The document provides an overview of IBM z Systems and how it enables digital transformation through hybrid cloud infrastructure, rapid application creation, real-time insight, and combating cyber threats. It discusses how the new IBM z13s delivers more performance, scale, and capabilities to fuel innovation with a secure hybrid cloud. The z13s is designed to perform in the open digital era through improvements like increased throughput, faster analytics processing, encryption functions, data compression, and memory management. It also discusses how z Systems provides an optimized platform to accelerate time to value for organizations in the API economy.

1. Announce overview

2. © 2016 IBM Corporation
Trademarks
The following are trademarks of the International Business Machines Corporation in the United States and/or other countries.
CICS*
BigInsights*
Bluemix*
DB2*
WebSphere*
z13
z13s
zSecure*
Guardium*
IBM*
IBM (logo)
IMS
* Registered trademarks of IBM Corporation
Notes:
Performance is in Internal Throughput Rate (ITR) ratio based on measurements and projections using standard IBM benchmarks in a controlled environment. The actual throughput that any user will experience will vary depending upon considerations such as the amount of
multiprogramming in the user's job stream, the I/O configuration, the storage configuration, and the workload processed. Therefore, no assurance can be given that an individual user will achieve throughput improvements equivalent to the performance ratios stated here.
IBM hardware products are manufactured from new parts, or new and serviceable used parts. Regardless, our warranty terms apply.
All customer examples cited or described in this presentation are presented as illustrations of the manner in which some customers have used IBM products and the results they may have achieved. Actual environmental costs and performance characteristics will vary
depending on individual customer configurations and conditions.
This publication was produced in the United States. IBM may not offer the products, services or features discussed in this document in other countries, and the information may be subject to change without notice. Consult your local IBM business contact for information on
the product or services available in your area.
All statements regarding IBM's future direction and intent are subject to change or withdrawal without notice, and represent goals and objectives only.
Information about non-IBM products is obtained from the manufacturers of those products or their published announcements. IBM has not tested those products and cannot confirm the performance, compatibility, or any other claims related to non-IBM products.
Questions on the capabilities of non-IBM products should be addressed to the suppliers of those products.
Prices subject to change without notice. Contact your IBM representative or Business Partner for the most current pricing in your geography.
This information provides only general descriptions of the types and portions of workloads that are eligible for execution on Specialty Engines (e.g, zIIPs, zAAPs, and IFLs) ("SEs"). IBM authorizes customers to use IBM SE only to execute the processing of Eligible Workloads of
specific Programs expressly authorized by IBM as specified in the “Authorized Use Table for IBM Machines” provided at www.ibm.com/systems/support/machine_warranties/machine_code/aut.html (“AUT”). No other workload processing is authorized for execution on an
SE. IBM offers SE at a lower price than General Processors/Central Processors because customers are authorized to use SEs only to process certain types and/or amounts of workloads as specified by IBM in the AUT.
The following are trademarks or registered trademarks of other companies.
Adobe, the Adobe logo, PostScript, and the PostScript logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States, and/or other countries.
Cell Broadband Engine is a trademark of Sony Computer Entertainment, Inc. in the United States, other countries, or both and is used under license therefrom.
Intel, Intel logo, Intel Inside, Intel Inside logo, Intel Centrino, Intel Centrino logo, Celeron, Intel Xeon, Intel SpeedStep, Itanium, and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.
IT Infrastructure Library is a registered trademark of the Central Computer and Telecommunications Agency which is now part of the Office of Government Commerce.
ITIL is a registered trademark, and a registered community trademark of the Office of Government Commerce, and is registered in the U.S. Patent and Trademark Office.
Java and all Java based trademarks and logos are trademarks or registered trademarks of Oracle and/or its affiliates.
Linear Tape-Open, LTO, the LTO Logo, Ultrium, and the Ultrium logo are trademarks of HP, IBM Corp. and Quantum in the U.S. and
Linux is a registered trademark of Linus Torvalds in the United States, other countries, or both.
Microsoft, Windows, Windows NT, and the Windows logo are trademarks of Microsoft Corporation in the United States, other countries, or both.
OpenStack is a trademark of OpenStack LLC. The OpenStack trademark policy is available on the OpenStack website.
TEALEAF is a registered trademark of Tealeaf, an IBM Company.
Windows Server and the Windows logo are trademarks of the Microsoft group of countries.
Worklight is a trademark or registered trademark of Worklight, an IBM Company.
UNIX is a registered trademark of The Open Group in the United States and other countries.
* Other product and service names might be trademarks of IBM or other companies.
z Systems
z/OS*
z/VM*

3. The digital transformation is changing
the face of business
• Size = Power
• Ongoing process improvement
• Nimble and agile
• Rapid creation of new services
A new competitive landscape: Disrupt or be disrupted
Dominate through
physical presence
Lead with exceptional
digital presence

4. At the same time power has shifted from
the business to the consumer
• Mass production of services
• Set service standards
• Personalized service expectation
• The arbiter of trust
Social and mobile gives the consumer the biggest voice

5. These business shifts place new
demands on IT infrastructure
• Nimble and agile
Flexible and responsive infrastructure
tuned for digital & mobile workloads
• Rapid creation of new services
Efficient, rapid and agile app creation
and new service delivery
• Personalized service expectations
Creating excellent customer experiences
through real time insight
• The arbiter of trust
Build trust, confidence and partnerships
by combating cyber threats

6. IBM z Systems™
Designed for digital transformation
Infrastructure
Create a new IT core, a hybrid cloud infrastructure that
serves as the backbone of your enterprise
App creation
Enable developer creativity and productivity through open
and collaborative methodologies
Real time insight
Discover, deliver and act on insight within the current
business transaction
Combating cyber threats
End-to-end security that ensures privacy and protection
of all data and every transaction

7. A hybrid infrastructure will be the backbone of your business
Through
as public cloud adoption grows,
hybrid cloud scenarios will increase
the need for management and
security services that extend on-
premises environments to public
cloud services
2017
of respondents stated that
security in the public cloud is
their primary reason for
keeping data on premise
35%
More than
of enterprise IT organizations
will commit to hybrid cloud
technologies before 2016,
65%
1) IDC, Date published: 12/22/2014: Worldwide cloud 2015 predictions
2 09/09/2014 Source: Gartner: Forecast Overview: Public Cloud Services, Worldwide, 2014 Update
3 01/06/2015 Source: PAC: 2015 Piper Jaffray CIO Survey

8. © 2016 IBM Corporation
Heterogeneous data centers are evolving to hybrid cloud
• The best of centralized and
distributed architectures
• The best of private and
public clouds
• The best of enterprise and
open computing

9. © 2016 IBM Corporation
Hybrid Cloud
Hybrid applications running on z that
draw on data and services from other
clouds; can leverage Bluemix® as well
as interoperability with SoftLayer,
AWS, and other cloud offerings
Private Cloud
z/OS® and Linux® on IBM z
Systems as the foundation of the
most secure, scalable private
cloud infrastructure, with
microservices, APIs, and
containers for agility
Public Cloud
Enabling MSPs/CSPs to deliver
differentiated mainframe-based
service offerings
Virtually limitless expansion: containers, virtual machines
Shared everything design for extreme utilization
Secure isolation of virtual servers, containers, systems resources, at every level
9
IBM z enables disruptive innovation with agility, scale,
and trusted security

10. © 2016 IBM Corporation
z Systems delivers on the private cloud imperatives
24x7x365
application
availability
Users expect
<1 second
app utility
70%
lack confidence in
data security
TrustAvailability Response Time
35%
mobile transaction
growth annually
Scale

11. © 2016 IBM Corporation
Fuelling innovation with
a secure hybrid cloud
The all new…

12. © 2016 IBM Corporation
z13s delivers more: More performance, more scale, more capabilities
Capacity per
core
System Capacity
z/OS 30% 40%
Linux 50% 110%
Model
Max
CPs
Max
Cores
Max
Memory
N10 6 10 1TB
N20 6 20 4TB
• 2 Models
• Greater scale for Linux and z/OS
• 2X increase in channel speed
• 8X increase in memory
• 2x increase in cache
• 50-80% more bandwidth
per I/O domain

13. The z13s is designed to perform in the open digital era
• Scale with simultaneous multi-threading delivering more throughput for Linux and
zIIP-eligible workloads
• Accelerate analytics processing for mathematical models trough Vector processing using
Single Instruction Multiple Data (SIMD)
• Faster processing of encryption functions with up to 2.3X faster cryptographic coprocessor
• Compress more data reducing costs and data transfer time with improved on chip hardware
compression
• Better and faster memory management and execution time with new hardware instructions and
functional facilities to optimize compilers
1) The Customer-activated Enterprise, Insights from the Global C-suite Study, IBM Institute for Business Value, 2013
2) IDC Directions, "How SaaS Gets Built" Doc # DR2014_T3_RM March 2014
3) See ProgrammableWeb, http://www.programmableweb.com/category/all/apis?order=field_popularity

14. © 2016 IBM Corporation
z Systems provides an optimized platform to accelerate time to value for
the API Economy
CICS ®
IMS™
WebSphere ®
DB2 ®
StrongLoop runs on-prem (using Linux on
z Systems), in the cloud (via Bluemix), as
well as other distributed platforms
MobileFirst
Platform
(cloud)
Serving mobile data directly from z/OS is less
expensive than exporting to a system of engagement
z/OS Connect
EE and
LoopBack
Connector
API
API
API
MobileFirst
Platform
(on-prem)
API
API
API
Additional enterprise APIs
Additional enterprise APIs
14
MobileFirst
Platform
(on-prem)
API
API
API
Node.js is faster on
z13 vs Haswell
Colocation of Node.js on Linux
with z/OS cuts response times
by and improves
throughput by
API Connect
API Connect

15. Collaborative Development: choice and consistency, standardization with options
Enterprise Big Data and Analytics Hybrid Cloud Enterprise Open Source
Systems of Record Systems of Insight
Pattern-Enabled Infrastructure
as a Service
Flexibility & Choice
Manager
vRealize

16. © 2016 IBM Corporation
Blockchain and z Systems: Working in synergy
A new streamlined way to create an
official record of transactions
without going through a central
point of control.
Exploiting the speed, security, availability
and specialized technologies of the IBM z
platform and integrating with the systems
of record that run on it.

17. © 2016 IBM Corporation
Speed application development through a growing,
flexible open ecosystem
The new z Developers Community Hub
Accelerate development with a portfolio of starter code, APIs and microservices
Next-generation API capability: Create, run, manage APIs, enforcing the
standards behind those interfaces
Free Rocket Data Virtualization non-production license with every z13 and
z13s, offering modern, native access to developers with no z skills: SQL interfaces or
noSQL such as MongoDB APIs
IBM z development toolkit
Apply the latest Agile practices with a comprehensive workbench
Digital Engagement, Meetups, Hackathons & Rocket Launchpad
Iterate quickly with the NoSQL
database built for cloud and
mobile apps with IBM Cloudant.
Visually develop APIs in Node.js
and connect them to your
enterprise data with Strongloop.

18. Robust data and analytics
1) The Customer-activated Enterprise, Insights from the Global C-suite Study, IBM Institute for Business Value, 2013
2) IDC Directions, "How SaaS Gets Built" Doc # DR2014_T3_RM March 2014
3) See ProgrammableWeb, http://www.programmableweb.com/category/all/apis?order=field_popularity
By 2018 Apps with advanced and
predictive analytics
are growing
of all consumers will
regularly interact with
services based on
cognitive.
50%
faster than apps
without predictive
functionality.
65%
By 2020,
of new information will be
created every minute for
every human being on
the planet.
1.7 MB

19. Best of class integrated data and analytics
life cycle management
Streamlined decision process
Faster
transactions
Faster
transformation
of data
Faster, more accurate
reporting
Faster, more accurate
modeling
Easier integration of other data sources
Faster, more accurate scores

20. © 2016 IBM Corporation
IBM IT Operational Analytics for z Systems
Analyze operations data from z to …
Predict
• Pro-Active Outage
Avoidance
• Predict problems
before they occur
• Log anomaly
detection
Investigate & Automate
• Search and analyze
logs and metrics
across the enterprise
• Domain insights and
expert advice
• Alert notification and
automation
Optimize
• Software cost
analysis
• Enterprise resource
optimization
• SME insights in
cloud
IBM zAwareIBM Operations
Analytics for z
Systems
IBM Capacity
Management Analytics
(CMA)
Operational Insights
(SaaS)

21. © 2016 IBM Corporation
z Systems delivers right time insight from structured
and unstructured data
1) The Customer-activated Enterprise, Insights from the Global C-suite Study, IBM Institute for Business Value, 2013
2) IDC Directions, "How SaaS Gets Built" Doc # DR2014_T3_RM March 2014
3) See ProgrammableWeb, http://www.programmableweb.com/category/all/apis?order=field_popularity
Drives timely and
relevant insights via
in-line predictive
analytics through
Zementis for
IBM z Systems
Analyze all your
enterprise data in
place, in real time
with Apache Spark
on z Systems
Apply next-generation
in-database
transformation and
modeling optimization
with the updated
IBM DB2 Analytics
Accelerator V5
Detect events in real time
to optimize decisions with
the Operational Decision
Manager Advanced and
Decision Server Insights

22. Creating a security framework for the new threat landscape
Or respondents cited significant
outage of a public or community
cloud as the most damaging
incident to their organization
23%
Or respondents say mobile
devices such as smart phones
represent the greatest risk of
potential IT security risk within
the IT environment
75%
of sensitive data breaches
go undiscovered for
months or years
>50%
Spending on security is the highest priority for CIOs1
1 CEB Information Risk Leadership Council, “2015 Security Outlook – Ten Imperatives for the Information Security Function,” November 2014.
2 Published date: 05/20/2015 Source: EIU. Preparing for next-generation cloud: lessons learned and insights shared
3 Ponemon institute: 2014 State of Endpoint Risk
4 Verizon, 2014 Data Breach Investigations Report, 2014.

23. © 2016 IBM Corporation
A trusted infrastructure with end-to-end security built in
Cloud Mobile
Advanced fraud
management
Identity and
access protection
Endpoint
management
Data security
Security intelligence
and operations
Application
security
Network protection
Infrastructure
security

24. © 2016 IBM Corporation
Protect your business and client data with security you can trust
Encrypt sensitive data without compromising throughput and
response time with Crypto Express5S
Prevent unauthorized access to sensitive data with Multi-Factor
Authentication
Automate and speed security intelligence in the cloud with IBM
zSecure™ and IBM Security Guardium®
Extending security leadership beyond the firewall through new
partnerships
Detect and intercept cyber threats through cognitive analytics
with Cyber security analytics (Beta now open!)
• Save space with new
Rack mounted Trusted Key
Entry (TKE)
• Faster processing of
encryption functions with
up to 2.3X faster
cryptographic coprocessor

25. z Systems Announcement Summary
Operating Systems
NEW z/OS V2.2 Enhancements
NEW z/VM® 6.4 Preview
NEW IBM Wave 1.2 for z/VM SOD
UPDATE KVM for IBM z Systems v1.1.1
Cross Platform
NEW Open Blockchain Code on IBM z
NEW Rocket Data Virtualization
NEW z Developers Community Hub
NEW Rocket LaunchPad
HYBRID CLOUD
• NEW z/OS Cloud Beta (Middleware as a Service -
WAS, DB2, CICS, IMS)
• UPDATE z/OS Connect Enterprise Edition
• NEW StrongLoop & Loopback Connectors
• NEW API Connect
• NEW Cloudant
• RECENT SUSE Cloud OpenStack® 6
DEVOPS / MODERNIZATION
• NEW Application Delivery Intelligence (Test Optimization)
• UPDATE COBOL v6.1
• NEW Application Delivery Foundation (RDz + PDTools)
• RECENT Automatic Binary Optimizer
• RECENT CICS 5.3 (with Liberty); IMS 14
• NEW WebSphere Application Server for z/OS
• NEW HACP v12
• UPDATE Rational Programming Patterns
• UPDATE IBM Workload Scheduler
• NEW IBM Tivoli OMEGAMON XE on z/OS Monitoring Feature
for JVM
• UPDATE IBM Service Mgmt Suite for z/OS
• UPDATE IBM Advanced Storage Mgmt Suite
• UPDATE IBM Performance Mgmt Suite for z/OS
• UPDATE UrbanCode® Deploy 6.2.1
• NEW IBM Explorer for z/OS 3.0 Aqua
ANALYTICS
• RECENT Zementis in-transaction analytics
• RECENT Spark for z/OS and Mainframe Data
Service for Spark
• RECENT DB2 Analytics Accelerator
• RECENT ODM Decision Server Insights for z
• NEW IBM BigInsights® for Hadoop
• RECENT IBM BigInsights BigIntegrate and
BigQuality for z Systems
• NEW IBM Operations Analytics
• NEW IBM z Operational Insights v.Next Beta
CYBER SECURITY
• NEW Multifactor Authentication for z/OS
• NEW Cyber Security Analytics Beta
• NEW Ready for Security Intelligence Partner Program
• NEW Security Workload Pricing
• UPDATE IBM Security SW for z Systems (Guardium,
QRadar, zSecure)
25
New
IBM z13s
Updated
IBM z13

26. © 2016 IBM Corporation
IBM z Systems
Designed for digital transformation
Discover, deliver and act on real time insight
within the current business transaction
Enables rapid and high quality app creation
through open and collaborative methodologies
A hybrid cloud infrastructure that
serves as the backbone of your enterprise
End-to-end security to combat cyber threats
for privacy and protection
ZSP04506-USEN-01
