 mm thick, with a stepped handle in the anterior region of the tray to facilitate removal from the mouth.
Materials used for spacer
1. Tin foil: as recommended by Roy mac Gregory in the region of incisive papilla and mid -palatine raphe.
2. Casting wax: as recommended by Neil. In thickness of 0.9mm to be adapted all over except PPS area.
3. Nonasbestos ring liner (wet): used shellac is used for custom tray fabrication.
4. Base-plate wax: used as a spacer mostly when acrylic resin is used for custom tray fabrication.
A spacer for completely or partially edentulous cases are generally 1-3mm thick.
But the thickness depends on the type of impression material used for making secondary impressions and the demand of the clinical situation.
Are to be placed strategically.
He advocates the placement of a 1mm thick baseplate wax within the outlined border on the cast to provide space for the final impression. He suggests not to cover the posterior palatal Seal Area with the wax spacer so that the custom tray touches the mucosa directly and the additional stress placed here during impression making would create a posterior palatal seal. Also this part of the tray will act as a guiding stop to help position the tray properly during impression procedures. In the mandible 1 mm thick base-plate wax covers the mandibular ridge except buccal shelf area and retromolar pad area.1 He has also advocated the placement of Escape holes in the palatal area using 6mm round burs
It is based on the Minimal Pressure Technique. Firstly beginning with marking an outline on the cast where the borders are usually shorter than the vestibular depth, and the posterior border is marked as a line extending between the two hamular notches with a midpoint 2mm distal to the fovea palatina, The undercuts are then blocked with wax and a layer of baseplate wax is adapted to the cast for relief (2mm short of the resin custom tray borders) With the placement of 3 tissue stops, 4mm equidistant from each other.
It is also based on the Minimal Pressure Technique and advocates the adaptation of a layer of baseplate wax even on the PPS area and giving 4 tissue stops in the molar and cuspid regions 2mm in width running from the palatal aspect of the ridge to the muccobuccal fold. Also placing a vent hole in the incisive papilla region. To be used while taking Final impressions from metallic oxide impression materials.
On the Selective Pressure Technique, he recommends placing a layer of pink base plate wax on the areas of soft tissue. And making the spacer all around except on the posterior part of the palate which are at high angles to the occlusal forces and also not on the midpalatine raphe which is usually relieved in other designs but he says exposed palatal area acts as a stopper.
He recommends making a custom tray by giving Peripheral relief by providing 1 mm thick wax relief over the peripheral extensions and buccal slope region of tray including PPS and that the custom tray be in intimate contact with basal seat areas. Which makes the internal finish lines to form a butt joint of the compound to the tray after border molding is completed. No secondary wash impression is needed. As the tray surface and border-molded areas acts as final impression surface itself. Thus a master cast is directly poured into border molded trays.
It is based on the selective pressure technique. Recommends placement of a sheet of metal foil in the region of incisive papilla and midpalatine raphe. He says that the other areas which must be relieved are the maxillary rugae, other areas which are subject to mucosal damage, buccal surface of the prominent tuberosities. But he says that relief need not be given routinely in the dentures.
Neill recommends the adaptation of 0.9 mm casting wax all over except PPS area.
Has recommended the use of two techniques to achieve selective pressure for the maxilla.
In the first he says to make a primary impression with impression compound in a nonperforated stock tray; the borders are refined. Then, space is provided in selected areas by scraping of the impression compound.
In the second technique, he recommends the fabrication of a custom tray (but did not mention about the wax spacer). Border molding is done with low fusing compound. He recommends the placement of five relief holes on the palatal region,three in the rugae area and two in the glandular region, before making the secondary impression with zinc oxide eugenol paste.
Also describes two techniques. First involving the use of low-fusing modelling compound (Kerr white cake compound) to make the primary impression and borders are refined with Kerr green stick compound. Once the operator is satisfied with the retention, selective relief is accomplished by scraping in the region of incisive papilla, rugae, and mid palatine area.
While in the second technique, he describes of making a primary impression with alginate. Undercuts are blocked out. Then, he recommends the placement of spacer or pressure control. Border molding is done with green stick compound before making the secondary impression with ZOE paste, based on selective-pressure technique used on high arched palate.
SHETTY: Described a technique in which a thin wax of 0.4mm major connector wax (Germany) is to be placed in all areas except the PPS as this area needs to be compressed during the border-molding procedures. Then a 1.5 mm thick layer of modelling wax is applied on top of the already adapted wax sheet. The modelling wax is removed in the region of the crest of the alveolar ridge and the horizontal palates as these are the stress-bearing areas.
According to his design a 1 mm thick base-plate wax covers the ridge and midpalatine raphe then two tissue stops are placed at the canine region and exposed hard palate, which will help in the vertical seating of the tray and will also control the thickness of impression material.
There is no absolute contraindication as such, but in cases of highly resorbed ridges, spacer is not used as a solid tray is easier to manage. In such cases, carbide bur can be used to remove about 1 mm of the custom tray material from the crest of ridge area.
First heat the modelling compound over a flame. Slowly soften the very end of the compound.
Dry the tray, then add the compound to the distobuccal area.
Temper the compound in the water bath temp. should be 110oc. The temperature varies depending on the type of the compound used.
Insert the tray with compound being careful to retract the cheek with a mouth mirror or index finger.
This area is molded by pulling the cheek outwards, downwards and inwards.
Patient is asked to open the mouth wide, close and move the mandible from side to side.
Opening the mouth wide delineates the depth and width of the distobuccal flange as governed by the muscle attachments, while moving the mandible from side to side, accommodates for the movement of the coronoid process.
Trim away the compound that has flowed into the inner surface of the tray. Failure to do so will result in an impression that displaces tissues inappropriately.
Then add the compound in the buccal frenum area.
This may be performed unilaterally.
The cheek is elevated and pulled outwards, downwards and inwards and moved backwards and forwards.
Patient is asked to pucker the lips and smile.
Then record the labial frenum by adding the compound.
The lips are elevated and then extended outwards, downwards, and inwards.
patient is asked to pucker the lips and suck on the dentist’s finger.
Finally record the posterior palatal seal area. Observe line with patient saying ‘ah’ and trim compound to this line or area. Palpate the displacement bilaterally onto the displaceable tissues that border the hard palate and soft palate junction and place compound in a butterfly-shape border seal.
Tray should be seated in mouth with firm pressure.
Junction of tray and compound smoothened.
Border molded maxillary custom tray.
In the same manner like maxillary border molding, first heat the compound over flame and place over the buccal flange.
Always temper the compound in the water bath for 5 seconds before placing the heated compound in the mouth.
Insert the tray and molding done by the cheek is lifted outwards, upwards and inwards and moved backwards and forwards and the patient is asked to pucker and smile.
Remove the tray from the mouth and chill the compound and Trim the excess.
This defines the proper tray extension for this area.
Then add compound over the distobuccal area and place the tray in the mouth.
The cheek is pulled buccally to ensure it is not caught in the tray and then moved upwards and inwards.The masseteric notch is recorded by asking the patient to close, while dentist exerts a downward pressure on tray.
Then place the compound over the labial flange.
The lip is slightly lifted outwards, upwards and inwards.
Then place the compound over the anterior lingual flange.
patient is asked to protrude the tongue and then push the tongue against the anterior part of the palate. This develops the length and thickness of the flange in this area, respectively.
Then place over the Middle portion of the lingual flange: Developed bilaterally.
patient is asked to protrude the tongue and lick the upper lip from side to side.Finally Distolingual flange should be recorded: Developed bilaterally.
patient is asked to protrude the tongue and then place the tongue in the distal part of the palate in the right and left buccal vestibules.
Border molding is completed. Inspect carefully to ensure that the extensions are well defined. The borders should be smooth and rounded.
The wax spacer is removed from the inside the tray along with any border molding material that has flown over it.
Any excess material on the outside of the tray is removed.
Vent holes can be drilled through the tray approximately 10mm apart.
These will provide escapeways for the final impression material and relieve pressure over the crest of the residual ridge and the retromolar pads when the final impression is made.
For good adhesion between impression material and custom impression trays, use of tray adhesives and escape holes both should be encouraged because this provides a chemical - mechanical type of adhesion.
If ZOE paste is used, patient’s lips and some part of the face are covered with vaseline as the material is sticky and will be hard to remove.
Border molding, is gently performed simultaneously on all the sections both passively and actively.
After placing the material evenly on the tray and around the borders, the tray is inserted by centering and aligning the labial notch in the tray with the labial frenum.
The index fingers of each hand are used to apply an upward pressure in the molar regions until the tray seats posteriorly in the hamular notches.
The tray is then held in position with a finger in the hard palate just anterior to the posterior palatal seal area.
Border molding, is gently performed simultaneously on all the sections both passively and actively.
The material is allowed to set and then removed and inspected for any discrepancies.
Although there are many techniques with varied logic, the success of the prosthodontics treatment depends on the clinical diagnostic procedure, understanding of the theories of impression making and it’s application by the operator.
If the tray position is improper, the flange of the impression which lies on the side of deviation will be excessively thick and the flange of the impression opposite to the deviation will be thin.
The tray should be seated first anteriorly with labial notch acts as a guide for the placement of the tray in the patients mouth for making final impression.
